Cloud9 Ergonomics F1-DM User manual

Tool required:
Tool required:
Attach legs to crossbar ends using 8 pcs M6*12 screws.
Piece required：
A Screws
Piece required：
B Screws
A Screws 8pcs
A Screws 4pcs
B Screws 8pcs
4mm hex key
Tool required:
Piece required：
A Screws
4mm hex key
Tool required:
4mm hex key
4mm hex key
Attach foot margins to leg using 8 pcs M6*14
screws and tighten with 4mm hex spanner.
Attach brackets to each crossbar end using
4 pcs M6*12 screws.
Begin by loosening the 8pcs M6*10 screws (included as packaged).
Align the crossbar with pre-drilled holes (if included) and then tighten
the 8pcs screws.

Tool required: Piece required：
C Screws
D Screws
E Screws
Drill / Driver
Part required:
Rubber Cushion
Insert rubber cushions and plastic pads into
crossbar and side brackets.
Plastic Pad
Attach the brackets and the crossbar to the table
top using 6 pcs ST4.8*25 screws. Next, attach the
control box using 2pcs ST4.8*19 screws. Lastly,
attach the keypad to the table top using 2pcs.
Attach cables from each of the two motors to the
control box. Then plug the cable from the keypad
to the control box. You’re finished!

AM6*12 Screw 12
BM6*14 Screw 8
CST3.5*19 Screw 2
DST4.8*19 Screw 2
EST4.8*25 Screw 6
6
Plastic Pad
6Rubber Cushion
1Control Box
1Keypad
14mm Hex Spanner
5Cable Tie
Drill / Driver

Activating & Troubleshooting
**Lock and Unlock
Memory Function
You will need to activate the memory handset once the desk is fully assembled. Side
note: if the frame doesn’t seem to be working properly, rest assured that most issues
can be fixed by performing a simple reset on the frame via the handset:
1. Start by unlocking the handset if it is locked (See Lock/Unlock instructions below**).
2. Perform a reset by pressing and holding the “Up” and “Down” buttons at the same
time.
3. Continue to hold as the frame lowers itself all the way down (if extended ). You will
hear a slight beep sound followed by a brief flash on the display.
4. Press the “Up” button once to engage the motors. Your desk should now be activat
-ed and ready to go.
Press and hold the lock button for 1 second and the handset will lock. Press and hold
the lock button for 3 seconds to unlock.
To preset a specific height, elevate the desk to the desired height. Then press the “Up”
directional arrow and 1 button at the same time for about 2 seconds. “P1” should
appear on the display. Repeat the procedure to preset height elevation for button 2.
Programming Alternative Measurements
Press “1” “2” and “unlock” button together for about 5 seconds. “C-I” should appear on
the display. Then press the “2” button and you should see “I” displayed. You have
successfully programmed the handset from centimeters to inches.
Revert Back to Centimeters
Press“1” “2” and “unlock” button together for about 5 seconds. “C-I” should appear on
the display. Then press the “1” button you and should see “C” displayed. You have
programmed the handset from inches back to centimeters.
