Code 3 Cw300x User manual

Page 1 of 8

Installation and Operation Instructions

Specications:

CW300X

Peak current draw: 1.7A @ 12VDC

Max power: 23.2W @ 12VDC

CW301X

Peak current draw: 2.7A @ 12VDC

Max power: 37.5W @ 12VDC

REMOTE SPOTLIGHT

IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user. CODE 3 is not

responsible for the misuse of products by un-authorized personnel.

WARNING!

Failure to install or use this product according to manufacturer’s recommendations may result in property damage, serious injury, and/

or death to those you are seeking to protect!

Do not install and/or operate this safety product unless you have read and understood the safety information

contained in this manual.

1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to

ensure the safety of emergency personnel and the public.

2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical

connections.

3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,

which can cause personal injury and/or severe vehicle damage, including re.

4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of

the system is maximized and the controls are placed within convenient reach of the operator so that they can operate the system without

losing eye contact with the roadway.

5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator

should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors),

people, vehicles or other obstructions.

6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal.

Never take the right-of-way for granted. It is the vehicle operator’s responsibility to be sure they can proceed safely before entering an

intersection, drive against tra󰀩c, respond at a high rate of speed, or walk on or around tra󰀩c lanes.

7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws

regarding emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The

manufacturer assumes no liability for any loss resulting from the use of this warning device.

Page 2 of 8

Installation & Mounting:

Permanent Mounting:

1. Select a level surface for installation.

2. Drill mounting holes using the base as a template and attach with included hardware.

Carefully remove the unit from its packaging. Examine the unit for transit damage. If damage is found, return the product to your local dealer for war-

ranty replacement. Do not use damaged or broken parts.

Wiring:

The wiring for this conguration is as shown in Figure 1 below. All wiring should be a minimum of 18AWG. The positive line must have a 5 amp

fuse, as shown. Routing the ground wire directly back to negative battery terminal is recommended. Pack dielectric grease, such as Dow Corning 4,

around each electric connection exposed to moisture or the ambient environment.

GROUND 5 AMP FUSE

BLACK WIRE

RED WIRE

Notes:

1. Larger wires and tight connections will provide longer service life for components. For high current wires it is highly recommended

that terminal blocks or soldered connections be used with shrink tubing to protect the connections. Do not use insulation displacement

connectors (e.g., 3M Scotchlock type connectors).

2. Route wiring using grommets and sealant when passing through compartment walls. Minimize the number of splices to reduce voltage

drop. All wiring should conform to the minimum wire size and other recommendations of the manufacturer and be protected from moving

parts and hot surfaces. Looms, grommets, cable ties, and similar installation hardware should be used to anchor and protect all wiring.

3. Fuses or circuit breakers should be located as close to the power takeo󰀨 points as possible and properly sized to protect the wiring and

devices.

4. Particular attention should be paid to the location and method of making electrical connections and splices to protect these points from

corrosion and loss of conductivity.

5. Ground termination should only be made to substantial chassis components, preferably directly to the vehicle battery.

6. Circuit breakers are very sensitive to high temperatures and will “false trip” when mounted in hot environments or operated close to their

capacity.

CAUTION!

When drilling into any vehicle surface, make sure that the area is free from any electrical wires, fuel lines, vehicle upholstery, etc. that

could be damaged.

IMPORTANT! Disable power before wiring the product.

CW300X CW301X

Figure 1

Page 3 of 8

Wireless Remote: Pairing and Programming

1. All remotes operate at 433.92MHz. Operating more than one wireless

remote in close range will cause interference with other units if paired

incorrectly.

2. Power o󰀨 the spotlight by removing the fuse or disconnecting from

main power. Install the fuse or reconnect to main power, the press the

▲ and ▼ buttons simultaneously within 5 seconds.

3. When programming is successful, the spotlight will ash 1 to 4 times.

Each ash represents which memory slot the wireless remote is

programmed to.

4. One wireless remote can be programmed to 4 spotlights. The

spotlight will remember up to 4 wireless remotes.

5. To program more than one remote, follow existing steps to pair remote

within initial 5 seconds of power up.

6. Each unit can be controlled by a single remote if the single remote is

paired through all four channels as directed above. This means one

vehicle can control up to 4 spotlights with four di󰀨erent remotes.

7. The optional in-dash controller will override the wireless remote.

8. In open air with full powered 23A batteries, the wireless remote will

have a 65M range.

NOTE: The light beam direction is adjustable while the spotlight is o󰀨.

Remote Control Operation for CW300X:

LIGHT BEAM

DIRECTION OPERATION

EW300X: STROBE ON/OFF

CW301X: SPEED FAST/SLOW

ON/OFF

BUTTON

Remote Control Operation for CW301X:

LED INDICATOR:

WHEN ANY BUTTON IS PRESSED, THE LED

INDICATOR WILL BE ON TO SHOW IT IS

TRANSMITTING SIGNALS, GREEN LED

MEANS SUFFICIENT BATTERY POWER, RED

LED MEANS POWER LOW, SUGGEST TO

CHANGE BATTERY.

ON/OFF

BUTTON

Page 4 of 8

Joystick Control Operation for CW301X:

Wired Dash Mount Joys�ck Control

LED Power Indicator:

This LED power indicator will be

steady on when main power is on

to show the light is power on

and

is able to rotate or lt.

Joysck Funcons:

1. Direcons: Up, Down, Le, Right

Switch the joysck to above direcns to rotate or lt the light.

2. Main Power:

Push the switch to the icon once, power will be on, the light is able to rotate or t

(LED will not be on), press one more  power will be o, the light will rotate to

the front and lt all the way down (return to home posion).

3. Fast/Slow:

Push the switch to the icon to switch movement speed.

4. LED on/o:

When main power is on, the LED light can be turn on or oby pushing the switch to

the icon.

5. Strobe:

When LED light is on, push the switch to the icon to let LED sh as warning signal.



Page 5 of 8

Replacement Parts and Accessories:

Description Part No.

Replacement Remote (For use with CW3000 & CW3001 CR3010

Replacement Remote (For use with CW3010 & CW3011) CR3011

Flood Di󰀨user (For use with CW3010/11) CZ3010F

Colored Lens (For use with CW3010/11) CZ3010X*

In-Dash Joystick Controller (For use with CW3010/11) CZ3011

5 Meter Joystick Cable (For use with CZ3011) CZ3012

5 Meter Joystick Cable Extension (For use with CZ3011) CZ3013

Magnet Mount Kit, Black (For use with CW3000) CZ3014

Magnet Mount Kit, White (For use with CW3001) CZ3015

Magnet Mount Kit, White (For use with CW3011) CZ3016

Magnet Mount Kit, Black (For use with CW3010) CZ3017

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may

not cause harmful interference, and (2) this device must accept any interference received, including interference that may

cause undesired operation.

*X indicates color: A=Amber, R=Red, and G=Green

Page 6 of 8

Notes:

Page 7 of 8

Notes:

Page 8 of 8

Manufacturer Limited Warranty Policy:

Manufacturer warrants that on the date of purchase this product will conform to Manufacturer’s specifications for this product (which are

available from the Manufacturer upon request). This Limited Warranty extends for Sixty (60) months from the date of purchase.

DAMAGE TO PARTS OR PRODUCTS RESULTING FROM TAMPERING, ACCIDENT, ABUSE, MISUSE, NEGLIGENCE, UNAPPROVED MODIFICA-

TIONS, FIRE OR OTHER HAZARD; IMPROPER INSTALLATION OR OPERATION; OR NOT BEING MAINTAINED IN ACCORDANCE WITH THE

MAINTENANCE PROCEDURES SET FORTH IN MANUFACTURER’S INSTALLATION AND OPERATING INSTRUCTIONS VOIDS THIS LIMITED

WARRANTY.

Exclusion of Other Warranties:

MANUFACTURER MAKES NO OTHER WARRANTIES, EXPRESS OR IMPLIED. THE IMPLIED WARRANTIES FOR MERCHANTABILITY, QUALITY

OR FITNESS FOR A PARTICULAR PURPOSE, OR ARISING FROM A COURSE OF DEALING, USAGE OR TRADE PRACTICE ARE HEREBY

EXCLUDED AND SHALL NOT APPLY TO THE PRODUCT AND ARE HEREBY DISCLAIMED, EXCEPT TO THE EXTENT PROHIBITED BY APPLI-

CABLE LAW. ORAL STATEMENTS OR REPRESENTATIONS ABOUT THE PRODUCT DO NOT CONSTITUTE WARRANTIES.

Remedies and Limitation of Liability:

MANUFACTURER’S SOLE LIABILITY AND BUYER’S EXCLUSIVE REMEDY IN CONTRACT, TORT (INCLUDING NEGLIGENCE), OR UNDER ANY

OTHER THEORY AGAINST MANUFACTURER REGARDING THE PRODUCT AND ITS USE SHALL BE, AT MANUFACTURER’S DISCRETION, THE

REPLACEMENT OR REPAIR OF THE PRODUCT, OR THE REFUND OF THE PURCHASE PRICE PAID BY BUYER FOR NON-CONFORMING

PRODUCT. IN NO EVENT SHALL MANUFACTURER’S LIABILITY ARISING OUT OF THIS LIMITED WARRANTY OR ANY OTHER CLAIM RELAT-

ED TO THE MANUFACTURER’S PRODUCTS EXCEED THE AMOUNT PAID FOR THE PRODUCT BY BUYER AT THE TIME OF THE ORIGINAL

PURCHASE. IN NO EVENT SHALL MANUFACTURER BE LIABLE FOR LOST PROFITS, THE COST OF SUBSTITUTE EQUIPMENT OR LABOR,

PROPERTY DAMAGE, OR OTHER SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES BASED UPON ANY CLAIM FOR BREACH OF

CONTRACT, IMPROPER INSTALLATION, NEGLIGENCE, OR OTHER CLAIM, EVEN IF MANUFACTURER OR A MANUFACTURER’S REPRESEN-

TATIVE HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. MANUFACTURER SHALL HAVE NO FURTHER OBLIGATION OR

LIABILITY WITH RESPECT TO THE PRODUCT OR ITS SALE, OPERATION AND USE, AND MANUFACTURER NEITHER ASSUMES NOR

AUTHORIZES THE ASSUMPTION OF ANY OTHER OBLIGATION OR LIABILITY IN CONNECTION WITH SUCH PRODUCT.

This Limited Warranty defines specific legal rights. You may have other legal rights which vary from jurisdiction to jurisdiction. Some

jurisdictions do not allow the exclusion or limitation of incidental or consequential damages.

Product Returns:

If a product must be returned for repair or replacement*, please contact our factory to obtain a Return Goods Authorization Number (RGA

number) before you ship the product to Code 3®, Inc. Write the RGA number clearly on the package near the mailing label. Be sure you use

sufficient packing materials to avoid damage to the product being returned while in transit.

*Code 3®, Inc. reserves the right to repair or replace at its discretion. Code 3®, Inc. assumes no responsibility or liability for expenses incurred for the removal and /or reinstallation of products requiring service and/or repair.; nor for the packaging,
