Cobra GCT200P User manual

MODEL: GCT200P
GARDEN TROLLEY
OWNERS MANUAL
CAUTION:
Before using this product, please read this manual carefully to understand the proper use of your
garden trolley. Please keep this manual for future reference.
PLEASE NOTE: NEVER CARRY PASSENGERS IN THE GARDEN TROLLEY
Product colours may vary.

Safety Instructions
1. Read all the instructions carefully before use.
2. Do not load the trolley with more than 200kg. Do not use the tipping/dumping feature of the trolley
for more than 100kg.
3. Do not allow children to use the trolley unsupervised. This trolley is not a toy. Special care is
required when tipping loads.
4. Always distribute loads evenly over the surface of the bed of the trolley.
5. Do not load anything on the edges of the plastic tray.
6. Do not use if any parts of the trolley are damaged or broken.
7. Do not operate or use on ground that may damage the pneumatic tyres and wheels.
8. Please use a manual foot or hand pump to inflate tyres. Do not inflate tyres to more than 20 PSI
(137Kpa)
PLEASE NOTE: NEVER CARRY PASSENGERS IN THE GARDEN TROLLEY
Parts List
Assembly Instructions
Before assembling the tipping trolley please check all the parts and hardware, if anything is missing or
damaged, please contact your retailer.
Tools required: Screwdrivers, socket set and adjustable wrench.
Step 1
Assemble the lock frame to the tub using M8x18 bolts
(4pcs), washers (4pcs) and M8 lock nuts (4pcs).

Step 2
Assemble the legs to the tub using M8x18 bolts (4pcs),
washers (4pcs) and M8 lock nuts (4pcs).
Step 3
Assemble the frame and legs through the axle(1pc) .
Step 4
Assemble the wheels using flat washers (4pcs) and nuts (4pcs). Attach to the front axle support and
the Rear axle frame.
Step 5
Assemble the handle to the yoke using M8x60 bolt
(1pc), M8 lock nut (1pc) and washer (1pc).
Using the Tipping/Dumping feature
To operate this feature, pull the Tipping /dumping
release handle to release the plastic bed from the
locking mechanism. Lift up the release handle to raise
the trolley into the dumping position.

Returning the Plastic Bed to the lowered Position
Move the plastic bed back down to the lower position.
Make sure the release handle is locked into place when
the trolley is in the lowered position.
Caution: Do not exceed maximum overall load capacity of 200kgs. When the tipping
mechanism is being used, do not exceed dumping capacity of 100kgs.
Store your trolley
Covered or indoors
To prevent corrosion
And deterioration of
The plastic.
