Clarke MBS600D User manual

ASSEMBLY INSTRUCTIONS
GC05/12
600mm COMPOUND MITRE SAW
MODEL NO: MBS600D
Part No: 6461516

2
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
INTRODUCTION
Thank you for purchasing this CLARKE Mitre Saw.
Before attempting to use the product, it is essential that you read this manual
thoroughly and carefully follow all instructions given. In doing so you will
ensure the safety of yourself and that of others around you, and you can also
look forward to the product giving you long and satisfactory service.
GUARANTEE
This CLARKE product is guaranteed against faulty manufacture for a period of
12 months from the date of purchase. Please keep your receipt as proof of
purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for its intended purpose.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission. This guarantee does not effect
your statutory rights.
ENVIRONMENTAL PROTECTION
Do not dispose of this product with general household waste. All tools,
accessories and packaging should be sorted, taken to a re-cycling centre
and disposed of appropriately.

3
Parts & Service: 020 8988 7400/E-mail: Part[email protected] or [email protected]
COMPONENT GUIDE
Upon receipt of the product, unpack all loose components and check for
any missing parts. Any identified should be reported to your Clarke dealer.
The MBS600D includes the following:
1 x Saw Table with wooden base
1 x 600 mm Saw mounted in Saw Frame
4 x Support Rods
2 x Polymer Guide Pieces
1 x Work Stop
1 x Work Retaining Clamp
2 x Allen (Hexagonal) Keys
2 x Depth Stop Collars
1 x Work Clamp Securing Knob
1 x Work Stop Securing Knob
DEPTH STOP
COLLAR
WORK CLAMP
WORK STOP
QUADRANT
RELEASE LEVER
SUPPORT RODS
WITH GUIDE PIECES
SAW BLADE
BLADE
TENSIONER
MITRE ANGLE CARRIAGE
HORIZONTAL QUADRANT
VERTICAL
QUADRANT
SAW TABLE

4
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
ASSEMBLY
GUIDE RODS, SAW FRAME AND BLADE
1. Attach the handle to the upright
part of the saw frame using the
two screws, with the nuts seated in
the handle moulding.
2. Connect the polymer guide
pieces to the saw frame assembly
as shown in Fig 1.
2. Insert the guide support rods
through the holes in each guide
piece as shown in Fig 2, noting
that two of the rods include a
small end stop. This must remain at
the top of the guide rod.
3. Slide a depth stop collar onto one
front and one rear guide rod from
below and lock in position with
the thumbscrew.
4. Lift the saw frame, complete with
guide rods, and place the guide
rods into their respective sockets
in the mitre angle carriage.
5. Tighten the grub screw for each
socket using a hexagonal key to
secure the saw frame/guide rod
assembly in place.
FIG 1
FIG 2
END STOP
DEPTH STOP
COLLAR
FIG 3
SOCKETS
WITH GRUB
SCREWS
FRAME
UPRIGHT
FIXING SCREWS

5
Parts & Service: 020 8988 7400/E-mail: Part[email protected] or [email protected]
6. With the saw frame assembly in
position, tension the blade using
the wing nut, until any sideways
deflection of the blade is minimal.
• This is essential to ensure a straight
and repeatable cut from the
blade.
• The saw blade can be removed
for replacement by loosening the
wing nut fully and disengaging
the blade from its mounting pegs
at each end of the frame.
WORK CLAMP
1. Pass the threaded shaft of the
work clamp into one of the holes
in the front face of the saw table,
(see fig 5), depending upon
which end of the table your work
is to be mounted.
2. Screw on the retaining nut to
keep it in place.
WORK- STOP
1. Screw the stop rod adjusting knob
into the threaded hole at one end of the saw table depending upon
which side of the saw blade your work is to be mounted.
2. Slide the work stop rod through the base until it emerges from the hole in
the opposite end. Set it in the position required, by tightening the thumb-
screw.
• Your saw is now fully assembled and ready for use.
BENCH MOUNTING
You may wish to install the saw on a firm foundation such as a workbench or
work table. This is particularly advisable if you are cutting larger workpieces.
Use the holes in the wooden base plate for this purpose, securing with bolts,
flat washers and wing nuts for quick and easy removal, if required (not
supplied).
TENSIONING WING NUT
FIG 4
FIG 5 WORK
CLAMP
WORK
STOP
ROD
RETAINING NUTS

6
Parts & Service: 020 8988 7400/E-mail:Part[email protected] or [email protected]
USING THE MITRE SAW
CUTTING SIMPLE MITRES OR BEVELS
Simple mitres or bevels are cuts made in one plane only. For simple mitres, the
carriage is moved to the desired angle to the base by pulling the horizontal
quadrant release lever to allow the carriage to swivel, with the saw blade
remaining perpendicular to the table.
Setting the carriage to the angles shown in Fig 6, will produce the mitres
illustrated. The angle is shown by the pointer.
COMPOUND MITRES
For compound mitres the saw frame
is tilted over at an angle to the table.
This is done by releasing the large
socket bolt in each end of the mitre
carriage sufficiently to free the
vertical quadrant and to allow the
saw frame to be tilted to the desired
angle. The socket bolt is then
tightened when the saw frame is set
at the desired angle.
Compound mitres are therefore cut
using a combination of these
settings.
CUTTING TECHNIQUE
When cutting, DO NOT force the saw blade, as this will lead to blade
distortion and inaccurate mitres/bevels. Only a very gentle pressure is
required. Let the saw do the work.
Ensure the socket screws at both ends of the carriage are tight before use.
FIG 6
FIG 7
SOCKET
BOLT
VERTICAL
QUADRANT

7
Parts & Service: 020 8988 7400/E-mail: Part[email protected] or [email protected]
Always clamp the workpiece to the saw table before work.
Ensure the saw blade is correctly tensioned before use - too slack will allow
the blade to twist, producing inaccurate mitres. Take care never to use
damaged saw blades. Release the blade tension if the saw is not to be used
again for some time.
Use the depth stop collars as required when making either a horizontal or
sloping cut. Tighten them securely with the thumb-screws before cutting.
Replacement blades are available from your CLARKE dealer;
Part No: 6470175
SPECIFICATIONS
erutaeF noitacificepS
htgneLxhtdiWesaBmm002xmm084
)emarfwas(htpeDmm537
htgneLedalBwaSmm006
htpeDedalBwaSmm54
thgieWgk8.
3
tuCfohtpeDxaMmm051
09@tuCfohtdiWxaM
O
mm071
hcnIrephteeTipt91
Please note that the details and specifications contained herein, are correct at the
time of going to print. However, CLARKE International reserve the right to change
specifications at any time without prior notice.
