Colorbeam T021 User manual

ORBIT TP Easy Touch Panel &
T021 Remote Control System
Version 1.0 December 2012
DRY
User Guide

CONTENTS
1
www.colorbeam.com
1. ITEMS INCLUDED BEFORE UNPACKING.........
2. INTRODUCTION..............................................
3. SPECIFICATION..............................................
4. FUNCTION SCHEMA & INSTALLATION............
5. WIRING DIAGRAM...........................................
6. WARNING.......................................................
7. OPERATION....................................................
8. ORDER INFORMATION....................................
2
3
4
5
5
6
7
10

ITEMS INCLUDED
ORBIT TP
Wall Fixed Plate
(1pcs.)
Screw
(4pcs.)
Remote Controllor
Please make sure the below items were inlcuded when unpacking.
If there is anything missing, please call your local dealer immidently.
2
www.colorbeam.com

1. Easy wiring
2. Easy operation by touch panel
3. IR remote control
4. Friendly Interface
5. 3 Channel modes
6. 11-fixed color mode
7. 7-fading mode
8. RGB and WHITE adjusting
9. BRIGHTNESS and SPEED adjusting
10. Memory Capability
Features:
COLORBEAM design simple operation control system ORBIT TP and
T021 remote control for ORBIT series lights, built in program with 3
channel modes (1 color channel mode, 3 color channel mode, 4 color
channel mode) which is suitable with any led lighting fixture in the
market.
The Orbit TP with 11 built in fixed color can be memories easily with
adjustable the brightness and color, 7 built in fading mode can adjust
the speed by user's preferences.
INTRODUCTION
www.colorbeam.com
3

SPECIFICATION
4
www.colorbeam.com
Electrical
Power Voltage: 24 VDC (ORBIT TP)
Power Requirement: Lithium Battery (model no.CR2025) T021
Communication: USITT DMX512-A address setting
90mm
90mm
21.5mm30.89mm
82.89mm
T021 ORBIT TP
Function
Power on / off
Channel mode (single color, 3colors, 4colors )
11 pre-set static colors
7 pre-set fading mode
RGB, White adjustment individual
Speed adjustment
Brightness adjustment
Storage function
Housing
Dimension (mm): ORBIT TP (L90 × W90 × H21.5)
T021 (L82.89 x W30.89 x H9.4)
Weight: ORBIT TP ( 138.5 g)
T021 ( 16.5 g)
Color: White
Listing
Certifications: CE / RoHS / WEEE
DIMENSIONS

FUNCTION SCHEMA
INSTALLATION
www.colorbeam.com
5
INSTALLATION
FUNCTION SCHEMA
NOTICE:
1. Please notice the idea of the wiring for all Colorbeam fixture is in series connection.
2. The warranty will be invalid when the fixture is not under normal usage (including trimming the cable
and do wiring by user).
Please contact with your sales representative for the detailed information if the trimming will be happen.
Seven Segment Displays
Touch Panel
Touch Slide
Channel Mode Key
On/Off
Lights Adjustment Key
Terminal Block of Wiring
Wiring Information
D+
D-
GND
DC+
Description
DMX-
GROUND
DC24V +
Symbol
DMX+
Cable Color
White
Green
Black
Red
1. Pass the wires through the metal backplate, and tighten the plate on the wall with 4
screws.
2. Connect the wires to the customized terminal block in accordance with D+, D-, GND,
DC+.
3. Place Orbit TP on the metal backplate.
3
2
1
WALL
WALL
WALL
Please unplug from the mains before installation.

Read the instructions carefully before you install or powering!
2. Operation Determinations
The device must only be used indoor.
If the device has been exposed to drastic temperature fluctuation, do not switch it on
immediately. The arising condensation water might damage your device. Leave the device
switched off until it has reached room temperature.
Only operate the device after having checked the housing which is firmly closed and all
screws are tightly fastened. Do not shake the device. Avoid brute force when installing or
operating the device.
Operate the device only after having familiarized with its functions. Do not permit operation
by persons who are not qualified for operating the device. Most damages are the result of
unprofessional operation!
The maximum ambient temperature 40 degree must never be exceeded.
Please consider that unauthorized modifications on the device are forbidden due to safety
reasons!
WARNING
CAUTION!
Be careful with your operations.
You can suffer a dangerous electric shock when touch the wires inside the unit.
Keep this driver away from rain and moisture.
Unplug mains lead before opening the housing.
Make sure the plug is tightly connected with outlet.
Make sure all connector are connected properly.
Make sure the AC power that complies with local electrical codes.
Do not expose the device to heat source, corrosive, flammable or explosive area.
Do not block any of ventilation openings.
Do not open the device and try to repair the device personally.
Important
Every person involved with installation and maintenance of the this device has to :
-be qualified.
-following the instructions of manual
Please make sure that there are no obvious transport damages.
Please immediately contact the local dealers as the device is in fault operation or damage.
Damages caused by the disregard of this user manual or unauthorized modification to
products are not subject to warranty.
1. Safety Instructions
6
www.colorbeam.com
!
CAUTION!
For non-Colorbeam fixtures, refer to the
wiring diagram for installation.

Attention: It is import to read this manual before you install or use this product.
OPERATION
ORBIT TP
•POWER ON/OFF
(1)Power ON/OFF
Press the circle with [ON/OFF] letter on the panel to turn the unit ON/OFF.
The display will fade out when turning off the device. When the device is turned
on,『---』will be displayed and it will start in the last used mode.
(2)Memory function
Memory function: The controller will automatically memories the last setting when
turn off the unit and will continue to perform when turn on the unit again.
•CHANNEL MODE SETTINGS
(1)
Orbit TP is suitable for single color (1CH) / tri-color (RGB)(3CH) / four-color
(RGBW) (4CH) fixtures. Please kindly note that the channels need to be set
accurately before operations.
(2)Setting
Press [RGB] and [WHITE] on the device (panel) together and select the channels
by slider while the device is turned off. The display will show 『---』 after finished
the setting. After finished the setting, touch the button [ON/OFF] to start operating
the device.
1 Color CH Mode
4 Color CH Mode
Channel Mode
1CH=W
1CH=W, 2CH=R, 3CH=G, 4CH=B
First Light
1CH=R, 2CH=G, 3CH=B
3 Color CH Mode
•RESET
(1)This function is for user to reset to original setting from factory.
Make sure the panel device is in OFF condition and the display shown『---』.
Touch and hold the [BRIGHTNESS] and [SPEED] together until 『---』 vanish and
the display show 『C01』. When see the display show 『C01』means the
resetting is success.
(2)Original setting
MODE: 4CH
COLOR: C01
FADING: F01
RGB: 000
WHITE: 000
BRIGHTNESS: 255
LGHTS: 12 nos
C1: Red
C2: Green
Note: T-021 can not operate the reset function.
www.colorbeam.com
7

OPERATION
4 COLOR CHANNEL MODE
(3)Operation Example
•Fixed Color Effects
(1)
There are 11 built-in fixed colors. The fixed colors can be selected by gliding the
slider on Orbit TP.
(2)
Adjust the hue spectrum value of fixed colors by touching the slider on Orbit TP,
and pressing [COLOR] again to create custom colors. When see the display is
blinking (one time) means the custom color is saved.
Note: COLOR mode is not functional under fixed COLOR mode.
Condition: Adjust 『C01』 to light orange color under fixed COLOR mode：
Touch the bottom [RGB] and select『C01』, using slider to select the number 30.
Touch the bottom [WHITE] to mix the color, using slider to select the number 70.
Touch the bottom [BRIGHTNESS] to adjust the brightness to get your favorite
light orange color.
When finish the above steps, touch bottom [COLOR] again to save the new color.
•RGB
•WHITE
For a quick change of the color illumination in fixed COLOR mode, the colors can
be adjusted touching the slider on Orbit TP.
Press [COLOR] again on Orbit TP, the changes will be saved and replaced the
prime colors.
(1)
For a quick change of the intensity, it can be adjusted by gliding the slider on Orbit
TP.
Press [COLOR] again on Orbit TP, the changes will be saved and replaced the
prime color.
0 255
OFF Red Orange Yellow Green Blue Indigo Purple White
(2)Memory function
(1)
Note: SPEED mode is not functional under RGB mode.
(2)Memory function
Note: WHITE only can be applied in CH04 mode. T-021 can not operate this
function
Under the power off circumstances, Press [RGB] and [BRIGHTNESS] on the
device (panel) at same time, and select the numbers of lights by gliding the
slider. After finished setting, press the circle with [ON/OFF] letter to start
operating.
For DMX address setting, please refer user manual of dipswitch page of Orbit
lighting include with package.
The maximum channel number can be set up are 60 groups (1 DMX channel
needed for single color led fixture / 3 DMX channel needed for tri-color led
lighting fixture / 4 DMX channels needed for four-color led lighting fixtures).
DMX setting example:
Before operate this FADING mode, please check every lighting fixtures has set the
DMX address correctly.
•FADING
8
www.colorbeam.com

OPERATION
(1)There are 7 preset fading effects
F01 Color fade: All the fixtures run the fixed colors in order simultaneously.
F02 Cross fade: All the fixtures will be separated into two groups which based on
odd and even numbers. Each group will run a smooth transition from one
solid color to another sequentially.
F03 Color Cavort: An animated color effect will chase in order from the first fixture
to the last one.
F04 Color Sweep: A smooth color transition will spread from the first fixture to the
last one
F05 Rainbow Cavort: A sequence of rainbow colors will chase from the first fixture
to the last one in one direction.
F06 Rainbow Sweep: A sequence of rainbow colors moving in one direction
gradually.
F07 Color fade: All the fixtures run the fixed color C1 and C2 in order
simultaneously. example: C1 C2 C1 C2 C1 C2.
Example 1
a. Condition: Total 30 units with RGBW 4-color led, install in 5 groups, needed
every 6 units in same address, total needed 5 DMX address number.
b. DMX address setting
Group 1 (the first 6 units): DMX address setting 1
Group 2 (the second 6 units): DMX address setting 5
Group 3 (the third 6 units): DMX address setting 9
Group 4 (the fourth 6 units): DMX address setting 13
Group 5 (the fifth 6 units): DMX address setting 17.
(For DMX address setting, please refer user manual of dipswitch page of Orbit lighting include with package)
c. CH setting must be 5 for each group under this condition.
Example 2
a. Condition: Total 4 units with tri-color led, every unit need one address, total
need 4 DMX address number.
b. Group 1 (the first unit): DMX address setting 1
Group 2 (the second unit): DMX address setting 4
Group 3 (the third unit): DMX address setting 7
Group 4 (the fourth unit): DMX address setting 10.
(For DMX address setting, please refer user manual of dipswitch page of Orbit lighting include with package)
c. CH setting must be 4 for each group under this condition.
Condition: Under the FADING mode, adjust BRIGHTNESS and SPEED of F01 .
To adjust the brightness of F01 , touch the [BRIGHTNESS] bottom first, and slide
the slider to get favorite brightness.
To adjust the speed of F01, touch the [SPEED] bottom first, and slide the slider
to get the favorite speed.
The adjustment of BRIGHTNESS and SPEED will save automatically. Please do
not touch [FADING] bottom again.
(4)Operation Example
NOTE: RGB and White mode cannot be used in FADING mode, the display will
shown『---』; only the BRIGHTNESS and SPEED can be adjusted.
NOTE: In FADING mode, the lowest brightness value can only be adjust to the
100.
The FADING effects can be selected by gliding the slider on Orbit TP.
(2)
In fading mode, the changes are saved automatically each time when enter a new
value.
(3)Memory function
www.colorbeam.com
9

•SPEED
(1)
In FADING mode, it can adjust from value 1-10 for the desired color.
(2)
For a quick change of the speed in FADING mode, the colors can be
adjusted by gliding the slider on Orbit TP.
•BRIGHTNESS
(1)
For a quick change of the brightness in COLOR and FADING mode, the colors can
be adjusted by touching the slider on Orbit TP.
NOTE: In FADING mode, the lowest brightness value can only be adjust to the 100.
3 COLOR CHANNEL MODE
(1)
In 3 color channel mode, only WHITE can't be display. The other functions are the
same as 4 Color channel Mode.
1 COLOR CHANNEL MODE
(1)
In 1 color channel mode, only the slider can adjust BRIGHTNESS .『---』will be
shown when press other button.
T-021
Press the button 「 」 to turn on/off the device.
1、Press 「 」 to see the present channel mode.
2、To adjust the channel mode, press 「 」 and hold the buttom still for 3 seconds until
the display flickering then select the channel mode. After finished setting, press 「
」 to operating the device.
Press 「 」 and 「 」 to select the fading mode.
Press 「 」 and 「 」 to select the fixed color.
Press 「 」 and 「 」 to adjust the fading speed.
Press 「 」 and 「 」 to adjust the brightness.
When the device is power off, press 「 」 or 「 」 buttom to change the numbers of the
light address group. Press 「 」 after finished setting.
ORDER INFORMATION
OPERATION &
SPEC.
GOBC0111
CONTROLLER
1M
SPEC.
D03-994001-002
ITEM PART NUMBER
ACCESSORY
ITEM PART NUMBER
4-PIN CABLE for ORBIT Series
ORDER INFORMATION FORM
------
ORBIT TP
ORBIT T021 B030210001
------
10
www.colorbeam.com

COLORBEAM CO. LTD.
314, 3F., No. 87, Minguang E. Rd.,
Taoyuan City, Taiwan 33052
TEL : [phone]
FAX : [phone]
E-MAIL : [e-mail]
W : www.colorbeam.com
