Cognex DataMan 8600 Series User manual

DataMan®8600
Quick Reference Guide
2020 June 24
Revision: 6.2.0.2

Precautions
WARNING: LASER LIGHT, DO NOT STARE INTO BEAM: CLASS 2
LASER PRODUCT. FAILURE TO FOLLOW THESE INSTRUCTIONS
MAY CAUSE SERIOUS INJURY.
To reduce the risk of injury or equipment damage, observe the following precautions
when you install the Cognex product:
lThis product is intended for industrial use in automated manufacturing or
similar applications.
lThe safety of any system incorporating this product is the responsibility of
the assembler of the system.
lThis product does not contain user-serviceable parts. Do not make
electrical or mechanical modifications to product components.
Unauthorized modifications can void your warranty.
lRoute cables and wires away from high-current wiring or high-voltage
power sources to reduce the risk of damage or malfunction from the
following causes: over-voltage, line noise, electrostatic discharge (ESD),
power surges, or other irregularities in the power supply.
lChanges or modifications not expressly approved by the party responsible
for regulatory compliance could void the user’s authority to operate the
equipment.
lEnsure that the cable bend radius begins at least six inches from the
connector. Cable shielding can be degraded or cables can be damaged or
wear out faster if a service loop or bend radius is tighter than 10X the cable
diameter.
2

lThis device should be used in accordance with the instructions in this
manual.
lAll specifications are for reference purposes only and can change without
notice.
3

Product Overview
DataMan 8600 Reader
WARNING:LASER LIGHT, DO NOT STARE INTO BEAM
1 UltraLight
2 Laser aimer
3 Trigger (press and hold to read)
4 Communication module insertion point
5 Indicator light
6 Lanyard hook
7 Extended Read Attempts button (acts as an optical button to arm the
reader for predefined actions)
8 RS-232 connection
9 USB connection
10 Power plug (24V, max. 15W)
11 Alternative power supply connector (24V, max. 15W, polarity marked on
the plastic part near the connector)
12 Ethernet connection
4

DataMan 8600 Accessories
Accessory Name Product ID Illustration
Serial/USB slide-in DMCM-SERIALM-00
Ethernet slide-in DMCM-ENETM-00
Bluetooth slide-in DMCM-BTM-00
Wireless slide-in DMCM-WLESSM-00
Charging base station DMA-CBASE-01
Intelligent base station DMA-IBASE-01
Intelligent Bluetooth base station DMA-IBASE-BT-01
Intelligent Bluetooth base station DMA-IBASE-BT-02
Power Supply for base station DMA-24VPWR-xx*
Power Supply for reader DM100-PWR-000
Battery for the wireless reader DMA-HHBATTERY-01
Multi-battery charger DMA-MBC-xx*
POE adapter CPS-24V-POE1
POE adapter CPS-24V-POE4
POE adapter CPS-AC-POE1A-xx*
Wall mount for base station DMA-IBASE-WALL-00
Stand DM-STAND-00
Rubber sleeve DM8600-SLEEVE-00
5

*xx can be US, EN, UK, or JP.
Lens Options and Covers
6.2 mm lens kit DM150-LENS-62
Clear lens cover DM150-CVR-CLR
Clear lens cover,ESD safe* DM150-CVR-ESD
Polarized front cover DM260-LENS-62CVR-F
Red LED illumination (Risk Group Exempt acc. IEC 62471)
White LED illumination (Risk Group Exempt acc. IEC 62471)
Blue LED illumination (Risk Group Exempt acc. IEC 62471)
DM150-LED-RED
DM150-LED-WHT
DM150-LED-BLU
High Powered red LED illumination DM260-LED-RED-HP
Cables
Accesory Name Product ID Illustration
Coiled RS-232 cable for reader, 2.5 m DM8000-RS232-02
Industrial RS-232 cable for reader, 2.5 m DM8000-RS232IND-02
Coiled RS-232 cable for reader, 4 m DM8000-RS232-05
Coiled USB cable, 2.5 m DM8500-USBC-02
6

Ethernet cable, 2.5 m DM8000-ECABLE-02
Ethernet cable, 30 m DM8000-ECABLE-30
Ethernet cable, 5 m DM8000-ECABLE-05
USB cable, 2.5 m DM8500-USB-00
Coiled Ethernet cable, 5m DM8000-ECABLEC-05**
Coiled Ethernet cable with X-coded M12 connector, 5m DM8000-ECABLEC-M12
RJ25 (RJ12) to DSUB9 cable for base station, 5 m DMA-RS232RJ-05
** Collimated cable length including DM8000-ECABLE-X should not
exceed 50 m.
lUSB cable for base station: Use any standard USB-A to USB-B
2.0 cable up to 3 meters.
lEthernet cable for base station: Use any standard CAT5/5e,
SF/FTP or S/FTP cable.
lDMA-USB-00: Straight 10ft USB cable.
7

Field of View and Reading Distances
Depth of Field values
Note: All values beginning with 0 denote the minimum distance where the
Field of View is able to see the entire code.
Note: The calibration distance is 143.0 mm from the nose of the lens, and the calibration tolerance is +/- 5
mm.
8

Connecting the Reader
Wireless Readers
1. Connect the slide-in to the reader and tighten the screws to lock the slide-in.
2. Insert the battery.
3. Insert the plug.
Corded Readers
1. Connect the slide-in to the reader and tighten the screws to lock the slide-in.
2. Insert the plug. Slide the cable lock up to the reader and twist the cable lock
in place.
Note: Disconnect the DataMan 8600 from powerbefore inserting the communication modules.
9

Installation
Installation procedures are detailed in the DataMan 8600 Reference Manual, which
is installed with the DataMan Setup Tool. From the Windows Start menu, select the
following to access the manual: All Programs > Cognex > DataMan Software vx.x.x >
Documentation.
Note:
lCables are sold separately.
lIf a standard component is missing or damaged, immediately contact
your Cognex Authorized Service Provider (ASP) or Cognex
Technical Support.
CAUTION:All cable connectors are "keyed" to fit the connectors on the
DataMan system; do not force the connectors or damage may occur.
Install Software, Documentation and
Connect the Reader
To configure a DataMan 8600 reader, the DataMan Setup Tool software must be
installed on a PC on the network. The DataMan Setup Tool is available from the
DataMan support site: cognex.com/support/dataman.
1. After installing the software, connect the DataMan 8600 to your PC.
2. Launch the DataMan Setup Tool and click Refresh.
3. Select your DataMan 8600 reader from the list and click Connect.
10

DataMan 8600 Specifications
Specification DataMan 8600 Reader
Weight 303 g (without slide-in),
345 g (with tethered slide-in)
Operating Temperature 0 ºC — 45 ºC (32 ºF — 113 ºF)
Storage Temperature DataMan 8600 wireless: -10 ºC — 45 ºC (14 ºF — 113 ºF),
DataMan 8600 tethered: -40 ºC — 60 ºC (-40 ºF — 140 ºF)
Maximum Humidity < 95% (non-condensing)
Environmental IP65
Symbologies 1-D barcodes: Codabar, Code 39, Code 128, and Code 93, Interleaved 2 of 5,
Pharma, GS1 DataBar, Postal, UPC/EAN/JAN, DataBar
2-D barcodes: Data MatrixTM; QR Code and microQR Code, RSS/CS, PDF 417,
MicroPDF 417
Power Supply Requirements USB: external 5.0 W maximum LPS or NEC class 2 power supply: +5 V - +6 V
DC
RS232 external 5.0 W max LPS or NEC class 2 power supply
+6.0 V 1 A DC (5.0 m RS-232 cable)
+6.0 V 1 A DC (2.5 m RS-232 cable)
ETH: Class 2 PoE supply IEEE 802.3af (connect only to PoE networks without
routing to the outside plant)
Inrush current peak 5A maximum
Duration: approx. 30 μs
Electrical charge: 60 μAs at 6 V
Maximum capacity: 10 µF
Maximum inrush: 50 µC
Battery life for wireless
reader (typical use case)
ca. 2900 triggers can be operated within a 10 hour working shift
The expected life time of the wireless reader is 5 years.
Ethernet 10/100 Base-T FULL/HALF DUPLEX, IEEE 802.3
Bluetooth Bluetooth™ 2.1, 2.4 GHz
Wi-Fi 802.11 b/g, 2.4 GHz, User Selectable channels 1-11
Protection Base Station: IP65
11

DataMan Base Station Specifications
Specification
DMB-8700-xx
(depending on the
communication type)
DMA-IBASE-01
Weight 328 g
Operating
Temperature
0 ºC — 40 ºC (32 ºF — 104 ºF)
Storage
Temperature
-40 ºC — 60 ºC (-40 ºF — 140 ºF)
Maximum
Humidity
95% (non-condensing)
Power Supply
Requirements
24 V +- 10%, 13 W maximum LPS or NEC class 2 power supply, or
PoE class 3 (connect only to PoE networks without routing to the
outside plant)
LED Wavelengths for DataMan 8600 Reader
The following table shows LED types and the related wavelengths:
LED λ [nm]
RED 660
12

Regulations and Conformity
The DataMan 8600 has Regulatory Model 1AAT, the wireless slide-in has
Regulatory model 1ABB, and the Bluetooth slide-in has Regulatory model 1AAJ,
and meets or exceeds the requirements of all applicable standards organizations for
safe operation. However, as with any electrical equipment, the best way to ensure
safe operation is to operate them according to the agency guidelines that follow.
Please read these guidelines carefully before using your device.
Note: For the most current CE declaration and regulatory conformity
information, see the Cognex support site: cognex.com/support.
The following specifications apply to the corded DataMan 8600 readers:
Regulator Specification
USA FCC Part 15B, Class A
FDA/CDRH Laser Notice No 50
Canada ICES-003
European Community EN55022, Class A
EN60950
EN60825-1
EN61000-6-2
EN61000-6-4
The following specifications apply to the DataMan 8600 wireless readers:
Regulator Specification
USA FCC Part 15B, Class A
FCC Part 15.247
FDA/CDRH Laser Notice No 50
Canada ICES-003
RSS 210
13

European Community For Bluetooth:
EN301 489-1 / -17
EN55022
EN55024
For WiFi:
EN300 328
EN61000-6-2
Safety and Regulatory
Manufacturer Cognex Corporation
One Vision Drive
Natick, MA 01760 USA
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take immediate measures. This
equipment complies with the essential requirements of the EU Directive 2014/30/EU.
Declarations are available from your local representative.
EU RoHS Compliant to the most recent applicable directive.
FCC FCC Part 15, Class A
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Canadian Compliance This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe A est conforme à la norme NMB-003 du Canada.
UL and cUL Statement UL and cUL listed: UL60950-1 1st ed. and CSA C22.2 No.60950-1 1st ed.
14

Safety and Regulatory
Brazilian Compliance
This 1AAJ Bluetooth slide-in with model number DMCM-BTM-00 has frequency range
between 2.402 GHz and 2.480 GHz. Its Bluetooth specification is 2.1, 2.4 GHz with
FHSS modulation, PCB antenna with 3dB peak antenna gain.
Mexican Compliance For Bluetooth: RCPCO1A15-0074
For wifi: RCPC01A15-1366
Chinese Compliance For Bluetooth: CMIIT ID: 2015DJ0236
For wifi: CMIIT ID: 2015DJ3460
Laser Safety Statement
WARNING:Complies with FDA performance standards for laser products
except for deviations pursuant to Laser Notice No. 50, dated June 24, 2007.
This device has been tested in accordance with IEC60825-1 3rd ed., and has
been certified to be under the limits of a Class 2 Laser device.
15

For European Community Users
Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT
AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment
(WEEE).
This product has required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health and the
environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment and to
diminish the pressure on the natural resources, we encourage you to use the
appropriate take-back systems for product disposal. Those systems will reuse or
recycle most of the materials of the product you are disposing in a sound way.
The crossed out wheeled bin symbol informs you that the product should not
be disposed of along with municipal waste and invites you to use the appropriate
separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling systems, please
contact your local or regional waste administration.
You may also contact your supplier for more information on the environmental
performance of this product.
16

Compliance Statements: DataMan Base Station
The DataMan Base Stations have the following Regulatory models respectively:
DMA-IBASE-01 has R00043, DMA-IBASE-BT-XX has 1AAG, DMA-CBASE-01 has
R00046, and they meet or exceed the requirements of all applicable standards
organizations for safe operation. However, as with any electrical equipment, the best
way to ensure safe operation is to operate them according to the agency guidelines
that follow.
Note: For the most current CE declaration and regulatory conformity
information, see the Cognex support site: cognex.com/support.
Please read these guidelines carefully before using your device.
Regulator Specification
USA FCC Part 15B, Class A
FCC Part 15.247
Canada ICES-003
RSS 210
European Community EN301 489-1 / -17
EN300 328-2
EN60950
Safety and Regulatory
Manufacturer Cognex Corporation
One Vision Drive
Natick, MA 01760 USA
DMA-IBASE-BT-XX
DMA-IBASE-01
DMA-CBASE-01
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take immediate measures. This
equipment complies with the essential requirements of EU Directives 2014/30/EU and
2014/53/EU. Declarations are available from your local representative.
EU RoHS Compliant to the most recent applicable directive.
17

Safety and Regulatory
FCC FCC Part 15, Class A
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
Canadian Compliance This Class A digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe A est conforme à la norme NMB-003 du Canada.
UL and cUL Statement UL and cUL listed: UL60950-1 2nd ed. and CSA C22.2 No.60950-1 2nd ed.
Mexican Compliance DMA-IBASE-BT-XX: RCPCO1A15-0073
DMA-IBASE-01: RCPCODM12-0655
Chinese Compliance DMA-IBASE-BT-XX: CMIIT ID: 2015DJ0237
DMA-IBASE-01: CMIIT ID: 2012DJ2857
18

中国大陆RoHS (Information for China RoHS
Compliance)
根据中国大陆《电子信息产品污染控制管理办法》(也称为中国大陆RoHS)，
以下部份列出了本产品中可能包含的有 毒有害物质或元素的名称和含量。
Table of toxic and hazardous substances/elements and their content, as required by
China’s management methods for controlling pollution by electronic information
products.
Hazardous Substances 有害物质
Part Name
部件名称 Lead (Pb) 铅Mercury
(Hg)
汞
Cadmium
(Cd)
镉
Hexavalent
Chromium
(Cr (VI))
六价铬
Polybrominated
biphenyls
(PBB)
多溴联苯
Polybrominated
diphenyl ethers
(PBDE)
多溴二苯醚
Regulatory Model 1AAT
Regulatory Model 1ABB
Regulatory Model 1AAJ
Regulatory Model R00043
Regulatory Model 1AAG
Regulatory Model R00046
X O O O O O
This table is prepared in accordance with the provisions of SJ/T 11364.
这个标签是根据SJ / T 11364 的规定准备的。
O: Indicates that said hazardous substance contained in all of the homogeneous materials for this part is below the
limit requirement of GB / T26572 - 2011.
表示本部件所有均质材料中含有的有害物质低于GB / T26572 - 2011 的限量要求。
X: Indicates that said hazardous substance contained in at least one of the homogeneous materials used for this
part is above the limit requirement of GB / T26572 - 2011.
表示用于本部件的至少一种均质材料中所含的危害物质超过GB / T26572 - 2011 的限制要求。
19

Copyright © 2020
Cognex Corporation. All Rights Reserved.
