CoCo AMST-606 User manual

USER’S MANUAL
version 1.1
English
AMST-606 WIRELESS DOOR/WINDOW SENSOR

AMST-606 WIRELESS DOOR/WINDOW SENSOR
A: Part 1 magnetic
switch
B: Part 2 magnetic
switch
C: Battery
compartment
D: Mounting point
E: Switch time selector
C
E
A
B
DD
*
*Picture of an arbitrary COCO receiver
(not included)
1

AMST-606 WIRELESS DOOR/WINDOW SENSOR
2
[1] Slide open the battery compartment and place
a battery in the recess of the battery holder with
the "+" pole face up. Now slide the holder back into
the product.
[2] Turn the switch time selector to the "0" position.
Only after a connection is made with the
receiver (see [4]) can another switch time be
selected!

AMST-606 WIRELESS DOOR/WINDOW SENSOR
[3] Activate the automatic search mode of the
COCO receiver (see the corresponding manual).
The figure shows the AC-1000 mains socket
switch (not included)!
This product only works with receivers that
automatically program themselves with the
transmitter code!
[4] Set both parts against one another so the
arrows point toward each other. Now pull the parts
away from each other to send an "on" signal.
To confirm, the receiver switches on and off two
times!
3

AMST-606 WIRELESS DOOR/WINDOW SENSOR
4
[5] If desired, set a different "switch off" time:
“0”: The off signal is sent as soon as the two parts
are put against one another again.
“2m”: The off signal is sent after approx. 2
minutes, regardless of whether or not the
door/window is open or closed.
“4m”: The off signal is sent after approx. 4 minutes
etc.
[6] Attach one of the parts to the door or window
and the other to the frame. The arrows on the two
parts must point toward each other. Attach the
parts with as little space between them as
possible.
When the door/window is closed, the space
between the parts must be less than 1.5 cm!

AMST-606 WIRELESS DOOR/WINDOW SENSOR
Remarks
Reminders
• This product must be used in combination with at least one COCO receiver. The receivers that are used
must automatically program themselves with the transmitted code (see manual of the concerned
receiver). Receivers on which the letter code ("house code") must be programmed manually are not
suitable for use with this product.
• With this transmitter/magnetic switch, multiple receivers can be operated both simultaneously and
independently.
• To prevent interference, avoid placing multiple products close to each other. The minimum distance
between units should be approx. 50 cm.
• If the product does not work or does not work properly:
- Check the correct placement and/or function of the battery (replace if necessary).
- Check step for step whether the concerned receiver is programmed properly (see the manual for the
receiver in combination with steps [2 – 4] of this manual).
- Make sure the distance between the parts does not exceed 1.5 cm when the door or window is closed.
- Set the switch time to a lower value (see [5]).
Safety instructions
• Do not expose this product to excessive heat, direct sunlight or moisture.
• Remove the battery from this product if it will not be used for an extended period.
• Do not attempt to repair this product. If the product is damaged or if you are in doubt about the proper
operation, take the product back to the place of purchase.
• Never use COCO products for life support systems or other applications in which equipment
malfunctions can have life-threatening consequences.
• Do not use the product in damp areas. Clean the device with a clean cloth.
Power
• Replace the battery if the concerned receiver no longer responds when the door or window is opened or
closed.
• Only use a 3 Volt CR2032 lithium battery.
5

AMST-606 WIRELESS DOOR/WINDOW SENSOR
6
• Do not throw the battery into an open fire.
• Respect the local regulations when disposing of batteries.
Wireless
• This product works using a radio signal that passes through walls, windows and doors. The range is
maximum 75 metres in the open air. The range indoors is strongly influenced by local conditions such
as concrete, glass and metals. On average, the indoor range is approximately 30 metres.
• New double glass often includes a thin metallic layer. This type of glazing (“HR glass”) allows most
visible light to pass through but has a negative impact on radio signals. If there is HR glass between the
transmitter and receiver, you should expect a significant reduction of the range of the wireless signal.
• This product operates at a frequency of 433.92 MHz. It complies with the essential requirements and
other conditions of R&TTE Directive 1999/5/EC and can be used in all EU countries.
• There may be restrictions on the use of this device outside the EU. If this device is used outside the EU,
check whether the device complies with the local directives.
This product complies with the essential requirements and other relevant provisions of the applicable
European directives. The Declaration of Conformity (DoC) is available at www.coco-technology.com.
If possible, submit this product for recycling after use. Do not dispose of the product with household trash.
Warranty and copyright
This device is covered by a 2-year warranty that begins on the day of purchase. Visit www.coco-
technology.com/warranty for additional information. Reprinting of (portions of) this manual without
permission from Pan-Trade International B.V. is expressly prohibited.

AMST-606 WIRELESS DOOR/WINDOW SENSOR
PAN-TRADE INTERNATIONAL B.V.
P.O. BOX 126
4760 AC ZEVENBERGEN
THE NETHERLANDS
www.coco-technology.com
7
Declaration of Conformity
Pan-Trade International BV declares that the COCO product, model:
type designation AMST-606 WIRELESS DOOR/WINDOW SENSOR
item number 74018
is in compliance with the essential requirements and other relevant provisions of directives R&TTE
1999/5/EC, EMC 2004/108/EC and LVD 2006/95/EC and is compatible with the standards EN 300 220-
1/3, EN 55015, EN 301 489-1/3 and EN 60950.
Manufacturer / Authorised representative,
M.A. Hoekstra, managing director
Zevenbergen, 2008-01-30
