Clevo P775TM1 Quick start guide

1. What you get:
3. Tools and Parts you need before you start: (not included in GPU upgrade kit)
2. What you get:
4. Extras: (can be bought separately)
A. RTX20XX MXM3.1 GPU Module (X-bracket &
proper vBIOS Installed)
B. GPU Power Cable | P/N: 6-43-P7750-210-1
Length: 110mm / 4.3in
C. Screws (2pcs) – Silver | P/N: 6-35-B2125-4R2
D. Thermal Pad – 28.12x4.5x3.6mm
Blue Protective Film
E. Thermal Pad – 47x34.5x3.6mm
Over Capacitors – Yellow Protective film
F. Thermal Paste
G. Updated Standard BIOS/EC (via Email) if required
H. P750TM1 Heatsink | P/N: 6-31-P75F3-202
Thermal Pads (attached)
I. Screws (4 pcs) – Black | P/N: 6-35-82125-6RA
Precision Slotted and Phillips
Screwdriver
ESD Strap
ESD Mat
Thermal Paste
RTX20XX CPU+GPU
Heatsink [P750TM1]
WIHA 261/PH1x60
P/N:6-31-P75F3-202
P750TM1 RTX 2080/2070/2060 GPU UPGRADE KIT 5/28/19
P750TM1 RTX 2080/2070/2060 HEATSINK UPGRADE KIT 5/28/19

5. Installation Steps:
Step 6. Place Thermal Pads
(item
D) on iTE chips on
Motherboard
Step 10. Connect the 8-pin
side of the
GPU Power
Cable (item
B) to GPU card
(item A)
Step 8. Place Thermal Pad
(item
E) on the back of the
GPU card (item A)
Step 9. Connect GPU Card
(item A) to the
motherboard
’s MXM3.1
slot
Step 11. Add the Screws
(2pcs)
-Silver (item C) to
mount the GPU card (item
A) to the motherboard
Step 4. Disconnect the
power cable from the GPU
and remove existing GPU (2
screws)
Step 7. Remove the
protective film
s from
thermal pad (item
E)
Step 1. Unlock the Battery
and move the latch to
r
emove the battery
Step 3. Remove the existing
CPU+GPU heatsink
(9 screws
)
Remove
protective
film
Step 14. Add the Screws
(4pcs)
-Black (item I) to
mount the heatsink (item
H
)
to the unit
Step 12. Add thermal paste
to GPU
die
Step 13. Install the new
CPU+GPU heatsink (
item H)
Step 2. Remove Bottom case
of your laptop (5 screws)
Step 5. Cut thermal pad
(item D) in half and remove
the protective films
Remove
protective
film
Step 15. Add the rest of the
screws to mount the
heatsink onto the unit.
Step 16. Reinstall Bottom
case of your laptop (5
screws)
and the battery
