COBI PLATEC X-PLA mini User manual

Automotive Plasma Air Sterilizer
Automotive Plasma Air Sterilizer
CPT-XP200M-Rev.1.1 (21.05)
ECO-FRIENDLYECO-FRIENDLY
IMPORTANT SAFETY INSTRUCTION
WARRANTY
SPECIFICATION
WARNING ― To reduce the risks of, burns, fire, electric shock,
or injury to persons and product damage
Leave enough space between the product and any other products.
When installing, must secure the product with the included fixing belt.
Avoid any mechanical or physical shock to the product and power
adaptor.
Always unplug the product when not in use.
Always unplug the product before cleaning or carrying out other
maintenance.
If you need to move the product, disconnect the product from the
power supply first.
Always unplug the product before cleaning or carrying out other
maintenance.
If you need to move the product, disconnect the product from the
power supply first.
Do not touch the product and power plug with wet hands.
When you smell gas or suspect a gas leak (e.g. city gas, propane,
etc.), change the plasma mode to auto mode, and do not touch the
power cord, and leave the area leaving doors and windows open to
ventilate if possible.
When noticing abnormal sounds, smells, and smokes from the product,
power off the product immediately and contact a service center.
— Need to replace new filter to remove the odor from the used filter.
Do not unplug the cigarette lighter plug while driving.
Do not place anything around/on to the product. Never block the air
intake/outlet.
Do not splay any flammable materials such as insecticides or fragrance
around/to the product.
Do not use the product with tilting or turning it upside down.
COBI PLATEC provides the limited warranty for individuals or organiza-
tions purchasing the device from COBI PLATEC or an authorized
distributor.
COBI PLATEC warrants material and manufacturing defects during
normal use for one year from the date of original purchase. (“Warranty
Period”) If the device is returned to COBI PLATEC during the warranty
period, COBI PLATEC may repair the device, replace it with a fully
refurbished one, or refund the purchase price. (Excluding discount or
promotional code purchases) If the warranty period has expired or
does not apply to the scope of warranty and restrictions, COBI PLATEC
may return the device to the user.
Warranty and coverage : 1- year limited warranty
CUSTOMER SERVICE
TROUBLESHOOTING
Thank you for purchasing an Automotive Plasma Air Sterilizer X-PLA mini.
Visit COBI PLATEC website for special promotion, online help, general tips
and useful information about Automotive Plasma Air Sterilizer X-PLA mini.
*The product design and specification is subject to be changed without prior notice.
PROBLEM
Product does not
operate.
The “buzzing” sound
continues while the
product is operating.
The “whirring” sound
continues while the
product is operating.
The product produces
a strange smell.
POSSIBLE CAUSE / SOLUTION
Ensure the cigarette lighter plug is connected.
Ensure the switch on the cigarette lighter plug
is on.
Ensure the power lighter plug is disconnected
to the product.
The sound is generated in normal when the
plasma mode is activated.
This is the sound of a fan running.
When the product stop running, the fan may
make a whirring sound as it slows down and
stops.
When the plasma mode is operated, a charac-
teristic odor may be emitted due to the steriliza-
tion effect. The smell is harmless to the body,
and it is normal to use as it is.
(This is nothing to do with ozone since it is the
product with under the 0.002ppm ozone
generation.)
Website
www.cobilplatec.com
Address
2F, 131 Yangjaecheon-ro, Seoho-gu, Seoul, Korea
Website
www.cobilplatec.com
Address
2F, 131 Yangjaecheon-ro, Seoho-gu, Seoul, Korea
Read all instructions and cautionary markings in this manual before using
the product.
Warning
Automotive Plasma Air Sterilizer
CPT-XP200
DC12~24V , 1A
9W
Atmospheric-Pressure Plasma
Pre Filter
Deodorization Filter
1.0kg (2.2lb.)
W305xD155xH85mm (W11.8xD6.1xH3.3in.)
Item
Model
Power Supply
Power Consumption
Purifying Techniques
Gross Weight
Dimensions

①
②
③
No.
①
②
③
HOW TO INSTALL
PREPARATION
Join the Pre filter and deodorization filter in order into the filter frame.
No. Description
①Operation Status Indicator
②Filter Frame
③ Power Connector
CONTROLS OVERVIEW
PRODUCT PACKAGE
Cigarette Lighter Plug
Securing Straps (2ea)
— For armrest (Long Type)
— For headrest (Short Type)
X-PLA mini
Cover
X-PLA mini
Body
User Manual
Pre Filter
Deodorization Filter
①Power ON — Press a red button on the cigarette lighter plug.
②Operate the product — The LED of operation status indication is lit on.
③Power OFF — Press a red button of the cigarette lighter plug.
INSTALLATION
Warning
• Ensure to secure the product firmly.
• According to the type of vehicle, the product can be installed to
armrest, headrest or rear.
• For the safety reason, the armrest installation is recommended
when a baby or child is seated or in case of sudden stops.
• Always unplug the cigarette lighter plug before cleaning.
• Clean after fan is completely stopped.
• Never use alkaline detergent or flammable cleaning agents such as
acetone, bleach or alcohol to clean any part of product.
• Do not disassemble the product.
Warning
Warning
• Power off completely by pressing the button on the cigarette lighter
plug if the product is activated after the engine is off.
IMPORTANT SAFETY INSTRUCTION
HOW TO OPERATE
DANGER ― To reduce the risk of serious injury or death
HOW TO CLEAN AND MAINTANANCE
• Inquiry for purchasing: [phone]
Do not install the product near a heating device or under the direct
sunlight.
The product can be installed to the armrest or headrest according to
vehicle types. — For the safety reason, installing the product to the
armrest is recommended when a baby or child is seated or in case of
sudden stops.
The 12 &24 volt DC options can only be used.
When removing the cigarette lighter plug from the socket, always hold
the cigarette lighter plug and never pull by the cord.
Do not run cord/adaptor under carpeting and heavy objects including
furniture or appliances, and cover cord/adaptor with throw rugs,
runners, or similar coverings.
Do not bend or twist cigarette lighter plug badly.
Do not operate the product with a damaged cord and plug. Do not
disassemble, modify, and repair the product. All other repairs or
exchanges should be completed by a qualified technician, manufacturer
or distributor to avoid any risk. — Contact Customer Service. See the
information on the last page of this manual.
When the cigarette lighter plug is damaged, contact the service center.
Always unplug the product before cleaning or carrying out other
maintenance.
If you need to move the product, disconnect the product from the
power supply first.
The product should not be used by person (including children) with
reduced physical, sensory or mental capacities or lack of experience
and knowledge, unless they are supervised or have been given instruc-
tions beforehand concerning use of the product by person responsible
for their safety. Children must not play with or on the product.
Do not place anything around/on to the product. Never block the air
intake/outlet.
Never allow any liquid to enter the product.
④Insert cigarette lighter plug into the car socket.
* Warning: Do not touch with wet hands.
③According to the type of car, install the product to armrest or headrest.
* The two types of securing (armrest-long type and headrest-short type)
straps are packed separately, use it properly.
②Insert the power lighter plug into the power connector as the picture above.
①Insert the securing straps into the bracket on the back of the product.
(Start with the corner of strap for inserting easily.)
Filter Change Cycle
-
At least once a month,
clean with water
Change every 3 months
(Sold Separately)
1. Clean the outside of the appliance
Wipe away dust with a soft cloth soaked in warm water from the
surface of the product.
2. Clean the Pre filter
Remove the dust on the intake with a kind of vacuum cleaner.
3. How to store when the product is not used for long term
Avoid the place exposed to high humidity. Store the product with
silica gel.
— This page is designed to ensure user safety and the prevention of damage to
the product.
— Read this user manual carefully before you use the product, and ensure the
product is used properly.
Description
Filter Frame
Pre Filter
Deodorization
Filter
