JCROffroad JT Configuration guide

Thank you for purchasing from JcrOroad! Checkout our website, www.jcroroad.com for other great o-road
products. Be sure to rate and review our product online. If you have any questions or are missing parts, please
don’t hesitate to call us at 269-353-1184!
Please read the mounting instructions below carefully before attempting to install.
Be sure to check out the install video on the product page, if available.
JT
UNDERSEAT MOLLE
STORAGE BASKET
INSTALL INSTRUCTIONS

INCLUDED HARDWARE
8x
1/4”-20 X 3/4”
Button Head
1/4”-20
Serr. Flange Nut
1/4”
Washer
8x
1/4”-20 X 1”
Hex Head
5/16”-18 X 1”
Hex Head
1/4”
USS Washer
5/16”
USS Washer
1/4”-20
Flanged Nylock Nuts
5/16”-18
Flanged Nylock Nuts

INCLUDED PARTS
1x 1x
1x
1x
1L/1R
1x
1x

1Start by attaching the lock to the front panel of the basket. Simply insert
the lock through the hole, making sure it is right side up, and then put the
nut on the other side to secure it in place.
ASSEMBLY
2Next, attach the small bracket that goes behind the lock using two
1/4”-20 X 3/4” bolts, 1/4” washers and 1/4”-20 serr. flange nuts.

3
ASSEMBLY
4Now, attach the bottom panel using the 1/4”-20 X 3/4” bolts, 1/4” washers
and 1/4”-20 serr. flange nuts. Once you have all bolts started, go back and
tighten them all up. Tighten the side panels fully into place at this time as
well.
Next, Mount both side panels to the sides of the front panel using three
1/4”-20 X 3/4” bolts, 1/4” washers and 1/4”-20 serr. flange nuts on each
side. Leave the bolts a little loose for now in order to make attaching the
bottom panel easier.

5With the basket assembled, you can now decide if you want to use the
divider. If you decide you do want to use it, there are several mounting
locations for it. It can go in any of the long thin slots on the bottom panel.
Once you decide where you want it, slip the tabs in the bottom of the
divider into the slots in the bottom panel and then attach it to the front
panel using two 1/4”-20 X 3/4” bolts, 1/4” washers and 1/4”-20 serr. flange
nuts.
ASSEMBLY

ASSEMBLY
6Next, place the basket in the Gladiator, lining the factory holes up with
the mounting slots in the basket, and mount the basket using the factory
hardware. Leave it a little loose for now in order to make mounting the
latches easier.
7Finally, mount the latch brackets to the bottom of the seats. For
information on how to do this, please watch the instruction video on the
product page.
