Cocraft LS5T User manual

Important!
Read the entire instruction manual
carefully and make sure that you fully
understand it before you use the
equipment. Keep the manual for future
reference.
Viktig information:
Läs hela bruksanvisningen noggrant och
försäkra dig om att du har förstått den
innan du använder utrustningen. Spara
bruksanvisningen för framtida bruk.
Viktig informasjon:
Les disse anvisningene nøye og forsikre
deg om at du forstår dem, før du tar
produktet i bruk. Ta vare på anvisningene
for seinere bruk.
Tärkeää tietoa:
Lue nämä ohjeet huolellisesti ja varmista
että olet ymmärtänyt ne, ennen kuin
alat käyttää laitetta. Säilytä ohjeet
myöhempää tarvetta varten.
Wichtiger Hinweis:
Vor Inbetriebnahme die komplette
Bedienungsanleitung sorgfältig
durchlesen und aufbewahren.
Ver. 20200324
Original instructions
Bruksanvisning i original
Originalbruksanvisning
Alkuperäinen käyttöohje
Original Bedienungsanleitung
Art.no Model
41-2361 LS5000/520C-S
LS5T 5T
41-2361
LOG SPLITTER
VEDKLYV VEDKLØYVER
HALKOMAKONE HOLZSPALTER
SPLITTING LENGTH: 15-52 CM
ENGLISH
SVENSKANORSKSUOMI
DEUTSCH

2
ENGLISH
Cocraft 5-Tonne Log Splitter
Art. no 41-2361 Model LS5000/520C-S
Please read theentire instruction manual before using theproduct and then save it for future reference.
We reserve theright for any errors in text or images and any necessary changes made to technicaldata.
In theevent of technical problems or other queries, please contact our Customer Services
(see address details on theback).
Warning:
When using this product, thesafety instructions included in this manual should always be followed to avoid
therisk of fire, electric shock, and personal injury.
Warning: Electric shockrisk.
Warning: Risk of crushing. Keephands well away from any moving parts during theentire
splitting operation.
Warning: Risk of crushing. Always pay attention to themovement of theram.
Warning: Objects ejected by theproduct can hit theoperator or other persons in thevicinity and
cause damage to property. Keepchildren and bystanders at asafe distance from theworkarea.
Neverallow another person to help you free ajammedlog. Ifpersons under 18 years of age are
to operate thelog splitter, they must be instructed in thesafe use of theproduct and understand
thehazards involved. Persons under 18 years of age must be supervised by anadult whilst operating
thelog splitter.
Make sure that you have read and understood theentire instruction manual before using theproduct.
Use protective eyewear and hearing protection.
Always unplug themains lead from thewall socket before servicing or making any adjust-
ments to theproduct.
Product safety symbols
Bleed Screw

3
ENGLISH
Warning: None of thesafety devices on theproduct must be modified in anyway.
Wear protective gloves.
Wear non-slip safetyshoes.
Switch off and unplug theproduct whenever it is not in use and before it is cleaned or serviced.
Warning: Always work alone with thelog splitter. Twopeople must not operate thelog
splitter at thesametime.
Warning: Never use theproduct in therain or in wet conditions.
General safety instructions
1. Keeptheworking area tidy. Cluttered surfaces and benches invite accidents.
2. Donot use themachine in dangerous environments. Themachine should not be used on moist or wet
surfaces or in rain. Makesure that thework area is well lit. Whenworking in dusty atmospheres, make
sure that theair is adequately circulated. Donot operate power tools in explosive atmospheres, such as in
thepresence of flammable liquids, gases ordust.
3. Avoidelectric shocks. Avoidbody contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators when using powertools.
4. Keepchildren and bystanders away. Keepchildren and visitors at asafe distance from electrical machi-
nery/tools and electric cables in theworkplace.
5. Storepower tools out of thereach of children. Whennot in use, power tools should be stored locked
away in asafe place, away from children.
6. Donot force themachine. Thecorrect feed rate makes thework better andsafer.
7. Usethecorrect tool for thejob. Donot force atool to perform atask that it was not designed for.
8. Wearsuitable attire. Donot wear any loose-fitting clothing, gloves, necklaces, bracelets or other jewellery
that can get caught in moving parts. Non-slip footwear is recommended. Wearahairnet or similar if you have
longhair.
9. Alwayswear safety glasses. Normalglasses are not tough enough to withstand impacts. Useadust mask
or dust filter when working in dusty environments.
10.Connect dust extraction equipment. Ifthemachine is equipped with dust extraction equipment, ensure
that it is connected and used properly. Makesure to empty thedust bag regularly.
11.Donot abuse themains lead. Donot carry themachine by its mains lead. Donot yank themains lead to
turn thepower off, pull theplug out instead. Makesure that themains lead does not come into contact with
heat, oil, or sharpedges.
12.Securetheworkpiece firmly. Wherepossible, use clamps or avice. Youcan then operate thetool using
two hands. Thisis much safer than holding theworkpiece in onehand.
13.Donot overreach. Makesure that you stand steady and balanced alltimes.
14.Lookafter your tools. Keepblades sharp and clean for thebest and safest performance. Followtheinstruction
manual’s recommendations regarding lubrication and replacement of accessories. Inspect themains lead regularly.
Ifit is damaged it should be replaced by aqualified service technician. Inspect all leads and cables regularly to check
for any damage. Makesure that themachine’s handles and controls are clean, dry and free from oil and grease.
15.Turnthepower off. Pullout theplug and push in theemergency stop button before servicing or changing
any blades, drill bits, cutters or sanding discs.

4
ENGLISH
16.Removeall spanners and repair tools. Makeahabit of checking to make sure that themachine is free of
all spanners and tools before turning thepoweron.
17.Avoidaccidental starts. Donot walk around with your finger on thetrigger of apower tool if it is plugged in.
Makesure that theon/off switch is set to OFF before plugging in any powertool.
18.Usethecorrect extension leads. Ifyou use extension leads outdoors, only use those designed for outdoor
use. Onlyuse extension leads with thick enough diameter core wires and roll out thewholelead.
19.Usecommon sense and be careful. Thinkcarefully before carrying out every action, so that it is carried out
safely. Neveroperate machines/power tools when you are tired or under theinfluence of medicine.
20.Inspect thetool for damage. Beforestarting thetool, make sure that theguards and other parts are unda-
maged and working properly, that moving parts can rotate freely and are correctly aligned, that no moving
parts can get caught and that there is no fault or defect that could affect theperformance of themachine.
Asafety guard or any other part that is damaged should be repaired by atradesman or replaced. Damaged
power leads and switches must always be replaced by atradesman. Neveroperate atool if you cannot stop
or start thetool comfortably.
21.Useonly recommended accessories. Theuse of non-recommended accessories can cause accidents
and personal injury.
22.Repairs should only be carried out by aqualified repair person using genuine identical replacement parts.
23.Allpower tools should be connected to themains via aportable residual current device (PRCD).
Theproduct must not be modified or used for any other purpose than that for which it has been designed.
Regularly check that all screws and nuts are securely tightened.
Specic safety instructions for log splitters
• The log splitter is only intended to be used by one operator at atime. Thelog splitter must not be operated
by more than one person at atime.
• Locate thelog splitter on dry, level ground which is not slippery.
• Make sure that branches are cut off flush with thelog before splitting.
• Save theinstruction manual, make sure that it accompanies thelog splitter if it is borrowed.
• Split wood in thedirection of thegrain. Donot attempt to split wood across thegrain.
• Read thewarning labels on thelog splitter and make sure that they are legible.
• Make sure that theelectrical socket you intend to use has thecorrect voltage (230 V) before connecting
thelog splitter.
• Never attempt to adjust theforce setting yourself. Thelog splitter is pre-set at thefactory for amaximum
splitting force of 6 tonnes.
• Tampering with thepressure settings can lead to diminished performance and damage to themachine and
result in serious person injury.
• Do not attempt to split two logs at thesametime.
• Never attempt to right aleaning log with your hand whilst theram is in motion. Stopthemachine and move
thelog so that it is standing vertically.
• Never attempt to hold alog with your hand whilst theram is in motion.
• If alog jams or fails to be split because it exceeds thecapacity of theram, release both control levers and let the
ram return to its original position, otherwise there is arisk that themotor will become damaged by overheating.
• Switch off thelog splitter and disconnect it from themains supply whenever you take abreak and before
starting any maintenance procedures. Makesure that log splitter cannot be started by any children or unaut-
horised person.
• Make sure that all thesafety features on thelog splitter are correctly fitted and functioning properly.
• Wear safety glasses, ear defenders and safety shoes if necessary.
• Always stand in such away that you can perform all work tasks whilst maintaining good balance and grip
thecontrol levers in bothhands.
• Keep your hands and fingers well away from theand splitting wedge. Whenoperating machines, always use
your common sense and be careful.
• Make sure that there are no bystanders or pets close to themachine, sharp splinters can be ejected by
theblade with greatforce.
• Connect thelog splitter to awall socket via anRCD.
• Never use thelog splitter in therain or wet conditions.

5
ENGLISH
• Never use thelog splitter if thepower switch, plug, mains lead or any other part is damaged.
Thedefective part must be replaced by aqualified repair person.
• Make sure that this instruction manual always accompanies theproduct and that it is kept accessible and legible.
• Make sure that everyone who uses theproduct has read and understood theentire instruction manual.
• Always be alert and careful when operating theproduct. Thinkcarefully before carrying out every action, so
that it is carried out safely. Neveruse theproduct when you are tired, sick or under theinfluence of alcohol,
drugs or medicine.
Other safety symbols
Warning: Do not overreach. Keepproper footing and balance at alltimes. Neverstack your
logs in such away that you need to stretch to reachthem. Onlyuse your hands to operate
thelog splitter. Neveruse other parts of thebody or devices which could enable your hands
to become crushed between thesplitting wedge and thelog. Payattention to themove-
ment of thehydraulic ram at alltimes. Neverstack logs on top of each other and try to split
two atonce. Neverattempt to load alog into thelog splitter while theram is in motion.
Keephands away from movingparts.
Warning: Keep your hands clear of theram when it is returning after it has split thelog.
Thelog splitter is designed to stop only when theram has returned to its original position.
Keepyour hands away from any splits and cracks which open inlogs. Theymay close
suddenly which could cause serious personal injury. Neverattempt to remove jammed logs
byhand.
Consider theenvironment, dispose of waste oil in accordance with local regulations.
Make sure that thelog splitter is undamaged, that none of thesafety features are missing and
that they are fitted correctly and working. Neveroperate thelog splitter if any of thesafety
features is damaged or missing. Checktheoil level before starting thelog splitter.

6
ENGLISH
AE
BF
C
D
G
1
8
2
9
3
10
4
11
5
12
6
13
14
15
7
Bolt M6 x 14 2 pcs
Washer M6 2 pcs
Nut M6 2 pcs
Washer M8 90 pcs
Lock nut M8 44 pcs
Bolt M8 x 45 14 pcs
Bolt M8 x 16 28 pcs
Coach bolt M8 x 45 4 pcs
Washer 14 6 pcs
Coach bolt M8 x 40 2 pcs
Locking knob 2 pcs
R-clip 2 pcs
Axel 2 pcs
Spanner 2 pcs
Spare gasket for
oil dipstick 1pcs
H
I
J
K
L
M
O
Q
R
S
P
N
H Wheeled left support legs x 2
I Wheels x 2
J Cross member
K Upper guard
L Rear guard
M Splitting wedge
N Rear log retaining plate
O Front log retaining plate
P Log splitter leg
Q Right support leg upper sections x 2
R Right support leg lower sections x 2
S Handle
A End guard
B Control lever guard
C Control lever
D Power switch
E Front guard
F Log collector table
G Electric motor
Product description

7
ENGLISH
5 4 4 6
Q
R
I 9 139912H 4 6J
8
5
S 11
8
5 4 4 6 5 4 4 6
A End guard
B Control lever guard
C Control lever
D Power switch
E Front guard
F Log collector table
G Electric motor
Assembly
Important
Always get someone to help you assemble thelog splitter. Thelog splitter is heavy and it will be easier and
safer if two people carry out theassembly.
When splitting logs however, you must always operate thecontrols of themachine by yourself. Twopeople
must never operate themachine at thesametime.
1. Wheeled left support legs
2. Right support legs 3. Handle
4. Attaching thesupport legs to thelog splitter
Turn thelog splitter upside down and bolt thelegs ontoit.

8
ENGLISH
4 4 7
7
4
4
5
K E
A
5 4 4 7
L
5. Turn thelog splitter over so that it is standing on itslegs. Attach thetwo log retaining plates, front andrear.
7. Assembling thelog splitter guard
8. Attaching theguard to thelog splitter
6. Control lever

9
ENGLISH
1 2 2 3
10
7
7
4
4
4
5
4
4
5
5
Instructions for use
Handle
1. The handle can be raised to make it easier to move thelog splitter.
10. Attaching thecollector table
2. Undo thetwo locking knobs and
remove thecoachbolts.
3. Lift thehandle up until theholes in theend line up with
thelower holes in thelegs, refit thecoach bolts and tighten
thelockingknobs.
9. Attaching thecontrol lever guard

10
ENGLISH
Before starting
• The log splitter should be placed on afirm and level surface.
• Inspect thelog splitter to make sure that all nuts and bolts are securely tightened and that there is no visible
damage to themains lead, theplug or thepower switch.
• Connect themains lead to anearthed wall socket. Thewall socket should be protected by aresidual current
device (RCD) with anactuating current of 30mA. Donot route themains lead where it could be damaged or
where someone could trip overit.
Splitting a log
• Always place theleast knotty end of thelog toward
thewedge, always split along thegrain.
• Lay thelog as stably as possible between thelog
retaining plates.
• Start themotor by pressing and holding in the
power switch.
• Start thehydraulic ram by depressing thecontrollever.
• The hydraulic ram will now force thelog against
thesplittingwedge.
• Release thecontrol lever and thepower switch to
discontinue thesplitting operation, thereturn springs
will now return theram to its starting position.
Important: If thewood does not start to split after 5 seconds despite full pressure: release thecontrol lever
and thepower switch and let theram return to thestarting position. Turnthelog through 90 degrees and try to
split itagain.
Important: Unscrew thebleed screw 3 or 4 turns
to ensure adetectable flow of air to theoil tank while
thelog splitter is in operation.
