Clarke CSE2 Instruction Manual

OPERATION & MAINTENANCE
INSTRUCTIONS
GC11/18 - ISS 2
ORIGINAL INSTRUCTIONS
SUBMERSIBLE WATER PUMPS
MODEL NO: CSE2,CSD3,CSV1A,CSV2A
PART NO: 7230560, 7230610, 7230580, 7230600

2
INTRODUCTION
Thank you for purchasing this CLARKE Submersible Water Pump. CSE pumps
are designed for pumping clean water only and will pump down to a water
level of 20mm.
This pump is designed for pumping clean water or water containing solids in
suspension and is ideally suited for draining ponds, pools, sumps etc. It is not
designed for pumping slurry, sludge, mud or heavily polluted water, or any
water containing chemicals or other acidic contaminants including salt water.
Pumps fitted with float switches are suitable for permanent or semi-permanent
installations where it is necessary to maintain water at a particular level.
As the water level rises, the float switch will rise and start the pump. As the
water level falls, so will the float switch until it stops the pump. Float switches
are factory set to provide the correct on/off switching mode, however, you
can adjust the level at which the pump cuts out by sliding the float switch
cable in its clip attached to the handle, to either shorten or lengthen as
required. The shorter the cable, the earlier it will cut out and therefore, the
deeper the water will remain at this point.
PUMP SPECIFICATION
CSE2 CSD3 CSV1A CSV2A
Dimensions excluding
the elbow
140 x
302mm
149 x
400mm
143 x
300mm
143 x
335mm
Weight 4.3kg 8.0 kg 4.6 kg 5.6 kg
Cable Size 10 x 0.75
(m x mm2)
15 x 1.0 (m
x mm2)
10 x 0.75
(m x mm2)
10 x 0.75
(m x mm2)
Max. Capacity 253 L/min 95 L/min 118 L/min 236 L/min
Head Max 10 m 45 m 5 m 9 m
Motor Output 750 W 900 W 330 W 650 W
Outlet Diameter 1¼”/
32mm
1”/ 25mm 1¼”/
32mm
1¼”/
32mm
S

3
SAFETY PRECAUTIONS
1. These pumps are designed to pump WATER ONLY. Never use for pumping
flammable liquids or chemicals.
2. Never run the pump dry.
3. An approved Residual Current Device (RCD) which has a tripping current
of less than 30mA must be used when pumping from ponds or swimming
pools.
4. Never carry the pump by the mains lead or float switch.
5. Never pull the mains lead to disconnect the pump from the mains socket.
6. Your submersible pump may only be used for pumping water from a
swimming pool when there is no person or animal in the pool.
7. Always disconnect the pump from the electrical supply before placing it
into, or removing it from the water and before any cleaning or
maintenance.
8. Always use the moulded handle (or lifting eye), with a rope or cable
attached when lifting the pump. NEVER lift the pump by the mains cable
or, where fitted, the float switch cable.
9. DO NOT run the pump with the body exposed for longer than 10 minutes.
10. DO NOT install the pump on sand or ground which is likely to shift.
11. Do not use the pump if the water is liable to freeze, as this can cause
damage to the pump. Remove the pump from the water and store it in a
frost free location.
12. If the pump is to be used where there may be silt or mud (for example,
garden ponds), keep the pump clear of any sediment by standing it on a
platform or brick.
13. Do not allow children to touch the pump, cables or connections.
14. Disconnect the pump from the mains supply when not in use.
15. Have the pump repaired by a qualified person.
16. Keep the mains cable away from heat, oil and sharp edges.
17. Always check the plug, mains cable and float switch cable for damage
before use. Do not use the pump if damaged. Refer to qualified service
personnel for repair.
18. If you have to use an extension lead with this product, it must be designed
for outdoor use and incorporate a cable suitable for use with Class I
appliances.

4
ELECTRICAL CONNECTIONS
Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply
through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch.
If the plug has to be changed because it is not suitable for your socket, or
because of damage, it must be removed and a replacement fitted, following
the wiring instructions shown below. The old plug must be discarded safely, as
insertion into a power socket could cause an electrical hazard.
If the colours of the wires in the power cable do not agree with the markings
on the plug.
• The BLUE wire must be
connected to the
terminal which is
marked N or coloured
black.
• The BROWN wire must
be connected to the
terminal which is
marked L or coloured
red.
• The YELLOW AND
GREEN wire must be
connected to the terminal which is marked E or or coloured green.
AN APPROVED RESIDUAL CURRENT DEVICE (RCD) WHICH HAS A TRIPPING
CURRENT OF LESS THAN 30 mA MUST BE USED.
If you are not sure, consult a qualified electrician. DO NOT try to do any
repairs.
WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS
SUPPLY.
WARNING: THE WIRES IN THE POWER CABLE OF THIS PRODUCT ARE
COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE:
BLUE = NEUTRAL BROWN = LIVE YELLOW AND GREEN = EARTH
Plug must be BS1363/A approved.
Always fit
Ensure that the outer sheath of
Neutral
(Blue)
Live
(Brown)
Earth
(Green and
a 13 Amp
the cable is firmly held by the clamp
fuse.
Yellow)

5
PREPARATION
1.
ELBOW
Fit the elbow adaptor to the
pump outlet as shown in the
diagram opposite.
2. Screw the multi-hose adaptor
onto the elbow.
• The multi hose adaptor is
capable of accepting 1”,
¾”and ½” hoses.
3.
1”
¾”
½”
Simply cut the multi hose
connector to the required size
and attach a suitable hose using
with a worm drive clip.
• For maximum efficiency, we
strongly recommend that you
connect a 1¼” diameter hose
to the multi hose adapter.
• Alternatively, you may remove
the multi adapter altogether,
and screw on a 1¼” BSP hose adapter.
The pump is completely submersible and should be placed in a vertical
position on a solid flat surface, placing the pump on a couple of house bricks if
required.
SUITABLE HOSES AND SPARE/REPLACEMENT MULTI HOSE ADAPTERS ARE
AVAILABLE FROM YOUR CLARKE DEALER.
WARNING: DISCONNECT THE PUMP FROM THE MAINS POWER SUPPLY
BEFORE CONNECTING THE MULTI HOSE ADAPTOR.

6
USING THE PUMP
1. Place the pump on a flat surface in the area that you want to drain.
• If there is sediment in the operating area the pump should be
placed on house bricks or similar.
• Ensure the pump is positioned with adequate space so that the
movement of the float switch is not restricted - recommended
minimum area of 40 x 40cm.
• ALWAYS raise and lower the pump using a rope attached to the
lifting handle.
• Take all necessary precautions as described on page 3 before
plugging in and switching ON.
2. Connect the mains plug to a high sensitivity residual current device (RCD)
which has a tripping current of less then 30mA.
3. Switch the mains power supply on.
• The pump incorporates a float switch which automatically switches
the pump ON when the water is above a pre-determined level.
• The pump will begin to drain water.
• As the water level falls, so will the float switch until it stops the pump.
4. Disconnect the pump from the mains power supply when finished.
• These pumps are fitted with automatic thermal overload protection.
If the pump overheats due to an obstruction in the pump or
pumping warm water for example, it will shut off automatically.
Switch the pump OFF and disconnect from the mains supply. Check
for blockages and allow the motor to cool (at least 5 minutes)
before attempting to re-start.
WARNING: CHECK THE PUMP FOR DAMAGE BEFORE USE. DO NOT USE THE
PUMP IF IT IS DAMAGED IN ANY WAY.
WARNING: THE WATER BEING PUMPED WILL BE POLLUTED IF THIS PUMP
BECOMES DAMAGED AND LUBRICANT WITHIN THE PUMP ESCAPES.
WARNING: NEVER CARRY THE PUMP USING THE MAINS POWER CABLE.
DAMAGE TO ELECTRICAL CABLES CAN BE HAZARDOUS. ALWAYS USE THE
HANDLE WHEN MOVING THE PUMP.
CAUTION: DO NOT ALLOW THE PUMP TO RUN DRY

7
MAINTENANCE
These pumps should require no maintenance other than regular cleaning.
If the pump starts to show signs of wear or damage, contact your CLARKE
dealer for advice.
Do not use the pump if there is any damage to the mains supply cable or to
the float switch or its cable.
Do not attempt to repair the pump yourself as you may damage the
waterproof seal and invalidate your guarantee. Repairs must be carried out
by your CLARKE dealer or contact the CLARKE Service Department on 020
8988 7400.
If the troubleshooting on page 8 does not solve your problem please contact
the Clarke service department.
CLEANING
1. Check the pump installation regularly to ensure the base inlet is clear of
leaves or other debris.
• These pumps have screwless fittings at
their base, allowing the removal of the
plastic cover by prising the two
release clips apart in the direction of
the arrows.
• This allows better access to the cavity
at the bottom, should the pump
become badly clogged. Flush the
cavity and the impeller housing with
clean water.
• To replace the cover, ensure the
release clips line up with the holes on the base of the pump and
press the cover home.
NOTE: Do not attempt to strip the pump further as this will invalidate the
guarantee.
WARNING: BEFORE CHECKING THE CONDITION OF THE PUMP, ENSURE IT
IS UNPLUGGED FROM THE MAINS SUPPLY.

8
TROUBLESHOOTING
PROBLEM SOLUTION
PUMP WILL
NOT START
1. Check to ensure power is switched on.
2. Check fuse (consult an electrician if in doubt).
3. If extension lead is fitted, check connections (consult an
electrician if in doubt).
4. Internal thermal cut-out has not re-set. Leave for 5
minutes and try again.
5. The impeller may be jammed. Disconnect from the mains
supply, remove the bottom strainer and remove any
objects that may be obstructing the impeller. Replace
the strainer and try again.
6. If the pump still fails to start consult your CLARKE dealer for
advice.
7. Floatswitch may be jammed against side wall or
prevented from moving.
8. Water level too low - float switch in OFF position - lift float
to check switch.
PUMP WILL
START BUT NOT
PUMP
1. Check to ensure strainer is not blocked.
2. Discharge tube clogged or obstructed.
3. The head may be too great, i.e. you are trying to lift the
water too great a distance for the pump to cope with.
(See specifications on page 2).
4. Air bubble in the pump, produced during the plunge.
Plunge the pump again at an angle and shake it whilst
lowering to remove any air trapped in the system.
5. Impeller may be damaged - Consult your CLARKE dealer.
PUMP WILL
NOT STOP
1. Float switch may be prevented from moving to the fully
down position.
2. Float switch may be faulty. Consult your CLARKE dealer
for advice.
PUMP STOPS
RUNNING
1. Thermal overload has operated. If this condition persists,
investigate the cause. Are you attempting to pump liquid
which is too heavy for the pump (mud, slurry etc.)
2. Pump has run dry or float switch has cut in.
3. A foreign object has jammed the impeller.

9
DECLARATION OF CONFORMITY

10
EXPLODED PARTS DIAGRAM - CSV1A/2A

11
PARTS LIST
NO DESCRIPTION CSV1/A CSV2/A
1Floatswitch LDP1380002 LDP1380002
2Cap LDS3600170 LDS3600170
3Cable 10m LDP1320016 LDP1320016
4Grommet CSV2 ONLY
5Grommet LDP1230003 LDP1230003
6Flux Capacitor LDP1360030 LDP1360030
7Lock LDS3500011 LDS3500011
8Anti-tear Ring-piece LDS3500336 LDS3500336
9Cable Fastener LDS3500335 LDS3500335
10 Screw LDP1100008 LDP1100008
11 Earth Screw LDP1100003 LDP1100003
12 Spring Washer LDP1120003 LDP1120003
13 Washer LDP1120051 LDP1120051
14 Insulation Disc LDS3500106 LDS3500106
15 Upper Flange LDS3120005 LDS3120005
16 Wave Washer LDP1120002 LDP1120002
17 Ceramic Shaft/Bearings LDS3101001 LDS3101002
18 Bearing LDP1180001 LDP1180001
19 Washer LDP1120007 LDP1120007
20 Lip Seal LDP1210001 LDP1210001
21 Stator LDS3410004 LDS3410017
22 Joint O-ring LDP1200007 LDP1200007
23 Pump Housing LDS3500206 LDS3500207
24 Joint O-ring LDP1200009 LDP1200009
25 Elbow with O-ring LDS3600111 LDS3600111
26 Washer LDP1120006 LDP1120006
27 Nut LDP1110005 LDP1110005
28 Impellor LDS3500013 LDS3500014
29 Joint O-ring LDP1200008 LDP1200008
30 Pedestal LDS3500018 LDS3500018
31 Joint O-ring LDP1200033 LDP1200033
32 Screw LDP1100090 LDP1100090
33 Screw LDP1100014 LDP1100014
34 Washer LDP1120017 LDP1120017
35 Sphere LDP1180003 LDP1180003
36 Twin Lip Seal LDP1210004 LDP1210004
37 Joint O-ring LDP1200002 LDP1200002
38 3-step Fitting with O-ring LDS3600162 LDS3600162
- CSV1A/CSV2A

12
EXPLODED PARTS DIAGRAM - CSE2

13
PARTS LIST
NO DESCRIPTION PA R T NO NO DESCRIPTION PA R T N O
1Float-switch LDP1380002 21 Stator LDS3410017
2Cap LDS3600170 22 Joint O-ring LDP1200007
3Cable 10m LDP1320016 23 Pump housing LDS3600075
4Grommet LDP1230002 24 Joint O-ring LDP1200009
5Grommet LDP1230003 25 Elbow with O-ring LDS3600111
6Capacitor LDP1360030 26 Washer LDP1120006
7Lock LDS3500011 27 Nut LDP1110005
8Anti-tear ring LDS3500336 28 Impeller LDS3500559
9Cable fastener LDS3500335 29 Joint O-ring LDP1200008
10 Screw LDP1100008 30 Filter LDS3500017
11 Earth screw LDP1100003 31 Filter Base LDS3500107
12 Spring-washer LDP1120003 32 Joint O-ring LDP1200033
13 Washer LDP1120051 33 Screw LDP1100090
14 Insulation disc LDS3500106 34 Screw LDP1100014
15 Upper flange LDS3120005 35 Washer LDP1120017
16 Wave washer LDP1120002 36 Ball LDP1180003
17 Ceramic shaft with
bearings
LDS3101002 37 Twin Lip Seal LDP1210004
18 Bearing LDP1180001 38 Joint Ring LDP1200002
19 Washer LDP1120007 39 Step Fitting /O-ring LDS3600162
20 Lip seal LDP1210001 40 V-ring Joint LDP1210002
- CSE2
ENVIRONMENTAL RECYCLING POLICY
Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.
In effect, this means that this product must not be disposed of with general
household waste but according to the laws governing Waste Electrical and
Electronic Equipment (WEEE) at a recognised disposal facility.

14
EXPLODED PARTS DIAGRAM - CSD3

15
PARTS LIST
NO DESCRIPTION PA R T NO NO DESCRIPTION PA R T N O
1Pipe fitting/O-ring LDS3600107 23 Stator LDS3410014
2Joint O-ring LDP1200002 24 Twin lip seal LDP1210004
3Non-return valve LDS3600099 25 Joint O-ring LDP1200007
4Spacer LDP1230003 26 Joint O-ring LDP1200012
5Power cable LDP1330011 27 Pump housing LDS3500737
6Float-switch LDP1380002 28 Joint O-ring LDP1200020
7Cap LDS3600186 29 Joint O-ring LDP1200015
8Capacitor LDP1360003 30 Screw LDP1100012
9Grommet LDP1230003 31 Diffuser flange LDS3600156
10 Anti-tear ring LDS3500336 32 Washer LDP1120012
11 Cable fastener LDS3500335 33 Hexagonal shaft LDS3100019
12 Screw LDP1100008 34 V-ring LDP1210005
13 Earth screw LDP1100003 35 Impeller LDS3250028
14 Spring washer LDP1120003 36 Joint O-ring LDP1200014
15 Washer LDP1120051 37 Diffuser LDS3250006
16 Insulation disc LDS3500106 38 Diffuser cap LDS3500611
17 Upper flange LDS3120005 39 Washer LDP1120014
18 Wave washer LDP1120002 40 Nut LDP1110009
19 Bearing LDP1180001 41 Filter ring LDS3220006
20 Shaft with bearings LDS3101004 42 Filter base LDS3500743
21 Washer LDP1120007 43 Screw LDP1100017
22 Lip seal LDP1210001 44 Cap LDP1230006
- CSD3
GUARANTEE
This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.
This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.
Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.
This guarantee does not effect your statutory rights.
