This Quick Installation Guide is a basic introduction of the NPM hardware and software configuration. It is
provided with the hope of helping you to configure the device fast and easily. For more detailed information,
please refer to the User Manual.
Ⅰ. Hardware Configuration
1. Checking the devices and accessories first, one set of NPM and one piece of network cable.
2. Set up the NPM as Master. See the top right corner of the LCD display, ‘M” means Master, “S” means
Slave.
Master Setting Method: Press Reset button on the device for 5 seconds (the interval of RUN light is 2 seconds.
Setting is successful when “M” appears on the LCD.
Slave Setting Method: Press Reset button on the device for 3 seconds (the interval of RUN light is 2 seconds.
Setting is successful when “S” appears on the LCD.
1. M/S：Master or Slave status
2. RUN：Operating state indicator
3. RESET：to set the device as Master or Save, reset button.
4. NET: 10-100Mbps Ethernet RJ45 Connector, to connect to
RJ45 port of PC, HUB, router, switch etc.
1
4 2
3
3. Device connection:
a. Single device connection: Single device must be set as the Master. Connect the NET port of device to PC
by network cable.
b. Multiple device connection: Multiple devices can take the daisy-chain style by setting one of them as the
Master and others as slaves. One Master can daisy-chain nine slaves at most. Please see the specific
connecting ways as illustrated in figure 1 and figure 2:

NPMQuickInstallationGuide
Figure 1 Hand by hand
Figure 2 Through CLEVER HUB
Ⅱ. Software Configuration & User login
Opening IE browser (support IE 6.0, 7.0 and 8.0 versions; other browsers except IE are not available
currently). Default IP address is 192.168.1.163 and default Login Name is "clever", Password is "clever" .
Please note that the login name and password are all Lower-case letter. Please see details as following:
1. Connect the PC and the device directly;
2. Revise the PC network configuration to access NPM firstly; making sure the changed PC IP address and
the default device IP address are in the same network segment. For instance: set the PC IP address to be
192.168.1.X (X can be 0 to 255 except 163); the Sub-net Mask 255.255.255.0; the default gateway
192.168.1.1;As shown in the following :

NPMQuickInstallationGuide
3. Log on to the user administration interface through IP 192.168.1.163 with the default login name and
password: clever / clever
4. Click on and open the "Device Configuration" interface, enter the device address which is a unique one that
could be viewed on the LCD screen of the device panel:

NPMQuickInstallationGuide
NPM address checking method: Press “RESET”and remove hand, the LCD will be lighted, NPM address is
under the IP which is made up of six numbers, letters or number-letter combinations.
5. According to working environment to configure the NPM network: open the menu of "Network" to set the
network address required. Make sure the NPM new IP must be in the same network segment with the original
IP of your PC. Submit and save after confirmation. This configuration will come into force after software
restart.

NPMQuickInstallationGuide
6. Return to the original PC network configuration.
7. Connect NPM and PC to WAN, and access NPM with the new IP configured.
NPM also support SNMP, SSH and Telnet management. Details refer to the User Manual.
