cleer STAGE User manual

STAGE
QUICK START GUIDE

STAGE QUICK START GUIDE
Top
Front
Front light lndicator
NFC sensor
Voice assistant
Long press:
2
1

STAGE QUICK START GUIDE
Rear
3
Connections
Aux In
Open the cover to plug in 3.5mm
audio jack for line in or micro USB
charging cable for charging.
Power
4
1s
> 3s
ON
ON

STAGE QUICK START GUIDE
Download Cleer Connect app.
Amazon Alexa
5
Bluetooth pairing
2
1
Power ON the speaker.
Turn ON NFC on your
device and place it near
the NFC sensor on the
speaker.
Pair
Cleer
STAGE
or
1s

STAGE QUICK START GUIDE
Maximize your listening experience
with Cleer Connect app.
Login to Amazon Alexa to access voice assistant
services.
Due to recent security changes made by Apple, iOS
customers accessing Alexa Voice services via Bluetooth
speakers has been modified. If you’d like to still use this
feature, the Cleer Connect app has to run in the
foreground (app seen on mobile device screen). When
multi-tasking, the Cleer Connect app will not communi-
cate with Alexa Voice services making this feature not
available. There is no impact to Android customers.
*

STAGE QUICK START GUIDE
You can pair an additionnal Cleer STAGE speaker by
longpressing Bluetooth button.
Phone call
Cleer Connect
6
7
Speaker A Speaker B
Press Play to pick up / hang up
a phone call.
Then talk to the
mic.
>3s >3s

STAGE QUICK START GUIDE
LED behavior
8
Blinking Steady
NA
Power On
Speaker
connected
NA
NA
NA
Bluetooth
pairing
NA
Front light indicator
Charging mode
Charging
0-20%
Charging
20-100%
Charging complete
Cleer Connect mode
Master speaker
Slave speaker
Searching speaker

STAGE QUICK START GUIDE
For Amazon Alexa
State
Listening and active listening
Thinking
Speaking
Notification queued
Notification arrives
System error
LED
behaviors
Master speaker
Master speaker
Slave speaker
Slave speaker
Speakers connected
Phone call

STAGE QUICK START GUIDE
Warnings
Do not push the
speaker passive
radiator during
audio playback.
9
Specifications
• Driver size: 2PCS 48mm x 48mm dynamic driver
• Frequency response: 20HZ-20KHZ
• Connections: Micro USB cable for charging
• Support: BT 4.2, A2DP v1.3, AVRCP v1.7 , HFP
v1.7, HSP v1.2.
• Bluetooth transmitter frequency range: 2.402-
2.480GHz
• Bluetooth transmitter power: <4dBm
• Bluetoorh transmitter modulation: GFSK, π/4
DQPSK, 8DPSK
• Battery type: rechargeable lithium ion
cylindrical cell (3.7V, 2600mAh)
10

STAGE QUICK START GUIDE
Cleer Limited Warranty
(United States Only)
Cleer Limited warrants this product against defects in
material or workmanship for (1) year as set forth below
when purchased directly from Cleer Limited or a Cleer
Limited retailer. Pursuant to this Limited Warranty, Cleer
Limited will, at its option, (i) repair the product using new
or refurbished parts or (ii) replace the product with a
new or refurbished product. For purposes of this Limited
Warranty, “refurbished” means a product or part that has
been returned to its original specifications. In the event
of a defect, these are your exclusive remedies.
Labor: For a period of (1) year from the original date
of purchase of the product (“Labor Warranty”), Cleer
Limited will, at its option, repair or replace with new
or refurbished product, product determined to be
defective. If Cleer Limited elects to replace the product
after this Labor Warranty has expired but while the parts
labor charge.
Parts: For a period of (1) year from the original date of
purchase of the product (“Parts Warranty”), Cleer Limited
will supply new or refurbished replacement parts in
exchange for parts determined to be defective.
This Limited Warranty covers only the hardware
components packaged with the Product. It does not
cover technical assistance for hardware or software
usage and it does not cover any software products
whether or not contained in the Product; any such
software is provided “AS IS” unless expressly provided
for in any enclosed software Limited Warranty. Please
refer to the End User License Agreements included with
the Product for your rights and obligations with respect
to the software.
Instructions: To obtain warranty service, you must
deliver the Product, freight prepaid, in either its original

STAGE QUICK START GUIDE
protection to the original Cleer Limited retailer (point of
purchase) or Cleer Limited Customer Service. It is your
responsibility to backup any data, software or other
materials you may have stored or preserved on your
unit. It is unlikely that such data, software or other
materials will be lost or reformatted during service
and Cleer Limited will not be responsible for any
such damage or loss. A dated purchase receipt from
Cleer Limited or a Cleer Limited retailer is required. For
specific instructions on how to obtain warranty service
for your product,
Visit the Cleer Limited website: www.cleeraudio.com
Or call Cleer Limited Customer Service at:
1 888 672 5337 (67 CLEER)
For an accessory or part not available from your
authorized dealer call: 1 888 672 5337 (67 CLEER)
Following warranty service your original Product or a
replacement Product will be returned to you as your
Product was configured when originally purchased.
Repair / Replacement Warranty: This Limited
Warranty shall apply to any repair, replacement part or
replacement product for the remainder of the original
Limited Warranty period or for (90) days, whichever is
longer. Any parts or product replaced under this Limited
Warranty will become property of Cleer Limited
This Limited Warranty shall not apply to: (a) consumable
parts, such as batteries that are designed to diminish
over time, unless failure has occurred due to a defect
in materials or workmanship; (b) cosmetic damage,
including but not limited to scratches, dents and broken
plastic on ports; (c) defects caused by normal wear
and tear or otherwise due to the normal aging of the
device; (d) damage caused by accident, negligence,
abuse, misuse, fire, earthquakes, acts of God or damage
resulting from liquid outside of the approved levels; (e)
damage caused by operating the device outside Cleer
Limited published guidelines; (f) damage caused by

STAGE QUICK START GUIDE
service performed by anyone who is not a representative
of Cleer Limited or a Cleer Limited authorized service
provider; (g) Products whose seals are tampered; (h)
Products whose serial numbers have been removed or
defaced from such Product; (i) modifications, alterations
or repairs to the Product made by a party other than
Cleer Limited or a party authorized by Cleer Limited; (j)
any failure by End User or a third party to comply with
environmental and storage requirements for the Product
specified by Cleer Limited, including, without limitation,
temperature or humidity ranges; or (k) use of the Product
in combination with any third-party devices or products
that have not been provided or recommended by Cleer
Limited. This Limited Warranty is valid only in the United
States.
LIMITATION ON DAMAGES: CLEER LIMITED
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT.
DURATION OF IMPLIED WARRANTIES: EXCEPT
TO THE EXTENT PROHIBITED BY APPLICABLE LAW,
ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED TO THE DURATION OF THIS
WARRANTY.
DISCLAIMER: THE LIMITED WARRANTY SET FORTH
HEREIN IS EXCLUSIVE AND IN LIEU OF ALL OTHER
WARRANTIES OR CONDITIONS RELATING TO
THE PRODUCT, WHETHER EXPRESS OR IMPLIED,
AND CLEER LIMITED EXPRESSLY DISCLAIMS ALL
OTHER WARRANTIES AND CONDITIONS WHETHER
EXPRESS, IMPLIED OR STATUTORY, INCLUDING
ANY IMPLIED WARRANTIES OF MERCHANTABILITY,
NON-INFRINGEMENT, FITNESS FOR A PARTICULAR
PURPOSE, AND ANY WARRANTIES ARISING OUT
OF COURSE OF DEALING OR USAGE OF TRADE
AND AGAINST HIDDEN DEFECTS, TO THE FULLEST
EXTENT PERMITTED BY LAW. CLEER LIMITED DOES
NOT WARRANT THAT THE PRODUCT WILL MEET
CUSTOMER’S REQUIREMENTS OR THAT USE OF

STAGE QUICK START GUIDE
THE PRODUCT WILL BE UNINTERRUPTED OR ERROR
FREE. NO ADVICE OR INFORMATION, WHETHER
ORAL OR WRITTEN, OBTAINED FROM CLEER LIMITED
OR ELSEWHERE WILL CREATE ANY WARRANTY NOT
EXPRESSLY STATED IN THIS WARRANTY.
Some states do not allow the exclusion or limitation of
incidental or consequential damages, or allow limitation
on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you. This
Limited Warranty gives you specific legal rights and you
may have other rights which vary from state to state.
NOTICE
Compliance with FCC rules
1. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference
received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate
radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment

STAGE QUICK START GUIDE
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment andreceiver.
• Connect the equipment into an outlet on a
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure
requirement. The device can be used in portable
exposure condition without RF restriction.
©2020 Cleer Limited. All rights reserved
The Bluetooth® word mark and logos are registered trademarks
owned by Bluetooth SIG, Inc. and any use of such marks by Cleer
Limited, Incorporated is under license. Other trademarks and
trade names are those of their respective owners. Made in China
03
Register your product and get support
at www.cleeraudio.com
