Clean Logix BLX-100W User manual

USER
MANUAL
English (Original Instrucons)
Updated: 02/11/21
MODEL:
BLX-100W
Single Manual BootScrubber (Wet)

BLX-100W Manual Page 2 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
The BLX-100W is an all manual, single footwear
scrubbing unit. Designed and built as a solid member,
open stainless steel frame with a solid hand rail for
support. The BLX-100W features one removable sole
brush and four removable vercal side brushes, each
of which require no tools. Being a manual based, wet
unit the BLX-100W requires no electrical and is pre-
congured for easy plumbing of water and sanizer.
Overview
▪Frame - 304 Stainless Steel
▪Length - 28 in.
▪Width - 15 in.
▪Height - 44 in.
Specicaons
!
CAUTION:
1. Avoid contact of cleaning agent with skin
and eyes. If contact occurs, see MSDS sheet
for further rst aid measures.
2. Follow safety instrucons of chemical
manufacturer (MSDS).
3. Always follow plant and OSHA guidelines
about the use of hygiene equipment.
4. All personnel using this unit must be
familiar with the informaon contained
in this manual. Follow all installaon and
maintenance instrucons.
5. Always wear appropriate footwear. Secure
or remove loose items on footwear.
6. Ensure solid foong and use both hands
when operang the unit.
▪Cold Portable Water
▪ 35 PSI Minimum Pressure
▪100°F Max Temperature
Water Requirements
NOTE: A back ow preventer must be installed
in the water line for this unit. Check local
codes to ensure proper installaon
!
WARNING:
DO NOT use ammable liquids (i.e. alcohol
based soluons or similar) without diluon.

BLX-100W Manual Page 3 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
GeneralInstallaonOperaonAppendix
Fig. 3.1: Rear mounng brackets
Installing and Mounng the Unit
1. Set unit in desired locaon.
2. Aspects to consider when deciding on placement:
• Clearance for entering and exing.
• Trac ow for unit operaon.
• Emergency exit paths or egress in case of
emergency.
• Head room for personnel while using the
unit.
• Connecons for water.
3. Once the unit is in the desired locaon, use a
level to make sure the unit is stable and level in
all direcons. Make sure the locaon is a at
surface.
4. Using the 4 mounng brackets near each
corner, securely fasten the unit to the oor with
appropriate hardware for the given material (i.e.
concrete anchors and bolts) as shown in [Figures
3.1 and 3.2]
5. Dosing of sanizing chemicals into water supply
can be accomplished via the included venturi
injector.
Installaon
Fig. 3.2: Front mounng brackets
!
WARNING
If not properly secured to oor the unit may p
over and has the potenal to cause personal injury.
NOTE: The unit is compable with most
common sanizers. For further plumbing
recommendaons please contact Clean Logix.

BLX-100W Manual Page 4 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Installing Foot Plate
1. Align the Foot Plate at the opening of the unit.
2. Aach the tabs of the plate to the notches in the
unit as shown in [Figure 4.1]
Installaon (connued)
Fig. 4.1: Inserng and aaching Foot Plate
Plumbing
1. Connect the water regulator on the Venturi to the
water supply line (regulator thread = 1/2")
2. Using 3/8" OD polyethylene tubing (or similar)
connect the sanizer soluon to be used to the
Venturi's hose barb, as shown below:
NOTE: A back ow preventer must be installed
in the water line for this unit. Check local
codes to ensure proper installaon.

BLX-100W Manual Page 5 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
GeneralInstallaonOperaonAppendix
Installaon (connued)
Fig. 5.1:Water line of BLX-100W
Fig. 5.2: Brush clip rotaon for brush removal
Removing Brushes
The brushes are held in place by the brush clip at the
front of the unit.
1. To remove the brushes, pull up on the clip and
twist them outward, as shown in [Figure 5.2].
2. Once unlocked, the brushes can be removed for
cleaning, by slipping them out from their holders.
Plumbing (connued)
3. Using the push to connect ng, connect the
Venturi system to the BLX's water line located
under the unit, near the foot plate [Figure 5.1]
4. Test the system by stepping on the footplate to
engage the unit and begin spraying.
5. Adjust the soluon output as necessary using the
included metering ps (instrucons included).
NOTE: Injector must be mounted within 10 .
of boot scrubber.
!
WARNING:
DO NOT use ammable liquids (i.e. alcohol
based soluons or similar) without diluon.

BLX-100W Manual Page 6 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
General Use
Prior to use - ensure brushes and foot plate are
secured, the system itself properly installed, and that
water is both turned on and owing to the unit's
spray bars. To verify water/sanizer supply; step on
the Foot Plate to iniate water/sanizer ow. Before
operang the unit, ensure solid foong and use both
hands on the handrail for support.
1. To begin operaon, step up onto the Foot Plate
and grip the support handrail.
2. Place one boot in the unit.
3. Push the boot back and forth mulple mes so
every part makes contact with the brushes.
4. Once the rst boot is clean, remove it and repeat
the process with the second boot.
5. If boots are extremely dirty, it may be necessary to
scrub them mulple mes.
Cleaning and Wash-Down
1. Shut o water supply to unit and depressurize
water lines.
1. Remove the Foot Plate and brushes from the unit.
2. Brushes and Foot Plate can be washed,
individually, in a COP tank or wash machine
3. The frame can be washed down by convenonal
means.
Operaon
The following maintenance procedures are
recommended for normal use. Units which see a
high amount of daily use should be inspected more
frequently as necessary.
Weekly:
• Inspect brushes for damage or wear.
• Check for missing or deformed bristles.
• Inspect plumbing/water lines for damage
• Ensure solid mounng to oor.
Monthly:
• Check all fasteners to ensure they are ght.
• Ensure warning labels and decals are present
and in good condion.
• Inspect valve for damage
Quarterly:
• Inspect structure for cracked welds or bent
components.
Maintenance

BLX-100W Manual Page 7 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
GeneralInstallaonOperaonAppendix
Notes:

BLX-100W Manual Page 8 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
Appendix A - Parts Callout
Part No. Descripon
F1036 BOLT HHC 5/16-18 X 3/4 SS
F1151 WASHER 37/64 X 1-1/16 X 1/16 SS
M1388 BRUSH BOX WLDMNT
M1391 HANDLE WLDMNT BLX-100
M1392 BRUSH CLIP
M1393 FIXED SIDE BRUSH
M1394 FOOT PLATE BLX-100
M1396 FRONT PLATE BLX MANUAL
M1399 SPRAY BAR BLX MANUAL
P1047 VENTURI INJECTOR 3/8 SS
P1100 PIPE HEX NIPPLE 3/8 SS
P1102 PIPE NIPPLE 1/4 CLOSE SS
P1103 PIPE TEE 1/4 SS
P1104 PIPE ELBOW 1/4 X 90 SS
P1107 PIPE ELBOW STREET 1/4" SS
P1108 PIPE CAP 1/4" SS
P1196 PIPE COUPLER 1/4"
P1211 QUICK FIT 1/4 NPT X 3/8 TUBE
P1219 QUICK FIT 3/8 NPT X 3/8 TUBE
P1248 LABEL SLIP HAZARD
P1302 PIPE NIPPLE 1/4 X 3 SS
P1338 METERING TIP, LOW FLOW 100-15KU
P1355 VALVE PUSHBUTTON SS
P1358 PIPE BUSHING 1/2 X 3/8 SS
P1398 PRESSURE REGULATOR WATER 1/2" SS
P1599 METERING TIP, CAPILLARY TUBE
Venturi Kit:

BLX-100W Manual Page 9 of 9 Updated: 02/11/21
USER MANUAL: BLX-100W
READ ALL INSTRUCTIONS BEFORE OPERATING EQUIPMENT
GeneralInstallaonOperaonAppendix
Appendix B - Dimensions
