modway EEI-3676-NAT User manual

A
B
K
Bolt M6x60mm x 4
Bolt M6x45mm x 2
Allen Wrench M4 x 2
x1
x2
Hardware:
Component:
Page 1 of 5
Thank you for purchasing the MODWAY DINING CHAIR!
Before you start, here are some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the dining chair, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of children.
Customer Service 609-256-9000 www.modway.com
x1
1
2
x2
Nut M6 x 6
Screw M6x80mm x 2
C
H
EEI-3676-NAT DINING CHAIR
DBolt M6x30mm x 4
Cap M6 x 4
E
FPin x 4
3
4
5
1. Back
2. Seat
3. Arm
4. Leg Frame
5. Brace Rail
x2
Barrel x 4
G

STEP 1:
Insert 2 pieces of Pins (F) to tighten the Arm (3).
Repeat the same steps for other Arm (3).
Page 2 of 5
x4
Hardware & Tool required
x4
Hardware & Tool required
Customer Service 609-256-9000 www.modway.com
3
G
3
EEI-3676-NAT DINING CHAIR
F
4
Screw Driver (Not provided)
G
STEP 2:
Attach Leg Frame (4) to Arm (3) as shown.
Insert 2 pieces of Barrels (G) through Leg Frame (4), then insert the Arm (3) into the Leg Frame (4).
Tighten with Screw Driver (Not provided).
Repeat steps for the other Leg Frame (4) and Arm (3).

Page 3 of 5
STEP 3:
Hardware & Tool required
Customer Service 609-256-9000 www.modway.com
Hardware & Tool required
1
EEI-3676-NAT DINING CHAIR
2
x2
K
H
K
KD
x2
D
x2
E
K
E
Attach Back (1) to Seat (2) as shown.
Then insert 2 pieces of Screws (H) through Seat (2) into Back (1).
Tighten with Allen Wrench (K).
x2
H
x1
K
STEP 4:
Attach Leg Frame (4) with Arm (3) to the Seat (2) and Back (1), as shown.
Insert 1 piece of Nut (C) into the Arm (3), then insert 1 piece of Bolt (B) through the Back (1) into the Arm (3).
Insert 2 pieces of Caps (E) into Seat (2), then insert 2 pieces of Bolts (D) through Leg Frame (4) into Seat (2).
Tighten Bolts and Nuts with Allen Wrench (K).
K
B
C
K
x1
B
x1
C

Page 4 of 5
Hardware & Tool required
Customer Service 609-256-9000 www.modway.com
EEI-3676-NAT DINING CHAIR
KCK
A
KD
K
E
x2
A
x2
K
x2
C
Hardware & Tool required
5
5
K
B
C
K
x2
K
x2
D
x2
E
x1
B
x1
C
STEP 5:
Attach 2 pieces of Brace Rails (5) to Leg Frame (4) as shown.
Insert 2 pieces of Nuts (C) into Brace Rails (5),then insert 2 pieces of Bolts(A) through Leg Frame (4)
into Brace Rails (5).
Tighten with 2 pieces of Allen Wrench (K).
STEP 6:
Attach the other Leg Frame (4) with Arm (3) to the Seat (2), Back (1) and Brace Rails (5) as shown.
Insert 1 piece of Nut (C) into the Arm (3), then insert 1 piece of Bolt (B) through the Back (1) into the Arm (3).
Insert 2 pieces of Caps (E) into Seat (2), then insert 2 pieces of Bolts (D) through Leg Frame (4) into Seat (2).
Tighten Bolts and Nuts with Allen Wrench (K).

EEI-3676-NAT DINING CHAIR
Page 5 of 5
Hardware & Tool required
STEP 8:
Customer Service 609-256-9000 www.modway.com
KC
K
A
STEP 7:
Insert 2 pieces of Nuts (C) into Brace Rails (5), then insert 2 pieces of Bolts(A) through Leg Frame (4)
into Brace Rails (5).
Tighten with 2 pieces of Allen Wrench (K).
x2
K
x2
C
x2
A
Assembly is complete. Your dining chair is ready to be used now!
Carefully position the assembled dining chair to the desired location.

Do not fully tighten the Pin (F).
Page 1 of 2
STEP 1:
Hardware & Tool required
STEP 2:
Customer Service 609-256-9000 www.modway.com
EEI-3676-NAT DINING CHAIR
x2
F
Use Screw Driver to lift the Barrel (G). Then insert Pin (F) into Holes of Barrel (G).
ASSEMBLY INSTRUCTION ATTENTION
FOR STEP 1 AND STEP 2
3mm
G
F
4
3
3
FF

Page 2 of 2Customer Service 609-256-9000 www.modway.com
EEI-3676-NAT DINING CHAIR
STEP 3:
Make sure the curved part of Pin (F) is in the center of Barrel (G) before tightening the nut.
STEP 4:
Customer Service 609-256-9000 www.modway.com
Tighten the nut as shown.
Nut
4
3
3
4
