Coleman CX14WP User manual
About this Manual
Congratulations on purchasing the Coleman DV6000AF Sports & Action Camera! The
contents of this manual are subject to change without notice. Note that the example
screens and product illustrations shown in this User’s Guide may differ somewhat from the
screens and configuration of the actual camera.
Copyright
This manual contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic
or other means, in any form, without prior written permission of Elite Brands Inc. ©.
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1)
This device may not cause harmful interference and
(2)
This device must accept any interference received, including interference that
may cause undesired operation.
CE Mark Warning
This is a Class B product, in a domestic environment, this product may cause
radio interference, in which case the user may be required to take adequate
measures.
Camera Information
•
•
•
•
•
•
•
•
•
•
•
Do not disassemble or attempt to service the camera yourself.
Do not expose the camera to moisture, or extreme temperatures.
Allow the camera to warm up when moving from cold to warm temperatures.
Do not touch and put pressure on the camera lens.
Do not expose the lens to direct sunlight for extended periods.
Do not use abrasive chemicals, cleaning solvents or strong detergents to clean
the product. Wipe the product with a slightly damp soft cloth.
Do not use the flash or LED Light near a person's eyes to prevent possible eye
injury.
To prevent you from falling over or resulting in traffic accident, please do not
use the camera while you are walking, driving or riding a vehicle.
Please handle the camera strap with care, and never place the strap around the
neck of an infant or child. Wrapping the strap around a neck may cause
suffocation.
Do not subject the LCD screen to impact.
To prevent the risk of fire or electric shock, do not expose the inside of this
product to rain or moisture.
Battery Information
•
Turn off the camera before installing or removing the battery.
•
Use only the provided batteries or type of battery and charger that came with your
camera. Using other types of battery or charger may damage the device and
invalidate the warranty.
•
Inserting the battery upside down can cause damage to the product and possibly
cause an explosion.
•
When the camera is used for an extended period of time, it is normal for the
camera body to feel warm.
•
Download all pictures and remove the battery from the camera if you are going to
store the camera for a long period of time.
•
Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
•
Please keep the batteries out of the reach of children to prevent from swallowing
the batteries, which might cause poisoning.
•
If the battery's color or shape changes in any way, stop using the battery
immediately.
USB Adaptor Information
•
Do not expose the adapter to high temperatures or moisture places. Otherwise, it
may cause fire or electric shock.
•
Do not attempt to repair, disassemble, change or transform the adapter.
•
Avoid sudden changes in temperature, which may cause condensation on the
adapter’s internal surfaces. Please do not use it immediately in this situation.
•
Do not touch the plug with wet hands. Otherwise, it may cause electric shock.
•
Do not use the travel voltage converter or AC/DC power inverter. Otherwise, it
may cause damage, overheating, malfunction or fire to the camera.
Waterproof and Dustproof Information
•
The waterproof and dustproof performance described do not guarantee that the
camera will remain completely waterproof or free from damage and trouble under
all conditions.
•
Do not subject the camera to excessive shock, Vibration or pressure by dropping
it, hitting it or placing a heavy object on it. Failure to observe this precaution could
deform the camera, cause water to seep inside, or damage the airtight seals,
resulting in camera malfunction.
•
The battery door must be closed securely and the lock engaged in order for the
camera to be waterproof. Failure to do this can allow water to enter the camera
and damage it.
The camera can shoot images underwater at a depth of 3m (10ft) for up to 60
minutes.
xDo not drop the camera, strike it against a hard object such as a rock, or
throw it against a water surface.
xDo not subject the camera to shock when using it underwater.
xDo not expose to depths greater than 3m (10ft) underwater.
xDo not continuously use the camera underwater for 60 minutes or more.
xDo not insert a wet memory card or battery in the camera.
xDo not open the battery cover when the camera or your hands are wet. Doing
so may cause water to seep inside the camera or result in camera
malfunction.
xDo not open the battery cover underwater.
xIf moisture such as water droplets adheres to the outside of the camera or
inside of the battery cover, immediately wipe it off with a soft dry cloth.
xIf a foreign substance adheres to the outside of the camera or inside of the
battery cover, immediately remove it with a soft cloth.
xDo not leave the camera in cold conditions or hot conditions of 40°C (104°F)
or more for a long period of time.
xWhen using the camera underwater, make sure the water temperature is from
0°C-40°C (32°F to 104°F).
xDo not use the camera in hot springs.
Before Using the Camera Underwater
Check the items below before using the camera underwater.
xMake sure that there are no foreign substances inside the battery cover.
xMake sure that the waterproof packing of the battery cover is not cracked or deformed.
xMake sure that the battery door is firmly closed and the battery cover security lock is in the
LOCK position.
xFailure to follow these steps can result in damage to the camera.
Notes about Opening and Closing the Battery Door
xMake sure the camera and your hands are not wet.
xMake sure that there are no debris inside the battery-chamber or memory card slot.
xMake sure that the battery cover is firmly closed and the security lock is in the lock
position.
Precautions When Cleaning
xDo not puncture the microphone or speaker openings with a sharp
implement.
xIf the inside of the camera is damaged, the waterproof performance will
deteriorate.
xDo not use soap, natural detergents, or chemicals such as benzene for
cleaning.
Do Not Apply Strong Impact to the Camera
The product may malfunction if subjected to strong shock or vibration. In addition, do
not touch or apply force to the lens.
Avoid Sudden Changes in Temperature
Sudden changes in temperature, such as when entering or leaving a heated building
on a cold day, can cause condensation to form inside the device. To prevent
condensation, place the device in a carrying case or a plastic bag before exposing it
to sudden changes in temperature.
Keep Away from Strong Magnetic Fields
Do not use or store this device in the vicinity of equipment that generates strong
electromagnetic radiation or magnetic fields. Doing so could result in loss of data or
camera malfunction.
Do Not Point the Lens at Strong Light Sources for Extended Periods
Avoid pointing the lens at the sun or other strong light source light sources for
extended periods when using or storing the camera. Intense light may cause the
image sensor to deteriorate or produce a white blur effect in photographs.
Turn the Product Off before Removing or Disconnecting the Power Source or
Memory Card
Do not remove the battery while the product is on, or while images are being saved
or deleted. Forcibly cutting power in these circumstances could result in loss of data
or cause damage to the memory card or internal circuitry.
Notes about the LCD Screen
xThe LCD Screens are constructed with extremely high precision; At least
99.99% of pixels are effective, with no more than 0.01% being missing or
defective. Hence, while these displays may contain pixels that are always lit
(white, red, blue or green) or always off (black), this is not a malfunction and
has no effect on images recorded with the device.
xImages viewed on the LCD screen may be difficult to see under certain
lighting.
xDo not apply pressure to the LCD screen, as this could cause damage or
malfunction.
The Battery
Precautions for Use
xNote that the battery may become hot after use.
xDo not use the battery at ambient temperatures below 0°C (32°F) or above
40°C (104°F) as this could cause damage or malfunction.
xIf you notice any abnormalities such as excessive heat, smoke, or an unusual
smell coming from the battery, immediately discontinue use and consult your
retailer.
xAfter removing the battery from the camera or optional battery charger, put
the battery in a plastic bag, etc. in order to insulate it.
Charging the Battery
Check the battery level before using the camera and replace or charge the battery if
necessary.
xCharge the battery indoors with an ambient temperature of 5°C (41°F) to
35°C (95°F) before use.
xA high battery temperature may prevent the battery from charging properly or
completely, and may reduce battery performance. Note that the battery may
become hot after use; wait for the battery to cool before charging. When
charging the battery inserted into this camera using the Charging AC Adapter
or a computer, the battery is not charged at battery temperature below 5°C
(41°F) or above 55°C (131°F).
xWhen the battery is between 45°C (113°F) - 55°C (131°F), the chargeable
capacity may decrease.
xDo not continue charging once the battery is fully charged as this will result in
reduce battery performance.
xThe battery temperature may increase during charging.
Using the Battery When Cold
On cold days, the capacity of batteries tends to decrease. If an exhausted battery is
used at a low temperature, the camera may not turn on. Keep spare batteries in a
warm place and exchange as necessary. Once warmed, a cold battery may recover
some of its charge.
Recycling Used Batteries
Replace the battery when it no longer holds a charge. Used batteries are a valuable
resource. Please recycle used batteries in accordance with local regulations.
Cleaning After Using the Camera Underwater
Follow the procedure below to rinse the camera with fresh water within 30 minutes
after using it under saltwater or at the beach.
1.
Keep the battery cover closed and wash off the camera with fresh water.
Immerse the camera in a shallow basin filled with fresh water for 10
minutes.
2.
Immerse the camera in fresh water and shake it sufficiently in the water to
remove any foreign substances from the camera.
3.
When the cameras is immersed in the water, a few air bubbles may come
out from the water drain holes of the camera such as openings in the
microphone or speakers. This is not a malfunction.
4.
Wipe off water droplets with soft cloth and dry the camera in a well-
ventilated and shady place.
5.
Place the camera on a dry cloth to dry it.
6.
Do not dry the camera with hot air from a hair dryer or clothes dryer.
7.
After making sure that there are no water droplets on the camera, open the
battery cover and use a soft dry cloth to gently wipe off any water or sand
remaining on the waterproof packing or inside the camera.
xIf the cover is closed when the inside is wet, this could cause
condensation or a malfunction.
Cleaning After Using the Camera in Conditions Other than Underwater
Use a blower to remove any dust or lint that adheres to the lens, monitor or camera
body. To remove fingerprints or other stains that cannot be removed with a blower,
gently wipe the parts with a soft dry cloth. If you wipe with too much pressure or with
a rough cloth, it may damage the camera or cause a malfunction.
Storage
If you do not intend to use the camera for an extended period, remove the battery
and avoid storing the camera in any of the following types of locations:
xPlaces that are poorly ventilated or subject to humidity of over 60%
xPlace exposed to temperatures above 50°C (122°F) or below -10°C (14°F).
xPlace next to equipment that produces strong electromagnetic field, such as
television or radios.
To prevent mold or mildew, take the camera out of storage at least once a month,
and turn it on and release the shutter a few times before putting it away again.
DISPLAY
DOWN
UP
SPEAKER
LED INDICATOR
CHARGING INDICATOR
LENS
HDMI OUTPUT
USB PORT
MICROSD
SLOT
POWER / MODE
LED INDICATOR
OK / ENTER
LENS
WATERPROOF
CASE LATCH
POWER /
MODE
DOWN
UP
MOUNT
OK / ENTER
Operating Guide
1. Inserting / Removing a Memory Card
Ensure the camcorder is powered off. Insert a
MicroSD card into the MicroSD card slot. The
MicroSD card can only be inserted one way. Do
not force it through. Once successfully inserted, it
will click in. To remove, simply push the card in for
it to pop out.
2. Inserting / Removing the Battery
a. Remove the battery cover by pinching the
small tab inward and pull up.
b. The battery is purposely shaped so that it can
be inserted only one way. Follow the shape of
the battery compartment before inserting.
c. To remove the battery, first power the
camcorder off. Remove the battery cover. The
battery is easily removed by pulling on the
black plastic pull tab.
Charging the Battery
Connect the included USB cable’s small end into the camcorder’s USB input, and the larger
end into the AC adaptor. The LED will in red and will once the
battery is fully charged.
You may use the camcorder for recording or playback while it is plugged into auxiliary power
(AC adaptor, computer, mobile charger).
For the quickest charge, please ensure that the camcorder is powered off.
Power On / Off
Ensure that the battery is fully charged.
Press and hold the POWER button for 3 seconds until the camcorder powers on. Press and
hold the POWER button again for 3 seconds to power off.
Enabling / Disabling WiFi
Enabling WiFi: Press the UP button once. The LED light will flash in yellow and the screen
will display the WiFi details.
Disabling WiFi: Once the WiFi is enabled, press the UP button once. The yellow LED light
will no longer illuminate.
Changing Modes
The power button also functions as the MODE button. Once the camcorder is powered on,
press the power button to cycle between Recording Videos / Shooting Photographs / Slow-
Motion Video / Burst Photo / Playback / Settings.
9M=&"9=$MJ-$&9M&7AH>&MC,&M"5&>M-AM97M7$M-7MM59$&
:M!'*.8M?'#:?%/8*M
=&AAMC,&MM HCC97M ,&M"5&>MK-32M&5-CMMA9H7$M7$MC,&M
ACCHAMK023M 3-71MK,-2&M=&"9=$07+
:MBD:;M'#:?%/8*M
=&AAMC,&MM HEF97M+-7M ,&M"5&=MK033M&5-CM79C,&=M
A9H7$M7$MC,&MACCHAMMK-32M79M397+&>M-33H507C&
7AH=&MC,&M"5&=M0AM-7MM59$&M LMC<<07+MC,&M M HEF97
:M#;DI?'MM;,:D:
@&AAMC,&MM HCF97M ,&M"5&>MK-32M&5-CMMA9H7$
7AH>&MC,&M"5&>M0AM-7MM M 59$&MC<<-7+MC,&M M HG97
:MBD?DM!I?BDM;,:D:B
=&AAMC,&MM HCC97M ,&M"5&>MK-32M&5-CMA9H7$AM(>M&",M<,9C9
7AH>&MC,&M"5&>M0AM-7MM M59$&M LMC<<-7+MC,&M M HCC97M7$M
J&>-)MC,CM-AM&7 2&$M-7MC,&MA&CC07+AM5&7H
:MBD?DMMD/6'M4;B'MB'?/'B
=&AAMC,&MM HCF97M ,&M"5&>M-70C-C&AMM"9H7C$9K7M7$MK-33M&5-CMM
LED Light Color Statuses
Blue LED: The camcorder is busy processing an image or video.
Yellow LED: WiFi is enabled. When flashing yellow, the WiFi is waiting to connect; when
solidly lit, WiFi is connected.
Red LED: The battery is charging.
Recording Video
Once powered on, the camcorder automatically enters VIDEO mode. Press the ENTER button
to begin recording. The bottom of the screen will show a flashing red dot, denoting that video is
recording. Pres the ENTER button again to stop recording.
Shooting Photographs
Once powered on, press the POWER button again to enter PHOTO mode. Press the ENTER
button to capture a photo. The upper left corner of the screen will show that you are in PHOTO
mode.
Recording Slow Motion Video
Once powered on, press the POWER button twice to enter SLOW MOTION VIDEO mode.
Press the ENTER button to begin recording. The bottom of the screen will show a flashing red
dot, denoting that video is recording. Press the ENTER button again to stop recording.
Playback on Camcorder
Once powered on, press the POWER button to cycle through the modes until you enter
PLAYBACK mode. Press the UP and DOWN buttons to cycle through your media. Press
ENTER to playback a video file. Press and hold the ENTER button for 3 seconds to delete a
single file.
Connecting to a Computer
Connect your camcorder to a computer with the included USB cable. Power the camcorder
on and the following prompts will display.
Go to Start -> My Computer -> and find the removable disk. Your camcorder acts like a
card-reader when connected and can be easily accessed this way. Your media will be
stored in a folder on this removable disk. Copy the folder to your computer.
13. Connecting to a Smartphone
STEP 1: Download the Smartphone App
To wirelessly operate the DV6000AF amcorder you will need to
install the “XDV” app on your Android or iOS device. Scan the
QR Code below to download the app.
STEP 2: Connecting Your Camera to Your Smartphone
The camcorder can be operated remotely by following the steps below:
1.
Power the camera on and press the UP button once to activate the WiFi network. The
WiFi network name and password will be displayed on the screen.
2.
To disable the camera’s WiFi network, press the UP button once again.
3.
The status LED will blink YELLOW while searching for a WiFi connection.
4.
Go in to your smartphone’s WiFi network settings menu, turn all wireless settings ON
and connect to the network named “COLEMAN” to join your camera to the network.
The WiFi password is 12345678.
5.
The status LED will show a steady YELLOW color when connected and the
camcorder screen will turn off.
6.
On your smartphone, exit the wireless menu and open the “XDV” app to launch
remote operation of the camcorder.
7.
The app will automatically connect with your camcorder.
STEP 3: App Location Settings - iOS
Once connected successfully, launch the XDV app. When
launching the app for the first time, you will be prompted
to allow the XDV app to use your location.
Select "Allow While Using App". This will allow the app
to communicate with your camera and will allow the app
to work properly. The app will not connect to your camera
if you select "Don't Allow".
As part of the iOS operating system, your smartphone's
Location Settings must be enabled in order to allow
proper communication between your smartphone and
your Coleman camera. Selecting will prevent your camera
from connecting to the XDV app.
If you selected “Don’t Allow”, then you can change this
setting by going into your iOS Settings, selecting the XDV
app, selecting the Location settings and select “While
Using App”.
STEP 4: Operating the XDV App
Your camera can now integrate with your smartphone. Upon launching the app, it
will initially default to the video recording function. Follow the steps below to select
modes.
To change recording modes, tap the each mode icon on the at the center of the
smartphone app.
VIDEO MODE PHOTO MODE SLOW-MOTION
Recording Videos Remotely
1.
To start recording a video, tap the Video icon on your
smartphone screen. While a video is recording remotely, the
status indicator LED will flash
2.
The Video Recording mode can be changed by selecting
one of the options shown below. You can select Normal
video recording, Loop Recording or Time-Lapse.
Shooting Photos Remotely
1. Switch to Photo mode by tapping the Camera icon on your
smartphone screen. To capture a photo, tap the Camera
icon again.
2. The Photo mode can be changed by selecting one of the
options shown below. You can select Normal, Self-timer,
Photo Burst or Time-Lapse.
Table of contents
Other Coleman Action Camera manuals
