Introduction
RGB Color Changing Adjustable Flood Lights are active, top-of-the-line color changing
fixtures. They draw on solid-state elements in order to produce highlights and washes
in architectural spaces.
When installed and operated according to this manual, these downlights will operate
safely and dependably for their rated lifespan.
These luminaries require a USITT DMX 512 control signal on four consecutive
channels total. The unit includes a DATA OUT output for connection to additional units
or other DMX512 devices.
The flood lights are UL 1598 wet location rated for use in indoor or outdoor
environments.
Scope
The purpose of this manual is to properly install and use color-changing flood lights at
peak performance .
This manual must be complimented by additional references, consultation from
qualified professional(s), and observance of state and local codes and regulations. This
rule applies to any interior structure, exterior structure, or environment.
Therefore, it is important to: “please read and comply with all instructions and
warnings in this manual when installing or using this product.”
Who Is This Manual Intended for?
This manual is intended for electrical contractors, electrical engineers, and licensed
electricians.
Additional Supplies
DMX512 compatible controller (optional)
DMX extension (optional)
DMX feed connector
4x4 inch electrical junction box rated for the application (optional)
Controller (DMX512 compatible)
Proper mounting bolts, washers and lock washers to secure the fixture to the mounting
surface.

Page 3 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Spec f cat ons
Spec f cat onsSpec f cat ons
Spec f cat ons
Power Input: Direct 12 -24 VAC 5 Hz/6 Hz
Power Consumption: 1 5W
L70 Life: 5 , Hours.
Temperature Rating: °F - 1 4°F Ambient.
LED Die Colors: Red (62 -635nm)
Green (52 -535nm)
Blue (45 -465nm)
Neutral White (5 k)
Safety: Complies to UL1598 and ANSI/UL 875 .
Plann ng for Installat on
Plann ng for Installat on Plann ng for Installat on
Plann ng for Installat on
Unpacking
The data enabler and trim are shipped assembled with no additional assembly needed.
Housing and trim are shipped in two different boxes.
Any optional accessories are included in the package. Use the packing list located on the
outside of the box to ensure all accessories are included.
Survey the unit to make sure the data enabler/trim are all intact—not cracked or
damaged. Any damages to the package or its contents are of the buyer’s responsibility;
please follow protocol for filing damage claims. Please recycle or appropriately discard of
any packing materials.
Preparation
Before Installation, Coloronix suggests:
• Consulting the provided submittal drawings to recognize layouts of luminaries,
power supplies, and wiring layouts.
• Drawing out a layout plan consisting of locations of luminaries and wiring.
• Record DMX addresses on a mapping grid for easy reference and addressing
(where applicable).
• An electrical inspector reviews all wiring plans.
Points to Consider About Data
• Max power links is 9 per power feed
• AC Power and DATA cables may NOT run in the same conduit or within one
foot due to possible induced errors.
• 32 DMX DATA links max per run

Page 4 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Quick Step-by-Step Instructions
To successfully install, the steps are:
1. Mounting and alignment of fixture
2. AC power connections
3. DMX connections
4. Ready to go.
Sett ng Color Mode
Sett ng Color Mode Sett ng Color Mode
Sett ng Color Mode
For installations requiring DMX control, set the
personalized DMX address using the address table (Below)
for LCD menu settings. See figure.
Note: Up to 128 unique 4-channel addresses can be set
per DMX universe.
Lock unction:
If MENU is IDLE for 2 seconds, MENU will lock. Hold MENU and “DOWN” button to
release lock.
DMX Mode
1. Press the “MODE” ， enter the DMX mode “d.×××”.
2. Press the “UP” or “DOWN” ， set up the DMX address value d. 1-d.512
3. Press the “SETUP”, enter the DMX working mode: X-ch
4. Press the “UP” or “DOWN” ， set up the DMX working mode to Mode 1
DMX Working Mode 1: 4-CHANNEL
(For individual color dimming control)
Channel Value Function
CH1 -255 Red
CH2 -255 Green
CH3 -255 Blue
CH4 -255 Cool White

Page 5 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Pre-Programmed Mode (Static Color)
1. Press “MODE” ， enter the mode “Prxx”
2. Enter Pr. 1
3. Press “SETUP” and toggle between static color to achieve desired show
No. Color
1 Red
2 Lime Green
3 RGBW
4 Green
5 Light Blue
6 Blue
7 Purple
8 Magenta
9 Bright White
1 Pink
11 Light Green
12 Light Purple
13 Orange
14 RGBW
Pre-Programmed Mode (Show Mode)
Pr. 1 Static color program
Pr. 2 Four colors fading
Pr. 3 Ten color fading
Pr. 4 Four color dream
Pr. 5 Four color hopping
Pr. 6 Ten color hopping
Pr. 7 Red fading
Pr. 8 Green fading
Pr. 9 Blue fading
Pr.1 White fading
Mount ng and Al gnment of F xture
Mount ng and Al gnment of F xtureMount ng and Al gnment of F xture
Mount ng and Al gnment of F xture
• Mount and secure each fixture into the designated position in accordance to the
installation plan. Ensure there is sufficient cable length between the fixture and junction
box to allow for final alignment of the fixture.
• Secure the fixtures to a solid mounting surface using three threaded fasteners minimum
of 3/8 inch (10mm) stainless steel complete with flat and locking washer.
• Rotate the fixtures using tilt method into the desired position.

Page 6 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
•

Page 7 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Electrical Connection (Hardwire)
WARNING: Do not expose bare wires outside wire nut connectors.
1. Per local or “National Electric Code”, provide electrical service to junction box
located on the housing.
a. The insulation of supply wire must be rated for at least 9 °C.
b. Junction boxes should be rated for:
i. Max. 8 No. 12 AWG Circuit Conductors
ii. Also suitable for at least 9 °C
2. Remove cover of junction box.
3. Remove proper round pryout, and then connect junction box with (not included)
proper connector.
4. Using properly sized wire nuts, connect lead wires of junction box (line, neutral,
and ground) to supply lead wires in the fixture.
a. WARNING: Do not leave bare conductors outside wire nut connectors.
5. Connect green (from electrical service) to the supply side to the green wire in
the junction box. Connect black-to-brown, and white-to-blue.
a. Any excess wiring and connectors should be put in the junction box.
Then, replace the cover.
NOTE: Supply lead wires should not be connected to a dimmer of any sort.
Maximum power connection should not exceed 4 units.
Data Connection
Note: Inline DMX amplifier required if run length exceeds: 125 feet between fixtures (others)
Note: Maximum run length from DMX controller to last fixture: 1 feet.
Note: DMX must be continuous from controller to last fixture in a run. A splitter is needed if
signal is split.
Please follow below if provided data cables will not be used
Note: ixtures on a serial data link must be daisy chained in one single line. To comply with
the EIA-485 standard, no more than 32 fixtures should be connected on one data link.
Connecting more than 32 fixtures on one serial data link without the use of a DMX
optically-isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended serial data link distance: 5 m (164 ft)
Maximum recommended number of fixtures on a serial data link: 32
DMX Data Cable
If installer prefers 3-wire data cables, we suggest a Belden© 9481 or equivalent cable which meets the
specifications for EIA RS-485 applications. Standard microphone cables cannot transmit DMX data
reliably over long distances. The cable must have the following characteristics:
Type: shielded, 2-conductor twisted pair
Maximum capacitance between conductors:
3 pF/ft
Maximum capacitance between conductor and shield:
55 pF/ft
Maximum resistance: 2 ohms/1 ft
Normal impendance: 1
~ 14 ohms

Page 8 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Note: To comply with all local codes and jurisdiction, qualified communications technicians must do
communications wiring.
Note: Communication cables and AC power lines must not be run in the same conduit.
A. Route Data Cables in series between fixture and any communications accessories using DATA
IN and DATA OUT.
B. In order that they may be easily accessed once construction is complete, secure data cables in
the immediate proximity of the fixtures.
Note: To avoid signal transmission problems and interference, it is always advisable to connect to a
DMX signal terminator.

Page 9 of 9 - Coloronix SS2-RGBW-18L Direct Power Lighting Manual V.1. .1
Ma ntenance
Ma ntenanceMa ntenance
Ma ntenance
Coloronix recommends periodic cleaning of the heat sink and lens. Over time these
components can become dirty or full of debris. This can result in lack of cooling or can
limit the capabilities of the fixture.
Lens Maintenance
Clean the front Lexan® as required using any of the following cleaners:
• Window Cleaner
• Mild soap and water solution
In addition, dry the Lexan® with a quality paper towel to avoid scratches or streaks.
Mount/ asteners Maintenance
Check all fasteners annually for tightness and security to avoid damage to the fixture
and possibly liability.
Troubleshooting
If problems occur during usage, unplug the product immediately and call or email:
Coloronix, Inc.
Tech Support: (9 9) RGBW-555
[e-mail]
Replacing a Failed Fixture
“Hot Swapping” a fixture is not allowed. If a fixture needs to be replaced, the steps are
to:
1. Disconnect the DMX input at the junction box of the fixture needing
replacement.
2. Disconnect DMX output.
3. Replace fixture.
4. Reconnect AC negative.
5. Reconnect AC positive.
6. Reconnect DATA output.
7. Reconnect DATA input.
8. Reconnect power.
Make sure the replaced fixture and the entire system is in working order.
