Clevo P170EM User manual

Disassembly
Removing the Battery 2 - 5
2.Disassembly
1. Turn the computer off, and turn it over. 2. Slide the latch in the direction of the arrow (Figure 1a). 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a). 4. The battery may be levered up at point (Figure 1b). 5. Lift the battery out of the compartment (Figure 1c).
a. b.
21
4
3
c.
4
3
12
Figure 1
Battery Removal

Disassembly 2 - 14 Removing the Secondary System Memory (RAM)
2.Disassembly
1. Turn off the computer, and turn it over, remove the battery (page 2 - 5) and the component bay cover. 2. Remove the top cover module (Figure 10a). 3. Remove screws - (Figure 10a). 4. Carefully lift the keyboard up, being careful not to bend the keyboard ribbon cable (Figure 10c).
Figure 10
RAM Module
Removal
• 5 Screws
a. b.
AB
5
21 4
36

Disassembly
Removing the Secondary System Memory (RAM) 2 - 15
2.Disassembly
5. Disconnect the keyboard ribbon cable from the locking collar socket by using a small flat-head screwdriver
to pry the locking collar pins away from the base. (Figure 11e).
6. Remove the keyboard and the memory sockets & will be visible (Figure 11f). 7. Gently pull the two release latches ( ) on the sides of the memory socket(s) in the direction indicated below
(Figure 11g).
8. The RAM module will pop-up, and you can remove it. 9. Pull the latches to release the second module if necessary. 10. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 11. The module’s pin alignment will allow it to only fit one way. Make sure the module is seated as far into the slot as it
will go. DO NOT FORCE the module; it should fit without much pressure.
12. Press the module in and down towards the mainboard until the slot levers click into place to secure the module. 13. Replace the bay cover and screws. 14. Restart the computer to allow the BIOS to register the new memory configuration as it starts up.
f.
e.
6
7
88
g.
9
13
13
Figure 11
RAM Module
Removal (cont’d.)

Disassembly 2 - 16 Removing the Wireless LAN Module
2.Disassembly
1. Turn off the computer, remove the battery (page 2 - 5) and the keyboard (page 2 - 10). 2. The Wireless LAN module will be visible at point under the keyboard (Figure 12a). 3. Carefully disconnect cables - , then remove screw from the module socket (Figure 12b). 4. The Wireless LAN module will pop-up (Figure 12c). 5. Lift the Wireless LAN module (Figure 12d) up and off the computer
Figure 12
Wireless LAN
Module Removal
5
b.
a.
d.
2
35
c.
4
1
• 1 Screw
