Coloronix ColorFlood Square C-SS2-RGBW-10S-24 User manual

800.595.6302 coloronix.com |1
Specications are subject to change without notice.
DIMENSIONS
2022.03.01
APPLICATION
For use as linear, direct flood and/or accent lighting, installed as an
above grade fixture. Perfect for applications desiring a dynamic color
changing effect. Recommended for retail, modern residential, hospitality
and entertainment installations. RGBW design allows fine-tuned pastel
colors and saturated hues without sacrificing illumination brightness. DMX
control option allows the use of DMX512 Control Systems to individually
control and change colors, set looks, and add lighting effects which can
affect moods, feelings and atmosphere.
• 161W (24-LED) 5,196 Max. Lumen
• DMX direct via LCD display, Proprietary quick connectors included
• IP65
• 40obeam spread
• LED Die Colors: RGBW
• RDM function
• 16-bit dimming way
• Using proprietary technology, colors are efficiently blended together
through an internal mixing chamber. The one-color output reduces
unsightly views of isolated rainbow like striations.
• Smooth and flicker-free dimming of all colors down to 1%
• 3 Year Warranty
CAT. NO.:
TYPE:
PROJECT:
ColorFlood Square
C-SS2-RGBW-10S-24
24-LED Adjustable RGBW
Square Flood/Spot DMX Light
ACCESSORIES
60" Plug-In Cord (in addition to cord
included with unit)
C-SWR-PWR-WL--60-PI
For connecting mains power to unit.
Terminated in a 15A male Edison
connector.
C-SWR-PWR-WL-8080" Power Jumper
For daisy chaining power from powered
unit to unpowered unit. No more than
9units max from mains power feed.
300" (25') Data Cable Interconnect C-SWR-DMX-WL-300
For daisy chaining DMX from one
fixture to another. Pre-terminated in
4-Pin proprietary connector. Maximum
32 fixtures may be connected on any
DMX run (for bare-end at one end,
please specify -HW).
80" DMX/Data Jumper C-SWR-DMX-WL-80
For daisy chaining DMX from one fix-
ture to another. Pre-terminated in 4-Pin
proprietary connector. Maximum 32
fixtures may be connected on any DMX
run (for bare-end at one end, please
specify -HW).
Wet Location Power End Cap (in
addition to the set included with unit) C-PCL008-WL-PWR
Protective cover for use in wet location
environments for capping power
connector cable.
Wet Location DMX End Cap (in addition
to the set included with unit) C-PCL008-WL-DMX
Protective cover for use in wet location
environments to cap DMX cables. Not
a DMX terminator.

800.595.6302 coloronix.com |2
Specications are subject to change without notice.
SPECIFICATIONS
ColorFlood Square
C-SS2-RGBW-10S-24
24-LED Adjustable RGBW
OUTPUT
Beam Angle: 40°
Lumens: 5,196 Max. Lumen
Efficacy (lm/W): 32.27 lm/W
LED Channels: Red/Green/Blue/White
Color Mixing: Using proprietary technology, colors are efficiently blended
together through an internal mixing chamber. The one-color output
reduces unsightly views of isolated Red, Green and Blue Diodes for a
seamless rainbow-free appearance.
ELECTRICAL
Input Voltage: Direct 120-277V input comes standard. 50/60 Hz
Power Consumption: 161W
CONTROL
Interface: DMX direct via LCD display
Control System: DirectDMX Color Control. Color controlled with USITT
DMX512A Standard Protocol to work with Coloronix or 3rd Party DMX
Systems. On board LCD display inside the Data Enabler allow selecting of
DMX addresses between 1-512 in a given DMX universe. DMX Data fed
to housing via proprietary 4-wire data cable. Data Input/Output ports
allow daisy-chaining of DMX Signal.
LED Die Colors: Red (620-635nm), Green (520-535nm),
Blue (450-465nm) and Neutral White (4000K)
Dimming: Smooth and flicker-free dimming of all colors down to 1%
Stand Alone Control: Pre-Programmed static and dynamic scenes, as well
as specific colors, can be user activated by the integral Data Enabler's
computer eliminating the need for an external data source. On board
OLED display inside the Data Enabler allows selection of over 30 static
and dynamic color sequences. Display encased behind temperproof UV
protected glass to reduce deterioration after long exposure to outdoor
environments.
LUMEN MAINTENANCE
L70 Life: 35,000 Hours for ambient temperatures under 100ºF.
PHYSICAL
Dimensions (Height x Width x Length): 10.63" x 3.98" x 15.16"
Housing Material: Die-cast magnesium alloy to protect light emitting
diodes, other electronics and preserve optical alignment. Painted black
to maximize color mixing and eliminate stray light leaks. Integral split yoke
allows for 90° tilt.
Weight: 7.8 lbs. (3.55kg)
Lens: PMMA Impact Resistant
Mounting: Split yoke provided for pipe, truss or surface mounting.
Pre-drilled mounting holes on yoke.
Temperature Range: 14°F - 104°F Ambient
ENVIRONMENT
IP65
CERTIFICATION
ETL listing is pending/coming soon
WARRANTY
3-Years

The SS2 Series areactive, top-of-the-line RGBW color changing fixtures that can be used in indoor or outdoor projects. They
draw on solid-state elements, to produce highlights and washes in architectural spaces. RGBW is an acronym for Red Green
Blue and White. RGBW LED color mixing luminaires have the potential to produce 4.3 billion colors and 16.7 million white
light tones.
When installed and operated according to this manual, these fixtures will operate safely and dependably for their rated
lifespan.
These luminaries require a USITT DMX 512 control signal on four consecutive channels total. The unit includes a DATA OUT
output for connection to additional units or other DMX512 devices.
SCOPE
The purpose of this manual is to show proper use and installation of color-changing flood lights for peak performance. This
manual must be complimented by additional references, consultation from qualified professional(s), and observance of state
and local codes and regulations. Thisrule applies to any interior structure, exterior structure, or environment.
Therefore, it is important to: please read and comply with all instructions and warnings in this manual when installing or
using this product.
THIS MANUAL INTENDED FOR electrical contractors, electrical engineers, and licensed electricians.
ADDITIONAL SUPPLY OPTIONS
•DMX512 compatible controller (optional)
•DMX extension (optional)
•DMX feed connector
•4x4 inch electrical junction box rated for the application (optional)
•Controller (DMX512 compatible)
•Proper mounting bolts, washers, and lock washers to secure the fixture to the mounting surface
SAFETY HAZARD ICON KEY
DANGER = avoiding
pending danger will result in serious injury or death.
WARNING = avoiding this warning may result may in serious injury or death.
CAUTION = not exercising caution may result in minor to moderate injury, or property damage.
800.595.6302 coloronix.com |3
ColorFlood Square
C-SS2-RGBW-10S-24

SAFETY HAZARD PRECAUTIONS
DANGER: Not turning off the main power before wiring, installing, connecting, or disconnecting this product may
result in serious injury, or death.
WARNING: Not following NEC codes, local codes, or consulting a certified professional may result in property
damage, serious injury, or death.
WARNING: Not following instructions or safety labels may result in property damage, or serious injury.
WARNING: Modifying, servicing, or ignoring these safety indications may void the warranty.
WARNING: Inspect product before use. DO NOT use if damaged.
WARNING: Install safety cables per local and structural engineer’s code.
CAUTION: Hot swapping, not turning off fixtures before connection or disconnection, will void the warranty, and
damage property.
CAUTION: Do not go beyond the specified voltage, input current, maximum number of fixtures, or run length.
CAUTION: Do not use sharp tools near the reflector or lens.
CAUTION: Do not look directly into beam, with or without optical instruments.
Note: Instructions and warning referenced in this installation guide are not necessarily all-inclusive, all conceivable, or all
relevant to all applications as Coloronix by Nova Flex cannot anticipate all conceivable or unique situations.
PLANNING FOR INSTALLATION
Unpacking: Use the packing list to ensure all accessories are included. Survey the unit to make sure the data enabler/trim
are all intact—not cracked or damaged. Please recycle or appropriately discard of any packing materials.
Preparation:Before Installation, we suggest:
•Consult the provided submittal drawings to recognize layouts of luminaries, power supplies, & wiring layouts
•Drawing out a layout plan consisting of locations of luminaries and wiring
•Record DMX addresses on a mapping grid for easy reference and addressing (where applicable)
•An electrical inspector reviews all wiring plans
Points to Consider About Data:
•AC Power and DATA cables may NOT run in the same conduit or within one
•foot due to possible induced errors.
•32 DMX DATA links max per run
To Install Successfully:
1. Mount and align fixture
2. AC power connections
3. DMX connections
800.595.6302 coloronix.com |4
ColorFlood Square
C-SS2-RGBW-10S-24

SETTING COLOR MODE
For installations requiring DMX control, set the personalized DMX address
on the LCD menu (pictured at right) using the address table below.
Note: Up to 128 unique 4-channel addresses can be set per DMX universe.
The factory default setting for this unit is 4-channels.
Lock Function: If MENU is IDLE for 20 seconds, MENU will lock.
Hold MENU and “DOWN” button to release lock.
Operation Mode Transformation – press ‘MODE’, then ‘UP’ or ‘DOWN’ button to transform menus:
1. DMX
2. Slave
3. AUTO
4. Program
5. Dimmer
6. Settings
7. Information
DMX Mode – press the setup button to enter and select ‘UP’ or ‘DOWN’ button:
Address 001 – 512
Channels 4 / 6/ 10 ch
DMX Channels
Function
DMX Value
Setting
4 Ch
6 Ch
10 Ch
Dimmer
000-255
0 – 100%
1
1
Strobe
Linear
0–10
No function
2 2
11–255
Slow to fast
Strobe FX
0–10
No function
3
11–255
Random strobe slow to fast
Red
000–255
0 – 100%
1
3
7
Green
000-255
0 – 100%
2
4
8
Blue
000-255
0 – 100%
3
5
9
White
000-255
0 – 100%
4
6
10
Color
Preset
000–007
R (0) G (0) B (0) W (0)
4
008–013
014–020
R (255) G (0) B (0) W (0)
021-027
R (255) G (0) B (0) W (100)
028–034
R (255) G (0) B (0) W (200)
035–041
R (255) G (150) B (0) W (0)
042–048
R (255) G (255) B (0) W (0)
049–055
R (255) G (255) B (0) W (75)
056–062
R (0) G (255) B (0) W (255)
063–069
R (0) G (255) B (0) W (150)
070-076
R (0) G (255) B (0) W (50)
077-083
R (0) G (255) B (0) W (0)
800.595.6302 coloronix.com |5
ColorFlood Square
C-SS2-RGBW-10S-24

084-090
R (0) G (255) B (50) W (0)
091-097
R (0) G (255) B (150) W (0)
098-104
R (0) G (255) B (255) W (0)
105-111
R (0) G (255) B (255) W (75)
112-118
R (0) G (255) B (255) W (150)
119-125
R (0) G (100) B (255) W (255)
126-132
R (0) G (0) B (255) W (100)
133-139
R (0) G (0) B (255) W (50)
140-146
R (0) G (0) B (255) W (0)
147-153
R (75) G (0) B (255) W (0)
154-160
R (160) G (0) B (255) W (0)
161-167
R (255) G (0) B (255) W (0)
168-174
R (255) G (0) B (175) W (0)
175-181
R (255) G (0) B (100) W (0)
182-188
R (255) G (0) B (100) W (50)
189-195
R (255) G (0) B (25) W (50)
196-202
R (255) G (0) B (25) W (25)
203-209
R (255) G (0) B (25) W (0)
210-216
R (0) G (0) B (0) W (255)
217-223
R (75) G (75) B (0) W (255)
224-230
R (0) G (0) B (100) W (255)
231-255
R (255) G (255) B (255) W (255)
Color
Running
000-015
No function
5
016-031
Jump 1
032-047
Jump 2
048-063
Jump 3
064-079
Jump 4
080-095
Jump 5
096-111
Jump 6
112-127
Jump 7
128-143
Jump 8
144-159
Fade 1
160-175
Fade 2
176-191
Fade 3
192-207
Fade 4
208-223
Fade 5
224-239
Fade 6
240-255
Fade 7
Speed
0-255
Slow to fast Color running
6
Dimming Mode: Press the setup button to enter and select by the ‘UP’ or ‘DOWN’ button:
Dimmer
Red
000 - 255
Green 000 - 255
Blue
000 - 255
White 000 - 255
800.595.6302 coloronix.com |6
ColorFlood Square
C-SS2-RGBW-10S-24

Auto Mode: Press the setup button to enter, choose YES. Lights will run according to the speed and strobe of built-in
Program Mode:02-Program Mode:14
Built-In Program: There are 16 built-in programs. Press the setup button to enter and ‘UP’ or ‘DOWN’ button
Mode:01
static color
Color 00-33
Strobe 00-99
Mode:02-16
built-in program
Speed 001-100
Strobe 00-99
Slave Mode: Press the setup button to enter, choose YES. After connect the DMX cable, the light will run with the main
fixture at the same step
Settings: Press the setup button to enter and ‘UP’ or ‘DOWN’ button:
Settings
Curves Select
Dimmer Speed
DMX Fail
DMX Sync
Lock
Factory Reset
1. Dimming curve settings – there are four available. Press the setup button to enter and select by the ‘UP’ or ‘DOWN’
button:
Curves
1: linear
2: square law
3: Inv square law
4: S-type
2. Dimmer Speed - Press the setup button to enter and select by the ‘UP’ or ‘DOWN’ button:
Dimmer Speed Fast
Smooth
3. DMX Fail console DMX signal clear - Press the setup button to enter and select by the ‘UP’ or ‘DOWN’ button:
DMX Fail
Off When DMX signal connection fail, light off
Hold When DMX signal connection fail, light keeps current state
Dimmer When DMX signal connection fail, light keeps dimming mode
Program When DMX signal connection fail, light keeps built in program mode
800.595.6302 coloronix.com |7
ColorFlood Square
C-SS2-RGBW-10S-24

4. DMX Sync – In the DMX mode, several fixtures can also operate at the same step, even with no DMX control for a
period of time. Please press the setup button to enter and select by the ‘UP’ or ‘DOWN’ button:
DMX Sync On
Off
5. Lock:
Lock On
Off
6. Factory – All data will restore to initial state after factory sets. Press the setup button to enter and select by the ‘UP’
or ‘DOWN’ button:
Factory Yes
No
Information: Store relevant information as follows. Press the setup button for 5 seconds, then input the password 0088 to
clear the working time.
Information
Version x.x
Temp: xx °C
Work Time: xxxxxh
UID:xxxxxxxxxxxx
800.595.6302 coloronix.com |8
ColorFlood Square
C-SS2-RGBW-10S-24

RDM (Remote Device Management)
This product supports RDM communication protocol. RDM is a protocol that supports two-way traffic in the standard
DMX512 protocol. RDM controls devices and configurations, and detects lights, changing the DMX address of the fixture,
DMX mode, etc. Each RDM - compatible light can be identified by the built-in unique UID code.
Parameter ID Discovery Command SET command Get Command
DISC_UNIQUE_BRANCH *
DISC_MUTE *
DISC_UN-MUTE *
DEVICE_INFO *
SOFTWARE_VERSION_LABEL *
DMX_START_ADDRESS * *
IDENTIFY_DEVICE * *
SUPPORTED_PARAMETERS *
SENSOR_DEFINITION *
SENSOR_VALUE *
DMX_PERSONALITY * *
DMX_PERSONALITY_DESCRIPTION *
RESET_DEVICE *
FACTORY_DEFAULTS *
When the fixture is in INFO mode, press ‘SET’ and ‘DOWN’ button for 2 seconds to revise the UID mode.
NOTES:
•If no buttons are pushed for 30 seconds, the screen will lock and show current operating mode, WDMX mode,
temperature status and battery (this battery is reference value, changes for on and off is very large) To unlock press the
‘MODE’ and ‘SETUP’ buttons for 3 seconds.
•Press ‘MODE’ and ‘SETUP’ at the same time to quickly lock under unlock status.
•When the product powers on and shows version information, pressing the ‘MODE’ and ‘SETUP’ buttons at the same time
for a few seconds. After this, it can restore factory settings and the data will be initialized.
•Please follow the user manual to ensure safe installation and operation.
•To prevent overheating, please use within the acceptable ambient temp range, 14° F to 104° F.
•Do not take down the light while it’s plugged in.
800.595.6302 coloronix.com |9
ColorFlood Square
C-SS2-RGBW-10S-24

MENU INFO REFERENCE TABLE
Menu 1 Menu 2 Menu 3 Description
1: DMX
1. Address 001 - 512 DMX Address
2. Channels 4/6/10 - CH DMX Mode
2: Dimmer
Red 000 - 255
Dimming mode
Green 000 - 255
Blue 000 - 255
White 000 - 255
3: AUTO Yes/No Auto Run Mode
4: Program
1. Mode 1 - 16 Built-in Program Mode
2. Color (mode:1) 1 – 33 Static Color
2. Speed (mode: 2-16) 1 - 100 Speed
3. Strobe speed 0 - 99 Strobe
5: Slave Yes/No Slave
6: Settings
1. Curves Select 1 - 4 Dimming curve selection
2. Dimmer Speed Fast/Smooth Dimming speed selection
3. DMX Fail Off/Hold/Dimmer/Program DMX signal option
4. DMX Sync On/Off DMX Synchronization setting
5. Lock On/Off Standby lock screen
6. Factory Yes/No Factory reset
7: Information
Versions: Vx.x.x Version display
Temperature: xx °C Temperature detection
Work Time: xxxxxh Work time
UID:xxxxxxxxxxxx UID
800.595.6302 coloronix.com |10
ColorFlood Square
C-SS2-RGBW-10S-24

MOUNTING AND ALIGNMENT OF FIXTURE
1. Mount and secure each fixture into the designated position in accordance to the installation plan. Ensure there is
sufficient cable length between the fixture and junction box to allow for final alignment of the fixture.
2. Secure the fixtures to a solid mounting surface using three threaded fasteners minimum of 3/8 inch (10mm) stainless
steel complete with flat and locking washer.
3. Rotate/tilt the fixture into the desired position.
4-PIN INTERFACE
Pin 1 Pin 4
Pin 1
+
Line Voltage
Pin 2
-
Neutral
Pin 3
Shield
Ground
Pin 4
Reserved
Leave Open
REQUIRES ELECTRICIAN TO INSTALL
NOTE: Supply lead wires should not be connected to a dimmer of any sort.
DATA CONNECTION
•Inline DMX amplifier required if run length exceeds: 125 feet between fixtures (others)
•Maximum run length from DMX controller to last fixture: 1000 feet
•DMX must be continuous from controller to last fixture in a run. A splitter is needed if signal is split
•If provided data cables won’t be used, please note that any cables must meet EIA-RS485 requirements and warranty may
be voided
•To comply with all local codes and jurisdiction, qualified communications technicians must do communications wiring
•To avoid signal transmission problems and interference, it is always advisable to connect to a DMX signal terminator
•Communication cables and AC power lines must not be run in the same conduit
oRoute Data Cables in series between fixture and any communications accessories using DATA IN and DATA OUT
oTo ensure they are easily accessed once construction is complete, secure data cables near the fixtures
800.595.6302 coloronix.com |11
ColorFlood Square
C-SS2-RGBW-10S-24
DMX IN
DMX
DMX
DMX
PWR PWR PWR
PWR IN
To DMX SOURCE USE DMX SIGNAL REPEATER ON EVERY 32nd SS2 UNIT IN A CHAIN
OR WHEN A DATA CABLE RUN BETWEEN UNITS EXCEEDS 100'.
DMX = C-SWR-DMX-WL-80 or 300 PWR = C-SWR-PWR-WL-80
POWER (120-277V)
C-SWR-PWR-WL-60-Pl

MAINTENANCE
We recommend periodic cleaning. Over time these components can become dirty or full of debris. This can result in lack of
cooling or can limit the capabilities of the fixture. Lens:Clean the front Lexan® as required using window cleaner or mild
soap and water. Dry with a quality paper towel to avoid scratches or streaks. Mounts/Fasteners:Check annually for
tightness and security to avoid damage to the fixture and possible liability.
TROUBLESHOOTING
If problems occur during usage, unplug the product immediately and email supp[email protected]om or call 800-595-6302.
Replacing a Failed Fixture: “Hot Swapping” a fixture is not allowed. If a fixture needs to be replaced, the steps are to:
1. Disconnect the DMX input at the junction box of the fixture needing replacement, THEN disconnect DMX output
2. Replace fixture
3. Reconnect AC negative, THEN AC positive
4. Reconnect DATA output, THEN DATA input
5. Reconnect power and make sure the replaced fixture and the entire system is in working order
If fixture does not light, check if:
•Electrical power is not connected.
•Electrical power is less than specific voltage.
•Electrical power is greater than specified voltage.
If fixture does not respond to DMX control signal, check if:
•DMX control device and RGBW are addressed differently.
•DMX cable is damaged.
•DMX control device is disconnected or not operating.
•DMX device needs to be restarted.
•
LED fixture was not restarted after address change.
•Restart fixture.
If the fixture is not responding to DMX, check if:
•
DMX addressing is incorrect: Check Control Panel and unit addressing.
•The wrong polarity settings may be on the controller: Check polarity switch settings on the controller.
•DMX cables may be loose: Check cable connectors.
If DMX control operation flickers or is intermittent, check if:
•RGBW fixture or final DMX device in daisy chain is not terminated.
•DMX cable is damaged.
•DMX control device is operating at less than 25Hz.
If there is a loss of signal, check if:
•Non-DMX cables are being used: Use only DMX compatible cables
•Signals are bouncing:
DMX terminator is not installed as suggested.
If output is less than normal, check if:
•E
n v i r on m e nt t e m p e r a tu r e m a y b e i n e x c e ss o f 114 °F/ 45 ° C .
•Lens may be damaged or dirty.
•DMX control or RGBW channels may be set at low level.
View Nova Flex Terms & Conditions for more details.
800.595.6302 coloronix.com |12
ColorFlood Square
C-SS2-RGBW-10S-24
