Introduction
Thank you for purchasing your new KingPin Anchor system. Please read through these operating
instructions so you will know how to install and operate your model properly.
Safety Precautions
The safety precautions for this KingPin Anchor system have been prepared to assist the operator in
the performance of good safety procedures.
Warning!!
Only engage KingPin Anchor pole when stopped. NEVER MOVING. Disengage KingPin Anchor pole
before moving the watercraft. ALWAYS be aware of your surrounding while moving with KingPin
Anchor pole in its mount. Take CAUTION around bridges, low hanging trees, power lines, Etc. Make
sure KingPin Anchor pole is securely stored before trailering boat. Always use the comfort grips
while handing the KingPin Anchor pole. Never step on the KingPin Anchor mount. Take CAUTION
articles of clothing could get snagged on the KingPin Anchor mount. Use caution while docking with
KingPin Anchor mount attached to watercraft. FAILURE TO HEED TO ANY OF THESE INSTRUCTIONS
MAY RESULT IN DAMAGE TO YOUR KINGPIN ANCHOR SYSTEM, WATERCRAFT, AND/OR SERIOUS
PERSONAL INJURY OR DEATH.
Kit Includes
One (1) 3" or 6" Bow Four (4) O-Rings 5/8” Four (4) Screws
*Note: Kit does not include the (2) Rubber Pole Clips shown below.
(Included with the Pole Kit only.)

1.604.940.2010 | [e-mail]
Introduction
Thank you for purchasing your new KingPin Anchor system. Please read
through these operating instructions so you will know how to install and
operate your model properly.
Safety Precautions
The safety precautions for this KingPin Anchor system have been
prepared to assist the operator in the performance of good safety
procedures.
Warning!!
Only engage KingPin Anchor pole when stopped. NEVER MOVING.
Disengage KingPin Anchor pole before moving the watercraft. ALWAYS
be aware of your surrounding while moving with KingPin Anchor pole in
its mount. Take CAUTION around bridges, low hanging trees, power
lines, Etc. Make sure KingPin Anchor pole is securely stored before
trailering boat. Always use the comfort grips while handing the KingPin
Anchor pole. Never step on the KingPin Anchor mount. Take CAUTION
articles of clothing could get snagged on the KingPin Anchor mount. Use
caution while docking with KingPin Anchor mount attached to watercraft.
FAILURE TO HEED TO ANY OF THESE INSTRUCTIONS MAY RESULT
IN DAMAGE TO YOUR KINGPIN ANCHOR SYSTEM, WATERCRAFT,
AND/OR SERIOUS PERSONAL INJURY OR DEATH.
(1) 3 or 6 In Bow (4) O-Rings 5/8” (4) Machine Screws
Kit Includes
*Note: Kit does not include the (2) Rubber Pole Clips shown below.
Installing the KingPin Anchor
Required Tools For Installation
13/64” Drill Bit Phillips Bit
Power Drill Marker
1.) First use the Quick Disconnect Base as a template for marking
hole location.
Watercraft
2.) Drill holes using a 13/64” Drill
3.) Place 5/8” O-Rings in countersink groves on the boat
side of Base Plate.
4.) Align and secure quick disconnect base plate with
machine screws. CAUTION over tightening may cause
screws to strip.
13/64 Holes
5/8” O-Rings
Machine
Screws
Base Plate
5.) Align bow anchor studs over quick disconnect plate,
push down & twist clockwise until Quick Release Spring
Plunger Pin locks in.
Continued on back.
Quick Disconnect Base
*Included with the Pole Kit Only
Bow Mount
Quick Release Spring Plunger Pin
Required Tools For Installation
• 13/64” Drill Bit
• Phillips Bit
• Power Drill
• Marker
Installing the KingPin Anchor
1. First use the Quick Disconnect Base as a template for marking hole location.
2. Drill holes using a 13/64” Drill
3. Place 5/8”O-Rings in countersink groves on the boat side of Base Plate.
4. Align and secure quick disconnect base plate with machine screws.
CAUTION: over tightening may cause screws to strip.
5. Align bow anchor studs over quick disconnect plate, push down & twist clockwise until
Quick Release Spring Plunger Pin locks in.
