Claro R327600A98-00001 User manual
LATAMAmericaMovilAndroidTV2020
QuickReferenceGuide
Part number variants:
Cervino Base Platform
R327600A98-00001
CLARO
R327600A00-00004
ACTIVATING RF
The LATAM America Movil Android RCU shall support both IR and BLE command codes for each key. The default
operating mode when supplied and batteries are fitted is explained in the following section.
Programming Name Trigger
PAIRING_COMBO ‘Home’ and ‘Back’ keys pressed simultaneously
and held down for 2s
UNPAIR_COMBO ‘OK’ and ‘Play/Pause’ keys pressed
simultaneously and held down for 3s
Table 1: Pair & Un-pair combos
Item STB Pairing
Table
RCU Pairing
Table Behavior
1 Clear Clear Any key press initiates pairing with no further pre-requisites
on RCU or STB
2 STB #1 entry for
RCU #1 RCU #2 Clear
Either STB accepts pairing with 2 or more RCUs OR user
navigates to settings screen using IR mode and manually
deletes the pairing info for RCU #1
3 STB #2 Clear RCU #1 entry for
STB #1
User has to activate the RCU un-pairing combo to clear the
pairing table.
Table 2: Scenarios for pairing with other devices
INFRAREDASSISTANCE
IR assistance serves two purposes:
‐ProvidesatriggertotheSTBintheformofanIRcommandthattheSTBcanusetostartlisteningfor
Bluetoothadverts.
‐ProvidesamechanismfortheSTBtooptionallyrestrictofferingaconnectionrequestonlytotheRCUthat
senttheIRcommand.
IR assistance behaviour does not depend on the method of pairing initiation; i.e. both ‘auto-pairing’ and manual
pairing methods shall use IR assistance.
Action Behavior Terminating
Condition Host Response
1 Pairing activated
IR Macro transmitted
repeatedly where the 1st
frame is the pairing
command and the 2nd frame
is the last byte of the RCU
BT address (MAC) Pairing timeout of
PAIR_ADV_DURATION
reached
Optionally decode IR
Macro and filter out last
byte of MAC ID
2 Indirect Ad
(ADV_IND) sent Optionally only send
connection request if IR
Macro matches MAC part
of local name in Scan
response
3 Scan response
sent
Last byte of RCU BT
address included as part
of ‘Complete Local
Name’
Table3:IRassiststatetable
Note that the host response to use the second frame in the Macro for restrictive pairing is optional.
It offers a mechanism to restrict pairing to the device sending the IR frames but it is the host
decision to make this restriction and hence does not prevent pairing by default.
Features:
BLE using the UE878, 512K Flash and 64K RAM
Modeless two device support (TV, STB)
One RED feedback LED
Universal IR for TV
IR assisted pairing
Quickset for automated setup of devices
Modeless operation
Shall be compatible with Android ‘P’ operating system
Shall be able to pair with and support BLE features for the following Bluetooth Stacks –
oFluoride 1.2
No mode switching required for TV control
Low voltage warning when battery level gets critical using Bluetooth BAS service
Microphone for capturing voice in 16 bits 16KHz quality
Customer Reset
Software Version Verification
Factory Reset
Volume lock
UAPI
OTA (background OTA)
Operating Temperature
o0°C to +50°C
Battery Type: 2 x AAA alkaline
The remote is intended to be used with target STB/devices based on the Android ‘P’ platform. The
following table summarizes the host-side requirements.
BLE Radio Chip
on Host
Cypress ‘CYW20704UA2KFFB1G’
Bluetooth Stack Fluoride
Keys Standard HOGP
Voice Google voice GATT Profile as defined in section
Error! Reference source not found.
OTA UAPI via UUG
Quickset UAPI via UUG
Battery Status Standard Battery Service
UAPI – UEI’s API
HOGP – HID over GATT Profile
COMPLIANCEWITHFCCRULESANDREGULATIONS
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,
pursuanttopart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyandifnotusedinaccordancewiththeinstructions,maycause
harmfulinterferencetoradiocommunications.
However,thereisnoguaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis
equipmentdoescauseharmfulinterferencetoradioortelevisionreception,theuseris
encouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
•Reorient or relocate the receiving antenna.
•Increaseordecreasetheseparationbetweentheequipmentandreceiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
Consultthedealeroranexperiencedremotecontrol/TVtechnicianforhelp.
ThisequipmenthasbeenverifiedtocomplywiththelimitsforaClassBcomputingdevice,
pursuanttoFCCRules.Theuseriscautionedthatchangesandmodificationsmadetothe
equipmentwithouttheapprovalofmanufacturercouldvoidtheuser'sauthoritytooperatethis
equipment.
FCCAuthorizationLabel
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:
1.Thisdevicemaynotcauseharmfulinterference.
2Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperation.
FCCID:MG3‐R327600
