CodeLock Kitlock 1000 User manual

Step 9 Select the cam which suits your door and frame
and attach it to the square shaft at the end of
the spindle.
Step 10 Now check the operation of the lock using the
factory User Code 00 99.
Step 11 If the lock is functioning correctly, CHANGE
THE DEFAULT MASTER CODE 55 44 33 22 and
DEFAULT USER CODE 00 99 and program the
lock using the programming and operating
instructions enclosed.
B) New installation
Step 1 Place template on door and mark upper 6mm (1/4”)
hole and lower 16mm (5/8”) hole.
IMPORTANT NOTE: Before drilling fixing holes, please
ensure that the position of the KitLock when fitted will allow
enough clearance for selected cam to work.
Step 2 Drill both fixing holes.
Step 3 Continue installation from step 4 to 11, above.
II-KL1000RH-0912
CODELOCKS LTD UK
Tel: [phone]
Fax: [phone]
[email protected]
Helpline, service & spares
FREEPHONE 0800 393 405
CODELOCKS INC US
Tel: [phone]
Fax: [phone]
[email protected]
Help: 1.877.CODELOCK
www.codelocks.com WWW.KITLOCK.COM
INSTALLATION
INSTRUCTIONS
FOR RIGHT HAND
HORIZONTAL
KITLOCK1000

SPECIAL NOTES
• Beforeinstallingthelock,loadthebatteriesandfamiliariseyourself
with the operation and programming.
• Thehandlewillnotturnuntilyouenterthefactorydefault
Master Code 55 44 33 22 OR the User Code 00 99.
• Pleaseseeprogrammingguidetosetyourowncodes.
INSTALLATION GUIDE
A) Replacing existing cam lock with
the KitLock
Step 1 Remove existing cam lock.
Step 2 Place template over hole left by cam lock and mark
upper fixing hole.
Step 3 Drill the 6mm (1/4”) upper fixing hole.
Step 4 Fit the KitLock to the door by passing the spindle
through the 16mm (5/8”) hole.
Step 5 If required, from the inside of the door, pass either of the
packing pieces over the spindle to centralise the lock.
Step 6 Now secure the lock by threading the large nut onto
the spindle.
Step 7 Fit one of the upper fixing bolts to suit your
door thickness.
Step 8 Tightenthelowerfixingnutandupperbolt.
FITTING INSTRUCTIONS
TheKitLockcanbefittedto:
A) Cupboards, cabinets and lockers etc as a direct replacement for
existing cam locks.
B) It can also be easily fitted to cupboards and cabinets that do not
have an existing locking device.
1KitLock
2Upper fixing bolt x 2
3Packer pieces x 2
4Locking nut
5Cams x 2
6Cam fixing bolt
 • Batteries–2x1.5VAAA
 • Templatex1
1
2
345
6
