CleanFreak CF-100 Series User manual

CF 100 SERIES
BOTTOM HOUSING
2-2stg VAC MOTORS
100 OR 150 PSI
ITEM No. PARTS LIST QTY DESCRIPTION
1
FS07108 21/2" AXLE (ROD) END CAP
2
WC161094 210X1.75X1/2"NONMARKIWHEEL80CAB
3
FS05081808 1AXLE(ROD)1/2" X 18-1/2''
4
TC13330895 1RHINO BASE - GRANITE
5
TE438134 3COOLING FAN SCREEN
6
FR03604 8AL/ST 6-4 RIVET
7
FW302316 83/16 ALUM. RIVET WASHER AS6R
8
FB023416 21/4-20x1 HEX TAPTITE BOLT-ZINC
9
FW552400 21/4 PLASTIC CUT WASHER
10
FW302424 81/4X1-1/4 ZINC FENDER WASHER
11
FN1020421 81/4X20 KEPS NUT
12
TMC6225 1RHINO EXHAUST
13
FN1021032 510X32 KEPS NUT ZINC
14
TP110480 4RHINO EXHAUST HOLDING BRACKET
15
FB1032116 510-32X1 PH.PAN HEAD ZN
16
FN1141616 13/8 x 16 CENTER LOCK NUT ZN
17
FB022688 13/8-16x5-1/2 HEX BOLT-ZINC
18
TE101230 112-3SJTW-A POW.CORDX25'W/15M.P
19
TE101500 1CORD RETAINER (COMPLETE)
20
TMC6228 1RHINO BASE REINFORCE PLATE
21
FB022416 21/4-20 x 1 HEX BOLT-ZINC
22
FB022412 61/4-20 x 3/4 HEX BOLT-ZINC
23
WC120263 23"X1"NON MARKING SWIVEL CAST.*

CF 100 SERIES
SOLUTION TANK AND RECOVERY TANK PAGE
2-2stg VAC MOTORS
100 OR 150 PSI
ITEM No. PARTS LIST QTY DESCRIPTION
1
TC13320695 1RHINO SOLUTION TANK - GRANITE
2
TMC6131 1RHINO SOLUTION TANK LID
3
TPW20820 1STAND PIPE BASE S/S WASHER 2-1
4
TB231602 11-1/2" X 3/16GASKET(THICK)
5
TB436212 1REDUCING/M ADT1-1/2MPTx1-1/4SO
6
PM2320164 1STAND PIPE 2"O.D.#G (16-1/2")
7
ID67321 11/2 SS BN,SS, 1-9/16 TO 2-1/2
8
PM10142 1BALL FLOAT DUCT ONLY
9
PM10144 1
BALL FLOAT CAGE W/BALL
10 PM10155
1
VACUUM FILTER (BALL-FLOAT) - 4 filters/pack
11
TC13311795 1
RHINO RECOVERY TANK -GRANITE
12
FN1110420 21/4X20 S/S NYLON LOCK NUT
13
FW302300 41/4 S/S U.S.S. CUT WASHER
14
FB021428 21/4-20X1-3/4 HEX BOLT 18-8 S/S
15
TB231715 190DEG.ELBOW 1.5SPIG X 1.5FPT
16
DB10116 1MOBIL LASTIC TAPE 1/16X1FT.
17
FB9010808 6#8-18 x1/2 TRUSS PHIL SCREW S/
18
TMC6010 1RHINO REC. TANK LID COMPLETE
b
TMC6011 1RHINO REC. TANK LID ONLY
19
TB231601 11-1/2" X 1/8 GASKET(THIN)
20
TB231516 11.5"HOSE BARB W/FLANGE BLACK
21
129HB44 190 DEG. HB (HOSE X MPT)1/4X1/4
22
222P44 1ADAPTER 1/4MPTX1/4FPT
23
FW552910 19/16 PLASTIC CUT WASHER
24
TMC6203 1RHINO SWITCH PLATE W/3 CUT OUT
25
FB1032108 710-32X1/2PH.PAN HEAD ZN
26
FW302316 63/16 ALUM. RIVET WASHER AS6R
27
TE202012 3CV/ON-OFF ROCKER SWITCH (TMI)
28
BH2-6020 1BRASS COUPLER 1/4"FPT -FST
29
ID57060 4H.C.1/2 SS BN,PLT,3/8TO7/8
30
TB435010 11" FEMALE ADAPTER x SLIP

31
MS30G322 1O-RING FOR RHINO
32
TB436133 11-1/2" HOSE BARB x 1" MPT
33
THD150016 11.5"x16" DRAIN TUBE
34
FB022424 21/4-20X1-1/2 HEX BOLT-ZINC
35
FW302400 41/4 U.S.S. CUT WASHER ZINC
36
TV151194-27 11-1/2" WIRE BRAID INTRNL VAC H
37
ID57200 11/2 SS BN5/16PLT, 3/4 TO 1-3/4
38
TB261510 11-1/2" 90 DEG.HOSE BARBx1.5FPT
39
FN1020421 21/4X20 KEPS NUT
40
N6MEB4 190DEG.H.B.3/8HOSEX1/4MPT WH.NY
41
TSP10402 11/4FPTx1/4FPT SPIN FITTING
42
215PN4 1CLOSE NIPPLE 1/4
43
TF101050 1FILTER SCREEN S/S 50MESH 1/4FT

CF 100 SERIES
MOTOR PAGE
2-2stg VAC MOTOR
100 OR 150 PSI
ITEM No. PARTS No. QTY DESCRIPTION
1
11660033-A/C 1120V/5.7 2STG 93" W/STRG ADAP
b
11660033-C/C 1120V/5.7 2STG 93" W/1.5" STRA
2
ID57320 31/2 SS BN,PLT, 1-9/16 TO 2-1/2
3
TV200294-18 12" VACUUM HOSE x 18"
4
FB022412 41/4-20X3/4 HEX BOLT-ZINC
5
FW302424 81/4X1-1/4 ZINC FENDER WASHER
6
FN1020421 41/4X20 KEPS NUT
7
TP201211
2MOTOR STRAP HOLDING BRACKET
8
TP400401 4MOTOR CLAMP 5.7-2 STAGE MOTOR
9
TP400405 2VAC STRAP GUARD
10
ID57200 11/2 SS BN5/16PLT, 3/4 TO 1-3/4
11
TV151194 11-1/2" WIRE BRAID INTERNAL VACUUM HOSE GRAY
12
FT010204BLK 4HOSE TIE SOLID 4" BLACK
13
FT010112 12 HOSE TIE BLACK 11" LADDER
14
TH3630899-38 13/8"SOLUTION HOSE x 38"

CF 100 SERIES
PUMP PAGE
2-2stg VAC MOTOR
100 OR 150 PSI
ITEM No. PARTS No. QTY DESCRIPTION
1
ID57060 2H.C.1/2 SS BN,PLT,3/8TO7/8
2
N6MCB6 2HOSE BARB3/8HOSEX3/8MPT WH.NY
3
S80812288 1115V100PSI/VITON/INT80PSIBYPAS
4
FN1020421 21/4X20 KEPS NUT
5
FW302400 31/4 U.S.S. CUT WASHER ZINC
6
FB022424 11/4-20X1-1/2 HEX BOLT-ZINC
