CSV-5300A MANUAL
Multi Stream Transport (MST) Hub
DisplayPort™ 1.2 Triple Monitor
www.club-3d.com
Full HD
Monitors
3x
from a single DisplayPort™ 1.2 output
Use up to
TRIPLE
MONITOR
TRIPLE
MONITOR
DISPLAY
PORT
1.2
DISPLAY
PORT
1.2
MULTI
STREAM
TRANSPORT
MULTI
STREAM
TRANSPORT
FULL
HD
FULL
HD
3D3D
DPDP
Advanced DisplayPort™ 1.2 to 3x DisplayPort™ Splitter for Triple Monitor setup with Audio
Compliant to DisplayPort™ 1.2a Specification, total HBR2 bandwidth 21.6Gbps
Supports Dual Mode DisplayPort™ (DP++)
Supports up to 3x FHD 1080p, 2x WQXGA 1600p or 1x UHD 2160p Monitors
Supports AMD Eyefinity™ (SLS) and Duplicate/ Extend Desktop mode
Supports 3D Video output
Supports AMD, Nvidia and Intel Graphics solutions
Including Mini DP to DP Adapter for maximum compatibility

CSV-5300A MANUAL
Introduction
www.club-3d.com
Multi Stream Transport (MST) Hub DisplayPort™ 1.2 Triple Monitor
DC 5v input
3x DisplayPort™ 1.2
DisplayPort™ Uplink Cable
Reset
Display devices have always been a key part of the PC experience. PC Gamers want a
more immersive experience and Professionals seek more desktop space to run apps
side by side and increase their productivity. The easiest solution is to add multiple
Monitors to an existing Laptop or Desktop PC. The SenseVision MST Hub DisplayPort™ 1.2
Triple Monitor utilizes Multi Stream Transport, a unique DisplayPort™ 1.2 feature, to
split a single DP 1.2 signal into three DisplayPort™ outputs. This enables Three Full
HD Displays to be driven independently from one DisplayPort™ 1.2 output on the
source device. With multiple Monitors, games become more immersive,
workstations become more useful and you be- come more productive.

Multi Stream Transport (MST) Hub DisplayPort™ 1.2 Triple Monitor CSV-5300A MANUAL
www.club-3d.com
FULL HD FULL HD FULL HD
DC 5v input
Full HD
Monitors
3x
from a single DisplayPort™ 1.2 output
Use up to
Package contents
Application diagram
Features
Before installation, check the items in the package. The package should contain the
following items:
• Multi Stream Transport (MST) Hub DisplayPort™ 1.2 Triple Monitor
• CAC-1110 Mini DisplayPort™ to DisplayPort™ Adapter
• Power Supply 2.5 Watt ( 5V 0.5 Amp )
• Quick install guide
• Compliant with: DisplayPort™ v1.2a DisplayPort™ v1.1a VESA DDM Standard HDCP V2.0,
DisplayID and EDID V1.4 Standard
• Supports main link rates of 5.4Gbps (HBR2), 2.7Gbps (HBR) and (1.62Gbps RBR) from source
• Supports Dual Mode DisplayPort™ (DP++) x 3 which allows the use of DVI or HDMI™ Monitors
via passive Adapters
• Supported output resolutions: up to 3840x2160p @ 60Hz for Single Monitor, up to 2560X1600p
@ 60Hz for Dual Monitors and up to 1920x1080p @ 60 for Three Monitors
• Input pixel data depth 6/8/10/12 bits and supports output pixel format RGB444
• Supports Adaptive Sync technology and AMD Eyefinity
• Including Mini DisplayPort™ to DisplayPort™ adapter for max
compatibility (with Intel NUC, MS Surface Pro & other platforms)
• Works with AMD, Nvidia and Intel Graphics solutions
• Works with Windows 10, 8.1 and 7
• Functionality may vary per GPU and OS
DP++
Multi Stream
Transport Hub
PC
DP++
DP++ DP++ DP++

Multi Stream Transport (MST) Hub DisplayPort™ 1.2 Triple Monitor CSV-5300A MANUAL
www.club-3d.com
The DP Multi-Stream Hub requires the following:
Computer that supports DisplayPort™ 1.2 with multi-stream support*
• Microsoft Windows:
-Windows 7 SP1 (32-bit or 64-bit editions)
-Windows 8 (32-bit or 64-bit editions)
*Use of the DP Multi-Stream Hub with a computer that does not meet this specification is
not supported.
*Use the scan button only when the PC does not recognize the MST Hub
Troubleshooting
Here are the steps to solve possible problems.
Scenario: No video on any downstream monitor connected:
1. Check the LED to make sure the hub has power. Use only the power adapter that was provided
with the hub.
2. Check that each downstream monitor is powered on.
3. Check the DisplayPort cable to be sure it is connected to the computer and hub. Use only the
DisplayPort™ cable that was provided with the hub for the connection to the computer.
4. Check the computer or graphics card user manual to confirm that DisplayPort™ 1.2 and a
multi-stream video signal are supported.
5. Check the Windows Display Control Panel to confirm that the downstream monitors attached
to the hub have been detected and enabled.
Resolutions / Refresh Rate
Recommended system requirements
Quick start guide

Multi Stream Transport (MST) Hub DisplayPort™ 1.2 Triple Monitor
www.club-3d.com
Scenario: No video on some downstream monitors connected:
1. The hub can support up to three monitors at 1920 x 1080 resolution or two monitors at 2560 x
1600 resolution. NOTE: Playing audio over the DisplayPort™ connection will reduce the number of
monitors the hub can support.
2. Check the DisplayPort™ cable to be sure it is connected to the hub and monitor. Use only the
DisplayPort™ cable that was provided with the monitor for the hub connection.
3. If the monitor is a DVI or VGA monitor, check the DisplayPort™ cable to be sure it is connected to
the hub. Check the other end of the cable to make sure the DisplayPort-to-DVI or Display
Port-to-VGA adapter is properly connected to the DisplayPort™ cable and to the monitor.
4. If the monitor is a DVI or VGA monitor and the cable and adapter are properly attached, test the
monitor, cable, and adapter with another computer.
5. Check the computer or graphics card user manual to confirm the number of multi-stream video
signals that are supported and the maximum resolution.
6. Check the Windows Display Control Panel to confirm that the downstream monitors attached to
the hub have all been detected and enabled.
7. Check the monitor with no video to confirm the DisplayPort™ input has been selected.
Scenario: Same image appears on all downstream ports:
1. Check the computer or graphics card user manual to confirm that DisplayPort™ 1.2 and a
multi-stream video signal are supported.
2. Check the Windows Display Control Panel to confirm that all downstream monitors are set for
extended mode.
3. Update the video driver to the latest version available to enable the multi-stream functionality.
Regulatory information
DisplayPort™ Multi-Stream 1-3 Hub complies with the FCC/CE rules
