Clas Ohlson SV-2110 User manual

EnglishSvenskaNorskSuomi
Humidier
SE | Lufuktare
NO| Lufukter
FI | Ilmankostun
Art.no. Model
36-8325 SV-2110 Ver. 20230113

2

3
English
Humidifier
Art.no 36-8325 Model SV-2110
Please read theentire instruction manual before using theproduct and then save
it for future reference. We reserve theright for any errors in text or images and any
necessary changes made to technical data. In theevent of technical problems or other
queries, please contact our Customer Services (see address details on theback).
Safety
• The product is intended for indoor use only.
• The product should only be used when it is fully assembled.
• This product is only intended for domestic use and only in
themanner described in this instruction manual. Incorrect usage
could lead to health hazards and potentially lethal consequences.
• Always unplug theproduct from thewall socket when it is not
in use, before emptying it or filling it with water, before cleaning
it, before assembling/disassembling it and before moving it.
• The product must only be plugged into to an220–240 V, 50 Hz
power outlet.
• Never unplug theproduct from thewall socket by pulling themains
lead. Always grip and pull theplug. Never touch themains lead
with wet hands. Doing so will result in therisk of anelectric shock.
• The mains lead should be checked regularly. Never use theproduct
if themains lead or plug is damaged.
• The mains lead must be changed if damaged. This is to prevent
therisk of electric shock or fire and should only be carried out by
themanufacturer, qualified service facility or qualified technician.
• Repairs must only be carried out by qualified service technicians
and only using original spare parts.
• Never let children play with theproduct.
• Never leave unsupervised children together with theproduct.

4
English
• The product may be used by persons with reduced physical,
sensory or mental capabilities or persons with alack of
experience or knowledge which could jeopardise their safety,
provided they have been instructed in thesafe operation of
theproduct and understand thehazards involved.
• Cleaning of theproduct may be carried out by children with
adult supervision.
• Never use theproduct if you are under theinfluence of alcohol,
medication or other drugs.
• The product must not be immersed in water or other liquid.
Doing so could result in anelectric shock. The product must
never be washed in thedishwasher.
• Never use theproduct close to flammable substances, gases
or vapours.
• Foreign objects must not be inserted into theproduct.
• No additives such as fragrances, essential oils or water
conditioners must be added to thewater, they will cause
theproduct to malfunction.
• The high-frequency vibrations generated by theoperation of
theproduct are not harmful and cannot be heard by humans
or animals.
• High levels of humidity can promote thegrowth of biological
organisms in thevicinity.
• Never allow thearea around thehumidifier to get wet or damp.
Lower theoutput of theproduct if you detect moisture. If you
cannot lower theoutput of thehumidifier sufficiently, use it
more sparingly. Never let items made of absorbent material
such as carpets and curtains become damp.
• Always turn thehumidifier off and unplug it from thepower
outlet before removing or filling thewater tank.
• Never leave water standing in thetank when theproduct is not in use.

5
English
• Wipe off theproduct, empty and clean thewater tank before
you put it away for storage. Make sure that theproduct is
completely dry before storing it.
Caution: The water must be changed and thewater
tank cleaned every three days. Failure to do so will
increase therisk of thespread of micro-organisms
through theair outlet resulting in adverse health effects.
• Empty thewater tank and fill it with fresh water every three days.
Clean thetank and remove any impurities such as limescale
before adding fresh water.
Note:
• The water vapour outlet must not be blocked or covered.
Placement
• The humidifier should be placed on afirm, flat raised surface
such as atabletop or counter. Make sure that thechosen
surface and surrounding objects can withstand water vapour.
• Place thehumidifier where there is no risk of people tripping
over its mains lead.
• Recommended operating temperature: 5−40 °C. Protect
thehumidifier against frost.
• The humidifier should not be placed near heat sources or in
direct sunlight.
• The humidifier is designed for indoor use only.
• The humidifier should be placed in awell-ventilated position:
at least 90 cm above thefloor, at least 30 cm away from
thewall and at least 120 cm away from theceiling.

6
English
1
3
2
5
6
7
4
Description
1. Mist outlet
2. Filler cover
3. Water tank
4. Water level indicator
5. Base unit
6. [ ] On/off, LED indicator
7. [ ] Setting therequired level of humidity. Select
ahigh, medium or low level.
Operation
Fill thewater tank
Important:
• Do not fill thewater tank to alevel above the “MAX” mark.
• Never add water directly to thebase unit; only add water to thewater tank.
• Never fill thewater tank with water that is hotter than 40°C.
• Always turn thehumidifier off and unplug it from thewall socket before cleaning
it and before removing or filling thewater tank. Never switch thehumidifier on if
thewater tank is not fitted or is empty.
When thewater tank is empty, theproduct shuts off automatically.

7
English
Note: Remove all transport packaging before using.
1. Lift thefiller cover and water tank straight up.
2. Remove thetransport packaging on thefloat switch (fig 1).
Fill with water
1. Make sure that theproduct is unplugged from thepower socket.
2. You can fill thehumidifier with water in three ways:
Open thefiller cover,
take out thewater tank
and fill it.
Add water through
thefiller cover.
Open thefiller cover and
pour water directly into
thewater tank.
3. Check that thewater tank is in theright position when you
put it back on thebase unit. Replace thefiller cover and plug
thehumidifier back into thepower socket.
For thebest performance and for health reasons, use only
fresh, cold tap water that is free from contaminants. If you are un-
sure of thewater quality, use distilled water. The water temperature
must be between 5 and 40°C.
The mist outlet can be turned through 360º to point in thede-
sired direction.
On/off switch
1. Plug thehumidifier into apower socket. Three beeps will be heard and theLED
indicator will flash red (cleaning reminder).
2. If cleaning is not required, push and hold in [ ] for three seconds to cancel.
3. Press [ ] to switch thehumidifier on. A blue light will come on. The humidifier will
check thewater level. If there is water in thetank, ithe humidifier will start after 1 sec.
4. Press [ ] to switch thehumidifier off.
fig 1

8
English
Select therequired humidity level
Press [ ] repeatedly to select therequired humidity level:
Humidity LED indicator
High Blue
Medium Turquoise
Low White
Automatic shut-off when thewater tank is empty
1. When thewater tank is empty, thehumidifier shuts off automatically.
2. Unplug thehumidifier from thepower socket and fill thewater tank. Never fill
thewater tank with water that is hotter than 40°C.
3. When there is water in thetank, you can switch thehumidifier on again as usual.
Cleaning and care
Warning: Unplug thehumidifier from thepower socket before cleaning.
Cleaning theexterior
Clean theexterior of theproduct using asoft, damp cloth. Use amild detergent. Never
use solvents or abrasive cleaning agents.
Cleaning thewater tank
To prevent thegrowth of bacteria, never leave water in thetank for longer than 3 days
(72 hours). The humidifier has abuilt-in reminder function for cleaning and descaling
every time it is connected to themains power supply and after 72 hours, regardless of
whether it is in operation or not.
When thehumidifier is switched off and theLED indicator (6) flashes red:
1. Unplug thedehumidifier from thepower socket.
2. Rinse out and clean thewater tank
thoroughly. Use asoft brush and water
with adescaling agent if necessary to
clean thebase unit and theother parts of
thehumidifier. Note: Avoid contact with
thenebuliser.
3. Cancel thereminder by holding in [ ] for 3 sec.
Nebuliser

9
English
Storage
• Empty thewater tank completely and wipe away any remaining water from thetop
of thebase unit using soft kitchen towel.
• Store thehumidifier in adry environment at room temperature.
Troubleshooting guide
Problem Cause Possible solution
The humidifier will
not switch on.
Is the dehumidifier properly
plugged into a power socket?
Check that the dehumidifier
is properly plugged in. Is the
power socket live?
Is there water in the tank? Fill the water tank with water.
Is the water tank correctly
positioned?
Take out the tank and
reposition it.
The mist has an
unpleasant odour.
New humidifiers may initially
give off an odour or the water
that is being used may not
be clean.
Clean the water tank and
change the water.
Mist output
is minimal.
Is the humidifier set to a low
setting?
Is the water dirty or the outlet
clogged?
Clean the humidifier and
change the water.
Abnormal noise. Is the humidifier correctly
positioned?
Put the humidifier on a firm,
level surface.
There is water in the
tank, but the low
water indicator is on.
Water has not run down
from the tank.
Wait 1 minute and then
press [ ] to start.
Water is leaking
from the tank.
The packaging on
the float switch has
not been removed.
Pour out the water and
remove the packaging.

10
English
Responsible disposal
This symbol indicates that theproduct should not be disposed of with
general household waste. This applies throughout theentire EU. In order
to prevent any harm to theenvironment or health hazards caused by
incorrect waste disposal, theproduct must be handed in for recycling
so that thematerial can be disposed of in aresponsible manner. When
recycling your product, take it to your local collection facility or contact
theplace of purchase. They will ensure that theproduct is disposed of in
anenvironmentally sound manner.
Specifications
Ultrasonic humidifier
Operating voltage 220–240 V AC, 50 Hz
Power 22 W
Noise level < 38 dB
Operating temperature 5–40 °C
Capacity 4 L
Operating time on full tank 14 hours on continuous operation
Max humidification rate 270 ml/h
Coverage area Effective for rooms up to 25 m²
Net weight 1.2 kg
Size (d x w x h) 190 × 190 × 325 mm
