Lumascape Centria C4 LS1010 Configuration guide

1ARCHITECTURAL & FACADE LIGHTING | lumascape.com
READ ALL SAFETY INSTRUCTIONS FIRST
›Follow instructions carefully, failure to do so will void warranty.
›Ensure installation complies with local law and applicable standards.
›Input voltage: Line Voltage 120/277 Vac, 60 Hz
Low Voltage 30 to 48 Vdc
›Only use Lumascape power supply, control equipment and leader
cables.
›Ensure mains input power is surge protected.
›Never make connections whilst the power is connected.
›Do not make modications or alter the product.
›Keep luminaire and connections clean and free of debris and moisture.
›It is the installers responsibility that the installation is adequately
sealed to avoid moisture ingress.
WARNING
Install in accordance with
National Electric Code, ANSI/NFPA 70 or
the Canadian Electrical Code,
Part I (CEC), CSA C22.1
Centria C4 Surface-Mounted Spotlight LS1015
Products and specications are subject to change without notice.
IN0182US-230516

lumascape.com
ARCHITECTURAL & FACADE LIGHTING
23
Open Luminaire
Loosen the four screws and remove
the lid and open the luminaire.
Drill the hole for the gland.
Use a 16mm drill bit to drill the
gland hole.
In the base drill out gland holes as
required.
Install Gland
To Light
Engine
Ø16mm
Drill Bit
To Light
Engine
Feed supply cable through
gland and tighten. Outer
diameter of cable should
be Ø5-10mm
O-Ring
To Light
Engine
Outer Cable
Ø5-10mm
Centria C4 Surface-Mounted Spotlight LS1015

lumascape.com
ARCHITECTURAL & FACADE LIGHTING
23
Connect the supply cable to the
terminal block. Refer to table
below for conductor colour and
designation.
Re-attach lid to base, making sure the seal is correctly placed between the two components.
Bolt luminaire to mounting surface making sure the
gasket seal is inserted between the mounting surface
and the wall.
Connect Supply Cable Mount Base to Wall
Close Luminaire
Seal
Gasket
Seal
To Light Engine
Conductor
colours
shown are for
a standard
Lumascape
leader cable.
To Light Engine
Centria C4 Surface-Mounted Spotlight LS1015

lumascape.com
ARCHITECTURAL & FACADE LIGHTING
4PB
Using an Allen key adjust the luminaire’s tilt and rotation.
Loosen the screws to adjust and tighten to lock luminaire into place.
Luminaire Tilt
Luminaire Rotation
Centria C4 Surface-Mounted Spotlight LS1010
Aim Luminaire
Wiring Designation
Low Voltage 30 to 48 Vdc
Designation Color
+ DC Red
– DC Black
Data Orange
Line Voltage 120/277 Vac – North America
Designation Color
Line Black
Neutral White
Ground/Earth Green / Yellow
Data Orange or Red
