English
Dehumidifier
Art.no 36-8322 Model MDDF-20DEN7-QA3
Please read theentire instruction manual before using theproduct and then save it for
future reference. We reserve theright for any errors in text or images and any necessary
changes made to technical data. In theevent of technical problems or other queries,
please contact our Customer Services (see address details on theback).
Safety
• The product must only be connected to a230 V, 50 Hz
earthed power socket protected by anRCD.
• The product may be used by children aged 8 years and above
and by persons with reduced physical, sensory or mental
capability or lack of experience and knowledge provided they
have been given supervision or instruction concerning use of
theproduct in asafe way and understand thehazards involved.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
• If the mains lead is damaged, it must only be replaced by the
manufacturer, one of their service centres or a qualified person
in order to avoid a hazard.
• Never let children play with theproduct.
• The product must always stand upright.
• Never sit on, cover or place foreign objects on theproduct.
• The product must stand upright for at least 1 hour before
it is used for thefirst time. The same applies if theproduct
has been tilted from its upright position whilst being moved,
cleaned, etc.
• Never use theproduct if themains lead, plug or any other part
is damaged or does not work properly.
• Never try to dismantle or repair theproduct yourself.

4
English
Warning: When using refrigerant R290.
• If theproduct needs to be used with anextension lead or
trailing socket, make sure that thelead used is suitable for use
with theproduct.
• Never plug in or unplug theproduct with wet hands.
• Never insert foreign objects into theopenings in theproduct.
• Unplug theproduct immediately if it emits strange noises,
odours or smoke.
• Unplug theproduct immediately if it tips over or if it is splashed
with water. Contact aqualified service technician before using
theproduct again.
• The product must not be covered in any way. Make sure that
no foreign objects cover or block theair inlet/outlet. Blockages
can lead to fires, electric shocks or damage to theproduct.
• Unplug theproduct when it is not in use.
• Never use themains lead plug for turning theproduct on or off.
The product should only be switched on and off using theon/
off switch.
• Before moving theproduct, make sure it is switched off,
unplugged and that thewater tank is empty.
• Never expose theproduct to running/splashing water or other
liquids.
• Liquid coming in contact with electrical components can be
extremely hazardous.
• Do not place theproduct where it could fall into water or
other liquid.
• Do not place any objects which contain liquid such as vases or
drinks onto theproduct.

5
English
IMPORTANT NOTE: Read this instruction manual
carefully before installing or using thedehumidifier unit.
Keep this instruction manual for future reference.
• Do not use any other agents than those recommended by
themanufacturer for cleaning or to speed up thedefrosting
process.
• Never use theproduct in areas where flammable liquids/
materials or gases (petrol, solvents, gas cylinders) are stored
or used.
• Make sure that there are no holes or burns on theproduct.
• Be aware that refrigerants can be odourless.
• The product should be used in areas with afloor space greater
than 4 m².
Safety regulations for service and repair work
Repairs must only be carried out by authorised service personnel
and only using genuine spare parts.
1. Check thework area
Prior to beginning work on systems containing flammable
refrigerants, safety checks are necessary to ensure that therisk
of ignition is minimised. For repair to therefrigerating system,
thefollowing precautions shall be complied with prior to
conducting work on thesystem.
2. Work procedure
Work shall be undertaken under acontrolled procedure so as
to minimise therisk of aflammable gas or vapour being present
while thework is being performed.
3. General work area
All maintenance staff and others working in thelocal area shall
be instructed on thenature of work being carried out. Work in
confined spaces shall be avoided. The area around theworkspace
shall be sectioned off. Make sure that theconditions within
thearea have been made safe by control of flammable material.

6
English
4. Checking for thepresence of refrigerant
The area shall be checked with anappropriate refrigerant
detector prior to and during work, to ensure thetechnician
is aware of potentially flammable atmospheres. Ensure that
theleak detection equipment being used is suitable for use with
flammable refrigerants, i.e. non-sparking, adequately sealed or
intrinsically safe.
5. Presence of afire extinguisher
If any hot work is to be conducted on therefrigeration equipment
or any associated parts, appropriate fire extinguishing equipment
shall be available to hand. Have adry powder or CO2fire
extinguisher adjacent to thecharging area.
6. No ignition sources
No person carrying out work in relation to arefrigeration system
which involves exposing any pipe work that contains or has
contained flammable refrigerant shall use any sources of ignition
in such amanner that it may lead to therisk of fire or explosion.
All possible ignition sources, including cigarette smoking, should
be kept sufficiently far away from thesite of installation, repairing,
removing and disposal, during which flammable refrigerant can
possibly be released to thesurrounding space. Prior to work
taking place, thearea around theequipment is to be surveyed to
make sure that there are no flammable hazards or ignition risks.
‘NO SMOKING’ signs shall be displayed.
7. Ventilated area
Ensure that thearea is in theopen or that it is adequately
ventilated before breaking into thesystem or conducting any hot
work. A degree of ventilation shall continue during theperiod that
thework is carried out. The ventilation should safely disperse
any released refrigerant and preferably expel it externally into
theatmosphere.

7
English
8. Checks to therefrigeration equipment
Where electrical components are being changed, they shall
be fit for thepurpose and to thecorrect specification. The
manufacturer’s maintenance and service guidelines shall be
followed at all times. If in doubt consult themanufacturer’s
technical department for assistance. The following checks shall
be applied to installations using flammable refrigerants:
• That thecharge size is in accordance with theroom size within
which therefrigerant containing parts are installed.
• That theventilation machinery and outlets are operating
adequately and are not obstructed.
• That if anindirect refrigerating circuit is being used,
thesecondary circuit shall be checked for thepresence of
refrigerant. That markings on theequipment continue to be
visible and legible.
• Markings and signs that are illegible shall be corrected.
• Refrigeration pipe or components are installed in aposition
where they are unlikely to be exposed to any substance
which may corrode refrigerant containing components, unless
thecomponents are constructed of materials which are
inherently resistant to being corroded or are suitably protected
against being so corroded.
9. Checks to electrical devices
Repair and maintenance to electrical components shall include
initial safety checks and component inspection procedures. If afault
exists that could compromise safety, then no electrical supply
shall be connected to thecircuit until it is satisfactorily dealt with.
If thefault cannot be corrected immediately but it is necessary to
continue operation, anadequate temporary solution shall be used.
This shall be reported to theowner of theequipment so all parties
are advised. Initial safety checks shall include:
• That capacitors are discharged: this shall be done in asafe
manner to avoid possibility of sparking.

8
English
• That no live electrical components and wiring are exposed
while charging, recovering or purging thesystem.
• That there is continuity of earth bonding.
10. Repairs to sealed components
During repairs to sealed components, all electrical supplies shall
be disconnected from theequipment being worked upon prior
to any removal of sealed covers, etc. If it is absolutely necessary
to have anelectrical supply to equipment during servicing, then
apermanently operating form of leak detection shall be located at
themost critical point to warn of apotentially hazardous situation.
Particular attention shall be paid to thefollowing to ensure that
by working on electrical components, thecasing is not altered in
such away that thelevel of protection is affected. This shall include
damage to cables, excessive number of connections, terminals
not made to original specification, damage to seals, incorrect
fitting of glands, etc.
• Ensure that apparatus is mounted securely.
• Ensure that seals or sealing materials have not degraded such
that they no longer serve thepurpose of preventing theingress
of flammable atmospheres. Replacement parts shall be in
accordance with themanufacturer’s specifications.
Note: The use of silicone sealant may inhibit theeffectiveness
of some types of leak detection equipment. Intrinsically safe
components do not have to be isolated prior to working on them.
11. Repair of intrinsically safe components
Do not apply any permanent inductive or capacitive loads to
thecircuit without ensuring that this will not exceed thepermissible
voltage and current permitted for theequipment in use. Intrinsically
safe components are theonly types that can be worked on while
live in thepresence of aflammable atmosphere. The test apparatus
shall be of thecorrect rating. Replace components only with parts
specified by themanufacturer. Other parts may result in theignition
of refrigerant in theatmosphere from aleak.

9
English
12. Cabling
Check that cabling will not be subject to wear, corrosion,
excessive pressure, vibration, sharp edges or any other adverse
environmental effects. The check shall also take into account
theeffects of aging or continual vibration from sources such as
compressors or fans.
13. Detection of flammable refrigerants
Under no circumstances shall potential sources of ignition be used
in thesearching for or detection of refrigerant leaks. A halide torch
(or any other detector using anaked flame) must not be used.
14. Leak detection methods
The following leak detection methods are deemed acceptable
for systems containing flammable refrigerants. Electronic leak
detectors shall be used to detect flammable refrigerants, but
thesensitivity may not be adequate, or may need re-calibration.
Detection equipment shall be calibrated in arefrigerant-free area.
Ensure that thedetector is not apotential source of ignition and
is suitable for therefrigerant used.
Leak detection equipment shall be set at apercentage of theLFL
of therefrigerant and shall be calibrated to therefrigerant employed
and theappropriate percentage of gas (25 % maximum) is
confirmed. Leak detection fluids are suitable for use with most
refrigerants but theuse of detergents containing chlorine shall be
avoided as thechlorine may react with therefrigerant and corrode
thecopper pipe-work.
If aleak is suspected, all naked flames shall be removed/
extinguished. If aleakage of refrigerant is found which requires
brazing, all of therefrigerant shall be recovered from thesystem,
or isolated (by means of shut off valves) in apart of thesystem
remote from theleak. Oxygen-free nitrogen (OFN) shall then be
purged through thesystem both before and during thebrazing
process.

10
English
15. Removal and evacuation
When breaking into therefrigerant circuit to make repairs (or
for any other purpose) conventional procedures shall be used.
However, it is important that best practice is followed since
flammability is aconsideration. The following procedure shall be
adhered to:
• Remove therefrigerant.
• Purge thecircuit with inert gas.
• Evacuate.
• Purge again with inert gas.
• Open thecircuit by cutting or brazing.
The refrigerant charge shall be recovered into thecorrect recovery
cylinders. The system shall be flushed with OFN to render
theunit safe. This process may need to be repeated several
times. Compressed air or oxygen shall not be used for this task.
Flushing shall be achieved by breaking thevacuum in thesystem
with OFN and continuing to fill until theworking pressure is
achieved, then venting to atmosphere, and finally pulling down to
avacuum.
This process shall be repeated until no refrigerant is within
thesystem.
When thefinal OFN charge is used, thesystem shall be vented
down to atmospheric pressure to enable work to take place. This
operation is absolutely vital if brazing operations on thepipe-work
are to take place. Ensure that theoutlet for thevacuum pump is not
close to any ignition sources and there is aventilation available.
16. Charging procedures
In addition to conventional charging procedures, thefollowing
requirements shall be followed:
• Ensure that contamination of different refrigerants does not
occur when using charging equipment. Hoses or lines shall
be as short as possible to minimise theamount of refrigerant
contained in them.

11
English
• Cylinders shall be kept upright.
• Ensure that therefrigeration system is earthed prior to charging
thesystem with refrigerant.
• Label thesystem when charging is complete (if not already).
• Extreme care shall be taken not to overfill therefrigeration
system.
• Prior to recharging thesystem it shall be pressure-tested
with OFN. The system shall be leak-tested on completion of
charging but prior to commissioning. A follow up leak test shall
be carried out prior to leaving thesite.
17. Decommissioning
Before carrying out this procedure, it is essential that thetechnician
is completely familiar with theequipment in every detail. It is
recommended good practice that all refrigerants are recovered safely.
Prior to thetask being carried out, anoil and refrigerant sample
shall be taken in case analysis is required prior to re-use of
reclaimed refrigerant. It is essential that electrical power is
available before thetask is commenced.
a) Become familiar with theequipment and its operation.
b) Isolate thesystem electrically.
c) Before attempting theprocedure ensure that:
- Mechanical handling equipment is available, if required,
for handling refrigerant cylinders.
- All personal protective equipment is available and being
used correctly.
- The recovery process is supervised at all times by
acompetent person.
- Recovery equipment and cylinders conform to
theappropriate standards.
d) Pump down therefrigerant system, if possible.
e) If avacuum is not possible, make amanifold so that
refrigerant can be removed from various parts of thesystem.

12
English
f) Make sure that cylinder is situated on thescales before
recovery takes place.
g) Start therecovery machine and operate in accordance with
manufacturer’s instructions.
h) Do not overfill cylinders. (No more than 80 % volume liquid
charge).
i) Do not exceed themaximum working pressure of thecylinder,
even temporarily.
j) When thecylinders have been filled correctly and theprocess
completed, make sure that thecylinders and theequipment
are removed from site promptly and all isolation valves on
theequipment are closed off.
k) Recovered refrigerant shall not be charged into another
refrigeration system unless it has been cleaned and checked.
18. Labelling
Equipment shall be labelled stating that it has been decommissioned
and emptied of refrigerant. The label shall be dated and
signed. Ensure that there are labels on theequipment stating
theequipment contains flammable refrigerant.
19. Recovery
When removing refrigerant from asystem, either for servicing
or decommissioning, it is recommended good practice that all
refrigerants are removed safely.
• When transferring refrigerant into cylinders, ensure that only
appropriate refrigerant recovery cylinders are employed.
Ensure that thecorrect number of cylinders for holding
thetotal system charge are available. All cylinders to be used
are designated for therecovered refrigerant and labelled
for that refrigerant (i.e. special cylinders for therecovery of
refrigerant). Cylinders shall be complete with pressure relief
valve and associated shut-off valves in good working order.
• Empty recovery cylinders are evacuated and, if possible, cooled
before recovery occurs.

13
English
• The recovery equipment shall be in good working order with
aset of instructions concerning theequipment that is at hand
and shall be suitable for therecovery of flammable refrigerants.
In addition, aset of calibrated weighing scales shall be
available and in good working order.
• Hoses shall be complete with leak-free disconnect couplings
and in good condition. Before using therecovery machine,
check that it is in satisfactory working order, has been properly
maintained and that any associated electrical components are
sealed to prevent ignition in theevent of arefrigerant release.
Contact themanufacturer if you are unsure.
• The recovered refrigerant shall be returned to therefrigerant
supplier in thecorrect recovery cylinder, and therelevant
Waste Transfer Note arranged. Do not mix refrigerants in
recovery units and especially not in cylinders.
• If compressors or compressor oils are to be removed, ensure
that they have been evacuated to anacceptable level to
make certain that flammable refrigerant does not remain
within thelubricant. The evacuation process shall be carried
out prior to returning thecompressor to thesuppliers. Only
electrical heating of thecompressor body shall be employed
to accelerate this process. When oil is drained from asystem,
it shall be carried out safely.

14
English
1
2
3
4
5
6
7
8
9
10
11 12 13 14 15 16 17
Product description
1. Control panel
2. Handle, one each side
3. Water level window
4. Water tank
5. Wheel
6. Air outlet
7. Grille over air intake with mesh filter
8. Drain hose outlet for
continuous operation
9. Mains lead hanger
10. Mains lead
Control panel
11. [TIMER] Timer button for setting
start and stop times
12. [FAN]Fan button for choosing
thespeed setting:
- Low: low fan speed
- Med: medium fan speed
- High: high fan speed
13. Control used for setting thehumidity
level and timer
14. Display screen Full indicator light
(flashes when thewater tank is full)
15. Control used for setting thehumidity
level and timer
16. [MODE] Mode selector. Chose between:
- Dryer: Dryer mode. Drying mode in
which thefan runs at maximum speed
(non-adjustable). The desired level of
humidity cannot be set.
- Cont: Continuous operation mode,
adesired humidity level cannot be set.
- SMD: Smart dehumidification mode.
The humidity in theroom is kept within
therecommended range of 45–55%
depending on theroom temperature.
Example: if theroom temperature
drops, thehumidity is automatically
increased to acomfortable level.
17. [POWER] On/off button

15
English
Instructions for use
Placement
• The dehumidifier is only intended for normal domestic use and only in themanner
described in this instruction manual.
• Do not use thedehumidifier in aroom in which thetemperature might fall to below 5°C.
• Make sure that thedehumidifier is standing firmly on aflat surface capable of
supporting its weight even when thewater tank is full.
• Make sure that themains lead is easily accessible and is not damaged by sharp
edges or is crushed in any way during use.
• Extra caution should taken be when thedehumidifier is used in thesame
environment as infants, small children and theelderly.
• The dehumidifier should be placed where it can draw in air from theentire house.
• All interior doors should be opened. Close exterior doors and windows.
• If any part of your house suffers from severe humidity, thedehumidifier can be
placed there first and then moved to another part of thehouse later.
• Position thedehumidifier where theair can circulate freely, leave at least 20 cm of
clearance on all sides.
• Never place thedehumidifier next to aradiator or heating appliance.
• Make sure that therubber plug is firmly pushed into thedrain hose connector
before operating thedehumidifier without adrain hose connected.
• The water tank must be correctly fitted before thedehumidifier can be switched on.
• Remember to empty thewater tank before moving thedehumidifier.
• The dehumidifier works best at normal room temperature, its efficiency is reduced if
theambient temperature falls below 15 °C.
• Let thedehumidifier operate continuously for 24 hours thefirst time it used.
• If thedehumidifier is turned off and then turned back on again immediately, it will
take approximately 3 minutes to reach full power. If you switch thedehumidifier off,
you can wait 3 minutes before switching it back on.
• Never use thedehumidifier without themesh filter and grille in place.
• If thedehumidifier is switched off by apower cut it will automatically switch back on
once thepower is restored.
Switching thedehumidifier on/off
1. Read all theinstructions in theSafety and Placement sections above.
2. Connect themains lead to awall socket with thespecifications listed in part 1 of
theSafety section above.
3. Turn thedehumidifier on by pressing the [ ] button.
4. Select one of theoperating modes Dryer, Cont or SMD explained in theControl
panel section.
5. Turn thedehumidifier off by pressing the [ ] button. The fan will continue for 30 seconds
to dry theinside of thedehumidifier.

16
English
Timer setting
Setting thestop time
1. Make sure that thedehumidifier is switched on.
2. Press thetimer button (11).
3. Set thedesired stop time by pressing or holding down the [−] or [+] button.
The time is changed in 30-minute increments up to the10-hour mark. Thereafter
in increments of 60 minutes. The display shows theset timer time for 5 seconds
before reverting to whatever is was displaying previously.
Setting thestart time
1. Make sure that thedehumidifier is switched off.
2. Press thetimer button (11).
3. Set thedesired start time by pressing or holding down the [−] or [+] button.
The time is changed in 30-minute increments up to the10-hour mark. Thereafter
in 60-minute increments up to the24-hour mark. The display shows theset timer
time for 5 seconds before reverting to whatever is was displaying previously.
• The timer button (11) can be pressed at any time to check thesettings.
• The timer settings can be changed at any time by pressing thetimer button (11)
and then the [−] or [+] button.
• If thedehumidifier is switched off after thetimer settings have been made,
thesettings will be deleted.
• If thewater tank becomes full (P2 appears on thedisplay) while thedehumidifier is
operating and before theset timer time has been reached, thetimer setting will be
deleted.
Automatic shut-off
• When thewater tank becomes full during use, thedehumidifier compressor shuts
off automatically.
• The fan will continue for 30 seconds to dry theinside of thedehumidifier.
• The dehumidifier will beep 8 times, the ‘Full’ indicator will flash and ‘P2’ will appear
on thedisplay.

17
English
Emptying thewater tank
1. Unplug themains lead from thewall socket.
2. Grip thewater tank by thehandles (one
on each side) and pull it forwards.
3. Empty thewater out of thewater tank
and then refit it into thedehumidifier. The
dehumidifier will restart automatically
once thewater tank has been refitted if it
was shut off automatically.
Automatic defrost function
• The dehumidifier is equipped with anautomatic defrost feature. Frost can build up
on some components inside thedehumidifier under certain conditions. The defrost
function removes this frost.
• The dehumidifier compressor will shut off when thedefrost function is activated and
thefan continues to run until thefrost has disappeared.
• A purling sound might be heard from thedehumidifier during defrosting, this is normal.
• No settings can or need to be made for thedefrost function.
Mesh filter
Remove thegrille and mesh
filter (7) and vacuum clean it
carefully every 14th day.
Operation using adrain hose, Cont (continuous operation mode)
When thedehumidifier is used in anenvironment with high humidity, thewater tank
will need emptying often. In such circumstances, it could be more practical to connect
adrain hose.
1. Remove therubber plug from thehose connector (8)
and connect adrain hose with a13.5mm bore (sold
separately). Make sure that thedrain hose is secure
and seal theconnection to prevent leakage.
2. The other end of thedrain hose should be inserted
into adrain which is lower than thedrain hose
connection on thedehumidifier.

18
English
3. Position thehose in such away that thewater can drain freely. Avoid kinking and
pinching thehose.
4. To remove thedrain hose, switch thedehumidifier off, unplug it and disconnect
thedrain hose.
Care and maintenance
• Before thedehumidifier is cleaned or serviced it must be switched off and
unplugged.
• Do not wash thewater tank in adishwasher.
• Clean theexterior of thedehumidifier using alightly moistened cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.
• Vacuum clean theair inlet and outlet grilles of thedehumidifier.
• Remove thewater tank (refer to theEmptying thewater tank section above) every
14th day and wash it by hand using amild detergent. Rinse it with clean water.
• Clean themesh filter every 14th day, refer to theMesh filter section.
• If thedehumidifier is not to be used for anextended period:
- Switch thedehumidifier off and disconnect it from thepower supply.
- Clean thehousing of thedehumidifier.
- Wait 24 hours before emptying thewater tank to ensure that all thewater in
thedehumidifier has had time to collect in it.
- Remove thewater tank, empty it, dry it and then refit it.
- Remove themesh filter, clean it and refit it.
- Store thedehumidifier upright in adry, well-ventilated place.
Troubleshooting guide
The dehumidifier
will not switch on.
• Make sure that themains lead is properly plugged in and
that there is power in thewall socket.
• The water tank is full or incorrectly fitted.
• The set humidity level has been reached.
The humidity is
not reducing.
• The dehumidifier has not been running long enough.
• Make sure that nothing is preventing theair in theroom
where thedehumidifier is used from circulating properly.
• The humidity level is not set low enough.
• Make sure that no outdoor air can enter theroom in which
thedehumidifier is being used.
• The ambient temperature is below 15°C.
• Is there aheat source in theroom which is raising thehumidity?

19
English
Unusual noises
emitted during use.
• Make sure that themesh filter is clean.
• The dehumidifier is tilted or standing on anuneven surface.
Error and
protection codes
(shown on
thedehumidifier
display)
AS: Defective humidity sensor. Unplug thedehumidifier and
then plug it in again. If this does not solve theproblem, contact
aqualified service centre.
ES: Defective temperature sensor. Unplug thedehumidifier and
then plug it in again. If this does not solve theproblem, contact
aqualified service centre.
P1: Automatic defrosting in progress. Let thedehumidifier
operate until P1 no longer appears on thedisplay.
P2: The water tank is full or incorrectly fitted. Empty or fit it
correctly.
E4: Control panel communication error. Unplug
thedehumidifier and then plug it in again. If this does not solve
theproblem, contact aqualified service centre.
Responsible disposal
This symbol indicates that theproduct should not be disposed of with
general household waste. This applies throughout theentire EU. In order
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner. When
recycling theproduct, take it to your local collection facility or contact
theplace of purchase. They will ensure that theproduct is disposed of in
anenvironmentally sound manner.
Specifications
Rated voltage 220−240 V AC, 50 Hz
Power 440 W
Extraction capacity up to 20 L/day
Water tank capacity 3 L
Noise level 46/43/41 dB(A)
Operating temperature 5−32°C
Refrigerant R290
Dimensions 51×35×24cm
Weight 14 kg

20
Svenska
Luftavfuktare
Art.nr 36-8322 Modell MDDF-20DEN7-QA3
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida bruk.
Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid tekniska
problem eller andra frågor, kontakta vår kundtjänst (se adressuppgifter på baksidan).
Säkerhet
• Produkten får endast anslutas till ettjordat vägguttag (230 V,
50 Hz) utrustat med jordfelsbrytare.
• Produkten får användas av barn från 8 år och av personer
med någon form av funktionsnedsättning, brist på erfarenhet
eller kunskap som skulle kunna äventyra säkerheten, om
de har fått instruktioner om hur den på ettsäkert sätt ska
användas och förstår faror och risker som kan uppkomma.
• Produkten får inte användas av personer (inklusive barn)
med nedsatt fysisk eller mental förmåga. Den får inte heller
användas av personer utan tillräcklig erfarenhet och kunskap
ifall de inte har fått instruktioner om användningen av någon
som ansvarar för deras säkerhet.
• Om nätkabeln skadats får den, för att risk för elektrisk stöt
eller brand ska undvikas, endast bytas av tillverkaren, dess
serviceställe eller av en kvalificerad yrkesman.
• Låt aldrig barn leka med produkten.
• Produkten måste alltid stå iupprätt läge.
• Sitt aldrig, och placera aldrig främmande föremål av något
slag, på produkten.
• Innan produkten tas ibruk för första gången ska den stå
iupprätt läge minst 1 tim innan den används. Detsamma gäller
om produkten kommit ur sin upprätta position genom att den
flyttats, rengjorts etc.
• Använd aldrig produkten om nätkabeln, stickproppen eller
någon annan del är skadad eller inte fungerar normalt.
• Försök aldrig själv ta isär eller reparera produkten.
This manual suits for next models
1
Table of contents
Languages:
Other Clas Ohlson Dehumidifier manuals
