CLS REVO Basic / Modular / Retail
INTRODUCTION
CLS’s brand new REVO product line belongs to a revolutionary flexible new IP67 range of products that can
be used for an enormous amount of applications. The REVO is designed in The Netherlands by a team of
architectural specialists.
Included items
The CLS REVO is shipped in one package containing the following items:
• 1 x CLS REVO
• 1 x manual
Optional accessories
• 110425 CLS REVO lens kit spot 12° 8 pcs of lenses
• 110435 CLS REVO lens kit medium flood 30° 8 pcs of lenses
• 110445 CLS REVO lens kit wide flood 54° 8 pcs of lenses
• 110455 CLS REVO lens kit elliptical 12x46° 8 pcs of lenses
• 110555 CLS REVO LED kit warm white 2700K 8 pcs of LEDs
• 110565 CLS REVO LED kit neutral white 4000K 8 pcs of LEDs
• 110575 CLS REVO LED kit cold white 6000K 8 pcs of LEDs
• 110585 CLS REVO LED kit amber 8 pcs of LEDs
• 110595 CLS REVO LED kit royal blue 8 pcs of LEDs
• 110605 CLS REVO LED kit red 8 pcs of LEDs
• 110615 CLS REVO LED kit green 8 pcs of LEDs
• 871992 CLS mold set, straight 8-26mm
• 110790 CLS REVO Modular/Basic coupling
• 110715 CLS REVO Modular connection cable length 1.5mtr
• 110725 CLS REVO Modular feed-through cable length 20cm
• 110735 CLS REVO Modular feed-through cable length 2mtr
• 110745 CLS REVO Modular feed-through cable length 4mtr
• 110750 CLS REVO Modular feed-through cable length 8mtr
• 110855 CLS REVO Retail 3-phase multi adapter grey XTSA 68
• 110865 CLS REVO Retail 3-phase multi adapter white XTSA 68
• 110875 CLS REVO Retail 3-phase multi adapter black XTSA 68
• 110895 CLS REVO Retail adapter nipple rotatable M10x12mm
• 110925 CLS REVO Retail 3-phase rail 1mtr aluminum XTS 4100
• 110929 CLS REVO Retail 3-phase rail 4mtr aluminum XTS 4100
• 110935 CLS REVO Retail end piece for 3-phase rail grey XTS 41
• 110945 CLS REVO Retail connection box for 3-phase rail grey XTS 11

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com
- 3 - - 4 -
CLS REVO Basic / Modular / Retail
Protection from burns and fire
• Provide a clearance of at least 50mm around the unit.
• Do not install this product near a heat source.
• Do not install this product in a corrosive, flammable or explosive area.
• Do not modify this product, or install other than genuine parts.
• Do not operate this product if the ambient temperature exceeds 40 ºC.
• Do not stare into the LED, this can cause damage to the eyes.
Protection from injury due to falls
• Verify that all covers and mounting hardware are securely fastened.
• Block the access below the work area whenever installing or removing the unit.
Note: It is important to read this manual before you install this product.
SAFETY INFORMATION
Warning! This product is for professional use only, not for domestic use.
Read this manual before powering up or installing the CLS REVO. Follow the instructions
listed below and observe all warnings in this manual.
Protection from electric shock
• Disconnect the power supply from AC power before installing, dismounting or maintaining the unit.
• Make sure all connectors are connected properly.
• Use only a source of AC power that complies with local building and electrical codes and has both
overload and ground-fault protection.
• Refer all service to a qualified technician.
Installation REVO Basic
ATTENTION!
ThE CLS REVO IS AN IP67 OuTdOOR uNIT, buT CAN uNdER NO
CIRCumSTANCES bE uSEd uNdER wATER!
ThE wARRANTy ON ThESE ARmATuRES fOR OuTdOOR uSE, ONLy
APPLIES wITh A CORRECT uSE Of ThE CLS mOLd SET
(ARTICLE NO. 871992).
WARNING
1 2
3 4
1. The CLS Revo can be installed by using the mounting hole. Drill a hole to secure it in the wall, floor,
ceiling, etc. Drill a second hole for the power wire.
2. Adjust the CLS Revo to the preferred position by turning the unit towards or away from the wall.
3. Put the power wire in the earth socket.
4. The CLS Revo is ready to use.

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com
- 5 - - 6 -
CLS REVO Basic / Modular / Retail
Glass
Cover plate
2b
2a
6b
6c
6a
Male Female
7c
7b7a
1 2 3
4 5 6
7 8 9
1. Take the CLS Revo and unscrew the cover plate and lift off the glass. Repeat this step on the next CLS REVO.
2a. unscrew one of the mounting circles.
b. Lift out the lance. Repeat these steps on the next CLS REVO.
3. Slide the REVOs to each other so the grooves come together.
4. Take the lance and slide it from above in the groove.
5. Carefully place the glass and cove plate back on the CLS REVO and tighten the screws crosswise.
6a. Mount the bracket on the CLS REVO.
b. Place the spacer between the left and right mounting bracket arms.
c. Tighten the spacer by screwing the bolts on the ends of the spacer as shown in picture 6.
7a. Place the CLS REVO Modular connection cable on the first male connector.
b. Connect the CLS REVO Modular feed-through from female to the male connector on the next CLS REVO.
c. Tighten the end plug on the female connector to close the circuit.
8. Put the CLS REVO Modular connection cable in the earth socket.
9. The CLS REVO Modular is ready to be used.
Installation REVO Modular

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com
- 7 - - 8 -
CLS REVO Basic / Modular / Retail
10 mm
1 2 3
456
78
10 11
9
4a
4b
4c
7c
7a
7b
1. Take the CLS Revo and cut the cable to its correct length.
2. Strip the powercable and the brown, blue and yellow/green wires.
3. Screw the front off the multi adapter and take the nipple out.
4a. Tread the powercable through the nut and ring.
b. Pass the cable through the mounting hole of the bracket.
c. Shove the nipple over the cable till the mounting hole.
5. Connect the coloured wires to the Live, Neutral and Earth connectors. Wire (EU) Function Marking
Brown Live L
Blue Neutral N
Yellow/green Earth
6. Tighten the nut on the nipple and screw the front back on the multi adapter.
7a. Place the REVO Retail with adapter in the mounted rail.
b. Secure the REVO by sliding the lever sideways. To remove the REVO always put the switch on "off"
and pull the lever back.
c. Select the desired phase (1, 2, 3).
8. Place the connection box on one side of the rail.
9. Connect the end piece on the other side of the rail so the circuit is closed.
10. Put the power wire in the earth socket.
11. The REVO Retail is now ready to use.
Installation REVO Retail

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com
- 9 - - 10 -
CLS REVO Basic / Modular / Retail
MEASUREMENTS
100 mm
13 mm
40 mm
100 mm
130 mm
70 mm
130 mm
100 mm
100 mm
25 mm
ø 10 mm
170 mm
REPLACE LENSES
This section shows how to replace the lenses inside the CLS Revo.
Glass
Cover plate
frame
Lensholder
Glass
Cover plate
frame
Lensholder
4 2
1 2 3
45
1 3
6
1. The CLS REVO.
2. Disassemble the cover plate by loosening the 4 screws.
3. Carefully lift the items out of the CLS REVO unit and take the lens holder.
4. Press the 8 lenses out of the lens holder and replace them with the desired lenses. Make sure all the lenses are
in the same direction as shown in picture 6.
5. Now carefully place the items in the CLS REVO unit in the right order as shown in picture 3.
6. Tighten the screws by order (crosswise) as shown in picture 6 on the cover plate
to keep the REVO waterproof. The CLS REVO is ready to be used with the desired lenses.
Make sure that the rubber sealing is correctly in place!

CLS Manuals
CLS Atmosphere LED-panel
www.cls-led.com
- 11 - - 12 -
CLS REVO Basic / Modular / Retail
TECHNICAL SPECIFICATIONS
LED: 8 x Cree or Luxeon Rebel
Available colours: Warm white 3000K, neutral white 4000K,
cold white 6300K, amber, royal blue and red
Lenses: Spot, medium flood, wide flood and elliptical
Power supply: 110 ~ 265 VAC
Power factor: 0,99 (115VAC), 0,95 (230VAC)
Power consumption: Max. 20 Watt
Housing: Anodised aluminum
Weight: 1,9 kg
IP value: IP67
Cable length: 3 meters
Measurements: 100 x 130 x 170 mm (hxwxd)
Ambient temperature: -30º C till +40º C
Multiple connection
Possiblities on a fixture
Installation depth
In centimeters
Swivel
Fixture is horizontally rotatable,
indicated in degrees
Swivel
Fixture is vertically rotatable,
indicated in degrees
Mounting hole
In centimeters
Application area
Indoor or outdoor
Application area
Floor, wall or ceiling
Protection class
One, two or three
Cable length
Maximum cable attached
on the fixture in centimeters
Lifespan
Of the light source in hours
Driver
Inclusive or exclusive
Pressure
Maximum pressure on
the fixture per kg/cm2
Weight
In gram/kilogram
Curve
Minimal bending curve
in centimeters
LED pitch
Pitch between the
LEDs in millimeters
Cutting length
Indicated by the
cutting marks
DMX channels
DMX channels on
a product
