CMP Wireless TROLLMaster PRO3+ User manual

3
+
CALL:
1.604.940.2010
EMAIL:
sales@cmpgroup.net
MAIL:
TROLLMASTER
7733 Progress Way
Delta, British Columbia
Canada V4G 1A3
FAX:
1.604.952.2650

3
+
Congratulations on your purchase of the Wireless TROLLMaster PRO3+. This addition to
the TROLLMaster lineup will allow you to control both your trolling speed and direction
from anywhere in the boat.
Connections
Power/Battery Connection 6’ (1.8m)
Connect the +/Positive wire to the +/Positive terminal on your 12V battery.
Connect the -/Negative wire to the -/Negative terminal on your 12V battery.
2 Way Molded Connector 6’(2.4m)
This connection is used to attach a Panther Electro Steer unit. Push the molded connector
to the corresponding connector on the Electro Steer unit until it is snug and both ends of
the connector meet.
Servo Connection 8’ (1.8m)
This cable will connect to the included Servo that mounts under the cowling of the motor.
For more details on how to install this servo refer to the Hardware Kit you purchased that
corresponds to our specic make of motor.
3
+
Congratulations on your purchase of the
Wireless TROLLMaster PRO3+. This addition to
the TROLLMaster lineup will allow you to
control both your trolling speed and direction
from anywhere in the boat.
+-
2-Way
Molded
Connector
(Steering)
6’ (1.8m)
Power/Battery
Connection
6’ (1.8m) Servo
Connection
8’ (2.4m)
Wired
Remote
Test Plug
Pairing
button
Activity
Indicator
3
+
Receiver
Antenna
Mounting HoleMounting Hole
Connections
Power/Battery Connection 6’ (1.8m)
Connect the +/Positive wire to the +/Positive terminal on your 12V battery.
Connect the -/Negative wire to the -/Negative terminal on your 12V battery.
2 Way Molded Connector 6’ (2.4m)
This connection is used to attach a Panther Electro Steer unit. Push the
molded connector to the corresponding connector on the Electro Steer unit
until it is snug and both ends of the connector meet.
Servo Connection 8’ (1.8m)
This cable will connect to the included Servo that mounts under the cowling
of the motor. For more details on how to install this servo refer to the
Hardware Kit you purchased that corresponds to our specific make of motor.
2
Connections cont’d
Wired Remote Test Plug
This plug is used in conjunction with a wired test remote to verify function of
the PRO3+ receiver. (sold separately)
Pairing button
Pushing this button will pair your remote to your receiver. Push this button
once and the Activity light will be solid. Then press any button on the
remote. Once the light goes off your remote is paired.
Activity Indicator
This blinks any time there is activity between your receiver and remote. It
will also be solid when you are in the process of pairing your remote.
Receiver Antenna
This wire is used for the receiver to be able to communicate to the remote.
It can lay loose and does not need any install attention.
Mounting Holes
The holes are used to mount your receiver to ensure it is secure and will not
be tossed around while the boat is in motion.
Quick Start
1. Install your servo and throttle rod following the directions that come
with the hardware kit.
2. Find a suitable location to install your receiver that will be out of direct
contact with constant water exposure and can be mounted securely
but allows all cables to reach their destination.
3. Run your power cable from your receiver to your battery
4. Run your servo cable from your receiver out to your servo that was
installed on the kicker motor in Step 1.
5. (Optional) Connect your Panther Electro Steer motor to the 2 Way
molded connector on the receiver.
6. Pair your remote (See ‘Pairing button’ above)
7. Verify proper operation of the servo (and steering if connected).
8. Go fishing!
If you need additional instructions or clarification refer to the Install Instructions.
3

3
+
Wired Remote Test Plug
This plug is used in conjunction with a wired test remote to verify function of the PRO3+
receiver. (sold separately)
Pairing Button
Pushing this button will pair your remote to your receiver. Push this button once and the
Activity light will be solid. Then press any button on the remote. Once the light goes o
your remote is paired.
Activity Indicator
This blinks any time there is activity between your receiver and remote. It will also be solid
when you are in the process of pairing your remote.
Receiver Antenna
This wire is used for the receiver to be able to communicate to the remote. It can lay loose
and does not need any install attention.
Mounting Holes
The holes are used to mount your receiver to ensure it is secure and will not be tossed
around while the boat is in motion.
Quick Start
1. Install your servo and throttle rod following the directions that come with the
hardware kit.
2. Find a suitable location to install your receiver that will be out of direct contact with
constant water exposure and can be mounted securely but allows all cables to reach
their destination.
3. Run your power cable from your receiver to your battery
4. Run your servo cable from your receiver out to your servo that was installed on the
kicker motor in Step 1.
5. (Optional) Connect your Panther Electro Steer motor to the 2 Way molded connector
on the receiver.
6. Pair your remote (See ‘Pairing button’ above)
7. Verify proper operation of the servo (and steering if connected).
8. Go shing!

3
+
REMOTE FUNCTIONS
Power
Power On
To power on your remote, push the Power On/O button for one second. You will see
TROLL Master on the screen. Select any function to start using the remote.
Power O
To power o your remote, push the Power ON/O button for two seconds until the
display clears.
Sleep Mode
If you do not touch any buttons for one minute, the remote will go into sleep mode. In
order to wake it, touch any button on the remote and it will resume to your last used
function.
Batteries
The remote runs on two standard AAA batteries. You will get a ‘Low Battery’ indication on
the screen when it is time to change them.
3
+
Remote Functions
Power
Power On
To power on your remote, push the Power On/Off button for one second.
You will see TROLL Master on the screen. Select any function to start using
the remote.
Power Off
To power off your remote, push the Power ON/Off button for two seconds
until the display clears.
Sleep Mode
If you do not touch any buttons for one minute, the remote will go into sleep
mode. In order to wake it, touch any button on the remote and it will
resume to your last used function.
Batteries
The remote runs on two standard AAA batteries. You will get a ‘Low Battery’
indication on the screen when it is time to change them.
Max
Throttle
Idle/Resume
Faster
Slower
Power
On/Off
Left/Right Steering*
Backlight LCD Screen
2 AAA Batteries
Replace by
removing two
screws
Lanyard Hook
4
Throttle Control
You have a range of 1-250 to adjust your speed. This does not correlate to
your actual GPS speed. Use an external GPS in order to get an accurate
speed reading for your situation.
Speed Adjustment
There are two buttons to control your speed, A rabbit icon for increasing
your speed and a turtle icon to decrease your speed. Press one time on
the corresponding button to change your speed in single increments.
Jog
If you hold down on either speed button for four seconds your increments
will increase by 10. Release the button and then press once again to go
back to increasing by single increments.
Feature buttons
These two buttons will allow you to max out the throttle control [approx.
80% of factory throttle], or return to idle.
Max Throttle
To use this feature you need to depress and hold the Max Throttle button.
You will see ‘Max Throttle’ appear on the screen while it is being held
down, and your motor will increase speed and stay at that Max Throttle as
long as the button is held down. To return to your previous speed setting
release the button.
Idle/Resume
To use this feature press the Idle button. When you do, the throttle will
drop to the 000 setting and it will say ‘Idle 000’ on the remote. To resume
your previous setting press the Idle button again. You will see ‘Resume
XXX’. The XXX will be the setting you had last been configured for.
Steering Control
When your unit is connected to a Panther Electro Steer (sold separately) you
are able to remotely steer your kicker motor.
Press once on the Left or Right Arrow button on the remote to move in
small increments. If you hold down the button it will move in larger
increments. See Installation Steps for more details.
5

3
+
Throttle Control
You have a range of 1-250 to adjust your speed. This does not correlate to your actual GPS
speed. Use an external GPS in order to get an accurate speed reading for your situation.
Speed Adjustment
There are two buttons to control your speed, A rabbit icon for increasing your speed and a
turtle icon to decrease your speed. Press one time on the corresponding button to change
your speed in single increments.
Jog
If you hold down on either speed button for four seconds your increments will increase
by 10. Release the button and then press once again to go back to increasing by single
increments.
Feature buttons
These two buttons will allow you to max out the throttle control [approx. 80% of factory
throttle], or return to idle.
Max Throttle
To use this feature you need to depress and hold the Max Throttle button. You will see
‘Max Throttle’ appear on the screen while it is being held down, and your motor will
increase speed and stay at that Max Throttle as long as the button is held down. To return
to your previous speed setting release the button.
Idle/Resume
To use this feature press the Idle button. When you do, the throttle will drop to the 000
setting and it will say ‘Idle 000’on the remote. To resume your previous setting press the
Idle button again. You will see ‘Resume XXX’. The XXX will be the setting you had last been
congured for.
Steering Control
When your unit is connected to a Panther Electro Steer (sold separately) you are able to
remotely steer your kicker motor.
Press once on the Left or Right Arrow button on the remote to move in small increments.
If you hold down the button it will move in larger increments. See Installation Steps for
more details.

3
+
INSTALL INSTRUCTIONS
1. Packaged in the hardware kit that you purchased with your PRO3+ is an install
manual that explains in detail how to Install your servo and throttle rod.
2. Your wireless receiver needs to be placed in a location where it will not be exposed
to constant water exposure. A battery compartment, rod box, anything similar would
be a good location. Keep in mind that this location also needs to allow for the wires
to be able to reach the battery, servo, steering, etc. As an additional consideration,
the signal between your remote and receiver is designed to work within a ~30ft
(9.1m) range even inside of an enclosed location. Once you nd a suitable location,
use the mounting holes and appropriate hardware to secure it.
3. Run your power cable from your receiver to your battery, and then attach the red
cable to the positive terminal and the black cable to the negative terminal.
4. The servo cable 8ft (2.4m) from your receiver needs to be routed to the servo
mounted on your kicker motor.
NOTE: If you need an extension to your servo cable visit trollmasters.comand look for
the Parts Shop link. There is a 10ft (3m) extension available.
5. (Optional Steering Device) Route the steering cable 6ft (1.8m) from your receiver
to the location of your Panther Electro Steer motor and connect the 2-Way molded
connectors until they are pushed together completely. Do not plug into the 3-way
molded connector in an existing relay control.
NOTE: If your electro steer is hardwired to your receiver and the turning controls
work in the reverse. You will need to reverse your wiring in order to correct that issue.
NOTE: Keep in mind that depending on which side your electro steer is mounted
on your kicker motor the turn controls might be reversed. To change this you can
reverse the polarity of the connection. First, disconnect the unit from the battery.
Then cut the wires between the receiver and connector. Now reconnect the wires,
but connect red to black and black to red. Be sure to use proper connections, like
Butt T splices or wire nuts
6. Pair your remote to your receiver. Push the pairing button on the receiver and you
will see a solid activity light. Then press any button on the remote. Once the light
goes o your remote is paired. It will always pair to the most recent unit. If you need
to replace your remote, following this step will pair your new remote and does not
store you older remote.
7. Once everything is connected and paired, ensure that operation is correctly working
by using your remote to verify that the servo (and steering) are responding to inputs.
Once this has been veried tie down any loose cables securely.

3
+
TROUBLESHOOTING
Inputs to remote do not cause the servo or steering to respond
yDouble check that your battery that is charged.
yVerify that your power cables are connected securely.
yTry pairing the remote one more time and ensure that the Activity Light comes on to
verify power.
yCheck that the screen on the remote is in fact showing any kind of text after pushing
the power button.
yFor testing ensure there is a clear line of sight between the remote and the receiver.
Once that works place back in your preferred location and retest.
yThere is a optional wired remote that can be purchased to verify wireless receiver
functionality.
Visit trollmasters.com and look for the Parts Shop link

3
+
SERVICE AND WARRANTY
Should your unit ever require service please do not return the product to your dealer.
Instead call the number below for special instructions on shipping and handling. Be sure to call between
9 00 AM and 5.00 PM (Pacic Time) Monday through Friday. If the service required is covered by the
warranty, it will be repaired or replaced as described below. If the service required is NOT covered by
warranty replacement parts are available for purchase and paid for by a major credit card.
The warranty coverage on this equipment is limited to the terms set forth below:
CMP Group LTD. warrants this product to be free of defects in material and workmanship for a period of
ONE (1) YEAR from the date of original retail purchase. Positive proof of date of purchase is required for
warranty service. If the service required is covered by warranty, you must obtain a Return Authorization
number from CMP Group . The unit will be repaired or replaced with new or factory rebuilt parts at no
charge. The defective components must he returned to the address specied, with shipping charges
prepaid. Be sure to include your name, address, telephone number and a copy of the sales receipt
showing the date of original retail purchase. All sales receipts are subject to verication.
This warranty does not apply if the unit has been damaged by accident, abuse, misuse, poor installation
or misapplication, or if It has been modied from its original condition, or if any serial number has been
removed or defaced or altered. This warranty does not cover any expense to remove or reinstall the unit
or any of its components. If a returned unit is not covered by warranty, the sender will he notied and
given an estimate of the charges to repair or replace the unit together with the return shipping charges.
THIS WARRANTY DOES NOT COVER SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING
FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT
LIMITED TO DAMAGE TO OR REPLACEMENT OF OTHER EQUIPMENT AND PROPERTY. THE WARRANTY
AND REMEDIES SET FORTH ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS, WHETHER ORAL OR WRITTEN,
EXPRESS OR IMPLIED. DUE TO THE SPECIAL AND UNIQUE CONDITIONS THAT MAY EXIST IN EACH
APPLICATION, THE MANUFACTURER SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. NO DEALER, AGENT OR EMPLOYEE IS
AUTHORIZED TO MAKE ANY MODIFICATION, EXTENSION OR ADDITION TO THIS WARRANTY.
Some states do not allow exclusion of incidental or consequential damages, so the above exclusions may
not apply to you. This warranty gives you specic legal rights, and you may also have other legal rights,
which may vary from state to state.
FOR SERVICE CALL: 1.604.940.2010
Other manuals for Wireless TROLLMaster PRO3+
1
Table of contents
Other CMP Remote Control manuals
