Code Corporation Code Reader 1.1 User manual

1
Code Reader 1.1
High-Density and
Ultra High Density Imager
User’s Manual
This manual is applicable for rmware versions 1.160 and earlier.

2
3
Table of Contents.....................................................................................................................2
Statement of Agency Compliance..........................................................................................3
Code Corporation Overview...................................................................................................4
Code Reader 1.1 Overview......................................................................................................5
Manual Overview and Code Reader Set Up .........................................................................6
Targeting and Reading Techniques.........................................................................................7
Programming: Code Reader Conguration ..........................................................................8
Installation Instructions: Keyboard Wedge Adapter ..........................................................9
Installation Instructions: Serial Port Adapter ................................................................... 10
Installation Instructions: PCMCIA Card Adapter ........................................................... 11
Programming: Code Reader Default Settings.................................................................... 12
Programming: Symbology Settings ................................................................................13-14
Programming: Reader Targeting Controls ......................................................................... 15
Programming: Prex and Sufx for Keyboard Wedge.................................................... 16
Programming: Prex and Sufx for Serial and PC Card............................................17-18
Programming: Word Length and Stop Bit Data ............................................................... 19
Programming: Baud Rate...................................................................................................... 20
Code Reader 1.1 - HD Specications ................................................................................. 21
Code Reader 1.1 - UHD Specications.............................................................................. 22
Maintenance and Troubleshooting...................................................................................... 23
Maintenance and Troubleshooting (con’t) ........................................................................ 24
Code Corporation Customer Service and Support .......................................................... 25
Table of Contents

2
3
Statement of Agency Compliance
The Code Reader 1.1 can be set to use targeting lasers. If the targeting
lasers are activated, do not stare into the beams. The Code Reader’s target-
ing lasers have been rated as Class 2 Lasers by ANSI 2136.1-1993.
The Code Reader 1.1 has been tested by an independent electromagnetic
compatibility laboratory in accordance with the applicable specications
and instructions.
The Code Reader 1.1 has been tested for compliance with FCC regula-
tions and was found to be compliant with all applicable FCC Rules and
Regulations.
The Code Reader 1.1 has been tested for compliance to CE standards
and guidelines and was found to conform to applicable CE standards,
specically the EMC requirements EN 55024, ESD EN 61000-4-2,
Radiated RF Immunity EN 61000-4-3, ENV 50204, EFT EN 61000-4-4,
Conducted RF Immunity EN 61000-4-6, EN 55022, Class B Radiated
Emissions, and Class B Conducted Emissions.
CAUTION
Laser Light-
Do Not Stare
Into Beam
In GaAIP Class 2

4
5
Code Corporation - Overview
The Code Corporation Designs, develops and manufactures data capture and automatic
identication technologies. The company specializes in image-based readers and advanced data
collection platforms.
The company is a leading developer and manufacturer of linear and two-dimensional code
readers. By utilizing new imaging technology, the Code Corporation has developed readers that
out perform comparable readers, but are half the cost. Code Readers feature simple, omni-
directional targeting and are ideal for professional and light-industrial uses.
The Code Corporation also has developed a unique data colloection platform called CodeXML.
CodeXML consists of innovative software products that allow businesses to easily migrate to
more progressive and exible data collection applications. The CodeXML platform allows
businesses to bring online new systems while keeping legacy applications unchanged. By
developing easy to use data denition software, and intelligent data routing software, the Code
Corporation improves implementation, maintenance, and eliminates problematic upgrades for all
automatic identication applications including 2-D codes, linear bar codes, RFID and OCR data.
The CodeXML platform consists of the following two software products:
Code Router Software
Code Router software was developed to simplify the acquisition, routing and
management of various data formats. The software recognizes and converts
various data element formats, and is capable of routing multiple data strings
to web-based or local applications. Code Router software is compatible with
Windows, and Windows CE platforms and works with RS232, PCMCIA
Card and Keyboard Wedge devices.
CodeXML Maker Software
CodeXML Maker Pro software is designed for the professional seeking
to integrate high density, two-dimensional bar codes into applications.
CodeXML Maker Pro features an easy user interface with drag and drop
functionality. Users can easily manipulate size, resolution, bleed correction,
error correction, and le format. CodeXML Maker Pro also allows users to
create private or public codes and features innovative reader authentication
features that simplies setting up a network of readers.

4
5
Code Reader 1.1 - Overview
The low-cost Code Reader 1.1 is an innovative, hand-held data capture device for read-
ing and decoding high density two-dimensional (2-D) codes and linear bar codes.
By utilizing new imaging technology, the Code Corporation has developed readers that
outperform comparable readers, but are half the cost. The Code Reader 1.1 is available
in a Ultra High Density (UHD) version for smaller very dense codes and a High Den-
sity (HD) version for larger codes.
This manual is applicable for rmware versions 1.160 and earlier.
Programmable Button
Trigger

6
7
Manual Overview and Code Reader Set Up
This manual is designed to help you understand how to use your Code Reader and
how to change Code Reader settings.
Before using your Code Reader, please read the instructions that were included with
your Code Reader on how to install it. Instructions on how to install your Code
Reader are also included in this manual. See the instructions on setting up your
Code Reader that follow in later sections.

6
7
Targeting and Reading Techniques
1. Hold Code Reader about 1 - 3 inches above the code.
2. Hold the Code Reader still - Do NOT swipe or move the reader.
3. Press and hold either scanning button found on either side of the Code Reader.
4. When the code has been read and decoded, the reader will beep and the LED lights
in the Code Reader’s head will turn off.

8
9
Congure your Code Reader to work from your computer’s serial port:
Congure your Code Reader to work from your computer’s keyboard port:
Save settings on Code Reader:
Programming: Reader Conguration
The Code Reader 1.1 is available with keyboard wedge, serial and PC Card interfaces.
Your Code Reader has been properly congured before shipping and may not need to
be recongured. If you need to switch congurations, please scan the appropriate code:

8
9
Installation Instructions: Keyboard Wedge Adapter
Ensure the power is off and unplug
your keyboard.
Simply follow the keyboard cord to where it plugs
into the computer, and unplug it. Note the location,
because you will be plugging it back in momentarily.
Note: For laptop computers, you must have an
external keyboard port (normally PS2 connector).
Included with your Code Reader is an adapter that
can be congured for use with a PS2 or an AT
keyboard connector.

10
11
E
Installation Instructions: Serial Port Adapter
Please read the following before setting up your Code Reader 1.1 with serial port adapter.
A. Plug the 120 Volt AC adapter into the wall socket.
B. DO NOT PLUG IN large end of Code Reader 1.1 (only used for keyboard ports).
C. Plug the small end of the serial port adpater into the 120 AC Volt adapter.
D. Plug the serial port connection to the serial port in the back of your computer.
E. Plug the large end of the serial port adapter into the Code Reader 1.1 PS2 plug.
A
B
C
D
A
B
C
D
E

10
11
Installation Instructions: PCMCIA Card Adapter
1. Insert PC card into expansion slot in PDA.
2. Turn the PDA on. When the PDA is turned on, the Code Reader will also be powered up.
3. If you have not received the appropraite software with your Code Reader for CE devices
please call [phone] for more information.

12
13
Programming: Code Reader Default Settings
Save settings on Code Reader:
The following are the factory default settings for your Code Reader rmware version 1.160:
Circle Laser OFF
Dot Laser ON
1-D Codes ON (Code 39, Code 128, UPC, EAN, JAN)
Negative Data Matrix Codes ON
Rectangle Data Matrix Codes ON
Dual Code Mode ON (Data Matrix and GoCode)
Baud Rate 9600 (PC Card ONLY)
Baud Rate 38,400 (Serial Adapter ONLY)
Prex None (Serial Adapter and PC Card)
Sufx None (Serial Adapter and PC Card)
Word Length 8 Bit (Serial Adapter and PC Card)
Stop Bit 1 Stop Bit (Serial Adapter and PC Card)
Restore Code Reader to factory default settings:

12
13
Enable negative Data Matrix codes
Disable negative (inverted) Data Matrix codes:
Enable rectangle-shaped Data Matrix codes:
Disable rectangle-shaped Data Matrix codes:
Enable Data Matrix codes only to be read:
Enable GoCodes only to be read:
Enable dual code mode (both Data Matrix and GoCodes can be read):
Save settings on Code Reader:
Programming: Symbology Settings
Setting multible symbologies will affect the performance of the Code Reader

14
15
Enable 1-D codes:
Disable 1-D codes:
Programming: Symbology Settings (con’t)
Setting multible symbologies will affect the performance of the Code Reader

14
15
Programming: Reader Controls
Enable targeting dot laser:
Disable targeting dot laser:
Enable targeting circle laser:
Disable targeting circle laser:
Enable continous scanning
Disable continous scanning
Save settings on Code Reader:

16
17
Scanning one the codes will add one of the following most common prexes or a sufxes.
Programming: Prex and Sufx - Ketboard Wedge ONLY
Scan the Prex None or Sufx None codes to turn the prex and sufx commands off.
Prex Sufx
Comma Comma
Space Space
Tab
Enter
Prex Sufx
None None
To create a custom prex or sufx you may purchase a copy of CodeXML Maker Pro software.
Call [phone] or visit www.codecorp.com for more details.

16
17
Scanning one the codes will add the corresponding prex or a sufx.
Programming: Prex and Sufx - Serial Port and PC Card ONLY
Prex Sufx
Tab Tab
Comma Comma
Space Space
Carriage Return
Line Feed
Carriage Return Line Feed

18
19
Scan the Prex None or Sufx None codes to turn the prex and sufx commands off.
Prex Sufx
None None
Programming: Prex and Sufx - Serial Port and PC Card ONLY (con’t)

18
19
Scanning the following codes will set the baud rate for your Code Reader. The baud
rate is the information transfer rate of data being passed between your Code Reader and
your computer.
1200:
2400:
4800:
9600:
19200:
38400:
Programming: Baud Rate - PC Card and Serial Adapter ONLY
Default for serial version is 38,400 baud . Default for PC Card is 9600 buad

20
21
For advanced users only: Set the word/character length with one of the following
codes. Standard default length is 8 bits.
7 bit:
8 bit:
For advanced users only: Set the stop bit to one or more bits with one of the following
codes:
1 stop bit:
2 stop bits:
Save settings on Code Reader:
Programming: Word Length and Stop Bit Data
