Code Blue CB 1-s w Service manual

800.205.7186 •www.codeblue.com
Administrator Guide
Public Address System
PAS
Installation | Configuration | Operation | Troubleshooting

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 2 of 26
Public Address System
Administrator Guide
WARNING
ONLY QUALIFIED PERSONNEL SHOULD INSTALL THESE UNITS. THE INSTALLATION
SHOULD CONFORM TO ALL LOCAL CODES. IN SOME COUNTRIES, A CERTIFIED ELECTRI-
CIAN MAY BE REQUIRED.
CAUTION
No caution is necessary for this product.
NOTICE TO USERS
Copyright © Code Blue Corporation. All rights reserved. This guide or software described herein, in
whole or part, shall not be reproduced, translated or reduced to any machine-readable form without
prior written approval from Code Blue Corporation.
CODE BLUE CORPORATION PROVIDES NO WARRANTY WITH REGARD TO THIS GUIDE, THE
SOFTWARE OR OTHER INFORMATION CONTAINED HEREIN AND HEREBY EXPRESSLY DIS-
CLAIMS ANY IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR ANY PARTICU-
LAR PURPOSE WITH REGARD TO THIS GUIDE, THE SOFTWARE OR SUCH OTHER INFORMA-
TION. IN NO EVENT SHALL CODE BLUE CORPORATION BE LIABLE FOR ANY INCIDENTAL,
CONSEQUENTIAL, OR SPECIAL DAMAGES, WHETHER BASED ON TORT, CONTRACT, OR
OTHERWISE, ARISING OUT OF OR IN CONNECTIONS WITH THIS GUIDE, THE SOFTWARE
OR OTHER INFORMATION CONTAINED HEREIN OR THE USE THEREOF.
Code Blue Corporation reserves the right to make any modications to this guide or the information
contained herein at any time without notice. The software described herein may also be governed
by the terms of a separate user license agreement.
Code Blue®is a registered trademark of Code Blue Corporation.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 3 of 26
Public Address System
Administrator Guide
Table of Contents
Section Page
2 Introduction.................................................................................... 4
3 Before You Start...............................................................................6
4 How to Update Connectors.............................................................7
5 Installation & System Setup.......................................................... 9
6 Software Conguration..................................................................17
7 Architectural Overview...................................................................18
8 Wiring Diagrams..............................................................................19
9 Troubleshooting..............................................................................24
10 Spare Parts......................................................................................25
11 Download Information.....................................................................26

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 4 of 26
Public Address System
Administrator Guide
2 Introduction
Thank you for choosing the Public Address option for your Code Blue application. Public Address is
a centralized amplier-based system designed to provide voice paging and broadcast alarm tones
during emergencies. The system can transmit alarm tones and voice messages in a reliable and
safe manner from a central location to all or selected areas of the facility via loudspeakers. The en-
tire operational area can be divided into one or more zones, which can be accessed independently
either for announcements or alarm broadcasting. Loudspeakers are installed in these zones. There
are no limitations to the number of zones in a system or number of loudspeakers in each zone. The
system is designed to o󰀨er clear reproduction of sound and intelligibility, even in high noise areas.
2.1 Overview
This manual contains all of the Code Blue PAS information needed on the CB 1 series with Public
Address, CB 5-s with Public Address, WM-180 Public Address System, CB 2-e with Public Address
and 360° PAS retrot top. This manual contains a general overview of the Code Blue PAS options
and its application, installation and wiring.
CB 5-s w/ PAS WM 180° CB 2-e w/ Public Address 360° PAS Retrot TopCB 1-s w/ PAS

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 5 of 26
Public Address System
Administrator Guide
2.2 PAS Options:
2.2.1 CB 1 Series with Public Address Units – Outdoor
• Large diameter towers; analog or IP
• An excellent choice when instant mass notication of a geographic area is essential.
The unique six-speaker design delivers optimal audio source dispersion utilizing state-
of-the-art ampliers and horn array.
2.2.2 CB 5-s with Public Address Units – Outdoor
• Small diameter towers
• Exclusively designed as an emergency communication system to deliver maximum
audio clarity and range to ensure notications are accurately broadcast to your intended
audience.
2.2.3 CB 2-e with Public Address Units – Indoor & Outdoor
• Wall or pole mount; analog or IP
• An excellent choice for parking decks, dorm entrances, hallways and public transit cen-
ters where instant mass notication of a geographic area is essential.
2.2.4 360 ° PAS Retrot Tops – Outdoor
• PAS top kit for existing standard CB 1 series towers in the eld to provide public ad-
dress capabilities.
• The unique six-speaker design delivers optimal audio source dispersion utilizing state-
of-the-art ampliers and horn array.
2.2.5 WM-180 Wall Mount PAS unit – Indoor & Outdoor
• Wall or pole mount option remotely adds public address capabilities to new or existing
CB units.
• By adding an analog or IP controller board, you enable the WM-180 to be directly man-
aged by Code Blue’s Blue Alert® MNS (Mass Notication System) soft¬ware, granting
the user messaging options. The controller also monitors the amplier and speaker for
various failures, which are reported to the appropriate maintenance personnel, and al-
lows the user to call a single WM-180 unit for a targeted message.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 6 of 26
Public Address System
Administrator Guide
3 Before You Start
3.1 NFPA 72 Chapter 24
This regulation covers the application, installation, location, performance, inspection,
testing and maintenance of fire alarm systems, supervising station alarm systems, public
emergency alarm reporting systems, fire warning equipment and emergency communi-
cations systems (ECS), and their components.
3.2 UFC-4-021-1
This provides technical criteria for systems that implement mass notification in compli-
ance with the Department of Defense’s antiterrorism requirements. Implement national
design standards and recommendations for mass notification systems, as provided in
NFPA 72, including Annex E.
3.3 Precautions
Code Blue recommends professional services before the order and installation of all PAS
products.
For survey information, please email [e-mail].
3.3.1 PAS Site Survey – call for scheduling and pricing
• Ambient Noise Survey: Measures the sound energy flowing into, or outward
from, a specified area.
• System Design Survey – Involves the placement, wiring and installation of PAS
equipment.
• Complete Survey – Includes ambient noise and system design of PAS equip-
ment.
3.4 In Case of Breakdown
Code Blue Technical Support
Email: [e-mail]
Toll free: 800-205-7186, Opt. 3
3.5 In Case of Abnormal Operation
If the unit emits smoke or an unusual smell, water or other foreign materials enter the en-
closure, or the unit is dropped or the enclosure is damaged, power o immediately and
contact Code Blue Customer Service.
Email: [e-mail]
Toll free: 800-205-7186, Opt. 2

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 7 of 26
Public Address System
Administrator Guide
4 How to Update Connectors
As of 2020, many Code Blue products come with Wago connectors. These connectors provide
ease of use and a much stronger connection. Below are the steps needed to change to the new
connectors.
Example:
Cut o both wires.
Strip all wires and twist tight.
Wago socket
connectors to
add to your wires.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 8 of 26
Public Address System
Administrator Guide
Place small screwdriver into square hole and push down. Insert cut wire into
round hole and remove screwdriver. Repeat on the rest of the connectors.
Once all connectors have been switched, you are ready to apply power to the
LED.
Please contact [email protected] if you need further assistance.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 9 of 26
Public Address System
Administrator Guide
5 Installation & System Setup
This section covers the following units:
• CB 1 Series with Public Address, including the 360° PAS Retrofit Kit
• CB 5-s with Public Address
• CB 2-e with Public Address
• WM-180°
5.1 CB 1 Series with Public Address, including 360° PAS Retrot Kit
The following models are covered in the installation instructions for CB 1 Series with
Public Address or the 360° PAS Retrofit Kit:
• CB 1-e
• CB 1-s
5.1.1 Tools Required
• Ladder – to reach the top of the unit.
• Security bit – to secure the PAS top to the adapter ring.
• 6mm Allen wrench – to secure the PAS adapter ring to the top of the unit.
• 3/8” socket set - to mount the mounting plate containing the new toroid
transformer.
5.1.2 Before You Begin
• Remove 120V AC power from the unit.
5.1.3 Install Adapter Ring
5.1.3.1 Remove the existing dome top assembly. Disconnect the red/black and
yellow/yellow wiring harnesses connected to the beacon/strobe mount-
ed in the dome top assembly.
5.1.3.2 Place the adapter ring on top of the bollard and tighten the three Allen
set screws to hold in place (see Figure 2 on Page 12).
5.1.4 Transformer Installation
Install new toroid transformer.
NOTE: Skip this section if you ordered a CB 1 Series with Public Address
as a complete unit.
5.1.4.1 Remove lower access door on the CB 1 bollard.
5.1.4.2 Remove the existing 120V AC step down transformer.
5.1.4.3 Install toroid transformer with mounting plate using supplied hardware
(see Figure 1 on Page 10).
5.1.4.4 Connect incoming 120V AC wiring to the transformer using the junc-
tion box on mounting plate. Refer to included wiring diagram for wiring

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 10 of 26
Public Address System
Administrator Guide
terminations (See Figure 5 on Page 18).
5.1.4.5 Run the supplied amplifier wiring harness, beacon/strobe power har-
ness (red/black), beacon/strobe auxiliary harness (yellow/yellow), 7 pin
control cable and RJ-11 audio cable to the top of the bollard. Connect
the molded quick connector on the red/black harness to the manifold
connector on the transformer. Connect the yellow/yellow harness, 7 pin
control cable and RJ-11 to the phone board. Connect the large white
connector of the amplifier wiring harness to the wiring connector on the
transformer. Refer to the included wiring diagram for wiring termina-
tions (See Figure 1 below).
5.1.5 Install 360° PAS Speaker Unit
5.1.5.1 Connect the red/black and yellow/yellow wiring harnesses to the red/
black and yellow/yellow wiring pigtails coming from the beacon/strobe.
5.1.5.2 Connect the 6 pin wiring harness, 7 pin control cable and RJ-11 audio
cable to the ports on the amplifier.
5.1.5.3 Set the PAS speaker unit on the adapter ring, lining up the screw holes
at the bottom of the unit. Secure the speaker unit with the provided
security screws.
5.1.5.4 Reapply power to the unit.
Figure 1

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 11 of 26
Public Address System
Administrator Guide
5.2 CB 5-s with Public Address Installation
5.2.1 Tools Required
• Ladder – to reach the top of the unit.
• Security bit – to secure the PAS top to the adapter ring.
• 3/8” socket set - to secure the PAS adapter base to the top of the unit.
• 6mm Allen wrench - to secure the PAS adapter ring to the top of the PAS
adapter base.
5.2.2 Before You Begin
• Remove 120V AC power from the unit.
5.2.3 Install Adapter Ring
5.2.3.1 Remove existing beacon/strobe assembly. Disconnect the red/black and
yellow/yellow wiring harnesses connected to the beacon/strobe mount-
ed on top of the CB 5-s unit.
5.2.3.2 Place a foam gasket on the unit, then the adapter base on top of the
bollard and tighten the 3/8” bolts with washers to secure the adapter
base to the set screws to hold in place.
5.2.3.3 Place adapter ring on top of the adapter base and tighten the three Al-
len set screws to hold in place (see Figure 2 on Page 12).
5.2.4 Install Adapter Ring
5.2.4.1 Connect the red/black and yellow/yellow wiring harnesses to the red/
black and yellow/yellow wiring pigtails coming from the beacon/strobe.
5.2.4.2 Connect the 6 pin wiring harness, 7 pin control cable and RJ-11 audio
cable to the ports on the amplifier.
5.2.4.3 Set the PAS speaker unit on the adapter ring, lining up the screw holes
at the bottom of the unit. Secure the speaker unit with the provided
security screws.
5.2.4.4 Reapply power to the unit (See Figure 7 on Page 20).

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 12 of 26
Public Address System
Administrator Guide
Figure 2

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 13 of 26
Public Address System
Administrator Guide
5.3 CB 2-e with Public Address Installation
5.3.1 Tools Required
• Security bit - to remove phone to access mounting holes.
• ½-inch concrete bit – to drill holes in wall for the mounting anchors for mount-
ing bolts.
• 9/16” socket set - to secure the housing to the wall with mounting bolts.
5.3.2 Installation Procedures
5.3.2.1 Electrical preparation: the unit may have supply wires run from either (a)
behind the unit through the wall, or (b) below the unit using an external
conduit through the bottom. Holes in the back and bottom have been
provided for this purpose (See Figure 10 on Page 23).
5.3.2.2 Remove the top of the unit.
5.3.2.3 Mark the mounting holes. In order to comply with the Americans with
Disabilities Act (ADA), the speakerphone button(s) should be posi-
tioned between 34 and 48 inches from grade level. Consult an ADA
specialist in your area to verify local and federal guidelines.
5.3.2.4 Drill all marked holes.
5.3.2.5 Install the housing. Four anchors of appropriate size and type should be
used to fasten the housing to the wall (see Figure 3 on Page 14).
IMPORTANT: If wiring is being supplied from the back, ensure that the
conduit is aligned at this time.
5.3.2.6 Reattach the top.
5.3.3 Electrical Wiring
5.3.3.1 Ground – The ground (green) wire should be stripped and fastened to
the supplied grounding lug.
5.3.3.2 24V AC supply – Using the proper crimping tool, attach a #8 fork to
each of the incoming power wires and fasten them to the terminal
screws labeled “Line” and “Neutral.”
5.3.3.3 120/240V AC supply – Using the proper crimping tool, attach a #8 fork
to each of the incoming power wires and fasten them to the correct ter-
minals as labeled on the transformer. After completing the wire connec-
tions, install the supplied terminal covers (see Figure 10 on Page 23).

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 14 of 26
Public Address System
Administrator Guide
5.3.4 Communications Wiring
5.3.4.1 Have category 3 or higher 4 pair cable terminated to a RJ45 applying
TIA/EIA T568-B specifications.
Figure 3

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 15 of 26
Public Address System
Administrator Guide
5.4 WM-180° Wall Mount Speaker Installation
5.4.1 Tools Required
• Ladder – to reach mounting height.
• Security bit - to remove phone to access mounting holes.
• ½-inch concrete bit – to drill holes for the mounting anchors for the mounting
bolts.
• 9/16” socket set - to secure the housing to the wall with mounting bolt.
Note: If unit does not include an IP or Analog controller board, then it must
be located near an IA4100 or IP5000 speakerphone for the 20-foot supplied
PAS cables to reach it.
*See included drawing for anchor bolt and conduit locations.
5.5 Installation with Controller Board
5.5.1.1 Supply 24V AC to Power Manifold (see Figure 9 on Page 22).
5.5.1.2 Supply phone line to phone port if the unit has an analog controller
board, or Ethernet IP connection to LAN port if it has an IP controller
board.
5.5.1.3 Reference IA4100 Admin and User Guide for analog controller board
programming.
5.5.1.4 Reference IP5000 Admin and User Guide for IP controller board pro-
gramming.
5.5.1.5 Code Blue guides are located at codeblue.com > resources > downloads.
5.6 Installation without Controller Board
5.6.1.1 Supply 24V AC to Power Manifold.
5.6.1.2 See attached wiring diagram for connecting the PAS Audio Cable and
PAS Control Cable to the nearby IA4100 or IP5000 speakerphone.
5.6.1.3 Reference IA4100 Admin and User Guide for analog controller board
programming.
5.6.1.4 Reference IP5000 Admin and User Guide for IP controller board pro-
gramming.
5.6.1.5 Code Blue guides are located at codeblue.com > resources > downloads.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 16 of 26
Public Address System
Administrator Guide
Suggested installation dimensions shown from ground to lower right mounting hole are
for single button faceplates.
• For dual button faceplate, deduct 3.25 inches.
• For keypad faceplate, deduct 4.5 inches.
• For wheelchair direct facing access only, deduct 6 inches.
DISCLAIMER: The dimensions above are intended as guidelines only. For specific installa-
tion requirements, reference your local codes.
Figure 4

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 17 of 26
Public Address System
Administrator Guide
6 Software Configuration
Blue Alert® MNS Software
Blue Alert MNS (Mass Notication Software) lls a need in the marketplace for an incident response
solution that is both comprehensive and cost-e󰀨ective, while also providing an e󰀩cient way to detect
and respond. The advanced mass notication system allows responders to deliver multi-layered
emergency notications via a wide range of platforms, including email, text message (SMS), emer-
gency phones, public address speakers, social media, desktop alerts and more, quickly informing
and directing people in emergency situations.
Blue Alert® EMS
Blue Alert EMS is an advanced software solution that handles all incoming events e󰀨ectively by re-
motely controlling emergency communication devices with an easy-to-use Graphical User Interface
(GUI). You also will have the ability to open gates and AED access doors, turn LED beacon/strobes
on or o󰀨, transfer calls to Public Address Systems to make area wide announcements and incor-
porate other ancillary devices and applications while the system securely archives data for future
reference.
ToolVox®
A sophisticated emergency management platform for your blue light phone network, ToolVox o󰀨ers
unique real-time monitoring and provisioning options for emergency phones and public address
speakers, e󰀨ectively acting as a hub for connecting Help Points®and other Code Blue devices. Us-
ing our proprietary incident response software, Blue Alert®MNS and EMS, you can send alerts via
outdoor platforms, such as blue light phones and public address speakers. It also provides connec-
tions to PBX, public telephone (PSTN) and Internet (ISP) networks, in addition to third party security
platforms.

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 18 of 26
Public Address System
Administrator Guide
7 Architectural Overview
IP Audio
Interface
WAN
Connectivity/
Internet
Business
Phones
WM180 with
IP Control
Analog Connectivity
CB4s
With
IA4100
WM180
with
Analog Control
PAS1s
with
IP5000
Over Head
Camera Mount
Secure Mesh
or
802.11g
Wireless
PAS1d
with
IA4100
PAS2e
With
IP5000
WM180
with
No Control
25/70
Paging
Amps
Indoor IP Speakers and clocks
IP Connectivity
IA500 Line
Powered
4100U
Smart Phones
Blue Alert
Web Interface
4100U
4100U
LAN Location 1
LAN Location 2
Hosted Mass
Notification
Platforms
Microphone
Control Points
IP Audio
Interface
IP Audio
Interface
IP2500, IP1501,
IP1500
IA4100
Figure 5

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 19 of 26
Public Address System
Administrator Guide
8 Wiring Diagrams
8.1 WM-180° PAS
Controller wiring diagram
Figure 6

Code Blue •259 Hedcor Street •Holland, MI 49423 USA •800.205.7186 •www.codeblue.com GU-153-Hpage 20 of 26
Public Address System
Administrator Guide
8.2 CB 2-e with Public Address
Wiring Diagram
Figure 7
