Cobra CPP8000 User manual

CPP8000
User Manual
Portable Power - Anytime,Anywhere!
Thank for purchasing the Cobra CPP8000 JumPack™jump
starter portable PowerPack. Before using this product,
please read these instructions carefully to learn about the
features and capabilities of the JumPack and how you can
get the best out of it.
Note: Please charge your CPP8000 JumPack completely
prior to using it for the first time.
©2015 Cobra Electronics Corp. Part No. 480-1024-P Printed in China Version A
Charge the JumPack fully prior to use.
WARNING: Keep the unit clear of fire and water.
WARNING: Shock Hazard. Keep away from children. Do not
insert foreign objects into the jumper cables port/jack, the
USB output port, or the USB input jack. Do not expose this
product to water, rain, snow, condensation, or spray. Do not
open the JumPack to replace the internal battery. No user
replaceable parts are inside the JumPack.
WARNING: Explosion Hazard. Do not use this product where
there are flammable fumes or gases, such as an inadequately
vented bilge of a boat, or near propane tanks. Do not use this
product in an enclosure containing automotive-type lead-acid
batteries.
The jump start cable clamps must be connected positive to
positive (red clip to battery (+)) and negative to negative
(black clip to battery (-)). A reverse polarity connection
(positive to negative) may cause damage to the JumPack
and/or create a sparking/explosion hazard.
WARNING: Fire Hazard
Do not crush or puncture the JumPack. Never allow the jump start
cables’ red and black clamps’ metal contacts to touch each other
or another common metal conductor. This could cause damage to
the unit and/or create a fire hazard. Always disconnect the jump
start cables from the JumPack after each use and store separately.
The jump start feature is designed for short term operation only.
Turn the ignition key for no more than 3 seconds at a time.
Operating the jump start feature for more than 3 seconds may
cause damage to the unit. Allow the JumPack to cool down for
at least 1 minute after each jump start attempt.
IMPORTANT SAFETY INSTRUCTIONS Caution: Operating temperature
Do not expose the JumPack to temperatures over +113° F (+45° C) or
under -14° F (-10° C). Using the JumPack at high or low temperatures
may reduce the internal battery capacity and shorten the battery life.
Note: In extreme cold weather conditions, please bring the JumPack
indoors for best results.
Precautions when working with batteries
WARNING: Explosion and fire hazard
1.
Follow all instructions published by the battery manufacturer and
the manufacturer of the equipment in which the battery is installed.
2. Make sure the area around the battery is well-ventilated.
3. Never smoke or allow a spark or flame in the vicinity of the
engine or batteries.
4. Be careful not to drop a metal object on the battery or allow a
metal tool to simultaneously touch the positive and negative
cable ends or battery terminals.
5. Remove personal metal items such as rings, bracelets,
necklaces, and watches when working with batteries. Batteries
produce a short-circuit current high enough to weld a ring or
other similar objects to metal, causing a severe burn.
6. If you need to remove a battery, always remove the negative
terminal from the battery first. Make sure all accessories are
off so you don’t cause an arc.
7. Someone should be within range of your voice, or close
enough to come to your aid when you work near batteries.
8.
Have plenty of fresh water, soap and a supply of baking soda on
hand in the area of the batteries in case of contact with battery
acid. Baking soda neutralizes lead acid battery electrolyte.
9. The JumPack is supplied with a rechargeable Li-Cobalt battery.
This battery is self-contained and not consumer replaceable. Battery
must be disposed of properly when it no longer holds a charge.
Proper charging practices will increase the life of the batteries.
For
information on battery recycling call toll free 800-822-8837.
Product:
Battery Status Indicator Light Bar
Jump Starter Cable Input
DC 14V Charge Input
USB 5V 2.4
Amp Output
LED Flashlight
Power/Flashlight/Battery
Capacity Button
Car adaptor
Recharging the JumPack:
The CPP8000 JumPack can be recharged with the supplied 13.8V
DC vehicle charger or with the supplied micro USB to standard USB
cable connected to a 5V, 1A USB source, laptop or USB output AC
adapter (not included).
When the CPP8000 is charging; the light bar will show the current
battery life. The last section of the light bar that is lit will blink to
show that the JumPack is charging. When the JumPack is fully
charged the light bar will turn off automatically.
For best battery performance the JumPack should be fully
recharged every 3 months.
Operation:
Check Battery Capacity:
To check the battery capacity of the JumPack press the
Power/Flashlight button on the top of the unit with no device
connected. The green lightbar will show the remaining
battery capacity:
1st Section on: 10%-40% charge
2nd Section on: 40%-65% charge
3rd Section on: 65%-85% charge
4th Section on: 85%-100% charge
Note: When charging a device the section light may decrease
while the JumPack is in use. The battery capacity indicator
cannot accurately measure the capacity during rapid
charging. To confirm the real battery capacity, disconnect
the device being charged and press the power/flashlight/
capacity button.
Battery Status Indicator Light Bar
123 4
INPUT
14V 1A
OUTPUT
5V 2.4A
INPUT
5V 1.8A
USB 5V 1.8
Amp Input
Jumper cable
with clamps
Micro USB to
Standard USB
Cable
Checking the Fuse:
The jump cables are designed with an in-line fuse to protect the
jumpack in the event of an over-load condition. The jump cables
include a clear case to use in checking to be sure the in-line
fuse is intact:
Fuse Intact
CAUTION: Do not use the jump cables if the fuse appears
to opened or damaged. Please go to www.cobra.com for more
information.
5
Open or Damaged Fuse
CPP8000_MANL.indd 1 5/22/15 8:55 AM

INPUT
14V 1A
OUTPUT
5V 2.4A
INPUT
5V 1.8A
Product Specification:
• Li-Cobalt rechargeable battery: 11.1V/22.2Wh
• Size: 5.60” x 3” x 0.75”
(142mm x 76.2mm x 19.05mm)
• Weight: 10.58 oz. (300g.)
• Recharge times: 3 hours/13.8V DC
15 hours/5V USB
• Starting/Peak Current: 180 Amps/360 Amps
• USB Output: 5V 2.4 Amps
6
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/television technician
for help.
WARNING: Any modifications made to this device that are not expressly
approved by party responsible for compliance could void the user’s authority
to operate this device.
Cobra®and the snake design are registered trademarks of
Cobra Electronics Corporation, USA.
Cobra Electronics Corporation™ is a trademark of Cobra
Electronics Corporation, USA.
PROPOSITION 65 WARNING: This product contains a chemical known to
the State of California to cause cancer and birth defects or other
reproductive harm.
7
Limited 1-Year Warranty:
For Products Purchased in the U.S.A.
Cobra Electronics Corporation warrants that its Cobra CPP8000 JumPack
USB Charger, and the component parts thereof, will be free of defects in
workmanship and materials for a period of one year from the date of first
consumer purchase. This warranty may be enforced by the first consumer
purchaser, provided that the product is utilized within the U.S.A.
Cobra will, without charge, repair or replace, at its option, defective
USB charger, products or component parts upon delivery to the Cobra
Factory Service Department, accompanied by proof of the date of first
consumer purchase, such as a duplicated copy of a sales receipt.
You must pay any initial shipping charges required to ship the product
for warranty service, but the return charges will be at Cobra’s expense,
if the product is repaired, this warranty gives you specific rights, and
you may also have other rights which vary from state to state.
Exclusions: This limited warranty does not apply:
1. To any product damaged by accident.
2. In the event of misuse or abuse of the product, or as a result of
unauthorized alterations or repairs.
3. If the serial number has been altered, defaced or removed.
4. If the owner of the product resides outside the U.S.A.
All implied warranties, including warranties of merchantability and
fitness for a particular purpose are limited in duration to the length of
this warranty.
Cobra shall not be liable for any incidental, consequential or other
damages; including, without limitation, damages resulting from loss of
use or cost of installation.
Some states do not allow limitations on how long an implied warranty
lasts and/or do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you.
For Products Purchased Outside The U.S.A.
Please contact your local dealer for warranty information.
10
Product Service:
For any questions about operating or installing this new Cobra
product, or if parts are missing…PLEASE CALL COBRA
FIRST…do not return this product to the store. If this product
should require factory service, please call Cobra before sending the
product. This will ensure the fastest turn-around time on any repair.
If Cobra asks that the product be sent to its factory, the following
must be furnished to have the product serviced and returned:
1.
For Warranty Repair include some form of proof-of-purchase,
such as a mechanical reproduction or carbon of a sales receipt.
Make sure the date of purchase and product model number are
clearly readable. If the originals are sent, they cannot be returned;
2. Send the entire product;
3. Enclose a description of what is happening with the product.
Include a typed or clearly printed name and address of where
the product is to be returned, with phone number (required
for shipment);
4. Pack product securely to prevent damage in transit. If possible,
use the original packing material;
5.
Ship prepaid and insured by way of a traceable carrier such as
United Parcel Service (UPS) or Priority Mail with delivery
confirmation to avoid loss in transit to: Cobra Factory Service,
Cobra Electronics Corporation, 6500 West Cortland Street,
Chicago, Illinois 60707 U.S.A.;
6. If the product is in warranty, upon receipt of the product it will
either be repaired or exchanged depending on the model.
Please allow approximately 3 – 4 weeks before contacting Cobra
for status. If the product is out of warranty, a letter will
automatically be sent with information as to the repair charge or
replacement charge.
For any questions, please call 773-889-3087 for assistance or visit
us online at www.cobra.com.
FCC Statement:
• Lithium Cobalt rechargeable battery.
• 180 Amp Starting Current / 360 Amp Peak Current.
• 5V/2.4 Amp USB Output for rapid charging of portable devices.
• High Intensity work LED light.
• Rechargeable by 13.8 V DC car adapter or by 5V USB.
Product Features:
Starting a Vehicle:
1 .Make sure the JumPack is fully charged.
2. Turn off all the accessories on the vehicle.
3. Disconnect the battery cables from the JumPack.
4. Connect the RED clamp to the POSITIVE post of the battery.
5. Connect the BLACK clamp to the NEGATIVE post of the battery.
6. Connect the battery cables into the jump cable port.
Be sure that the plug is firmly pressed into the JumPack.
7.
Turn the ignition key to start the vehicle. Do not crank the
ignition for more than 3 SECONDS. If the engine is cranked
for more than 3 SECONDS, the fuse may open. See page 5to
see condition of fuse.
NOTE: If your car does not start after 3 attempts, consult with
a mechanic.
If the engine starts;
8. Disconnect the cables from the JumPack, then from the
battery posts.
9. Leave the engine running for at least twenty minutes to
allow the vehicle battery to recharge.
10. If the vehicle does not start on the first try, WAIT FOR
1 MINUTE before trying to start the vehicle again
.
NOTE: Go to www.cobra.com for instructional steps to
jumpstart a vehicle.
Charging a 5V USB Device:
To charge a 5V USB device, connect the devices’ cable to the
JumPack’s USB output. The JumPACK will turn on, and start
charging the device automatically. The light bar will indicate that
the device is charging.
LED Flashlight:
Press the Power/Flashlight/Battery capacity button for 3 seconds to
turn on the LED flashlight. Press and hold to turn flashlight Off.
8 9
START
INPUT
14V 1A
OUTPUT
5V 2.4A
INPUT
5V 1.8A
Customer Support & Trademarks:
Customer Support
Should there be any problems with this product or further information
needed on its features please visit www.cobra.com for support, frequently
asked questions, Declarations of Conformity, and the electronic manual.
For warranty and customer service information please contact the seller.
WEEE
For European Community Users
Cobra Electronics Corporation complies with Directive 2012/19/EU OF
THE EUROPEAN PARLIAMENT AND OF THE COUNCIL 4 JULY 2012 on
waste electrical and electronic equipment ( WEEE).
Waste Electrical and Electronic Equipment Information
This product has required the extraction and use of natural resources for
its production. It may contain hazardous substances that could impact
health and the environment, if not properly disposed. In order to avoid
the dissemination of those substances in our environment and to
diminish the pressure on the natural resources, we encourage you to use
the appropriate take-back systems for product disposal. Those systems
will reuse or recycle most of the materials of the product you are disposing
in a sound way.
The crossed out wheeled bin symbol informs you that the product
should not be disposed of along with municipal waste and invites you
to use the appropriate separate take-back systems for product disposal.
If you need more information on the collection, reuse and recycling
systems, please contact your local or regional waste administration.
You may also contact your supplier for more information on the
environmental performances of this product.
The product label is located on the bottom of the unit.
Trademark Statement
Cobra and the snake design are proprietary trademarks of Cobra Electronics
Corporation, USA.
11
CPP8000_MANL.indd 2 5/22/15 8:55 AM
