Clevo A110EU User manual

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 29. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 57. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 85. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 113. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).

II
Contents
About this Concise User Guide .........................................................1
Instructions for Care and Operation ..................................................2
System Startup ..................................................................................4
System Map: Front View ..................................................................5
Optional Wireless Keyboard & Mouse Kit .......................................8
System Map: Left View ....................................................................9
HDMI-In Port ..................................................................................10
System Map: Right View ................................................................11
Tilting the Screen ............................................................................12
System Map: Rear View .................................................................13
Video Features ................................................................................14
Audio Features ................................................................................15
Power Management Features ..........................................................16
Driver Installation ...........................................................................17
PC Camera (Option) .......................................................................19
Wireless LAN Module (Option) .....................................................21
Intel® Wireless Display Application ..............................................22
Bluetooth Module (Option) .............................................................23
Trusted Platform Module ................................................................24
Troubleshooting ..............................................................................26
Specifications ..................................................................................27
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................29
Hinweise zu Pflege und Betrieb ......................................................30
Schnellstart ......................................................................................32
Systemübersicht: Ansicht von vorne ...............................................33
Optionale Funk-Tastatur/Maus .......................................................36
Systemübersicht: Ansicht von links ................................................37
HDMI-Eingangsanschluss ...............................................................38
Systemübersicht: Ansicht von rechts ..............................................39
Neigen des Bildschirms ...................................................................40
Systemübersicht: Rückansicht .........................................................41
Grafikfunktionen .............................................................................42
Audiofunktionen ..............................................................................43
Energieverwaltungsfunktionen ........................................................44
Installation der Treiber ....................................................................45
PC-Kamera (Option) .......................................................................47
Wireless-LAN-Modul (Option) .......................................................49
Intel® Wireless Display Application ..............................................50
Bluetooth-Modul (Option) ..............................................................51
TPM (Trusted Platform Module) ....................................................52
Fehlerbehebung ...............................................................................54
Technische Daten ............................................................................55

III
Sommaire
A propos de ce Guide Utilisateur Concis ........................................57
Instructions d’entretien et d’utilisation ...........................................58
Guide de démarrage rapide .............................................................60
Carte du système : Vue de face .......................................................61
Kit de clavier et souris USB sans fil optional..................................64
Carte du système : Vue gauche .......................................................65
Port d’entrée HDMI ........................................................................66
Carte du système : Vue droite .........................................................67
Incliner l'écran .................................................................................68
Carte du Système : Vue Arrière ......................................................69
Caractéristiques vidéo .....................................................................70
Caractéristiques audio .....................................................................71
Caractéristiques de gestion de l’alimentation .................................72
Installation du pilote .......................................................................73
Caméra PC (Option) .......................................................................75
Module LAN sans fil (Option) ........................................................77
Application Intel® Wireless Display ..............................................78
Module Bluetooth (Option) .............................................................79
TPM (Trusted Platform Module) ....................................................80
Dépannage .......................................................................................82
Spécifications ..................................................................................83
Contenidos
Acerca de esta Guía del Usuario Concisa .......................................85
Instrucciones para el cuidado y funcionamiento .............................86
Guía rápida para empezar ................................................................88
Mapa del sistema: Vista frontal .......................................................89
Kit de teclado y ratón inalámbrico opcional ...................................92
Mapa del sistema: Vista izquierda ..................................................93
Puerto de entrada HDMI .................................................................94
Mapa del sistema: Vista derecha .....................................................95
Inclinar la pantalla ...........................................................................96
Mapa del sistema: Vista posterior ...................................................97
Parámetros de vídeo ........................................................................98
Características de audio ...................................................................99
Funciones de administración de energía .......................................100
Instalación de controladores ..........................................................101
Cámara PC (Opción) .....................................................................103
Módulo WLAN (Opción) ..............................................................105
Intel® Wireless Display Application ............................................106
Módulo Bluetooth (Opción) ..........................................................107
TPM (Trusted Platform Module) ..................................................108
Solución de problemas ..................................................................110
Especificaciones ............................................................................111

IV
Sommario
Informazioni sulla Guida Rapida per l'Utente ..............................113
Istruzioni per la custodia e il funzionamento ................................114
Guida di avvio rapido ....................................................................116
Descrizione del sistema: Vista anteriore .......................................117
Kit tastiera e mouse senza fili optional .........................................120
Descrizione del sistema: Vista sinistra .........................................121
Porta d'ingresso HDMI .................................................................122
Descrizione del sistema: Vista destra ...........................................123
Inclinazione dello schermo ...........................................................124
Descrizione del sistema: Vista posteriore .....................................125
Funzioni video ..............................................................................126
Funzionalità audio .........................................................................127
Funzioni di risparmio energetico ..................................................128
Installazione driver ........................................................................129
Camera PC (Opzione) ...................................................................131
Modulo LAN Wireless (Opzione) ................................................133
Intel® Wireless Display Application ............................................134
Modulo Bluetooth (Opzione) ........................................................135
TPM (Trusted Platform Module) ..................................................136
Risoluzione dei problemi ..............................................................138
Specifiche tecniche .......................................................................139

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’sManual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information contained in the expanded User’s Man-
ual on the Device Drivers & Utilities + User’s Manual disc.
©August 2012
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Oper-
ation
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
computer could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost if
the battery is depleted.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to general
wear and tear, this adhesive may deteriorate over time and the
exposed logo may develop sharp edges. Be careful when handling
the computer in this case, and avoid touching the raised LCD
electro-plated logo. If any such wear and tear develops contact
your service center.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel but
it still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service
representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible
outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it
by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified service
personnel.
• Keep children away from, and promptly dispose of a damaged
battery. Always dispose of batteries carefully. Batteries may
explode or leak if exposed to fire, or improperly handled or dis-
carded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal
objects.

3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries.
Do not use polymer batteries in high ambient temperature envi-
ronments, and do not store unused batteries for extended periods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners on
any part of the computer.
• Before cleaning the computer remove the battery and make sure
the computer is disconnected from any external power supplies,
peripherals and cables (including telephone lines).
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.

Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end ofits use-
ful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discard used battery according to the
manufacturer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Securely attach any peripherals you want to use with the computer (e.g. keyboard and mouse) to their ports.
4. Attach the AC/DC adapter to the DC-In jack at the rear of the LCD, then plug the AC power cord into an outlet, and connect the AC
power cord to the AC/DC adapter.
5. Push the power button at the front of the computer to turn the computer “on”.
Figure 1 - Computer with AC/DC Adapter Plugged-In/Power Button
System Software
Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-
configuring your computer for a different system, you will find this manual refers to Microsoft Windows 7.

Shut Down
Note that you should always shut your computer down
by choosing Shut Down from the Start Menu.
This will help prevent hard disk or system problems.
Power Button

5
English
System Map: Front View
Figura 2 - Front View
1. Microphone
2. PC Camera (Optional)
3. PC Camera LED
4. LCD
5. Power Button
6. Function Buttons
7. LED Indicators
8. Speakers
4
31
5
2
768
8
5
76

6
English
LED Indicators
The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Table 1 - LED Indicators
Function Buttons
Table 2 - Function Buttons
Icon Color Description
Green The computer is On
Blinking Green The computer is in Sleep Mode
Orange The AC/DC Adapter is Plugged in
& the Computer is Powered Off
Orange The Battery is Charging
Blank The Battery is Fully Charged
Blinking Orange The Battery Has Reached Criti-
cally Low Power Status
Green HDMI Cable Plugged-In (if the
computer is off) - see page 15
Green System Activity
Green The Wireless LAN Module is
Powered On
Orange The Bluetooth Module is Pow-
ered On
Icon Description
Decrease/Increase Buttons - Use the buttons to
decrease/increase the brightness/volume
Menu Toggle - Use this button to switch between
the brightness or audio menus and use the but-
tons above to adjust
Mode Toggle - Use this button to toggle between
the computer and HDMI Input modes

7
English
On Screen Display Indicators
Press the function menu button for about two seconds (see Table 2 on page 6) to bring up the On Screen Display. The
OSD provides visual indicators for brightness, volume, camera power toggle and WLAN/Bluetooth power toggle (the
camera, WLAN and Bluetooth power indicators will only display if the modules are included in your purchase config-
uration) when the Hotkey AP is installed (see Hotkey AP on page 18).
Table 3 - On Screen Display Indicators
The indicators will appear when the computer boots up, or resumes from a power saving state, in order to display the
current power status of the camera and/or Bluetooth module. If you adjust the brightness or volume the OSD indicators
will appear, and will also allow you to adjust the power status of the camera and/or Bluetooth module using the mouse
to click on the icon.
OSD Icon Description
Brightness Decrease/Increase
Volume Decrease/Increase
WLAN Module Power Toggle
Bluetooth Power Toggle
Camera Power Toggle

8
English
Optional Wireless Keyboard & Mouse Kit
There is an optional RF wireless USB keyboard and
mouse kit available for this computer series. A USB port
located at the bottom of the rear cover is designed to house
the transceiver for the USB wireless keyboard & mouse
kit.
Figure 3
Optional
Wireless Key-
board &
Mouse Kit

Dongle & USB Ports
A single USB dongle (which acts as a trans-
ceiver for the keyboard and mouse) is provid-
ed with the keyboard and mouse kit. This
dongle may be inserted into any of the USB
ports. However, it is recommended that you
use the USB port specifically provided for this.

USB Port for Wireless Transceiver
Note that the USB port for the wireless transceiver is
designed specifically for the optional RF keyboard and
mouse kit supplied with this model only.
Do not use any other USB devices in this port.
1
Figure 4 - USB Port for
Wireless Keyboard &
Mouse Kit
1

9
English
System Map: Left View
Figure 5
Left View
1. Stand
2. Multi-in-1 Card Reader
3. ExpressCard Slot /
54(34)
4. 2 * USB 3.0 Port
5. HDMI-In Port
6. HDMI-Out Port
1

USB 3.0 Port
The USB 3.0 ports are col-
ored blue. USB 3.0 will transfer
data much faster than USB 2.0,
and is backwards-compatible
with USB 2.0.
Multi-in-1 Card Reader
The card reader allows you to
use the most popular digital stor-
age card formats:
MMC (MultiMedia Card) /
RSMMC
SD (Secure Digital) / Mini SD /
SDHC / SDXC
MS(MemoryStick)/MSPro/ MS
Duo
4
1
2
3
4
56
4

10
English
HDMI-In Port
This computer features an HDMI(High-Definition Multimedia Interface) inputport that allows you to display external
sources such as Blu-ray players, DVDs, set top boxes and games consoles etc. on your computer screen.
The computer itself does not need to be powered on to display video and audio from external sources. As long as the
computer is plugged-in to a power source through the AC/DC adapter (the LED indicator will be orange if the com-
puter is plugged-in but powered off),simply plug-in the HDMI cable from theexternal device to the computer’s HDMI-
In port and the computer will act as the display device. If the computer is powered by battery then press the power button
on the computer to turn the computer on to use the HDMI-In port.
Mode Toggle
Press & Hold the mode toggle button to switch between the computer and HDMI input modes. When the “Input
Source HDMI” is displayed you can use any HDMI device plugged in to the computer’s HDMI-In port. A quick press
of the button will toggle the display on/off.
The following table indicates the functions when an HDMI cable is plugged in to the HDMI-In port.
Table 4 - Mode Toggle Functions when HDMI Cable is Plugged-In
Computer Power
Status HDMI Icon Mode Toggle Button
(Press & Hold) Mode Toggle Button (Quick Press)
The computer is powered on
(using the AC/DC adapter/BAT-
TERY)
Indicates battery charge status
only Toggles between computer display and HDMI input Toggles the display on/off
The computer is powered off (but
is plugged in to the AC/DC adapter)
Green (when HDMI cable is
plugged-in and the Mode Toggle
Button has been pressed and held
to select HDMI input)
Toggles between computer
display and HDMI input Toggles the display on/off

11
English
System Map: Right View
3
1
2
Figure 6
Right View
1. Emergency Eject Hole
2. Optical Device Drive Bay
3. Headphone-Out Jack
4. Microphone-In Jack
5. 2 * USB 2.0 Port
6. Stand

Disc Emergency Eject
If you need to manually eject a
disc (e.g. due to an unexpected
power interruption) you may
push the end of a straightened
paper clip into the emergency
eject hole. Do not use a sharp-
ened pencil or similar object
that may break and become
lodged in the hole.
4

Moving the Computer
We strongly recommend using both hands to move the computer.
You can use one hand to grip the computer by the stand, and the
other to hold the top of the LCD screen.
It is recommended that you carry the computer with the LCD facing
your body to avoid scratching the surface against other objects.
However take care not to scratch the LCD with any personal items,
belt fittings or jewelry etc.(one hand gripping the stand and the other
gripping the top of the computer to avoid accidentally dropping it).
5
5
6

12
English
Tilting the Screen
It is possible to tilt the LCD screen in order to get the best
possible viewing angle of the screen without glare etc.
1. Place one hand at the top of the computer , and use the
other to open the stand to an angle of around 15 degrees
from the vertical position (the stand will allow you to adjust to
the appropriate angle if you pull it out and let it spring back).
Figure 7 - Adjust the Stand
2. Apply pressure with one hand at the top (at point ) of the
computer (while holding on to the side with the other hand) to
carefully push the LCD screen down in order to tilt it to the
appropriate viewing angle (up to 50 degrees from the vertical
position).
3. Use one hand at the top of the computer (while holding on to
the side with the other hand) to move the computer back to the
original position.
Figure 8 - Tilting the Screen
1
2
Adjust the stand to
tilt the computer to
15° from the vertical
position.
15°
1
2
3

DVD Operation
Note that although the com-
puter may be tilted up to an
angle of 50 degrees from
the vertical position, the
DVD-ROM drive will only
work (i.e continue to spin
and read DVDs) up until an
angle of around 35 degrees
from the vertical position.
If you have any problems
with the system reading
DVDs, adjust the tillt angle
accordingly.
Apply pressure
from the top of
the screen to ad-
just the stand
outwards (up to
50° from the ver-
tical position).
50°
50°
3

13
English
System Map: Rear View
1
3
2
8
3
4
5

Wall Mounting Information
The computer may be mount-
ed on a wall for display. The
system meets VESA (FDMI)
Standard (100mm * 100mm)
for wall mounting. However if
you intend to wall mount the
system please contact your
service center for information
in order to avoid personal in-
jury, or damage to the com-
puter.
CPU
The CPU is not a user ser-
viceable part. Accessing the
CPU in any way may violate
your warranty.
Overheating
To prevent your computer
from overheating make sure
nothing blocks the vent while
the computer is in use.
Figure 9 - Rear View
1. Rear Component Cover
2. Stand
3. Vent
4. Carrying Handle Area
5. USB Wireless Transceiver
Cover (for Optional RF
Keyboard & Mouse Kit)
6. Security Lock Slot
7. Battery (Optional)
8. 2 * Serial (COM) Ports
9. PS/2 Port (keyboard)
10. PS/2 Port (mouse)
11. DC-In Jack
12. 2 * USB 2.0 Ports
13. RJ-45 LAN Jack
8
7
10
11
6
12 13
9

14
English
Video Features
You can switch display devices, and configure display op-
tions, from the Display control panel in Windows and/or
the Intel Graphics and Media Control Panel as long as
the video dirver is installed.
To access Display control panel:
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click Display (icon) - in the Appearances and
Personalization category.
3. Click Adjust Screen Resolution/Adjust resolution.
OR
4. Alternatively you can right-click the desktop and select Screen
resolution.
5. Use the dropbox to select the screen resolution .
6. Click Advanced settings .
To access the Intel® Graphics and Media Control Pan-
el:
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click Intel(R) Graphics and Media in the icon view.
OR
3. Right-click the desktop and select Graphics Properties from
the menu.
OR
4. Click the icon in the notification area of the taskbar and
select Graphics Properties from the menu.
5. Choose the application mode (Basic, Advanced or Wizard)
and click OK.
1
2
2
1
Figure 10 - Display Control Panel
3
3
Figure 11
Intel Graphics
and Media Con-
trol Panel

15
English
Audio Features
You can configure the audio options on your computer
from the Sound control panel in Windows, or from the
Realtek HD Audio Manager / icon in the notifica-
tion area/control panel (right-click the notification area
icon to bring up an audio menu).
The volume may also be adjusted by means of theSpeaker
icon in the taskbar or the On Screen Display Indicators
(see page 7).
Setup for Audio Recording
To record audio sources on your computer at optimum
quality follow the instructions below:
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click Realtek HD Audio Manager (or right-click the notification
area icon and select Sound Manager).
3. Click Microphone Effects (tab) in Microphone (tab), and then
click to select Noise Suppression (button), or adjust the
Recording Volume level to around 60, to obtain the optimum
recording quality.
4. Click OK to close the Sound control panel.
Audio Setup for HDMI
HDMI supports video and audio signals. In some cases it
will be necessary to go to the Sound control panel and
manually configure the HDMI audio output.
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click Sound (Hardware and Sound).
3. Click Playback (tab).
4. The playback device will be selected.
5. In some cases you may need to select the audio device and
click Set Default (button).
6. Double-click the device to access the control panel tabs.
7. Adjust the HDMI settings from the control panel tabs.
8. Click OK to close the Sound control panel.
Figure 12
RealtekHD
Audio Man-
ager - Re-
cording
Setup
Figure 13
SoundPlayback
Options
