Coleman FOSSIL CREEK 200001391 User manual

3Attach Tent to Frame
Using Frame Clips
– Attach frame clips along
the edges of tent to frame poles.
(illus. 5), (illus. 6)
– Make any adjustments to the tent corner
stakes that are needed.
4Attach Rainfly
– Assemble rainfly pole by interlocking
shock-corded pole.
– Insert rainfly poles into pole sleeves located at
the center edges of the underside of rainfly.
(illus. 7)
– Drape rainfly over tent frame, pole side down.
Rainfly poles should cover door and rear
window.
– Connect the four elastic loops with “S” hooks,
(found at the rainfly corners) to the rings located
on the stake loops. (illus. 8)
– Insert the tips of the rainfly poles into the
grommets.
– Secure rainfly with attachments located on
underside of fly. (illus. 8)
– Assemble and insert (short) Vertical Hinged
Door Pole through vertical sleeve and into
bottom pole stop. Gently apply pressure to
insert top end into top pole stop and zip sleeve
closed. (illus. 9, 10)
– Assemble and insert (long) Hinged Door Pole
through curved door sleeve and into top pole
stop. Gently apply pressure to insert bottom
end into bottom pole stop and zip sleeve
closed. (illus. 9, 10)
– Attach and stake out guylines. (illus. 8)
illus. 6
Assembled tent without rainfly.
illus. 5
Frame clips
illus. 8
Completed
tent with
rainfly.
illus. 7
side guy
lines
Underside
of rainfly
attaches to
frame
poles
Rainfly poles
Rainfly pole sleeves
Stake down
Pole
Attachments
THE COLEMAN CO., INC.
3600 N. Hydraulic • Wichita, Kansas 67219
1-800-835-3278 • www.coleman.com
MADE IN CHINA
PRINTED IN CHINA Rev. 1/07
Things You Should Know
• Under certain conditions (cold weather, high humidity, etc.)
condensation will form on the inside surfaces of your tent. Condensation is
caused by water vapor from your breath, perspiration, or any wet clothing
inside your tent. It is NOT LEAKAGE through the tent fabric. It can be
minimized by removing wet clothing from your tent and by providing good
ventilation through the tent.
• Never store tent, even for a short period of time, without drying it
thoroughly and brushing off caked dirt. Do not pack stakes or poles inside
your tent. Use a separate storage bag.
• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE ITSELF.
NEVER PULL ON THE TENT FABRIC OR TENT STAKE LOOP TO
REMOVE STAKE.
• TENT POLES SHOULD NOT BE LEFT TELESCOPED
TOGETHER DURING STORAGE.
• Do not leave your tent set-up for weeks at a time, be aware that
exposure to the ultraviolet rays of the sun can seriously damage material
and/or cause it to become discolored.
WARNING: KEEP ALL FLAME AND HEAT SOURCES
AWAY FROM THIS TENT FABRIC. This tent meets the
flammability requirements of CPAI-84. The fabric may burn
if left in continuous contact with any flame source. The
application of any foreign substance to the tent fabric may
render the flame-resistant properties ineffective.
Grommets for rainfly poles
illus. 9 Hinged Door
Pole Stop illus. 10 Hinged Door
Long Door
Pole inserts
into sleeve
and pole
stops, then
zips in.
Vertical Door
Pole inserts
into sleeve
and zips in
