CLS Revo XL DUO DMX series User manual

www.cls-led.com www.cls-led.com
FloorWall Ceiling 360º 360º 200 cm 3,6 kg 50.000 h8º 12º 30º 61º 80º
12 x 46º 16 x
Luxeon C / TX
IP67
100~240
VAC
Max.
40 Watt
3000K2700K AmberBlue RedGreen
6500K5000K4000K
DRIVER
Included
DRIVER
Internal
RGB-A AWB 2700K-
5000K
1800K-
3000K
1800K-
4000K
DPC DTC
RGB-W
2
CLS REVO XL DUO DMX SERIESCLS REVO XL DUO DMX SERIES
Manual V1.2 - November 2021
Index 2
Safety information 2
Content 2
Technical 3
Specifications 3
Installation 4
Lens replacement 5
Ambiance
Max. 40º
Block access
below the work
area when
maintaining
the unit
Use a source
of AC power
that complies to
local electrical
codes
Disconnect the
power supply
before installing
or maintaining
Don’t install in
a flammable
or explosive
area
Warning!
Some surfaces
can be hot
Do not stare
into the LED
Don’t modify
or install
genuine parts
on this product
Qualified
technician
Make sure all
connectors are
connected
properly
Lens index 5
Programming 6
Wireless DMX 6
Programming table 7
Factory settings 7
List of symbols 8
INDEX
CONTENT
SAFETY INFORMATION
FloorWall Ceiling 360º 360º 200cm 3,6kg 50.000h8º 12º 30º 61º 80º
12x 46º 16 x
LuxeonC / TX
IP67
100~240
VAC
Max.
40Watt
3000K2700K AmberBlue RedGreen
6500K5000K4000K
DRIVER
Included
DRIVER
Internal
RGB-A AWB2700K-
5000K
1800K-
3000K
1800K-
4000K
DPC DTC
RGB-W

www.cls-led.com www.cls-led.com
3 4
210 mm
99 mm 152 mm 175 mm 100 mm
193 mm
270º
193 mm
110 mm
247 mm
99 mm
223 mm
100 mm
REVO XL DUO DMX (Bracket on short side)
REVO XL DUO DMX (Bracket on long side)
Tools M10 T20
SPECIFICATIONS
LED: 16 x High Power LED
Available colours: 2700K, 3000K, 4000K, 5000K, 6500K,
amber, red, green or Royal blue
Colour changing: RGBW, RGBA or AWB
Tunable White: 2700-5000K, 1800-3000K or 1800-4000K
Lenses: 8º, 12º, 30º, 61º, 80 or 12x46º
Power supply: 100 ~ 240 VAC
Power factor: 0,95 (230 VAC)
Power consumption: Max. 40 Watt
Housing: Anodised aluminum
Weight: 3,6 kg
IP value: IP67
Cable length: 2 meters
Ambient temperature: -30º C till +50º C
ACCESSORIES
110415 CLS REVO lens kit superspot 8°, 8 lenses
110425 CLS REVO lens kit spot 12°, 8 lenses
110435 CLS REVO lens kit medium flood 30°, 8 lenses
110445 CLS REVO lens kit wide flood 61°, 8 lenses
110455 CLS REVO lens kit elliptical 12x46°, 8 lenses
871992 CLS mold set, straight 8-26mm
110705 CLS REVO Wall bracket
122200 CLS D-ta DMX/adresser unit
Y110795-G CLS REVO XL snoot grey
Y110795-B CLS REVO XL snoot black
Y110776 CLS Power/DMX combi cable outdoor (per meter)
Y110777 CLS Power/DMX combi cable outdoor 100 meters
Y106016 CLS Magnet pin (4 pcs)
TECHNICAL
1
4
2
3
5
Brown =
Blue =
Red =
White =
L
N
DMX +
DMX -
=
Yellow /
Green
- Max. 12 pieces of REVO XL
DUO DMX in 1 power line!
- Combi cable = 5 x 0,5 mm2.
- Total cable length is max. 100 m.
5 core combi cable
yellow/green
Brown
Blue
Red
White
Position
indicator
INSTALLATION

www.cls-led.com www.cls-led.com
65
PROGRAMMING
All settings can be configured via DMX. Settings can be configured at once or separately. When one or a couple settings needs to be
changed just leave all other setting values zero. This keeps those settings unchanged. Please check the table for more information.
Always use a DMX controller with digital interface. If not available, you can purchase the CLS D-ta DMX addresser unit (#122200).
First make sure to set the DATA on the DMX controller. To program the setting into the LED fixture follow the next steps.
Place magnet
on the left
location mark.
All LEDs will
light up
* If all LEDs ash
10 times, something went wrong. Please try again. If the problem continues to occur, please contact your local sales distributor.
Repeat these
steps for the
right location mark
12
After 2 seconds
all LED’s will ash
3 times
conrming
storage*
3
2021 CLS-LED BV. All rights reserved. Information subject to change without notice, CLS-LED BV and all aliated companies disclaim
liability for injury, damage direct or indirect loss, consequential or economic loss or any other loss occasioned by the use of, inability to
use or reliance on the information contained in this manual. No part of this manual may be reproduced, in any form or by any means,
without permission in writing from CLS-LED BV. Other legal information can be found in our General conditions, found on the back of
your CLS-LED BV invoice, inside the CLS catalogue or on our website www.cls-led.com/General-Terms.pdf
2
4
2 x
1
2
3
4
5
6
2 x
Front plate
Glas
Lens holder
Front plate
Glas
Lens holder
1
3
6x
Secure in
order
T20
T20
Make sure that
the items are clean
and the rubber
sealing is correctly
in place!
LENS REPLACEMENT
LENS INDEX
15
234
Superspot 8º Medium Flood 30ºSpot 12º Flood 61º Extra wide flood 80º
5
Elliptical 12x46º
WIRELESS DMX
See the Manual of WIreless Solutions. The Manual can be found on our CLS website, in the Downloads section. Or use the link below
https://www.cls-led.com/wp-content/uploads/cls-files/W-DMX-manual.pdf
Unlink procedure
When the fixture does not receive a DMX signal (DMX controller off), place the magnet on the bottom of the fixture for 5 seconds.
Slow flash indicates that the fixture is unlinked.

www.cls-led.com www.cls-led.com
7 8
PROGRAMMING TABLE
Multiple connection
Daisychain connectivity
Installation depth
In centimeters
Swivel
Fixture is horizontally rotatable,
indicated in degrees
Swivel
Fixture is vertically rotatable,
indicated in degrees
Installation size
In centimeters
Application area
Indoor or outdoor
Application area
Floor, wall or ceiling
Protection class
One, two or three
Cable length
Maximum cable attached
to the fixture in centimeters
Lifespan
Of the light source in hours
Driver
Inclusive or exclusive
Internal or external
Pressure
Maximum pressure on the
fixture in kg/cm2
Weight
In grams/kilograms
Curve
Minimal bending curve
in centimeters
LED pitch
Pitch between the LEDs
in millimeters
Power supply
In VDC, VAC or milliAmpere
Power consumption
In VA or Watt
IP value
Ingress Protection classifies the
degrees of protection provided against
the intrusion of the product
Cutting length
Indicated by the cutting
marks
LEDs
Kind of LED used in the
fixture
Lenses
Availble lenses,
indicated in degrees
Performance Zoom
Adjustable beam angle
Plug & play
Easy connection using the
SmartConnect system
White colour temperature
In dierent Kelvin values;
Cold white, neutral white, warm
white or extra warm white
Colour
Available colours;
Amber, blue, red or green
Colour changing
RGB, RGB-W, RGB-A,
AWB or Tunable White
DMX input
Fixture works on DMX512
protocol or Wireless DMX
Magno dimming
Accurate dimming from
100 - 1% by using a magnet
Dynamic Control
Dynamic Power Control or
Dynamic Temperature Control
Combined product
Compose your own fixture
Warranty
3 or 5 years warranty on
the product
Energy label
Conformité Européenne
CE marking for free marketability
of industrial goods within the EU
r
h
ø w d
Dimmable
1-10 Volt, Phase, individual,
DMX dimmable or DALI
DRIVER
INCLUDED
DRIVER
EXTERNAL
Retail & Food LED modules
Clothing, furniture, kitchens, jewellery,
shoes, bread, meat, fish and
vegetables & fruit.
Lightsource
Equipped with a CLS, Citizen or a Xicato
LED module
Bluetooth controlled
By Casambi
PWM dimming
Traditional PWM dimming, DMX analog
or DMX Hybrid dim
CLS
DYNAMIC
COLOUR
COB
LIST OF SYMBOLS
