Coleman 14' EVENT SHADE User manual

14’ EVENT SHADE MODEL 2000001447
STITCH LINE
Before you begin
Read all instructions before set up.
• Select a level site clear of rocks, branches, and other hard
or sharp objects to install your shelter.
WARNING: Keep clear of overhead power lines.
• It is important to the stability and life of your shelter to have a
secure mounting surface.
• Consult a local contractor for any local building code
requirements.
• Enlist the help of at least one other person to assist you when it
is time to assemble the shelter.
Corner Locator
Important: All four Pad Feet of the Event Shade must be located
14 feet apart. For accurate placement, use the rings on the corner
locator to mark locations (Fig. 1):
a) Place white ring on corner locator at point “A” and mark with
a stake.
b) Extend rings “B” & “C” out to form a 90° angle and mark both
points with a stake. Distance between point “B” & “C” will
measure 19’ 8”.
c) To locate corner “D”, unhook white ring from corner “A” and
move diagonally as shown and mark.
d) Remove and stow corner locator for future use.
(continued on other side)
Fig. 1
To Set Up Shelter
1. Assemble Peak Pole
with Center Hub. (Fig. 2)
Fig. 2
Fig. 3
2. Assemble both Peak Connector
Poles. (Fig.3)
4. Partially assemble the four Leg Poles with Ridge Hub. (Fig. 7)
NOTE: Do not assemble the last pole on each side of the Ridge
Hubs at
this time.
3. Insert ends
of the Peak
Connector Poles
marked with the
arrows into the
Peak Pole with
Center Hub.
(Fig. 4, 5 & 6) Fig. 4 Fig. 5
Fig. 6
Fig. 7
19’ 8”
Fig. 9
5. Insert end of Peak Connector Pole into Ridge Hub (Fig. 8 & 9).
Repeat for the remaining three Leg Poles with Ridge Hub.
NOTE: Make sure
metal pin locks into
slot on top of Ridge
Hub, you may have to
twist Peak Connector
from side to side.
Slot
Metal Pin
Peak Connector
Pole
Fig. 8
Parts and Components
Description Part Number
Peak Pole w/Center Hub (1) 5010000462
Peak Connector Poles (2) 5010000463
Leg Pole w/Ridge Hub (4) 5010000464
Pad Feet (4) 5010000465
Canopy (1) 5010000466
Peak Pole w/Center Hub (1) Leg Pole w/Ridge Hub (4) Pad Feet (4)
Peak Connector Poles (2)
Center Hub
Ridge Hub

Fig. 10
STITCH LINE
The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA • PRINTED IN CHINA
© 2007 The Coleman Company, Inc.
Coleman®and are registered trademarks of The Coleman Company, Inc.
Things You Should Know:
• Never store your shelter, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes or poles inside
your shelter. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF.
NEVER PULL ON THE CANOPY TO REMOVE STAKE.
• SHELTER POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER
DURING STORAGE.
WARNING: Keep all flame and heat sources away from
this shelter fabric.
This shelter meets the flammability requirements of CPAI-84. The
fabric will burn if left in continuous contact with any flame source.
The application of any foreign substance to the shelter fabric may
render the flame-resistant properties ineffective.
To Set Up Shelter (continued)
Fig. 11
7. Locate the hook & loop fasteners
closest to the center of the under
side of the canopy and wrap around
poles to secure. (Fig. 11)
8. Position Pad Feet at the four corners
(determined with the use of the Corner
Locator in Step 1) as shown. (Fig. 12)
NOTE: Pad Feet must angle toward
center of shelter with vertical slots
facing outward.
Slots
Fig. 12
Fig. 13
9. Insert ends of Poles into Pad Feet and twist
until metal pin locks into slot (Fig. 13).
10. Repeat for other three Pad Feet locations.
Fig. 15 Fig. 16
Fig. 17 Fig. 18
Fig. 19
Angle faces
inward
Metal
Pin in
slot
12. Attach hook end of Canopy
tension strap to square slot
on the Pad Feet. Repeat for
the remaining three Pad
Feet. Pull down strap, at
each corner, to tighten.
(Fig. 15 & 16)
14. Locate all hook & loop fasteners
on the seams on the inside of
the Canopy. Wrap around Poles
and secure tightly. (Fig. 19)
15. Attach Guy Lines to web loops
located on outside seams of
Canopy then secure with stakes.
(Fig. 20)
Fig. 14
Web Loop
Guy Line
Stake
Fig. 20
Optional sun walls may
be placed in any of the
arched openings of the
Shelter. See your
local retailer or visit
www.coleman.com
to order part number
2000001440.
6. Unfold Canopy and pull over frame. Fold back one flap on
canopy to allow easy access to inside of shelter frame and under-
side of canopy. (Fig. 10)
13. Wrap web straps around
Pole at all four corners and
hook snap-in buckles.
Pull strap to tighten.
(Fig. 17 & 18)
11. Drive stakes through holes in Pad Feet
to secure BEFORE proceeding to Step 12.
(Fig. 14)
NOTE: Coleman provides 2 stakes per
Pad Foot. Soil type may dictate the use
of more stakes. Extra stakes may be
purchased at any local sporting goods
retailer.
Completed Shelter
Rev11/2007
