Clevo P570WM User manual

I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 39. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 77. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 115. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 153. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).

II
Contents
About this Concise User Guide .........................................................1
System Startup ..................................................................................4
RAID Setup .......................................................................................6
System Map: Front View with LCD Panel Open .............................9
Keyboard & Function Keys ............................................................11
Keyboard LED ................................................................................12
Control Center .................................................................................13
System Map: Front, Left & Right Views ........................................15
System Map: Rear & Bottom Views ..............................................16
Windows 8.1 Control Panel ............................................................17
Windows 8.1 Start Screen & Desktop ............................................17
Apps & Tiles ...................................................................................18
Charms Bar .....................................................................................18
Video Features ................................................................................19
Power Options .................................................................................23
Audio Features ................................................................................24
PC Camera ......................................................................................27
Driver Installation ...........................................................................28
Wireless LAN Module (Option) .....................................................30
Fingerprint Reader ..........................................................................31
Bluetooth Module (Option) .............................................................32
Trusted Platform Module ................................................................33
Troubleshooting ..............................................................................35
Specifications ..................................................................................36
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................39
Schnellstart ......................................................................................42
RAID Setup .....................................................................................44
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ..............................................................................47
Tastatur & Funktionstasten .............................................................49
Tastatur-LED ...................................................................................50
Control Center (Steuerzentrum) ......................................................51
Systemübersicht: Ansicht von vorne, links und rechts ...................53
Systemübersicht: Ansicht von hinten und unten .............................54
Windows 8.1 Systemsteuerung .......................................................55
Windows 8.1 Start-Bildschirm und Desktop ...................................55
Apps und Kacheln ...........................................................................56
Charms-Leiste .................................................................................56
Grafikfunktionen .............................................................................57
Energieoptionen ..............................................................................61
Audiofunktionen ..............................................................................62
PC-Kamera ......................................................................................65
Installation der Treiber ....................................................................66
Wireless-LAN-Modul (Option) .......................................................68
Fingerabdruckleser ..........................................................................69
Bluetooth-Modul (Option) ..............................................................70
TPM (Trusted Platform Module) ....................................................71
Fehlerbehebung ...............................................................................73
Technische Daten ............................................................................74

III
Sommaire
A propos de ce Guide Utilisateur Concis ........................................77
Guide de démarrage rapide .............................................................80
Configuration RAID .......................................................................82
Carte du système: Vue de face avec l’écran LCD ouvert ...............85
Clavier & touches fonction ............................................................87
LED du clavier ................................................................................88
Control Center (Centre de contrôle) ...............................................89
Carte du système: Vues de face, gauche & droite ..........................91
Carte du système: Vues arrière & du dessous .................................92
Panneau de Configuration de Windows 8.1 ....................................93
Écran d'accueil & bureau de Windows 8.1 .....................................93
Applications et Vignettes ................................................................94
Barre des charmes ...........................................................................94
Caractéristiques vidéo .....................................................................95
Options d’alimentation ....................................................................99
Caractéristiques audio ...................................................................100
Caméra PC ....................................................................................103
Installation du pilote .....................................................................104
Module LAN sans fil (Option) ......................................................106
Lecteur d'empreintes digitales .......................................................107
Module Bluetooth (Option) ...........................................................108
TPM (Trusted Platform Module) ..................................................109
Dépannage .....................................................................................111
Spécifications ................................................................................112
Contenidos
Acerca de esta Guía del Usuario Concisa .....................................115
Guía rápida para empezar ..............................................................118
Configuración RAID .....................................................................120
Mapa del sistema: Vista frontal con panel LCD abierto ...............123
Teclado & teclas de función ..........................................................125
LED del teclado .............................................................................126
Control Center (Centro de control) ...............................................127
Mapa del sistema: Vistas frontal, izquierda, y derecha .................129
Mapa del sistema: Vistas posterior e inferior ................................130
Panel de Control de Windows 8.1 .................................................131
Pantalla Inicio y escritorio de Windows 8.1 .................................131
Apps y Mosaicos ...........................................................................132
Barra Charms .................................................................................132
Parámetros de vídeo ......................................................................133
Opciones de energía ......................................................................137
Características de audio .................................................................138
Cámara PC .....................................................................................141
Instalación de controladores ..........................................................142
Módulo LAN Wireless (Opción) ...................................................144
Lector de huellas digitales .............................................................145
Módulo Bluetooth (Opción) ..........................................................146
TPM (Trusted Platform Module) ..................................................147
Solución de problemas ..................................................................149
Especificaciones ............................................................................150

IV
Sommario
Informazioni sulla Guida Rapida per l'Utente ..............................153
Guida di avvio rapido ....................................................................156
Configurazione RAID ...................................................................158
Descrizione del sistema: Vista anteriore con pannello
LCD aperto ....................................................................................161
Tastiera & tasti funzione ...............................................................163
LED della tastiera .........................................................................164
Control Center (Centro di controllo) .............................................165
Descrizione del sistema: Vista anteriore, sinistra e destra ............167
Descrizione del sistema: Vista posteriore e inferiore ..................168
Pannello di controllo di Windows 8.1 ...........................................169
Schermata Start e Desktop di Windows 8.1 ..................................169
App & Titoli ..................................................................................170
Charms Bar ...................................................................................170
Funzioni video ..............................................................................171
Opzioni risparmio energia .............................................................175
Funzionalità audio .........................................................................176
Camera PC ....................................................................................179
Installazione driver ........................................................................180
Modulo LAN Wireless (Opzione) ................................................182
Lettore d’impronte digitali ............................................................183
Modulo Bluetooth (Opzione) ........................................................184
TPM (Trusted Platform Module) ..................................................185
Risoluzione dei problemi ..............................................................187
Specifiche tecniche .......................................................................188

1
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for the
expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s Manual
disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper operation of
the computer (Note: The company reserves the right to revise this publication or to change its contents without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information
contained in the expanded User’s Manual on the Device Drivers & Utilities + Us-
er’s Manual disc.
© November 2013
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.

FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

2
English
Instructions for Care and Opera-
tion
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the
case and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and
power supply away from any kind of heating element. This is an
electrical appliance. If water or any other liquid gets into it, the
computer could be badly damaged.
•Avoid interference. Keep the computer away from high capac-
ity transformers, electric motors, and other strong magnetic
fields. These can hinder proper performance and damage your
data.
•Follow the proper working procedures for the computer.
Shut the computer down properly and don’t forget to save your
work. Remember to periodically save your data as data may be
lost.
• Note that in computer’s featuring a raised LCD electro-plated
logo, the logo is covered by a protective adhesive. Due to gen-
eral wear and tear, this adhesive may deteriorate over time and
the exposed logo may develop sharp edges. Be careful when
handling the computer in this case, and avoid touching the raised
LCD electro-plated logo. Avoid placing any other items in the
carrying bag which may rub against the top of the computer dur-
ing transport. If any such wear and tear develops contact your
service center.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this com-
puter.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel
but it still requires a steady, uninterrupted power supply. If you
are unsure of your local power specifications, consult your ser-
vice representative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature;
do not defeat its purpose. If you do not have access to a compat-
ible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect
it by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Only use batteries designed for this computer. The wrong bat-
tery type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair
or replacement to your service representative or qualified ser-
vice personnel.
• Keep children away from, and promptly dispose of a damaged
battery. Always dispose of batteries carefully. Batteries may
explode or leak if exposed to fire, or improperly handled or dis-
carded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check
with local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal
objects.

3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swell-
ing, however this is part of the battery’s safety mechanism and is
not a cause for concern.
• Use proper handling procedures when using polymer batteries.
Do not use polymer batteries in high ambient temperature envi-
ronments, and do not store unused batteries for extended peri-
ods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners
on any part of the computer.
• Before cleaning the computer remove the battery and make sure
the computer is disconnected from any external power supplies,
peripherals and cables (including telephone lines).
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the
operating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your
computer.

Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end of its use-
ful life, under various state and local laws, it may be illegal
to dispose of this battery into the municipal waste stream.
Check with your local solid waste officials for details in your
area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discard used battery according to the
manufacturer’s instructions.

4
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and tighten the screws.
4. Securely attach any peripherals you want to use with the computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC
power cord to the AC/DC adapter.
6. Use one hand to raise the lid/LCD to a comfortable viewing angle (do not to exceed 135 degrees);
use the other hand (as illustrated in
Figure 1) to support the base of the computer (Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
Figure 1
Opening the Lid/LCD/Com-
puter with AC/DC Adapter
Plugged-In
135o
Shut Down
Note that you should always shut your
computer down by choosing the Shut
down command in Windows (see below).
This will help prevent hard disk or system
problems.
Click Settings in the Charms Bar (use the
Windows Logo Key + Ckey combi-
nation to access the Charms Bar) and
choose Shut down from the Power menu.
Or
Choose Shut down or sign out > Shut
down from the contextmenu (use the Win-
dows Logo Key + Xkey combination
to access the context menu).

5
English
Model Differences
This notebook series includes two different model types
that mainly differ as indicated in the table below.
Table 1 - Model Differences
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 8.1.
HDD RAID Support
Your hard disk(s) can be set up in AHCI mode or RAID
mode (for increased performance or protection). Note that
setting up your hard disk(s) in RAID mode needs to be
done prior to installing the Windows OS.
RAID Setup
See RAID Setup on page 6.
Feature Model A Model B
3D Not Supported Supported
Video Adapters
Supported
See "Specifications" on page 36 for a full
list of video adapters supported by each
model.

6
English
RAID Setup
You may use your hard disks in combination with Striping
(RAID 0), Mirroring (RAID 1), Parity Across Disks
(RAID 5) or Recovery for either fault tolerance or perfor-
mance.
Table 2 - RAID Description
Prepare the following before setting up your serial ATA
hard disks in RAID mode:
1. The Microsoft Windows 8.1 OS disc.
2. A hard disk installed in the Primary HDD bay.
AND
For RAID levels 0/1/Recovery: A second (identical) hard disk
installed in the Primary HDD bay.
For RAID level 5: A third (identical) hard disk installed in the
Secondary HDD bay.
3. The Device Drivers & Utilities + User’s Manual disc.
4. A USB flash drive.
5. An operable computer (to copy files from the Device Drivers &
Utilities + User’s Manual disc to the USB flash drive).
Note: All hard disks in a RAID should be identical (the
same size and brand) in order to prevent unexpected sys-
tem behavior.
RAID Level Description
RAID 0
(at lease two
hard disks
needed)
Identical drives reading and writing data in par-
allel to increase performance. RAID 0 imple-
ments a striped disk array and the data is
broken into blocks and each block is written to
a separate disk drive.
RAID 1
(at lease two
hard disks
needed)
Identical drives in a mirrored configuration used
to protect data. Should a drive that is part of a
mirrored array fail, the mirrored drive (which
contains identical data) will handle all the data.
When a new replacement drive is installed,
data to the new drive is rebuilt from the mir-
rored drive to restore fault tolerance.
RAID 5
(three hard
disks
needed)
Identical drives (at least three drives must be
used) in a parity across disks configuration are
used to protect data and increase perfor-
mance. A RAID 5 array can withstand a single
disk failure without losing access to data.
Recovery
(at lease two
hard disks
needed)
Two Identical drives copying data between a
master and a recovery disk. This provides more
control over how data is copied between the
master and recovery drives, fast volume updates
and the ability to view the data in Windows
Explorer.

7
English
RAID Setup Procedure
Before setting up the system you will need to copy a driver
folder (on the Device Drivers & Utilities + User’s Manual
disc) to a USB flash drive or external USB hard disk.
However you will need to go to an operable computer and
copy the driver folder to a USB Flash drive or external
USB hard disk.
1. Go to the operable computer and insert a USB Flash drive or
external USB hard disk.
2. Insert the Device Drivers & Utilities + User’s Manual disc into
the CD/DVD drive of the operable computer.
3. Copy the f6flpy-x64 folder from the location below (D: denotes
your DVD drive) on the Device Drivers & Utilities + User’s
Manual disc to the USB flash drive or external USB hard disk.
• Windows 8.1 64bit
D:\Options\00_IRST\f6flpy\f6flpy-x64
4. Start-up your notebook computer and press <F2> to enter the
BIOS.
5. Go to the Boot menu, select UEFI Setting and press <Enter>.
6. Set UEFI Boot to “Enabled”.
7. Press <Esc> to exit the menu and go to the Advanced menu.
8. Select SATA Mode, press <Enter> and select “RAID Mode”.
9. Press <F4> and <Yes> to “Save Changes and Reset”.
10. After computer restarts press <F2> to enter the BIOS again.
11. Go to Intel(R) Rapid Storage Technology (in the Advanced
menu) and press <Enter>.
12. Select Create RAID Volume and press <Enter>.
13. You can now setup your RAID volume using any two installed
disks.
14. Go to Name: and press <Enter>.
15. Type a name of your choice for your RAID volume and press
<Enter>.
Figure 2 - Name the RAID Volume (Advanced > Intel(R)
Rapid Storage Technology)
16. Go to RAID Level: and press <Enter>.
17. Choose the RAID Level required (see Table 2 on page 6) and
press <Enter>.
• RAID 0 (Stripe)/RAID 1 (Mirror)/RAID 5 (Parity)
• Recovery
18. Go to any of the disks listed under Select Disks: and select a
disk name and press <Enter>.
19. Move the cursor down (use the arrow keys) onto to X(o select
the disk required) and press <Enter>.

8
English
If you have selected a Recovery level RAID then you
need to select one disk to be Master disk (M) and one
disk to be the Recovery disk (R).
20. You should select two identical disks to form your RAID volume.
21. If you have selected RAID 0 (Stripe) then you can adjust the
“Strip Size” to your requirements.
22. If you have selected Recovery then you can adjust the
Synchronization to “On Request” or “Continuous”.
23. Go to Create Volume and press <Enter>.
24. The RAID volume will then be createdand the RAID information
will be displayed under Intel(R) Rapid Storage Technology (in
the Advanced menu).
25. Press <Esc> to exit the menu.
26. Press <F4> and <Yes> to “Save Changes and Reset”,
however ensure that the two conditions in the bulleted
points below are met before doing so.
• Make sure the Windows 8.1 OS DVD is in the DVD drive and
as the computer starts up it will automatically boot from the
Windows 8.1 OS DVD (you will be prompted to press a key
to boot from the DVD).
• Make sure your USB Flash drive or external USB hard disk is
attached to one of the USB ports on the computer.
27. Press <F7> as the computer starts up to bring up the boot
device menu.
28. Select the DVD drive containing the Windows 8.1 OS DVD and
press <Enter>.
29. Press a key at system startup to begin installing Windows from
your Microsoft Windows 8.1 disc.
30. Click Next > Install Now to continue installing the operating
system as normal (see your Windows documentation if you
need help on installing the Windows OS).
31. A prompt will appear to ask you to Load Driver.
32. Click Browse and browse to the location you copied the files to
on your USB Flash drive or external USB hard disk (X: denotes
your USB Flash drive or external USB hard disk):
• X:\f6flpy-x64
33. Click Next.
34. Follow the on-screen instructions to install the Windows 8.1
operating system.
35. Install the Windows drivers as per Table 8 on page 28. Make
sure you install the Intel Rapid Storage Technology (IRST)
driver (see page 29).
Figure 3
Select
Disks
Figure 4
RAID Informa-
tion(Advanced>
Intel(R) Rapid
Storage Technol-
ogy)

9
English
System Map: Front View with LCD Panel Open
Figure 5
Front View with LCD
Panel Open
1. PC Camera (Optional)
2. Built-In Microphone
3. *PC Camera LED
*When the PC camera
is in use, the LED will
be illuminated in red.
4. LCD
5. LED Status Indicators
6. Touch Sensor Instant
Keys
7. Speakers
8. 3D IR Emitter (Model B
Only)
9. Power Button
10. Keyboard
11. Touchpad & Buttons
12. Fingerprint Reader
13. LCD Panel Color LED
13
2
1
6
8
9
5
3

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission
devices aboard aircraft
is usually prohibited.
Make sure the WLAN &
Bluetooth module(s) are
OFF if you are using the
computer aboard air-
craft by putting the sys-
tem in to Airplane Mode. 10
4
2
77
7
11
7
12
7

10
English
LED Indicators
The LED indicators on the computer display helpful infor-
mation about the current status of the computer.
Table 3 - LED Indicators
Touch Sensor Instant Keys
Press the touch sensor instant keys on the computer to tog-
gle the appropriate function on/off. When a module is in-
stalled the appropriate icon will be highlighted blue.
Table 4 - Touch Sensor Instant Keys
Icon Color Description
Blinking
Blue The Hard Disk/Optical Device is in use
Blue Number Lock (Numeric Keypad) Acti-
vated
Blue Caps Lock Activated
Blue Scroll Lock Activated
Orange The AC/DC Adapter is Plugged In
Blinking
Orange The powered USB 3.0 Port is on (see page 15)
Green The Computer is On
Blinking
Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange The Battery Has Reached Critically Low Power Status
Icon Description
The Bluetooth Module is Installed
The Wireless LAN Module is Installed
PC Camera Module Power Toggle
Volume Control (Press and hold your finger at either end /
of the volume control to adjust the system volume)
Mute Toggle

11
English
Keyboard & Function Keys
The keyboard includes a numeric keypad (on the right side of
the keyboard) for easy numeric data input. Pressing Fn +
NumLk turns on/off the numeric keypad. It also features
function keys to allow you to change operational features in-
stantly. The function keys (F1 - F12 etc.) will act as hot keys
when pressed while the Fn key is held down. In addition to
the basic function key combinations, some visual indicators
are available (in the Windows Desktop application only
and not in the Start screen) when the hot key driver is in-
stalled.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + Play/Pause (in Audio/Video Programs) Fn + F10/ PC Camera Power
Toggle
Fn + 1 Fan Automatic Control/ Full Power Fn + F11/ WLAN Module Power
Toggle
Fn + 5 Audio Toggle - Toggle between Standard and Enhanced
Audio (see page 24)Fn + F12/ Bluetooth Module
Power Toggle
Fn + F1 Touchpad Toggle Fn + NumLk Number Lock Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Fn + ScrLk Scroll Lock Toggle
Fn + F3/ Mute Toggle Caps Lock Caps Lock Toggle
Fn + F4 Sleep Toggle Fn + Power
Button Powered USB Port Power Toggle (see page 15)
Fn + F5/F6 Volume Decrease/
Increase Fn + Esc Control Center Toggle (see page 13)
Fn + F7 Change Display Configuration (see page 26)Fn + Keyboard LED Toggle (see page 12)
Fn + F8/F9 Brightness Decrease/
Increase Table 5 - Function Keys & Visual Indicators
Function Keys
Numeric
Keypad
Fn Key
ScrLk &
NumLk
Windows Logo Key
Figure 6 - Keyboard

12
English
Keyboard LED
Press Fn plus the key to toggle the keyboard LED on/
off. The keyboard LED may be configured using the Fn +
key combination outlined in the table below. In addition
press Fnplus the key to launch the keyboard backlight
application to configure the settings.
Table 6 - Keyboard LEDs
Keyboard Backlight Application
The Keyboard Backlight application can be accessed by
pressing the Fn plus key. Click the Help button in
the application to display the configuration keys.
• Click the Custom button to display the three sections
of the keyboard which may be configured.
• Click a section of the keyboard and the color buttons will
be displayed.
• Click a color swatch to apply the color to the selected sec-
tion when not overidden by any effect applied.
• Click on any of the effect buttons to apply random colors,
wave or flashing effects etc.
Figure 7 - Keyboard Backlight Application
Effect Buttons & Help
Table 7 - LED Effect Buttons
Keyboard LED Function key Combinations
Fn + Launch the
Keyboard
Backlight
Application
Fn + Toggle the
Keyboard LED
On/Off
Fn + *KeyboardLED
Illumination
Decrease
Fn + *KeyboardLED
Illumination
Increase

*Illumination Keys
Note that the keyboard il-
lumination (increase/de-
crease) keys may be
used to configure the key-
board LED in Custom
Mode only.
LED Effect Buttons
Random Color Up/Down Wave
Dancing Effect Breathing (All Colors)
Tempo Beat Cycle (Colors as Selected in
RGB)
Flashing Custom - Display & Configure
Keyboard Sections & Colors
Help Button
Keyboard Sections
Effect Buttons
Color Swatches

13
English
Control Center
When in the Windows Desktop application (not in the Startscreen), press the Fn + Esc key combination, or double-
click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives
quick access to frequently used controls, and enables you to quickly turn modules on/off.
Figure 8 - Control Center
Click on any button to turn any of the modules (e.g. Touchpad, Camera) on/off. Click on Power Conservationto switch
between Performance, Balanced or Energy Star modes. Click on the buttons (or just click and hold the mouse button)
to adjust the slider for Brightness/Volume. Click on Display Switch/Time Zone/ Desktop Background to bring up
the appropriate Windows control panel. Click on the Sleep button to put the computer into Hibernate or Sleep mode.

14
English
Power Status
The Power Status icon will show whether you are cur-
rently powered by the battery, or by the AC/DC adapter
plugged in to a working power outlet. The power status
bar will show the current battery charge state.
Brightness
The Brightness icon will show the current screen bright-
ness level. You can use the slider to adjust the screen
brightness or the Fn + F8/F9 key combinations, or use the
Fn + F2 key combination to turn off the LED backlight
(press any key to turn it on again). Note that screen bright-
ness is also effected by the Power Mode selected.
Volume
The Volume icon will show the current volume level. You
can use the slider to adjust the volume or the Fn + F5/F6
key combinations, or use the Fn + F3 key combination to
mute the volume.
Power Conservation
This system supports Energy Star power management
features that place computers (CPU, hard drive, etc.) into
a low-power sleep mode after a designated period of inac-
tivity. Click either the Performance, Balanced or Ener-
gy Star button.
Sleep
Click the Sleep button to bring up the Hibernate or
Sleep buttons, and click either button to have the
computer enter the appropriate power-saving mode.
Display Switch
Click the Display Switch button to access the menu (or
use the + P key combination) and select the appropri-
ate display mode.
Time Zone
Clicking the Time Zone button will access the Date and
Time Windows control panel.
Desktop Background
Clicking the Desktop Background button will allow you
to change the desktop background picture.
K/B LED
Click to access the keyboard setting control to configure
the keyboard LED.
Touchpad/PC Camera Module
Click either of these buttons to toggle the Touchpad or
camera module’s power status. A crossed out icon will ap-
pear over the top left of the icon when it is off. Note
that the power status of the camera is also effected by the
Power Mode selected.
