CLEAR DESIGN BHALGSA User manual

BHALGSA
BOOST L-SHAPE
HEIGHT-ADJUSTABLE
WORKSTATION
Includes Add-Ons: A1 | A2 | A3
General Installation Guide

TABLE OF CONTENTS
EDITION CODE
BHALGSA :: Workstation ......................................................1
ADD-ONS
A1 :: Modesty Panel ................................................................7
A2 :: Slim Pedestal................................................................. 11
A3 :: Cable Tray ..................................................................... 15

CODE QTY DESCRIPTION
###### 2Surface
BASB72 2Support Bar
BFB1 2Flat Bracket
PARTS LIST
WORKSTATION
OVERVIEW
BOOST L-Shape Height-Adjustable Workstation
All parts listed are for a single workstation;
additional parts will be needed for additional
workstations.
1

2
WORKSTATION
CODE QTY DESCRIPTION
BHALGSA
1Right & Left-Adjustable Beam
1Inner-Adjustable Beam
1Feet (Set of 2)
223"Arm Bracket
1Center Post Brackets (L, REAR, & R)
1Center Post Base
3Leg with Motor
1Handset
5Glides
3Extension Cords (SHRT, MED, & LG)
1Power Cable
14 Screw (A)
8Screw (B)
2Screw (C)
8Screw (D)
4Screw (E)
39 Screw (F)
2Screw (G)
1Flat Plate

3
WORKSTATION
1 | ASSEMBLE LEG POST SEPARATELY
Attach center leg with motor to the center post brackets using
screws (A). Then, attach side legs with motor and arm brackets to left
and right adjustable beams.
Note: Replace the default arm brackets if workstation requires BHA19
or T-brackets.
Right Center Post Bracket
Right Adjustable Beam Left Adjustable Beam
Left Center Post Bracket
Rear Center Post Bracket

4
WORKSTATION
2 | ATTACH WORKSTATION FRAME
Join all three legs by attaching the inner adjustable beams to the left and
right adjustable beams and center post brackets. Keep locking screws (B)
loose on the inner adjustable beams to accommodate surface size in step 3.
Inner Adjustable Beam

5
WORKSTATION
3 | PLACE FRAME ON SURFACE
Secure flat plate, flat bracket(s), and support bars to the surfaces using
screws (F).
Extend beam to fit table size accordingly. Secure locking screws on the
adjustable beam and attach to surface using screws (F).
Note: If using surface-mounted dividers, keep the frame 1.5 inches inset from
the surface edge. If not using surface-mounted dividers, bring frame flushed
to edge of surface. Use additional flat brackets as needed.
Flat Bracket
Support Bar
Flat Plate

6
END OF WORKSTATION SECTION
4 | INSTALL FEET, GLIDERS, AND CONTROL BOX , THEN
SECURE POWER.
Install feet using screws (D) for outside legs. Install center post base to
center leg using screws (E). Mount control box to the adjustable beam using
screw (G). Then, secure power cord to the control box. Mount handset using
wood screws (C) and attach to control box. If workstation is complete, flip
over. Reference handset guide for initialization and operation functions.
Center Post Base
Control Box

A2: MODESTY PANEL
OVERVIEW
BOOST L-Shape Height-Adjustable Workstation
All parts listed are for a single modesty panel;
additional parts will be needed for additional
modesty panels.
7

8
MODESTY PANEL
CODE QTY DESCRIPTION
GLMP##
1Laminate Modesty Panel*
4Machine Screws
BMPBFB
2L- B r a c k et s
4Wood Screws*
PARTS LIST
*NOTE: For Steel Modesty Panel: components may vary, but process is
similar.

9
MODESTY PANEL
1 | SECURE BRACKETS TO MODESTY PANEL
Connect the BMPBFB bracket to the modesty panel using screws.
Secure tightly.
NOTE: If modesty panel does not have pre-drilled holes, use wood screws
instead of machine screws.

10
END OF MODESTY PANEL SECTION
2 | ATTACH MODESTY PANEL TO SURFACE
Attach modesty panel to surface using wood screws provided with brackets.
Panel will be center aligned and flushed with back of surface.

A3: SLIM PEDESTAL
OVERVIEW
BOOST L-Shape Height-Adjustable Workstation
All parts listed are for a single slim pedestal;
additional parts will be needed for additional slim
pedestals.
11

12
SLIM PEDESTAL
CODE QTY DESCRIPTION
BFSLM.SM
1Large Mounting Bracket
1Small Mounting Bracket
BFSLM 1Slim Pedestal
BFSLM.HW
8Machine Screw
10 Wood Screw
PARTS LIST

13
SLIM PEDESTAL
1 | SECURE BRACKETS TO SLIM PEDESTAL
Align large mounting bracket to front of pedestal and align small mounting
bracket to back. Secure both brackets using provided screws.

14
END OF SLIM PEDESTAL SECTION
2 | ATTACH SLIM PEDESTAL TO SURFACE
Secure pedestal to surface using wood screws. The pedestal brackets will
connect on either side of the center beam.

15
A4: CABLE TRAY
OVERVIEW
BOOST L-Shape Height-Adjustable Workstation
All parts listed are for a single cable tray;
additional parts will be needed for additional
cable trays.

16
CABLE TRAY
CODE QTY DESCRIPTION
BHCT
1Surface-Mount Cable
Management Tray
10 Wood Screws
PARTS LIST

17
CABLE TRAY
1 | EXTEND CABLE TRAY TO DESIRED LENGTH
Extension range: 25"–45".
