Lumascape LS422LED User manual

INSTALLATION INSTRUCTIONS
Lumascape Lighting Industries Pty Ltd
38-44 Enterprise Street, Cleveland, QLD 4163, Australia
PO Box 1875, Cleveland D.C., QLD 4163, Australia
T 07 3286 2299
F07 3286 6599
E[email protected]
Wwww.lumascape.com.au
IN0098 - 28 August 2015
Copyright ©2015 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
120 mm
6 mm
cable strip length
2.5 mm² max per terminal
WARNINGS
Luminaires can become very hot. Use
discretion in placement
Luminaires optical assembly is factory sealed
and opening will void warranty
All connections must be kept dry; failure to
do so may result in product reliability issues
Do not allow soil, mulch or foreign material
to build up around the luminaire
Ensure installation complies with local
regulations
Run cable(s) to luminaire:
Run a power supply cable and if necesary
a CAT5 data cable (required for RGB
& dimming) to the luminaire, ensuring
compliance with local wiring rules.
1.
Punch gland holes:
Depending on your requirements punch
out one or two holes and install gland(s) as
shown in illustration on right.
2.
Water proof cable entry using gland:
Feed the cable through the gland and tighten
as shown in illustration. Repeat this process
if a secod gland is installed. Ensure a correct
sized cable is used or seal will not be IP67.
3. Terminate electrical connection:
Strip and connect the cable cores to the terminal block as shown in the illustration. Ensure correct
polarity is observed for the low voltage (24 V DC) luminaire.
For details on CAT5 data connection (required for RGB and dimming) refer to diagram in back.
4.
Mains Voltage Wiring Low Voltage Wiring
- +
Black
Green
White
Black
Red
Before you begin always check
luminaire label for correct supply
details and lamp type if applicable.
Refer to wiring
diagram and dip
switch settings in
back for details.
COMPONENTS
x4
screw
gland
x2
x1
Allen key
x1
x1
gasket seal
concrete
anchor
Use only a single, circular cable
with a diameter of 6-10 mm in
gland to ensure a watertight seal.
DANGER
ISOLATE LUMINAIRE FROM POWER
Failure to isolate power
supply before installation or
maintenance may result in
fire, serious injury, electric
shock, death and may
damage the luminaire.
SPOTLIGHT & FLOODLIGHT
LS422LED Centria Concrete Anchor
Warranty void if not installed as per installation instructions t 90 ºC N653
MODEL LS422LED
INSTALLATION TYPE Concrete Anchor
IP RATING IP66 / IP67
SUPPLY VOLTAGE 100-240 V AC, 50/60 Hz
24 V DC
INSTRUCTIONS COVER Single Colour
Single Colour Dimming
RGB (Integral Driver)
NO POWER
TOOLS
KEEP AWAY FROM
FLAMMABLE MATERIAL
DO NOT USE SILICONE
ON OUTSIDE SURFACE
KEEP ELECTRONICS FREE
FROM DIRT AND MOISTURE
DO NOT HOSE OR
PREASSURE CLEAN

IN0098 - 28 August 2015
Copyright ©2015 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
WARNING - To reduce the risk of FIRE or INJURY:
1. Luminaires and transformers to be installed by licensed electrical contractors.
2. Luminaires to be used for intended purpose only.
3. Do not operate the luminaires with a missing or damaged parts.
4. Use only genuine Lumascape parts to replace damaged or missing components.
5. Refer to instructions for installation and operating requirements.
6. Ensure installation complies with local regulations
Voltage insulation test (megger) will permanently damage product and will void warranty.
SAVE THESE INSTRUCTIONS.
SAFETY INSTRUCTIONS
Questions?
Call [phone]
Email [email protected]
www.lumascape.com.au
Mount luminaire to concrete anchor:
If required connet the top part of the luminaire
to power source by re-connecting to terminal
block. Screw top of luminaire to concrete
anchor ensuring the gasket seal is firmly in
place between the two components
5. Test luminaire:
Turn on power to test functionality of
luminaire.
6. FINISHED INSTALLATION
5o
10o
105o
365o
215 mm
265 mm
405 mm
Ø 110 mm
5o
10o
105o
365o
215 mm
405 mm
Ø 110 mm
Ø 140 mm
Finished level
Concrete
It is the installers responsibility to ensure
the luminaire is adequately sealed for its
operating environment during installation.
Correct installation Incorrect installation. Void warranty


Do not allow soil, ll or any material to build up
around the luminaire. Warranty will be void.

IN0098 - 28 August 2015
Copyright ©2015 Lumascape Lighting Industries Pty. Ltd. ABN 21 010 572 773
www.lumascape.com.au
Wiring Diagrams & Dip Switch Settings (Applicable to RGB & Single Colour Dimming with 24 V DC only)
Pull out the bracket with the LED driver.
See diagram below for wiring and dip-switch settings.
2.
Use a long screwdriver to unscrew the LED
driver from the luminaire.
1.
RJ45 DMX WIRING
Wire# Wire Colour DMX512 Function
1 white/orange data 1+
2 orange data 1-
3 white/green Not Assigned
4 green Not Assigned
5 blue Not Assigned
6 white/blue Not Assigned
7 white/brown GND
8 brown Not Assigned
Drain
DMX IN
DMX OUT
SWITCH SETTINGS
X100 X10 X1 Function
0 0 0 RDM address
001
DMX address / RDM capable
but no writes (responds to
rotary address)
5 1 0 Last address
9 9 0 0 output no DMX response
9 9 1 Ch1 100%
9 9 2 Ch2 100%
9 9 3 Ch3 100%
9 9 4 Ch1,2,3 0%
9 9 5 Ch1,2,3 100%
9 9 6 Ch1,2 100%
9 9 7 Ch2,3 100%
9 9 8 Ch1,3 100%
9 9 9 rainbow
CH1 CH2
CH3
X100 X10 X1
