Clevertronics L10 LIFELIGHT PRO LLIFE-PRO-SPOT Installation and operating instructions

1942032
V1.1
3 March 2020
Clevertest and Clevertest Plus
The Clevertronics Clever-test units (LLIFE-PRO-SPOT-CT) can be programmed to perform 90 minute
discharge tests at 6-month intervals. A manual test is initiated by pressing the test switch 3 times within a
5s period (immediate discharge test). A 24 hour delayed test (to allow batteries to fully charge before a
test) can be initiated by pressing the test switch and hold for 10 seconds (i.e., until LED Test Switch
indicator flashes rapidly). Refer Clever-test Operation Guide for more information. Once the test has been
completed, maintenance personnel then view the Status Indicator of each fitting to determine a pass or
failure:
SOLID GREEN (not flashing) NORMAL – The luminaire is in a normal state charging and awaiting
next discharge test.
SLOW YELLOW FLASH
(2s Yellow, 2s Off)
TESTING – The luminaire is currently performing a test.
VERY SLOW YELLOW & GREEN
(4s Yellow, 1s Green)
RECENTLY PASSED – The luminaire has previously tested and
passed. This indication remains for 5 days after the completion of the
test and then changes to SOLID GREEN to indicate a normal state.
FAST YELLOW & GREEN FLASH
(0.5s Yellow, 0.5s Green)
FAILED LAST TEST – The luminaire has previously tested and failed
to remain illuminated for the required duration. This indication will
remain until the required maintenance work has been completed and
the luminaire passes a subsequent discharge test.
Zoneworks and DATA Monitored Options
LLIFE PROs with part numbers LLIFE-PRO-SPOT-ZW, LLIFE-PRO-SPOT-DATA a
re fitted with
Zoneworks communications modules (nodes).These fittings are monitored using either Powerline Carrier
Technology that utilises the power cable to provide data communication or a dedicated data cable to/from
data routers installed on a dedicated data trunk connected to a central Server (can also be connected via
Ethernet/Internet/Fibre). Zoneworks software on the server is used to monitor, coordinate testing and
collate test data from each Lifelight. Zoneworks LLIFEs can be commissioned by a single push of the test
switch, or scanning of the supplied barcode. The LED Test Switch indicator provides a multifunction
indication of the status of the Lifelight during testing and normal operation:
State
LED Operation
Commissioned LED on Solid (Green)
Un-commissioned LED flashes at 0.5Hz (0.5s Green, 0.5s Yellow)
Emergency Light Test In Progress LED flashes at 3s On (Yellow) & 0.5s Off
In the case of the DATA version a 2-way “figure 8” cable and terminal block facilitates the connection to
the DATA network via a multi-drop bus (daisy chain connection). For further information of installation of
a Zoneworks LW system, please refer to the Zoneworks Users Guide and Commissioning Guide (incl.
DATA version)
DALI EM Option
LLIFE PROs with part number LLIFE-PRO-SPOT-DALI are fitted with DALI modules (nodes) that facilitate
connection and integration to 3rd Party Lighting
Control Systems. Before installing the
LLIFE-PRO-SPOT-DALI, please confirm that the Lighting Control System has the capability to monitor
DALI Emergency Luminaires. The LLIFE-PRO-SPOT-DALI will be addressed and configured into the
control system by the Lighting Control System Commissioning Technicians and not Clevertronics.
State
LED Operation
Commissioned/ Un-commissioned LED on Solid (Green)
Emergency Light Test in progress LED flashes at 1s On (Yellow) & 1s Off
“IDENTIFY COMMAND” Fitting goes into emergency mode for 10 seconds
A 2-way “figure 8” cable and terminal block facilitates the connection to the DALI network OR a 5/6way
“structured wiring system” lead and plug facilitating the power and DALI connection. DALI connections
are marked as Da Da.
L10TM LIFELIGHT PRO
Surface Mount Spotlight Emergency
Installation & Maintenance Instruction Leaflet
Models:
LLIFE
-PRO-SPOT, LLIFE-PRO-SPOT-DATA, LLIFE-PRO-SPOT-DALI, LLIFE-PRO-SPOT-ZW,
LLIFE
-PRO-SPOT-CT (Note: also applies to the four hour, -4HR, variants)
240V, 50Hz
Spare Parts:
153
0230 Battery, 3.3 Volt 5000mAh Li-ion (Note: 2 battery packs used on the -4HR versions)
1100869
Lifelight Pro Head Assembly, Ld:280mm,Rnd,LT,Gen 2
L
LIFE-PRO-CKIT Lifelight Pro, Control Only, L10 Lithium
Important
:
It is illegal for anyone, except for a licensed electrician to install or maintain this product. Before
installation, ensure that the electricity supply has
been switched off and isolated. Installation must be
carried out in accordance with the relevant Au
stralian and International Standards.
Designed in Australia to comply with the
requirements of AS2293.3: 2005 and AS/NZS
CISPR15: 2017
NOTE: Standard product codes with this symbol
are enabled with Clevertest Plus capability. Please
refer to the operation guide supplied with the product for
details.
Victoria (Head Office & Manufacturing)
Website:
www.clevertronics.com.au
Email:
[e-mail]
Phone:
[phone]
Fax:
[phone]
New South Wales
Phone:
[phone]
Fax:
[phone]
Queensland
Phone:
[phone]
Fax:
[phone]
South Australia/Northern Territory
Phone:
[phone]
Fax:
[phone]
Western
Australia
Phone:
[phone]
Fax:
[phone]
New Zealand
Phone:
[phone]

1942032
V1.1
3 March 2020
Testing:
When the
LLIFE-PRO-SPOT unit is connected to the un-switched active, it
must be allowed to charge the
battery for at least 24 hour
s. The emergency lamp only illuminates during a power fail. Conduct the
following tests:
•
The emergency lamp must illuminate for at least 2 hours after disconnection from the mains. The
results of all tests are required to be recorded in a service logbook, which is to be kept on-site at all
times. If the unit fails to illuminate for the requisite time, remedial action must be taken to repair the
situation and once completed, the unit must pass a subsequent test.
•
Press and hold Test Button or switch Off Mains Supply, check that the emergency lamp is On.
•
Release the Test Button or Switch On Mains Supply, check that the emergency lamp is Off
(Non-maintained operation).
Below are a list of common problems and their possible causes:
Fault:
The Green LED indicator is not illuminated.
Check:
A.C. is connected and is turned on.
Battery is connected.
Test Switch for damage.
Fault:
Lamp does not illuminate in emergency mode.
Check:
A.C. is connected.
Lamp is correctly inserted.
Battery is connected
Fault:
Lamp illuminates in emergency mode, but only stays on for a short period.
Check:
Battery has been allowed to charge for at least 24 hours.
Battery for damage.
Rated Emergency Lumen Output
in accordance with AS2293.1 (refer to
spacing tables for installation positions)
:
N/A
Caution:
On many building sites, power circuits may be cut off in an uncontrolled and repetitive basis during
construction. As a result, any Lifelight Units, on these circuits, will have their batteries discharged or
“cycled”. The
Li-ion battery in the Lifelight has been selected to give excellent long life performance in a
controlled IEC 60598
-2-22 testing environment. Excessive battery cycling will reduce through-life
performance and may lead to premature battery failure. Battery warranty claims, as a result of su
ch
abuse
, are specifically EXCLUDED from Clevertronics warranty terms.
Warranty:
For Product Warranty information and Terms and Conditions of Sales please refer to our website
http://clevertronics.com.au/terms
-conditions-sale-australia-nz/
Installation:
This
LLIFE-PRO-SPOT Surface Mount Non-maintained Spotlight Emergency Luminaire can be
installed on
any solid surface.
•
Locate the installation position.
•
Refer Images and Dimensions below for the Cut-out Hole and other dimensions.
•
Pre-drill mounting and cable access holes.
•
Route the LED cable from the head through the surface access hole.
•
Mount the LED head using suitable fixings.
•
Connect the LED cable to the control gear pack
•
Ensure the Battery is connected.
•
Apply power to the unit and test per instructions.
Upgrading a
LLIFE-PRO to Clever-test, Zoneworks (incl. DATA) or
DALI EM
All
LP Lifelight PRO Emergency Luminaires (LLIFE-PRO-SPOT) can be upgraded to Clever-test,
Zoneworks, Zoneworks DATA or DALI EM.
When upgrading simply insert the relevant smart node board.
Unlike previous versions of product
DO NOT remove or alter the configuration of jumpers.
T
here is NO need to remove any jumper for the correct operation of the plugin node.
Images and Dimensions:Mounting plate
