Light Sky AURORA User manual

AURORA
Please read these user manual carefully before use!
E-mail:
n
Add:No.51 Yunfeng Rd,Xinhua Industrial Zone,Xinhua Street,
Huadu District,Guangzhou,China.

Congratulations on choosing our company product! We thank you for your custom.
◆Please note that this product, as all the others in the rich my company range, has
been designed and made with total quality to ensure excellent performance and
best meet your expectations and requirements.
◆Carefully read this user manual in its entirety and keep it safe for future reference.
It is essential to know the information and comply with the instructions given in this
manual to ensure the fitting is installed, used and serviced correctly and safely.
◆My company disclaims all liability for damage to the fitting or to other property or
persons deriving from installation, use and maintenance that have not been carried
out in conformity with this user manual, which must always accompany the fitting.
◆My company reserves the right to modify the characteristics stated in this user
manual at any time and without prior notice.
Contents
1.Safety information.......................................................................................................2
2. Technical information...................................................................................................4
3. Attachment and body size.........................................................................................7
4. Installation and connecting.......................................................................................8
5. Control panel..............................................................................................................11
6. Menu setting...............................................................................................................12
7. Channel function.........................................................................................................17
8. Circuit connecting diagram.......................................................................................25
9. Cleaning and maintenances.......................................................................................26
10.Troubeshooting..........................................................................................................26
11.Duty exonerative and copyright protection............................................................28

■ Connection to mains supply
The double insulation between the LV power supply and the control conductor on the fixture.
SAFETY INFORMATION
2
■This lighting fixture is for professional use only - it is not for household use.
■ Installtion
Make sure all parts for fixing the projector are in a good state of repair.
Make sure the point of anchorage is stable before positioning the projector.
The safety chain must be prgperly hooked onto the fitting and secured to the framework.
When suspending the fixture, ensure that the supporting structure and all hardware used
can hold at least 10 times the weight of all the devices they support.
Ensure a minimum clearance of 0.5m around the cooling fans and ventilation.
Please do not install the fixture onto combustible surface.
Do not expose the front glass to sunlight or other strong light source from any angle.
Lenses can focus the sun's rays inside the fixture, creating a potential fire hazard.
■ Mounting surface and fire protection
Keep all combustible materials at least 1 m away from the fixture.
The fixture is intended for indoor and outdoor application.
Do not operate the fixture if the ambient temperature (Ta) exceeds 40℃
■Protection against electrical shock
Connection must be made to a power supply system fitted with efficient earthing (Class I
appliance according to standard EN 60598-1).
It is,moreover, recommended to protect the supply lines of the projectors from indirect
contact and/or shorting to earth by using appropriately sized residual current devices.
Connection to the electricity mains must be carried out by a qualified electrical installer.
Check that the mains frequency and voltage correspond to those for which the projector is designed
as given on the electrical data label.
This label also gives the input power to which you need to refer to evaluate the maximum number
of fittings to connect to the electricity line, in order to avoid overloading.
Don’t use the power cable when the insulation is damaged.
It must be the manufacturer or distributor or the professional person to change the damaged power
cable in order to avoid any dangerous.
ta40℃
■ Maximum ambient temperature

Never look directly into the light source. You risk injury to your retina, which may induce blindness.
Do not stare directly into the light output.Never look at an exposed lamp while it is lit.
Protection optical radiation
Protection against explosion
The protection screen, lens or ultraviolet screen on the lamp can be damaged to the degree
of failure if visible damage, such as a crack or deep mark, should be replaced。
The tting mounts a high-pressure lamp that needs an external .
Immediately replace the lamp if damaged or deformed by heat.
The light source in this xture shall be replaced by the manufacturer or its service agent or
similar qualication.
Always disconnect from mains before replacing the lamp.
3
■ Temperature of the external surface
The maximum temperature that can be reached on the external surface of the fitting, in a thermally
steady state, is 100℃.
■ Maintenance
Before starting any maintenance work or cleaning the projector, cut off power from the mains supply.
After switching off, do not remove any parts of the fitting, to avoid getting burnt for at least 30 minutes.
After this time the likelihood of the lamp exploding is virtually nill.
The fitting is designed to hold in any splinters produced by a lamp exploding.
The lenses must be mounted and, if visibly Damaged, they have to be replaced with genuine spares.
■ Lamp
Battery
This product contains a rechargeable lead-acid battery. To preserve the environment,
please dispose the battery at the end of its life according to the regulation in force.
When the luminaire projects an object, the minimum distance of the luminaire to
the ammable object is 12 meters.
The products referred to in this manual conform to the European Community Directives to which
they are subject:
Low Voltage 2014/35/EU
Electromagnetic Compatibility 2014/30/EU
The product implementation standard：GB 7000.1-2015 GB7000.217-2008

● Power supplies available
-A C100~240V~ 50/60Hz
● Power
- 620W PF0.988
● Lamp
- Brand：OSRAM S IRIUS HRI 471W SN
- Lamp power：470W
- Colour temperature：6900K
- A verage life：1500h
● Motors
- 23 ultra-quiet motors
● Inputs ：DMX512
● Channel ：32CH
● Color
- 13 colors + white，Bi-direction rainbow effect
● Color mixing system
- CMY mixed color system/CMY
● Color temperature：
- Colour temperature：7500K
- CCT Light Output: 6300K
● Static gobo wheel
- 14 static gobos + white,Bi-direction flow water
animation effect
●Rotation Gobo Wheel
- 9 rotating Gobos + white,Bi-direction flow water
animation effect
●Effect wheel:
- T wo-way rotation and dynamic effect.
● Prism
-3+1 double prism disc and multiple prism combination effect。
● Beam angle ：
- Beam Projection 2-21°，Spot Projection 3-42°
● Frost
- 1 ° and 5 ° two levels of atomization
● Focus and Lens
- High precision optical lens，linear adjustment
● Strobe
- Double lens strobe(0.5-9 times/second)
● Dimmer
- 0-100％ linear adjustment
● X/Y Travel 540°/250°：
● X/Y Resolution 2.11°/0.98°：
● X/Y Speed 2.7S/1.6S：
Lighting Size● （1sets）：401X300X646MM
Box Size● ：490X390X725MM
：29.0kg ，：32.50kg N.W. G.W.
● Flycase Size (2sets)：890X500X850MM
N.W.：58.00kg ，G.W.：101.00kg
● IP set
- Automatic chang battery,IP could be set without
electricity.
● Software upgrade
- Insert USB upgrade software.
● ：Display Menu
- The display panel adopts a 2.0-inch LCD12864 LCD
screen, which is used in both Chinese and English
languages to facilitate quick operation and browse
menus.
-Display board can record device’s using time , show
device’s temperature, channel data and software
version .
● Features
- Remote control lamp's swith function display light
and lamp's using time.automaticallay adjust cooling
fan's speed,Drop power when strobe lens.
- Remote reset DMX address。
- The built-in gravity induction system can change
the heat dissipation of the bulb in different directions
of the lamp。
●:IP IP RATE 20
● Safety Devices
- BIPOlar circuit breaker with thermal protection.
- Automatic break in power supply in case of
overheating or failed operation of cooling system.
● Cooling
- Forced ventilation with axial fans.
●Structure
- Heat-proof plastic+module pressing alloy materials.
●The vertical direction of the use of hidden locking
device,convenient transportation and maintenance.
● CE Marking
- In conformity with the European Union Low Voltage
Directive 2014/35/EU and Electomagnetic compatibility
Directive 2014/30/EU.
4
TECHNICAL INFORMATION

Static gobo wheel
5
Color wheel
Rotating gobo wheel
（Effect disk）
2
1
2
3
4
5
6
7
8
9
White
Movable pattern
location
CTO2
CT O1
Dark red
Magenta
Yellow
Cyan
Pink
Green
1
2
3
4
5
6
7
8
9
10
11
12
13
C M Y
CMY color mixing system
3
White

4
10 20 30 40 50 60 70 800
0
3
6
9
12
15
15
12
9
6
3
2° 21°
Distance(m)
2° Diameter(m)
21° Diameter(m)
0.3
3.46
0.62
6.95
0.92
10.42
1.26
13.75
1.6
17.35
1.91
20.75
2.18
24.25
2.45
27.79
21°Lux(照度)
2°Lux(照度)
Lux（fc）
3552(330.1)
422000(39219) 105600(9814) 45600(4238)
930(86.4) 408(37.9)
25200(2342)
228(21.2)
15840(1472)
170（15.8）
11760(1093)
120(11.2)
9000(836.4)
95(8.8)
6880(639.4)
61(5.7)
distance, spot diameter and illumination diagram（Beam model）
510 15 20 25 30 35 400
0
3
6
9
12
15
15
12
9
6
3
3° 42°
Distance(m)
3° Diameter(m)
42° Diameter(m)
0.46
7.52
0.69
15
0.92
11.2
1.15
18.8
1.38
22.5
1.6
26.3
1.84
30.1
42°Lux(照度)
3°Lux(照度)
Lux（fc）
2850(265)
695400(64628) 171000(15892) 84000(7807)
765(71.1) 388(36.1)
33200(3086)
216(20.1)
27800(2584)
132(12.3)
19100(1775)
81(7.5)
15000(1394)
60(5.6)
11400(1060)
45(4.2)
3.76
0.23
distance, spot diameter and illumination diagram（Spot model）
6

power cord
ATTACHMENT AND BODY SIZE
7
5
Magnetic column
Straight line six prism
2
Four prism14°
1
Eight prism12°
3Eight prism22°
Prism wheel 2
Prism wheel 1

Installing the projector- Fig. 3
The projector can be installed on the floor resting on special rubber feet, on a truss or on the ceiling or wall.
WARNING:with the exception of when the projector is positioned on the floor, the safety rope must be fitted.
This must be securely fixed to the support structure of the projector and then connected to the base handle.
8
Make sure all parts for fixing the projector are in a good state of repair.
Make sure the point of anchorage is stable before positioning the projector.
When suspending the fixture, ensure that the supporting structure and all hardware used can
hold at least 10 times the weight of all the devices they support.
INSTALLATION AND CONNECTING
Safety rope

9
The L terminal is connected with the brown line.
The N terminal is connected with the blue line.
● After doing the above operation and making sure all the devices had been
installed with natural operate, press the power switch to check whether every
-thing is working normally.
L
NGround
● connection to the eiectricty mains must be carried out by a qualified electrical
installer.
● The stage lighting power supply can not be more than 2pcs pre line
power in power end
out in out in

10
DMX512 in
out signal end out in in
DMX - output
1 - Shield
2 - Signal (-)
- Signal (+)
- Not connected
- Not connected
3
1
2
3
DMX-input
- Shield
- Signal (-)
- Signal (+)
- Not connected
- Not connected
4
5
4
5
The projector
all the projectors are together
dn’t touch each other or
plinth).
Recommend to use the DMX
nnection.

Up arrowhead : page up
Down arrowhead : page down
Left arrowhead : reduce
Right arrowhead : increase
Enter : OK function
Exit : in the choice screen
DMX:
001 DMX Address Information Personal Manual control
Service Language Reversal
UP
DOWN
LEFT RIGHT
ENTER
CONTROL PANEL
● Press the switch.The projector starts resetting the effects.
At the same time,the following information scrolls on the display
（please refer to the actual material)
Lamp
7
11
USB
Display

DMX
Address
→Address
:001-512
Informa
tion →
Totel Time →
Power: :****(h)
Lamp ON: :****(h)
Lamp hours →
Total :****(h)
Lamp open :****(h)
Temperature
→
PVG_TEM :000.0
Board :000.0
RDM UID → Undistributed
MOTOR UID →
Fan
speed/Voltag →
1.L_Fan 1:00.0V
2.L_Fan 2:00.0V
3.L_Fan 3&4:00.0V
4.U_Fan :00.0V
5.Mid_Fan :0000R
6.L_Fan 1:0000R
7.L_Fan 2:0000R
8.L_Fan 3:0000R
9.L_Fan 4:0000R
10.U-Fan 1:0000R
11.U-Fan 2:0000R
12.GoboFAN: :0000
1.Pan ***
2.Pan Fine ***
3.Tilt ***
4.Tilt Fine ***
5.P/T ***
6.Functional channel ***
7.cyan ***
8.magenta ***
9.yellow ***
10.Colour ***
11.Color trimming ***
12.Effect disk ***
12
Main
menu Ⅰ m enu Ⅱ menu Ⅲ menu

DMX live →
13.Effect of rotation ***
14.Fixed pattern disc ***
15.Rotating pattern plate ***
16.Pattern rotation ***
17.Prism1 ***
18.Prism1 rotating ***
19.Prism2 ***
20.Prism2 rotating ***
21.Prism macros ***
22.Prism macro rotation ***
23.Frost ***
24.Zoom ***
25.zoom tuning ***
26.Focus ***
27.Focus fine ***
28.Focus 2 ***
29.Automatic focus
***
30.Shutter ***
31.Dimmer ***
32.dimmer fine ***
System
version →
XY :V*.**
Color ：V*.**
Zoom ：V*.**
Prism ：V*.**
DIS Board :V*.**
Return(ESC)
Persona
l→
Auto lamp
on →
OFF
ON
P/T invert →
Pan invert →OFF
ON
Tilt invert →OFF
ON
Return(ESC)
13
Main
menu Ⅰ m enu Ⅱ menu Ⅲ menu
33.Uniformity ***
CRI Standard CRI
High CRI

Persona
l
→
Display →
Language → English
Chinese
Back Light →
Open
Auto close(15s)
Reversal → Normal
Rota.180
Backlight blink → ON
OFF
Return(ESC)
Return(ESC)
Manual
control →
Channel
control
→
1.Pan ***
2.Pan Fine ***
3.Tilt ***
4.Tilt Fine ***
5.P/T ***
6.Function of the channel ***
7.Cyan
***
8.Magenta
***
9.
Yellow
***
10.Colour ***
11.
Colour adjustment
***
12.Effect disk ***
13.Effect of rotation ***
14.Stat.Gobo ***
15.Rotating pattern plate ***
16.Pattern rotation ***
17.Prism1 ***
18. Rota ***
19.Prism2 ***
20.Prism2 Rota ***
21.PrismMacro ***
22.Prism macro rotation ***
23.Frost ***
24.Zoom ***
25.zoom tuning ***
26.Focus ***
14
Main
menu Ⅰ m enu Ⅱ menu Ⅲ menu
Prism1

27.Focus fine ***
28.Focus 2 ***
29.Automatic focus ***
30.Shutter ***
31.Dimmer ***
32.dimmer fine ***
Return(ESC)
Reset →
system reset The machine
Pan/Tilt reset
Gobo reset
Colour reset
Dimmer reset
Zoom reset
Effect reset
Return(ESC)
Test →
Test P/T → STEP ***
Test effect → STEP ***
Test
all → STEP
***
Return(ESC)
Return(ESC)
Service →
Error
list →
Clean error →Keep
Clean
Calibration →
Pan 000-255
Tilt 000-255
Dimmer1 000-255
Dimmer2 000-255
Focus 000-255
Zoom
Colour 000-255
Gobo 000-255
Frost 1 000-255
Frost 2 000-255
Rota.Gobo 000-255
Prism1 000-255
Prism2 000-255
15
Main
menu Ⅰ m enu Ⅱ menu Ⅲ menu
is reset
33.Uniformity ***

Service
→
Cyan 000-255
Magenta 000-255
Yellow 000-255
Return(ESC)
Factory →
Defualt
Time clean Power up time
Lights on time
Developer
Firmware update
Return(ESC)
Fan mode
Standard mode
altitudes 3000-4000M
altitudes 4000-5500M
return
(ESC)
Lamp →Off
On
Language
→English
Chinese
Reversal
→Normal
Rota.180
16
Main
menu Ⅰ m enu Ⅱ menu Ⅲ menu

10-255 0-100 Pan
20-255 0-100 Pan Fine
30-255 0-100 Tilt
40-255 0-100 Tilt fine
5
Pan/Tilt speed ,Pan/Tilt time
0Standard mode(0=default)
1Max.
Speed Mode
2-255
Speed from max. to min.
6
Power/Special functions
0-9 Reserved (0=default)
10-14
15-19
* function is active only10 seconds after switching the fixture on
20-24 LCD display On
25-29 LCD display Off
30-34 High
CRI(CRI=90+)/CMY uniformity
35-39 Standard
CRI(CRI=80)/CMYStandard
40-44 Reserved
45-49 Reserved
50-54 Reserved
55-59 Reserved
60-64 Fans mode: Auto
65-69 Fans mode: High
70-74 Reserved
75-79 Reserved
80-84 Reserved
85-89 Reserved
90-94 Reserved
95-99 Reserved
100-101 Reserved
102-103 Reserved
104-105 Reserved
106-107 Reserved
108-119 Reserved
120-124 Reserved
125-129 Reserved
130-139 Lamp On
140-149 Pan/Tilt reset
150-159 Colour system reset
17
DMX
Percentage
Function
Channel
Reserved
Re s erv e d
CHANNEL FUNCTION(V1.0)

160 - 169 Gobo wheels reset
170 - 179 Dimmer/Shutter reset
180 - 189 Zoom/focus/frost/prism wheels reset
190 - 199 Effect wheel reset
200 - 209 Total reset
210 - 229 Reserved
230 - 239 Lamp Off
240 - 244 Reserved
245 - 249 Reserved
250 - 255 Reserved
7Cyan
0 -255 0-1.2 Cyan
from min. saturation --> full cyan (0=default)
81.6-40.4 Magenta
0 -255 40.8-42 Magenta
from min. saturation --> full magenta (0=default)
942.4-61.6 Yellow
0 -255 62.0 - 81.2 Yellow
from min. saturation --> full yellow (0=default)
10
0-255 0-100 Colour
wheel
Continual
positioning
0Open/white
(0=default)
9Deep
Red
18 Orange
27 Aquamarine
37 Dark
green
46 Light
green
55 Lavender
64 Pink
73 Yellow
82 Magenta
91 Cyan
101 CTO
3200K CTO 2
110 CTO
2700K CTO 1
119 Dark
blue
128 -129 White
Positioning
130 -134 Deep Red
135 -138 Orange
139 -143 Aquamarine
144 -147 Dark green
148 -152 Light green
153 -157 Lavender
18
DMX
Percentage
Function
Channel

158 -161 Pink
162 -166 Yellow
167 -171 Magenta
172 -176 Cyan
177 -180 CTO 3200K CTO 2
181 -185 CTO 2700K CTO 1
186 -189 Dark blue
190 -215 Forwards
rainbow effect from fast to slow
216 -217 No
rotation
218 -243 Backwards
rainbow effect from slow to fast
244 -249 random
colour selection
250 -255 Auto
random colour selection from fast to slow
11 Colour
wheel - fine positioning
0 -255 Fine
positioning (0=default)
12
Effect wheel positioning
0-19 No function (0=default)
20-127 Proportional indexing
128 -170 Ramping
from open to full position ( max --->min.
speed)
171 -213 Ramping
from
open to half position ( max.
--->min. speed)
214 -255 Ramp.
from half position to fullposition (max.
--->min. speed)
13
Effect wheel rotation
0 No rotation
1-127 Forwards rotation from fast toslow
128 No rotation (128=default)
129 -255 Backwards rotation from slow tofast
14
Static gobo wheel
0-3 Open/Hole (0=default)
Positioning
4-9 Beam reducer 1
10-15 Beam reducer
2
16-21 Beam reducer 3
22-27 Beam reducer 4
28-33 Gobo 1
34-39 Gobo 2
40-45 Gobo 3
46-51 Gobo 4
52-57 Gobo 5
58-63 Gobo 6
64-69 Gobo 7
70-75 Gobo 8
19
DMX
Percentage
Function
Channel
