TOP VEHICLE TECH GR3FORD5 User manual

www.topvehicletech.com
The informaon provided in this document is subject to change without noce due to changes and/or
improvements to the product/s.
This dash image is a visual representaon for display purposes only.
V1.0522
GR3FORD5
INSTALLATION MANUAL
FORD MONDEO
(MK3, POST FACELIFT)
2004-2007

2
www.topvehicletech.com
ABOUT THIS PRODUCT
The GR3FORD5 installaon kit allows for the retenon of the vehicle’s steering wheel controls and maintains
the original aesthec of the interior when installing a new car stereo. The GR3FORD5 gives you everything you
need for a complete install in one box. The components of this kit are compable for the Ford Mondeo (MK3,
2004-2007) with square shaped 5000C, 6000CD & 6006CD stereos. The wiring harness and interface will help to
retain the steering wheel controls with the new stereo. Supplied with a Quadlock connector.
NB: the fascia in this installaon kit is only compable with square shaped OEM units.
CUSTOMER SUPPORT
Installaons should be carried out by, or under the guidance of an experienced installer. If you do encounter any
problems during the installaon of this product, then please contact our dedicated customer service team at:
Phone: [phone] E-Mail: [e-mail]
CONTENTS
• 1x Fascia plate (with accessories)
• 1x Instrucon manual
• 1x Steering wheel control harness and interface
• 1x Antenna adapter
• 1x DAB antenna adapter
• 1x Stereo patch lead

3
www.topvehicletech.com
FITTING GUIDE
1. Using a set of radio release keys, push them into the 4x ports found at each corner of the main radio.
1. Open the passenger side door and proceed to pull away the door trim from the pillar.
STEREO REMOVAL
DAB ANTENNA INSTALLATION
2. Using a set of panel removal tools, begin to pry away the pillar casing.
4. The DAB antenna not only has a self adhesive backing, but also features a black earth sheet. When
placing the DAB antenna, the earth sheet MUST be placed onto the metal part of the pillar. The antenna
itself must be located roughly 15cm from the top of the windscreen.
Note: this antenna must not be placed atop any kind of heang elements, this will interfere with the
antenna’s signal.
5. Once happy with the placement, take the 3m of wiring extension and feed it down through to the
stereo’s opening. With the wiring adjusted to the appropriate length, feel free to re-install the glovebox.
3. The glovebox will need to be made accessible to route the antennas wiring. To do this you will need to
open the glovebox and remove 4x screws atop the main lip as well as 3x screws that are hidden behind
plasc clips. Then all that is needed is to pull the main housing out.
2. Once done, simply pull the radio out of the dashboard and disconnect all of the wiring.
FASCIA PLATE SET-UP
1. Aach the metal clips that come with the kit onto the back of the new fascia.
3. With the cage secured into place, and once the “Stereo Installaon” process is complete, simply slide
the stereo into the fascia.
2. Once the clips are aached, simply push the new fascia into the dashboard.

4
www.topvehicletech.com
FITTING GUIDE
STEREO INSTALLATION
5. When all the above wires (and any addional accessories) have been connected, nally make the
connecons between the stereo and the vehicles pre-exisng power/stalk connectors.
3. Connect the DAB antenna’s SMB connector to the back of the new stereo.
4. Aach the antenna adapter to the vehicles pre-exisng connecon and the back of new stereo.
1. Take the steering wheel control interface in hand and connect both the 12-way stereo patch lead and
the 14-way steering wheel harness connectors to the corresponding sides.
2. Connect the bullet connector from the stereo patch lead to the ‘steering wheel remote input’ on the
back of the new stereo.

5
www.topvehicletech.com
Please note: conguraon layout may dier dependent on vehicle model.
STEERING WHEEL CONTROL FUNCTIONALITY
MODE
VOL +
-
1
2
3 4
VOL
SEEK
1. Volume +
2. Volume -
3. Source
4. Track +/- (Scroll on Back)
1. Volume +
2. Volume -
3. Mode
4. Track +/- (Scroll on Back)
Original Buon New Funcon

6
www.topvehicletech.com
ISO Connector
Connect to new stereo
Quadlock Connector
Connect to quadlock connector from vehicle
Main Wiring Loom
Connector [14 Pin]
Connect to Interface Box
Interface Box
Stereo Patch Lead Connector [12 Pin]
Connect to Interface Box
Note: Must be connected first, before
power connection is made to the
interface
Stereo Patch Lead Bullet Connector
Connect to ‘Steering Wheel Remote
Input’ on back of the stereo.
WIRING DIAGRAM

7
www.topvehicletech.com
NOTES

8
www.topvehicletech.com
If at any point you experience any problems and need any assistance before, during or aer the
installaon process, please contact us via :
Phone: [phone]
E-Mail: [e-mail]
Mon - Fri 9am - 5.30pm GMT
TECHNICAL ASSISTANCE
If you would like to download a digital copy of this manual, or any other product, then please
visit the www.topvehicletech.com website.
This manual is considered correct at the me of prinng but is subject to change. For the latest
manuals & updates, refer to our website.
