Clarke Contractor CTS12 Installation and operation manual

0207
Part Number 6500750
Operating & Maintenance
Instructions
10” TABLE SAW
Model CTS12
©
10” TABLE SAW
Model CTS12

2
SPECIFICATIONS
Model No ..............................................CTS12
Part No. ..................................................6500754
Motor .....................................................230V~ 50Hz 1ph
Power rating .............................. 1.5Kw
Speed ........................................ 6270 rpm
Fuse rating ................................. 13Amps
Saw Blade .............................................10” dia. (254x30mm) TCT
Maximum depth of cut at 0O..............75 mm
Maximum depth of cut at 45O............50 mm
Net Weight (Boxed)..............................29KG
Noise level at operating position ........112.3dB LWA (under load)
Overall dimensions - (LxWxH) ..............870 x 920 x 1250 mm
Overall dimensions - with extensions .. 870 x 1240 x 1250 mm
Use of machine
This machine is designed to rip and cross cut wood exclusively, up to a maximum thickness of
75mm.
For correct operation it must be fixed and operated as laid down in this manual.
Restrictions of use
This saw is NOT suitable for cutting:
•Timber greater than 75mm in thickness.
•Metal, Stone, Rubber, Plastic, Bones, Etc.
•Logs or round timber.
DO NOT use to rebate, tenon, mould or groove.
DO NOT fit any other tool or combination of blades.
DO NOT use as a free standing machine or as a hand held machine.
DO NOT modify the machine or its guards/controls in any way.
DO NOT use with any covers/guards removed.
When disposing of this product, do not dispose of with general waste. It must be disposed
of according to law at a recognised disposal facility.

3
Thank you for purchasing your new CLARKE 10” TABLE SAW.
Before attempting to operate this machine, please read this instruction manual thoroughly and
follow all directions carefully. In doing so you will ensure the safety of both yourself and others
around you, and, at the same time, you should look forward to it providing long and trouble
free service.
GUARANTEE
This product is guaranteed against faults in manufacture for 12 months from purchase date.
Keep your receipt as proof of purchase. This guarantee is invalid if the product has been found
to have been abused in any way, or not used for the purpose for which it was intended, or to
have been tampered with in any way. The reason for return must be clearly stated. This guarantee
does not affect your statutory rights.
CONTENTS
Specifications ............................................................................................. 2
Safety Instructions ......................................................................................4
Additional Safety Rules for Table Saws .................................................... 7
Electrical Connections ...............................................................................8
Features .......................................................................................................9
Glossary of Terms ......................................................................................10
Unpacking and Checking Contents ......................................................11
Assembly ...................................................................................................12
Mounting the Saw on to the stand.......................................................... 15
Important Checks before Starting ..........................................................16
Operation ..................................................................................................16
Starting & Stopping ....................................................................16
Turning the Laser on/off .............................................................16
Adjustment ................................................................................. 17
Cutting Practices ......................................................................................20
Maintenance ............................................................................................24
Changing the Saw Blade ..........................................................24
Adjusting the Positive Stops ......................................................25
Motor Brush Renewal ................................................................. 25
Trouble Shooting ....................................................................................... 26
Parts Lists and Diagrams .................................................................... 27-30
Declaration of Conformity ....................................................................... 31

4
SAFETY INSTRUCTIONS
KEEP WORK AREA CLEAN : Cluttered areas and benches invite injuries.
CONSIDER WORK AREA ENVIRONMENT: Do not expose power tools to rain. Do not use power tools in damp,
or wet locations. Keep the work area well lit. Do not use this saw in the presence of flammable liquids or
gases.
GUARD AGAINST ELECTRIC SHOCK: Avoid body contact with earthed, or grounded surfaces, e.g. pipes,
radiators, ranges, refrigerators etc.
KEEP CHILDREN AWAY: Do not let children, or persons not involved in the work, touch the tool, or the extension
lead and keep them away from the work area.
STORE IDLE TOOLS: When not in use, all tools should be stored in a dry, locked up place, out of reach of
children.
DO NOT FORCE THE TOOL: It will do the job better and safer at the rate for which it was intended.
USE THE RIGHT TOOL: Do not force small tools, to do the job of a heavy duty tool. Do not use tools for
purposes not intended.
DRESS PROPERLY: Do not wear loose clothing, or jewellery that can be caught in moving parts. Non-skid
footwear is recommended when working outdoors. Wear protective hair covering to contain long hair.
SAFETY GLASSES: Use safety glasses when operating this tool.
DUST MASKS: If the work is dusty, use dust masks to reduce the risk of inhalation of harmful dust.
CONNECT DUST EXTRACTION EQUIPMENT: Always connect a suitable vacuum cleaner attachment.
PROTECT YOUR EARS: Hearing protection should be worn when using this tool.
DO NOT ABUSE THE MAINS LEAD: Never pull the mains lead to disconnect it from the mains socket. Keep
the mains lead away from heat, oil and sharp edges.
SECURE THE WORK: Use clamps, or vices to hold the workpiece. It is safer than using your hand.
DO NOT OVERREACH: Keep proper footing and balance at all times.
MAINTAIN TOOLS WITH CARE: Keep the blade clean for better and safer performance. Follow the instructions
for changing the blade. Inspect the mains lead periodically and if damaged have it repaired by an
authorised service facility. Inspect extension leads periodically and replace if damaged. Keep all handles
and grips dry, clean and free from oil and grease.
DISCONNECT TOOLS: Disconnect tools from the mains supply when not in use, before servicing and when
changing accessories such as blades.
REMOVE ADJUSTING KEYS AND WRENCHES: Form the habit of checking to see that all keys and spanners
are removed from the tool before turning it on.
TRANSPORTING THE TABLE SAW: When moving or transporting the table saw, only lift from the table top. Do
not use the blade guard for lifting, moving or transporting the saw.
AVOID UNINTENTIONAL STARTING: Ensure that the switch is in the off position when plugging in to the mains
supply. (Switch cover locked position).

5
SAFETY INSTRUCTIONS
USE OUTDOOR EXTENSION LEADS: When the tool is used outdoors, use only extension leads intended for
outdoor use and so marked. Always make sure that the extension lead is suitably rated for the tool. Position
the extension lead so that it does not create a hazard.
STAY ALERT: Watch what you are doing. Use common sense. Do not operate tools when you are tired.
CHECK DAMAGED PARTS: Before further use of the tool, any part that is damaged should be carefully
checked to determine that it will operate properly and perform its intended function. Check for alignment
of moving parts, free running of moving parts, breakage of parts, mounting and any other conditions that
may affect its operation. Any part that is damaged should be properly repaired, or replaced, by authorised
service personnel, unless otherwise indicated in this User Guide. Have defective switches replaced by
authorised service personnel. Do not use the tool if the switch does not turn it on and off.
WARNING: The use of any accessory, or attachment, other than those recommended in this User Guide,
may present a risk of personal injury.
HAVE YOUR TOOL REPAIRED BY A QUALIFIED PERSON: This electric tool is in accordance with the relevant
safety requirements. Repairs should only be carried out by qualified persons using original spare parts,
otherwise this may result in considerable danger to the user.
SAW BLADES: Do not use saw blades which are damaged or deformed. Use only saw blades recommended
by the manufacturer which conform to EN847-1. Take care that the selection of the saw blade is suitable
for the type of wood to be cut which meets the requirements on page 2. Do not use High Speed Steel
(HSS) blades. Use only saw blades for which the maximum possible speed is not less than the maximum
spindle speed (no load speed) of the table saw and the material to be cut.
USE THE BLADE GUARD: Make sure that the blade guard moves freely on its pivot point and that the front of
the guard is always in contact with the saw table when not cutting. Always use the blade guard and riving
knife for every operation. IMPORTANT: THIS SAW IS NOT DESIGNED FOR NON-THROUGH CUTTING OPERATIONS
SUITABLE MATERIALS : Do not use the saw to cut materials other than wood.
MAXIMUM DEPTH OF CUT: The maximum depth of cut of this table saw is 75 mm. See the Product Specification
on page 2.
PROVIDE ADEQUATE SUPPORT FOR LONG WORKPIECES: Provide adequate support to the rear and sides of
the saw table for wide, or long pieces of work. Saw horses or similar devices should be used to prevent the
ends of the workpiece from drooping.
COMPOUND CUTTING: Take care when making compound cuts. If both mitre angles and bevel angles are
to be set for compound mitre cuts, set the bevel angle first. Make sure that the table saw is disconnected
from the mains supply before changing to the required angles.
ASSEMBLY: Do not operate this saw until it has been fully assembled and correctly prepared for use in
accordance with the instructions in this User Guide.
MIND YOUR HANDS: Keep your hands well away from the blade area at all times. Do not place them in the
path of the blade when operating the saw.
WEAR GLOVES: Wear gloves when handling saw blades and rough material. Saw blades should be carried
in a holder whenever practical.
SECURE HANDLES AND CLAMPS: Make sure that all handles, clamps and guards are securely fitted before
operating the saw. Do not perform any cutting operation freehand.

6
SAFETY INSTRUCTIONS
USE THE MITRE GAUGE: Always hold the work firmly against the mitre gauge fence when cross cutting.
LOCK THE GUIDES: Always ensure the rip fence is securely fastened when in use.
USE A PUSH STICK: Use a pushstick to feed the workpiece past the saw blade. The push stick should always
be stored with the machine when not in use.
DO NOT WORK FREEHAND: Never perform any operation ‘freehand’ i.e. do not use your hands alone to
support, or guide the workpiece. Always use either the rip fence, or the mitre gauge (as appropriate) to
position and guide the work.
STAY CLEAR: Never stand, or have any part of your body in line with the path of the saw blade. A small cut-
off piece could be caught by the back of the blade and thrown towards the operator. Stand to one side
of the blade. Keep your hands out of the line of the saw blade.
CROSSCUTTING: Move the rip fence out of the way when cross cutting. Never use the rip fence as a cut-
off gauge when crosscutting.
SWITCH OFF: If off-cuts of wood become jammed in the machine, switch off and disconnect from the
mains supply before removal.
STALLED BLADE: If the blade stalls, or stops while cutting, turn the switch off and disconnect from the mains
supply before attempting to free the blade.
RIPPING: When ripping or bevel ripping, always use the rip fence together with the push stick. Never make
these cuts freehand. The blade could bind in the cut and cause a kickback .
MOUNTING THE SAW TABLE: Mount the table saw to the table before performing any cutting operations.
Refer to the assembly instructions on page 12.
REMOVE THE MITRE GAUGE: Remove the mitre gauge from the table during any cutting operations which
involve the rip fence .
MAXIMUM BLADE EXTENSION: Have the blade extended to approximately 22mm above the top of the
workpiece. Additional blade exposure could be potentially dangerous.
DO NOT REACH OVER: Do not reach over, or behind the blade for any reason.
SMALL PIECES AND TRAPPED PIECES: Do not pick up small pieces of cut-off material from the table. Remove
them by pushing them off the table with the push stick. They could be thrown back at you by the rear of
the blade. Do not remove small pieces of cut-off material that may become trapped inside the blade
guard while the saw is running. This could endanger your hands, or cause a kickback . Turn the saw OFF
and when the blade has stopped turning, lift the guard and remove the piece of debris.
REBATING, SLOTTING AND GROOVING: Rebating, slotting and grooving should not be undertaken on the
saw..it is not designed for non-through cutting operations.

7
ADDITIONAL SAFETY RULES FOR TABLE SAWS
✔ALWAYS use saw Blade Guard and Riving Knife for every operation.
✔ALWAYS hold the work firmly against the mitre gauge or fence.
✔ALWAYS use a push-stick when required. Always use a push-stick for ripping narrow stock.
Refer to ripping applications in instruction manual where push-stick is covered in detail.
✔ALWAYS use in a well ventilated area. Remove sawdust frequently. Clean out sawdust from
the interior of the saw to prevent a potential fire hazard.
✔ALWAYS move the rip fence out of the way when crosscutting.
✔ALWAYS switch off and disconnect from supply before removing off cuts of wood from the
machine
✔ALWAYS provide adequate support to the rear and sides of the saw table for wide or long
workpieces.
✔ALWAYS keep the blade sharp, the Rip Fence parallel to the saw blade, and the Riving Knife
and Blade Guard in place. Do not release work before it is pushed all the way past the saw
blade.
✔ALWAYS avoid awkward operations and hand positions where a sudden slip could cause
your hand to move into the blade.
✔PERMANENTLY mount your table saw before performing any cutting operations. Refer to
‘Mounting the Saw’ on page 17.
✘NEVER stand or have any part of your body in line with the path of the saw blade. Keep
your hands out of the line of the saw blade.
✘NEVER reach behind or over the blade for any reason.
✘NEVER use the fence as a cutoff gauge when crosscutting.
✘NEVER attempt to free a stalled saw blade without first turning the saw OFF. Turn off power
switch immediately to prevent motor damage.
✘NEVER use solvents to clean plastic parts. Solvents could possibly dissolve or otherwise
damage the material. Only a soft damp cloth should be used to clean plastic parts.
✘NEVER force feed the work into the blade. A light pressure ONLY is required
✘NEVER cut metals or materials which may make hazardous dust.
✘NEVER perform any operation ‘freehand’ which means using your hands to support or guide
the work piece. Always use either the fence or the mitre gauge to position and guide the
work.

8
ELECTRICAL CONNECTIONS
WARNING! THIS APPLIANCE MUST BE EARTHED.
Connect the mains lead to a 230 volt (50Hz) domestic electrical supply via a standard 13 amp
BS 1363 plug fitted with a 13 amp fuse, or a suitably fused isolator switch.
IMPORTANT: The wires in the mains lead are coloured in accordance with the following code:
Green & Yellow - Earth
Blue - Neutral
Brown - Live
As the colours of the flexible cord of this appliance may not correspond with the coloured
markings identifying terminals in your plug, proceed as follows:
Connect GREEN & YELLOW coloured cord to plug terminal marked with a letter “E” or
Earth symbol “ ”, or coloured GREEN or GREEN & YELLOW.
Connect BROWN coloured cord to plug terminal marked letter “L” or coloured RED.
Connect BLUE coloured cord to plug terminal marked letter “N” or coloured BLACK.
We strongly recommend that this unit is connected to the mains supply via a Residual
Current Device (RCD).
IMPORTANT!
If this appliance is fitted with a plug which is moulded onto the electric cable (i.e. non- re-
wireable) please note:
1. The plug must be thrown away if it is cut from the electric cable. There is a danger of
electric shock if it is subsequently inserted into a socket outlet.
2. Never use the plug without the fuse cover fitted.
3. Should you wish to replace a detachable fuse carrier, ensure that the correct replacement
is used (as indicated by marking or colour code).
4. Replacement fuse covers can be obtained from your local dealer or most electrical
stockists.
Fuse Rating
The fuse in the plug must be replaced with one of the same rating (13 amps) and this replacement
must be ASTA approved to BS1362.
Extension Cable
If an extension cable is fitted, ensure the minimum cross section of the conductor is 1 .5mm2for
up to 15 metres in length, and 2.5mm2for up to 25 metres.
WARNING:
If the power cable is worn or cut, or damaged in any way, have it replaced
immediately to avoid shock or fire hazard.

9
FEATURES
Fig.1
To transport the the machine, turn the assembly on its side, resting on the table wheels, then collapse
the legs. The Handle may now be used to move the table saw as required.

10
FEATURES
1. The switch panel incorporates the ON and OFF switches.
Your saw also features an Overload Protection device, so that if the motor overheats (due to feed
pressure being too great, dull blade or low voltage), the Overload Relay will intervene, and the
motor will automatically cut out. A reset button is provided at the front of the machine... wait at
least 5 minutes before pressing and trying to restart.
2. A Dust Extraction Tube is provided at the rear of the machine. A vacuum extractor with a suitable
flexible hose (35mm ID.), may be connected and used either permanently or intermittently as
required.
3. The Table is provided with two slots, one each side of the saw blade, running front to back. These
slots are for use with the Mitre Gauge when cross cutting and is explained under ‘Operation’. A
scale on the Mitre Gauge indicates the angle at which the workpiece is being mitred.
4. Four holes are provided in the base so that the saw may be bolted to the table stand. Please note
that the machine MUST be firmly secured to either a workbench or the stand supplied to ensure its
complete stability. This is explained in detail under ‘Mounting the Saw on page 15.
5. The Blade Height Adjuster raises or lowers the blade.
6. The Blade Angle Adjuster, allows the saw blade to be tilted to any angle from 0Oto 45O, as shown
on the Scale on the front panel.
7. The Rip Fence is for use when rip cutting timber. It locates on the front rail and can be easily moved
or locked in place by pushing the locking handle down.
8. The Blade Guard protects the operator and must ALWAYS be in place and working
properly.
WARNING: THIS MACHINE IS NOT DESIGNED FOR ‘NON-THROUGH CUTTING’ OPERATIONS
9. The Table Insert is removable to facilitate the installation or removal of the saw blade,
and must ALWAYS be in place when the table saw is being used.
GLOSSARY OF TERMS
Arbor The shaft on which a cutting tool is mounted.
Crosscut A cutting operation made across the width of the workpiece - across the grain.
Featherboard A device which can help guide workpieces during rip type operation.
Heel Misalignment of the blade.
Kerf The amount of material removed by the blade in a through cut.
Kickback An uncontrolled grabbing, and throwing of the workpiece back toward the
front of the saw during a rip type operation.
Leading End The end of the workpiece which, during a rip type operation, is pushed
into the cutting tool first.
Push Stick A device used to feed the workpiece through the saw during narrow ripping
type operation and which helps keep the operator’s hands well away from
the blade.
Push Block A device used for ripping type operations too narrow to allow use of a Push
stick.
Rabbet A notch in the edge of a workpiece.
Ripping A cutting operation along the length of the workpiece - in the direction of the
grain.
Riving Knife Positioned behind the saw blade to prevent wood closing and jamming after

11
UNPACKING AND CHECKING CONTENTS
The Table Saw is shipped complete in one carton.
Separate all parts from the packing materials and check to ensure that all components are accounted
for, according to the following list, before discarding any packing material.
LIST OF CONTENTS
1. 10" Table saw x 1
2. 254 mm (10") saw blade x 1
3. Rip cut extension table x 1
4. Rip cut extension table brackets x 2
5. Cross cut extension tables x 2
6. Table saw stand x 1
7. Wheels for stand x 2
8. Blade guard x 1
9. Rip fence x 1
10. Mitre gauge x 1
11. Push stick x 1
12. Dust extraction hose x 1
13. Riving knife (with laser cutting guide attached) x 1
14. Fixings pack (nuts & bolts etc) x 1
Should any component be missing or damaged in transit, please contact your CLARKE dealer
immediately, or CLARKE Customer Service Department on 020 8558 7400
WARNING!
DO NOT plug the table saw into the mains until it is fully assembled and checks made
according to these instructions.

12
Fig.2
IMPORTANT:
Take great care to avoid contact with the saw teeth which are extremely sharp
when performing the following operations.
ASSEMBLY
A. TABLE EXTENSION
1. Loosen the extension table clamps.
2. Slide the extension table into the two holes on the side of the table saw.
3. Secure each extension table by tightening up the extension table clamps.
B. PUSH STICK STORAGE
1. Store the Push Stick in the holder provided.
C. RIVING KNIFE
1. Remove the table insert (1 countersunk
screw).
2. Raise the blade as far as possible and adjust
the blade angle, so that the blade lays at a
45o angle.
Fig. 3
Fig.4

13
3. Slide the Riving Knife into position, and adjust the Riving knife so that a clearance of no more than
5mm exists between blade and knife, and along the full length of the riving knife, as illustrated in Fig. 5
Note:
Make sure that the Riving Knife is directly in line with the blade at all times. If at any time it
becomes misaligned, it must be straightened before the table saw is used.
5. When satisfied, tighten the riving knife securing bolt before replacing the Table Insert.
D FITTING THE BLADE GUARD
1. Raise the saw blade as far as possible.
Fig.6
4. Tighten the riving knife securing bolt as shown in
Fig. 6.
Fig.7
2. Attach the Blade Guard to the Riving Knife, as
shown.
• The guard should be secure, but still be capable of
dropping under its own weight. Do not over
tighten.
✘✘✔
Fig.5

14
E. RIP FENCE
The rip fence has the following parts:
1. The handle assembly ‘A’
2. The fence ‘B’
3. Two fixings, each comprising a coach bolt and
securing knobs ‘C’.
1. Slide the handle assembly (A) into the slot in the
front rail, and push the handle down to lock the rip
fence to the table.
2. Pull the slide bar out slightly and slide the fence (B)
behind the slide bar as shown.
3. Tighten the securing knobs (C) to lock the fence to
the handle assembly.
Note: The rip Fence has two slots, allowing the fence
to be attached in the ‘high’ or ‘low’ position
Fig.8
Fig.19
Fig.9
F. CONNECT THE VACUUM HOSE
1. Attach the hose as shown in the diagram in Fig.9
2. Connect a vacuum cleaner to the dust outlet port
on the rear of the table saw.

15
MOUNTING THE SAW ON TO THE STAND
Fig.10
Fig.11
Fig.12
STAND SETUP
The Stand is supplied flat.
1. Stand the assembly on its two wheels.
2. Pull the front pair of legs down and out as shown
until they click into place.
3. Repeat the process with the second pair of legs.
4. The stand should appear as shown in Fig.12.
5. Place table saw on the stand aligning the holes in
the base with the holes drilled in the table.
6. Use the nuts, bolts and washers supplied to secure
the table saw to the stand.

16
IMPORTANT CHECKS - BEFORE STARTING
IMPORTANT:
Before attempting to use the machine, it is necessary to ensure the various
components are correctly adjusted, and securely fitted.
•Make sure that the blade is securely fitted.
•Ensure the Blade Guard is fitted securely and capable of dropping under its own weight.
•Remove all tools or pieces of wood from the top of the table.
•If the Rip Fence is being use, make sure it is secure before use.
•Ensure the saw Blade is at the desired height and locked in place before use.
OPERATION
STARTING AND STOPPING THE MACHINE
The ON and OFF switches are located on the front of the table saw.
1. Plug the mains plug into the mains supply.
2 Connect a vacuum cleaner nozzle to the dust outlet at the rear of the table saw.
3 Press the Green button of the switch marked ‘I’.
• The table saw will now start. Always allow the blade to reach full speed before performing any
cutting operations.
To switch the saw off:
4 Push the Red button of the switch marked ‘O’.
• The table saw will stop.
NOTE: The blade will continue to rotate for a few seconds after the saw has been switched
off.
If during use the power is interrupted for any reason, the table saw will automatically switch OFF. You
can restart the table saw by pressing the Green ON button.
TURNING THE LASER ON/OFF.
The saw is fitted with a laser cutting guide.
1. Use the ON/Off switch to turn the laser on or off.
Fig.13

17
OVERLOAD CUT-OUT
Your table saw features an OVERLOAD CUTOUT device, so that if the motor overheats (due to feed pressure
being too great, a dull blade or low voltage etc.), the motor will automatically cut out. In this event,
1. Switch the machine OFF by pressing the red button ‘O’,
2. Unplug the machine from the mains supply and allow the machine to cool for three to five
minutes before plugging in and attempting to restart.
Note the time taken to reset may be longer, depending upon ambient temperature etc.
WARNING!
THE MACHINE MUST BE IN THE OFF POSITION, AND THE PLUG REMOVED FROM THE POWER
SOURCE WHILST COOLING DOWN TAKES PLACE. THIS PREVENTS ACCIDENTAL STARTING WHEN
THE RESET BUTTON IS PUSHED, AS THE NO VOLT RELEASE WILL NOT HAVE TRIPPED .
ADJUSTMENTS
Fig.14
CHANGING THE BLADE HEIGHT
Turn the blade height handwheel ‘A’ Fig. 14, to
adjust the height of the blade.
•Turn the blade height adjuster handwheel,
clockwise to lower the blade and
anticlockwise to raise the blade.
Fig.15
CHANGING THE BLADE ANGLE
Release the blade angle locking lever ‘B’ Fig 15,
by pulling the lever outwards.
•Grasp the blade angle adjustment wheel
‘A’ and move the complete assembly in
the direction of the arrow in Fig. 15, so that
the pointer is aligned with the desired
angle as shown on the angle indicator .
•Lock the blade at the desired angle by
pressing the locking lever ‘B’ firmly inwards.

18
USING THE MITRE GAUGE
1. Screw the mitre gauge fence to the quadrant,
using the two securing wheels. As shown.
2. Slide the mitre gauge into one of the slots on the
top of the table.
3. Loosen the lock knob and set the mitre gauge to
the required angle.
4. Tighten the lock knob.
5. The calibration on the mitre gauge is suitable for
most applications but for extra accuracy, a
protractor or other measuring device should be
used when setting the cutting angle. Test the
accuracy of the angle on a piece of scrap
material before cutting the workpiece.
MITRE GAUGE ADJUSTMENT
To produce an accurate cut at 90Oyou should check the gauge
as follows:
1. Loosen the lock knob and, using a set square as shown , set
the slide bar at 90Oto the body.
2. Tighten the Lock knob and re-check with the square to ensure
no movement has taken place during the tightening process.
• The graduations on the mitre gauge provide accuracy for
average woodworking. In some cases where extreme
accuracy is required, make a trial cut and then recheck it
with an accurate square or protractor.
• When using the left hand groove, hold the workpiece firmly
against the mitre gauge head with your left hand, and push
with your right hand.
•When using the right hand groove, hold the work piece with the right hand and push with the
left.
WARNING: THE RIP FENCE MUST BE REMOVED FROM THE TABLE WHEN USING THE MITRE GAUGE.
Fig.16
Fig.17
Fig.18

19
ADJUSTING THE RIP FENCE
1. Lift the fence handle up.
2. Slide the rip fence to the position you
require.
3. Push the fence handle down to lock the Rip
Fence into place.
ADJUSTING THE LASER GUIDE
To align the laser guide proceed as follows.
1. Set the blade angle to 0o.
2. Remove the blade guard. From this point on,
take great care not to damage your hands
on the saw blade teeth.
3. Switch the laser guide on.
4. Carefully grip the end bezel on the laser guide
and turn it until the beam is parallel with the
blade.
5. Loosen the two adjustment screws in the
mounting bracket on the front of the laser
holder (Fig.21).
6. Move the front of the laser holder until the
beam is running along the edge of the
blade.
7. Retighten the two adjustment screws.
8. Replace Blade Guard.
Fig.19
Fig.20
Fig.21

20
Fig.23
Fig.22
CUTTING PRACTICES
RIPPING OR RIP CUTTING
Ripping means to cut a piece of timber in the same
direction as the grain, i.e usually lengthwise.
•The rip fence can be positioned to the right or
left of the saw blade, and can be adjusted to
suit the width of cut required,
1. Lock the rip fence into position.
• When the width of rip is 150mm (6”) and wider
use your right hand to feed the workpiece, only
use left hand to guide the workpiece. (Fig.22).
• If the width of rip is narrower than 50mm (2”), the
push stick cannot be used because it will interfere
with the guard. It is therefore necessary to use an
auxiliary fence, and push block as shown in fig.
15.
2. Attach auxiliary fence to rip fence with two ‘G’
clamps as shown in fig 24.
3. Feed the workpiece by hand until the end is
approximately 1” from the front edge of the table.
Continue to feed using the push block until the cut is
complete.
RIP CUTTING A BEVEL
By tilting the saw blade (up to 45O), it is possible to rip cut
a bevel in your work. To do this:
1. Set the blade angle using the blade angle adjuster.
• If the workpiece is less than 150mm (6”) wide,
position the rip fence on the RIGHT SIDE of the
blade. This will provide more space between the
fence and the saw blade for the use of a push
stick.
Fig.25
Fig.24
