Cobra NavOne 2100 User manual

2
Getting Started
THANK Y U F R PURCHASING
THE NAV NE 2100 SYSTEM.
The following items should be in the package:
AB UT THE NAV NE SYSTEM
Your unit is complete with a map of the entire United States
and Canada as well as a database of millions of points
of interest to help you navigate your vehicle.
Except for the Power and Custom function buttons, all the
controls are available with a few touches of the screen.
However, do not rely entirely on the unit while driving and
keep in mind the accompanying Important Information.
M RE INF RMATI N
These Operating Instructions combined with the intuitive
nature of the controls should have you up and running quickly.
For online support, visit www.cobra.com.
SMARTP WER
With the SmartPower feature turned on, a NAV ONE unit plugged
into a power port that does not turn off with the ignition, will not
drain the vehicle’s battery. The factory setting is on.
SmartPower shuts the system down when there is a combination
of no vehicle motion and no button press for 15 minutes.
With SmartPower off, the system continues to operate until it is
turned off with the Power button (or with the ignition if the power
port is connected to it).
1. The NAV ONE
system unit.
2. A mounting bracket
with suction cup.
3. A 12-volt fused
power cord.
4. A 120-Volt Adapter.
5. A foam cushion strip.
6. This Manual.
7. roduct registration
card. (Or register online
at www.cobra.com)
TRY I T U T
Using the NAV ONE is the most effective way to
learn about it. View the demonstration program
by choosing:
Advanced ModeSMenu SSettings SDemo
Then don’t hesitate to explore your own entries to see
how they work.
There are provisions to delete entries and, if things get
really tangled up, the factory defaults can be reset using
the sequence:
Menu SSettings SSystem SReset Factory Defaults
3
Important Information
Your safety is important. lease read all warnings
and cautions before installing and using the Cobra
NAV ONE system.
The user is responsible for operating this product
wisely. This NAV ONE unit is intended for use only
as a navigational aid and should not be relied upon
to the exclusion of other information. Be aware of
conditions around the vehicle and compare them to
the information provided by the NAV ONE system.
CAUTION
Observe the following precautions to avoid damage to the unit
or personal inconvenience.
This unit is not waterproof. Do not allow liquids to splash on
it nor expose it to rain during operation or transfer from vehicle
to vehicle.
The Global Positioning System is provided and operated by the
U.S. government, which is solely responsible for its accuracy and
maintenance. That system is subject to changes, which could
affect the accuracy and performance of this NAV ONE unit.
The NAV ONE’s map database provides information on suggested
routes without regard to some factors that may affect the user’s
driving experience. For example, the system does not reflect all
road detours, closures or construction, some road characteristics
(such as road surface, slope or grade, weight or height restrictions,
etc.), weather conditions and similar factors. Use personal
judgment or the navigation system’s detour function to
develop an alternate route if necessary.
WA NING
Avoid the following hazardous situations that could result in a
collision causing severe injury or death.
DO NOT substitute this NAV ONE for personal judgment. The route
suggestions should never supersede any local traffic regulation,
personal judgment or knowledge of safe driving practices. Before
making any maneuvers suggested by the NAV ONE system (for
example, a U-turn or a left turn), verify that the maneuver can be
legally and safely completed. Do not follow route suggestions that
would take the vehicle into an unsafe situation or locality.
DO NOT program this NAV ONE while driving. Only a passenger
should operate controls or program the unit while the vehicle is
in motion. The driver should not program the system unless
the vehicle is parked in a safe location.
DO NOT depend on this NAV ONE system to locate emergency
services (such as police, fire stations, hospitals and clinics).
The database may not include all emergency service providers. Use
judgment and ask for directions in these situations.
DO NOT disassemble or modify the system. If a problem occurs,
stop using the system immediately and contact Cobra.
DO NOT be distracted by the NAV ONE. DO position the unit so it
can be seen at a glance when safe to do so. DO listen to the voice
guidance. DO set the volume so you can hear outside traffic and
emergency services alarms.
4
Insta ation
INSTALLATI N
The NAV ONE can be easily mounted to the vehicle’s
windshield with the included bracket and suction cup.
Or, an alternative secure mounting can be used.
It is important that the NAV ONE antenna in the top of the unit can
“see” the sky. Radio signals from the GPS satellites are weak and
cannot penetrate solid portions of a vehicle’s structure.
When the NAV ONE has been unused for several days, or has been
moved more than 500 miles, it can take 15 minutes to acquire
satellites. Leaving the unit on for 20 minutes in this case will allow
faster acquisitions after that.
IMPO TANT: Check www.cobra.com for software updates.
Put the unit where it is visible
at a glance.
Let the antenna “see” the sky.
WA NING
Observe the following measures to prevent a collision or other
condition that could cause serious injury or death.
DO NOT position the unit in a location that obstructs the driver’s
view of the road or vehicle instruments or controls.
DO NOT mount the unit over airbag panels or within airbag
expansion spaces. The force of an expanding airbag can thrust
objects in its path toward the driver or passengers with
injurious result.
DO NOT drive the vehicle unless the unit is securely attached to
the windshield with the supplied bracket and suction cup or is
fastened by other reliable means to keep it from becoming a
projectile hazard inside the vehicle in the event of a violent
maneuver or collision.
Nothing Comes Close to a Cobra®
Installation 5
To secure and connect the NAV ONE:
1. Clean the mounting area using window
cleaner or rubbing alcohol.
2. Separate the mounting bracket from
the unit.
3. Firmly press the suction cup against the
windshield by applying pressure to
the suction cup base.
4. Pull the lock lever back until it “clicks”.
Maintain firm pressure on the suction
cup base and then push the lock lever
down toward the base.
5. Test the suction cup adhesion by pulling
firmly on the bracket. It should not wiggle.
6. Attach the unit to the bracket by sliding
the slot in the bottom of the unit over
the bracket until the locking tab clicks.
7. Adjust the unit position using the knobs
and tighten securely.
8. If the unit will rest on the dash or might
contact it, apply the foam strip to the
bottom of the unit to protect the dash.
9. Plug the power cord into the unit and
the vehicle’s 12-volt power port.




To Remove Nav ne:
Depress the locking tab and slide the
unit toward you to temporarily remove
the unit when the vehicle is parked to
prevent theft or heat damage.
The bracket can be left attached to
the windshield for quick reinstallation
of the unit.
6
Contro s, Indicators and System Overview
Power Button (on side of unit)
SPress to turn the unit off. Press and hold to turn it off.
SSmartPower default is on. See description on page 2.
Menu Key (User Programmable Key)
SPress to quickly bring up a frequently used function
you have chosen. (Default function is “Menu.”)
SPress and hold for 2 seconds to change from the chosen
function to any other on the available list.
Illuminated Touch Screen
STouch the on-screen buttons and icons to activate
unit functions.
Speaker
SD Memory Card Expansion Slot.
USB Port (for software/map updates
and optional traffic receiver).
Power Connector
Bracket Mounting Slots
8
Menu Access
MENU
Menu is the starting point for all system
features. Just touch the on-screen buttons to
progress from step to step. To access "Menu",
press the Menu Key to the right of the screen.
(Note: User rogrammable Key may be
customized at a later date as described under
“Controls” above.) Either the Basic or the
Advanced menu will appear.
You can choose between them
with the Mode Button at the
top right of the Main Menu.
The factory default setting is
Basic menu.
BAS I C
The Advanced menu provides
all the tools available on the
NAV NE. The Destination
Address menu is shown.
Press the buttons on the
bottom of the touch screen
to move to other functions.
The Basic menu provides access to the
most frequently used tools.
GO TO MAP
AD VA N CE D
Nothing Comes Close to a Cobra®
Controls, Indicators and System Overview 7
SYSTEM VERVIEW
When the NAV ONE is turned on, an opening
message and a safety warning are shown.
LANGUAGE CH ICES
At this display, the user has
the opportunity to change
the language from English
to French or Spanish.
Continuation from the warning message
depends on whether or not a navigation
was in progress when the unit was last
turned off.
NA VI G ATI N
WA S I N
PR GR E SS
NAV IG AT I N
WAS N T I N
PR GR E SS
NOTE
Menu can be pressed at any time to select a
destination and switch to the Navigation mode.
System in
Navigation
Mode
System in
View Mode
Speaker volume and display brightness
are adjusted using the +and –buttons
on the touch screen. The button between
the +and – Volume buttons toggles
the system between mute and un-mute
without affecting the volume setting.
ADD ESS BOOK allows entry and storage of addresses:
View Entries lets you see the entries you’ve made
and quickly choose from them.
Add to Book lets you enter addresses using
an on-screen keyboard.
Trails lets you record a trail – to retrace your steps or
repeat the trip.
Save Current Location quickly adds the current
location to the address book.
Nothing Comes Close to a Cobra®
Menu 9
FIND INTE EST POINTS allows choice of a destination from
millions of interest points in the NAV ONE database.
Telephone numbers are included with addresses. Points
can be found in any of four ways:
Name Search lets you spell out the name of a place
using an on-screen keyboard.
Category Search lets you choose categories, such as
lodging, to quickly narrow your search.
Favorite Brands lets you select a specific brand of
interest points to save as a favorite.
City Name allows you to route to a city by name, without
entering a specific address.
SYSTEM provides four utilities:
Settings allows you to customize the NAV ONE to
your preferences:
– System adjusts settings including time zone
and key click sounds.
– Navigate lets you control how the system will
calculate your route, such as whether or not to
use freeways or make U-turns.
– Map lets you set your preferred appearance
of the map including vehicle icon, map direction
and view angle.
Demo provides an interactive demonstration of the
NAV ONE and all its features.
Help gives tips on using features of the NAV ONE.
System Information provides information about the
system software version and similar items.
WA NING
DO NOT program this NAV ONE
while driving. Only a passenger
should operate controls or
program the unit while the
vehicle is in motion. The driver
should not program the system
unless the vehicle is parked in a
safe location.
NOTE
Some states / provinces prohibit attachment of any articles to
windshields or side or rear windows. Drivers in these areas should
use the dash mounting disk or another secure mount.
Users should determine if restrictions apply to jurisdictions where
they drive.



CUST MER ASSISTANCE
Should you encounter any problems with this
product or its many features, please refer to
these instructions For further assistance after
reading these instructions, Cobra Electronics
offers the following customer assistance services:
FR AS S IS TA NC E IN T H E U. S. A .
SAutomated Help Desk (English only) 24 hours a day,
7 days a week at 773-889-3087 (phone).
SCustomer Assistance Operators (English and Spanish)
8:00 a.m. to 6:00 p.m. Central Time, Mon. through Fri.
(except holidays) at 773-889-3087 (phone).
SQuestions (English and Spanish)
Faxes can be received at 773-622-2269 (fax).
STechnical Assistance (English only) www.cobra.com
(on-line: Frequently Asked Questions).
STechnical Assistance (English and Spanish)
product [email protected] (e-mail).
FR ASSISTANCE UTSIDE THE U.S.A.
SContact the local dealer
THE C BRA LINE F QUALITY
PR DUCTS INCLUDES:
CB RA D I S
MI C R TAL K ®RA DI S
RADAR/LASER DETECT RS
SAF E TY A LE RT ®TRAFFIC WARNING SYSTEMS
HA N DH EL D G PS R EC E IV ER S
M BI L E GP S NA VI G ATI N S Y ST EM S
HIG H GE AR ®AC CE SS R I ES
C BRAMARINE®VHF R A DI S
MARINE CHARTPL TTERS
PWE R I NV ER T ER S
AC C ES S RI E S
For more information or
to order any of our products,
please visit our website:
www.cobra.com
©2006 Cobra Electronics Corporation
6500 West Cortland Street
Chicago, Illinois 60707
PTI NAL ACCESS RIES
Optional accessories and map database
updates are available.
Real-Time Traffic (Optional Receiver/Subscription
necessary).
With optional traffic receiver, receive up-to-date traffic
information to help you avoid congested roads or
traffic incidents. View color-coded speeds and traffic
incidents along your route. Re-route around congestion.
View constantly updated ETA based on current traffic.
Traffic and incident reports are provided through Traffic
Message Channels over FM radio Data System,
currently covering 49 major metro areas.
For more information about optional accessories and
how to order them, please visit www.cobra.com or
call 1-773-889-3087, 8:00 am - 6:00 pm Central Time,
Monday through Friday (except holidays).
PR DUCT SERVICE
For any questions about operating or installing
this new Cobra product, or if parts are missing
…PLEASE CALL C BRA FIRST…do not return
this product to the store.
If this product should require factory service, please
call Cobra first before sending the product. This will
ensure the fastest turnaround time on any repair.
If Cobra asks that the product be sent to its factory,
the following must be furnished to have the product
serviced and returned:
1. For Warranty Repair, include some form of proof-of-purchase,
such as a reproduction or carbon of a sales receipt. Make sure
the date of purchase and product model number are clearly
readable. If the originals are sent, they cannot be returned.
2. Send the entire product.
3. Enclose a description of the product malfunction, a typed or
clearly printed name and address of where the product is to
be returned and a phone number (required for shipment).
4. Pack the product securely to prevent damage in transit.
If possible, use the original packing material.
5. Ship prepaid and insured by way of a traceable carrier such as
United Parcel Service (UPS) or Priority Mail (to avoid loss in
transit) to: Cobra Factory Service, Cobra Electronics Corporation,
6500 West Cortland Street, Chicago, Illinois 60707 U.S.A.
6. If the product is in warranty, upon receipt of the product, it
will either be repaired or exchanged depending on the model.
Please allow approximately 3 – 4 weeks before contacting
Cobra for status. If the product is out of warranty, a letter
will automatically be sent with information as to the repair
charge or replacement charge.
For any questions, please call 773-889-3087 for assistance.
10
Navigation
NAVIGATI N
After a destination is selected, the NAV ONE lets you preview and choose from multiple route possibilities.
As soon as one is chosen, the Map is shown in Navigation mode.
In Navigation mode, the Map shows
the vehicle icon in relation
to the surrounding streets as well
as next maneuver information.
Touch the INFO button for more
information and route options.
NAV IG AT E allows
recalculation of the route
during a trip: to detour,
for example, or to stop
navigation altogether.
Zooms in to
show less area,
but more detail.
Zooms out to
show more area,
but less detail.
TR I P DAT A provides
information on the
current or completed
trip including mileage,
speed and time.
Touch a Maneuver Bar
to reach options to:
Jump ahead on the
Map to see the maneuver.
Avoid the maneuver
and develop an alternate
route around it.
11
Se ecting a Point on the Map
and Panning the Map
SELECTING A P INT N THE MAP
Touch the Map at any point to bring up a Point
window with a list of possible actions related to
where you've touched.
The Point window also provides options to:
Quickly zoom from street to neighborhood to state levels.
Determine the latitude and longitude of a point.
Identify road segments to be avoided in future route
developments.
Add a Via point (intermediate destination) to your route
while in Navigation mode.
View Interest Points
PANNING THE MAP
You can easily view areas that are currently off the Map.
Touch the screen at any point and quickly drag your
finger in the direction you want the Map to move.
Touch the Recenter button to move the end point
of the screen and drag to the center of the Map.
The Recenter button will recenter the map on the
current GPS location.
Recenter
Button
WA NING
DO NOT program this NAV ONE while driving. Only a passenger
should operate controls or program the unit while the vehicle is
in motion. The driver should not program the system unless the
vehicle is parked in a safe location.
12
Optiona Accessories and Product Service
FCC C M P LI AN C E
This device complies with Part 15 of the FCC interference
limits for Class B digital devices for home or office use.
These limits are designed to provide more reasonable protection
against harmful interference in a residential installation and are
more stringent than “outdoor” requirements.
Operation of this device is subject to the following conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired operation.
Changes or modifications to the NAV ONE system may void
its compliance with FCC rules and make its use illegal.
MAINTENANCE
Very little maintenance is required to keep this
NAV ONE system in good operating condition.
Keep the unit components clean by wiping with a
soft cloth. Do not use solvents, glass cleaners or harsh
or abrasive products that could damage the case or
scratch the display screen.
rotect the unit from moisture and from being
dropped or struck by hard objects to prevent damage.
Consult the Cobra website (www.cobra.com)
for the latest software and database updates.
Display does not power up.
Power switch is turned off. Turn the unit on with the Power button.
Fuse in 12-volt power cord is blown. Check for green LED on 12-volt power plug. Unscrew the fuse holder,
inspect the fuse and replace it if blown.
No voltage is present at
the vehicle’s power port.
Troubleshoot vehicle wiring. NOTE for some power points,
ignition key must be at RUN position for the point to be energized.
“No satellite signal” appears
on the display at power up. GPS antenna cannot “see” the sky. Move vehicle to open area and make sure the GPS antenna
has a clear view of the sky.
System does not reflect
movement while driving. GPSis not working properly.
Turn unit off, then on to check for satellite signal. If the “no satellite
signal” message appears, go to the previous step. If the unit is
receiving a signal, go to the next step.
Vehicle motion is not
evident or the Map is blank.
Geographic area is not fully mapped. Drive to a main road. If the map shows the road, the system
is working properly, but the area is not fully mapped.
Map is zoomed in too far. Zoom out.
TR UBLESH TING
PR BLEM P SSIBLE CAUSE(S) S LUTI N(S)
WARRANTY
COBRA ELECTRONICS CORPORATION warrants that its Cobra
NAV ONE, and the component parts thereof will be free of defects
in workmanship and materials for a term of one year from the
date of first consumer purchase. This warranty may be enforced
by the first consumer purchaser, provided that the product is
used solely within the U.S.A and Canada.
Cobra will, without charge, repair or replace, at its option, defec-
tive NAV ONE products or component parts upon delivery to the
Cobra Factory Service Department, if accompanied by proof of the
date of first consumer purchase, such as a duplicated copy of a
sales receipt. The consumer must pay any initial shipping
charges required to ship the product for warranty service. Return
shipping will be at Cobra’s expense if the product is repaired or
replaced under warranty.
This warranty gives the consumer specific rights, and he or she
may also have other rights which vary from state to state.
EX C LU SI N S – T HI S LI M IT ED W A RR AN T Y
D ES N T AP PLY:
1. To any product damaged by accident;
2. In the event of misuse or abuse of the product or
as a result of unauthorized alterations or repairs;
3. If the serial number has been altered, defaced or removed;
4. If the owner of the product resides outside the U.S.A
and Canada.
All implied warranties, including warranties of merchantability
and fitness for a particular purpose are limited in duration to the
term of this warranty. COBRA SHALL NOT BE LIABLE FOR ANY
INCIDENTAL, CONSEQUENTIAL OR OTHER DAMAGES; INCLUD-
ING, WITHOUT LIMITATION, DAMAGES, RESULTING FROM LOSS
OF USE OR COST OF INSTALLATION. Some states do not allow
limitations on the duration of an implied warranty and/or do not
allow the exclusion or limitation of incidental or consequential
damages. Part or all of the above limitations may not apply to
some consumers.
13
Maintenance, FCC and Troub eshooting
14
Warranty
15
User License and Trademark Acknow edgement
NOTE
COBRA MA ES NO WARRANTY AS TO THE ACCURACY OR
COMPLETENESS OF THE MAP DATA UTILIZED IN THE NAV ONE
PRODUCTS AND DISCLAIMS ALL EXPRESS, IMPLIED OR
STATUTORY WARRANTIES, INCLUDING ANY IMPLIED OR
STATUTORY WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
It is the user’s responsibility to use this product prudently and responsibly.
This product is intended to be used only as a travel aid and must not be
used for any purpose requiring precise measurement of direction, dis-
tance, location and/or topography.
Shows route info
and options.
Nothing Comes Close to a Cobra®|English
P E RATIN G I N S TRU C T I N M ANU A L
NNAAVVOONNEE22110000
Printed in China
Part No.: 480-374-P
VersionA
USER LICENSE
This document and the software and data described in it are furnished under license
and may be used or copied only in accordance with such license. Except as permit-
ted by such license, the contents of this document, software and data may not be
disclosed to third parties, copied or duplicated in any form, in whole or in part, with-
out the prior written permission of Cobra Electronics Corporation. This document,
software and DATA contain proprietary and confidential information of Cobra
Electronics Corporation and its licensors.
Cobra grants the purchaser a limited license for use of this document, software and
data incorporated in the NAV ONE for personal use, and not for resale, sublicense or
commercial use. By using the NAV ONE, the purchaser agrees to be bound by the
terms and conditions of this license agreement. The purchaser acknowledges that
the content of this document, software and data are the property of Cobra and its
licensors and are protected by copyright laws of the USA and international treaties.
The purchaser agrees not to modify, decompile, disassemble, reverse engineer or
reduce to human readable form the software, DATA or any part thereof, nor to create
derivative works based on the contents of the document, software or data, nor
remove or obscure any copyright, trademark notice, or restrictive legend.
The purchaser agrees not to export or re-export this document or the NAV ONE to
any country in violation of the export control laws of the U.S.A.
The contents of this document, software and data are for informational use
only and are subject to change without notice. Cobra and its licensors intend to
provide their customers the most complete and accurate navigation information
available at a reasonable cost from government and private data sources. However,
all data sources have limitations and some have inaccuracies or are incomplete to
some degree. These characteristics carry over to the NAV ONE as well. As such,
COBRA AND ITS LICENSORS SHALL NOT BE LIABLE TO THE USER FOR ANY
INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT OR EXEMPLARY DAMAGES
ARISING FROM THE USE OF THE NAV ONE PRODUCT.
THE NAV ONE PRODUCT IS PROVIDED ON AN “AS IS” AND “WITH ALL FAULTS
BASIS” AND COBRA AND LICENSORS EXPRESSLY DISCLAIM ALL WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED
WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY, QUALITY, ACCURACY,
TITLE AND FITNESS FOR A PARTICULAR PURPOSE. NO ORAL OR WRITTEN
ADVICE OR INFORMATION PROVIDED BY COBRA AND/OR ITS LICENSORS OR ANY
OF THEIR AGENTS, EMPLOYEES OR THIRD PARTY PROVIDERS SHALL CREATE A
WARRANTY, AND USER IS NOT ENTITLED TO RELY ON ANY SUCH ADVICE OR
INFORMATION. THIS DISCLAIMER OF WARRANTIES IS AN ESSENTIAL CONDITION
OF THE AGREEMENT.
Cobra encourages customers to report any errors found in our electronic maps by
contacting technical assistance (available in English and Spanish) at product
i[email protected] (e-mail), by visiting our website: www. cobra.com, or by calling
customer assistance (available in English and Spanish) at 773-889-3087 between
8:00 a.m. and 6:00 p.m. Central Time, Monday through Friday (except holidays).
If End User is the United States Government, then use, reproduction or disclosure of
this commercial product and accompanying documentation may be subject to
DFARS 252.227-7014(a)(1); DFARS 227.7202-1; FAR 52.227-19; DFARS 252.227-
7015; FAR 52.227-14 Alternates I, II, and III; and/or FAR 12.211 and FAR 12.212 as
applicable and/or similar successor clauses in FAR, or the DOD or NASA FAR
Supplement.
TRADEMARK ACKN WLEDGEMENT
Cobra®, Intelligent Accelerated Satellite Acquisition Protocol (iASAP)
Technology®, Nothing Comes Close to a Cobra®and the snake design are
registered trademarks of Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™, Smart Power™, and NAV ONE™ are trade-
marks of Cobra Electronics Corporation, USA.
Windows®is a registered trademark of Microsoft Corporation
Tele Atlas®is a registered trademark of Tele Atlas, N.V.
Tele Atlas True Time Maps™ is a trademark of Tele Atlas, N.V.
All other product names are trademarks of their respective owners.
