Clas Ohlson Seahorse 38-4256 User manual

EnglishSvenskaNorskSuomi
Pool speakers with
radio and mp3-player
Poolhögtalare med radio och mp3-spelare
Poolhøyttalere med radio og mp3-spiller
Allaskaiutin radion ja mp3-soitin
Art.no Model
38-4256 Seahorse Ver. 201101

2

3
English
Pool Speakers with radio
and mp3-player
Art.no 38-4256 Model Seahorse
Please read the entire instruction manual before using the product and save it for
future reference. We reserve the right for any errors in text or images and any
necessary changes made to technical data. If you have any questions regarding
technical problems please contact Customer Services.
Safety
• Do not position the unit in such a way that its ventilation is impeded.
Do not place it on a bed, sofa or deep-pile carpet.
• Do not cover the unit.
• Do not place the unit on a narrow shelf or in a box where the air
cannot circulate freely.
• Do not place the unit close to a radiator, cooker, heat-emitting electronics
or any other kind of heat source.
• Do not expose the unit to naked flames.
• Do not use any accessories other than those recommended by the manufacturer.
• This product should only be repaired by qualified service technicians.
Product description
• Pool speakers with radio which can be preset to 20 stations.
• Plays MP3 files from USB memory and SD/MMC memory cards.
• Clock.
• LCD display.

4
English
1
34
5
6
7
8910
11
12
13
14
15
16
2
Buttons and functions
Exterior
Some of the buttons have dual functions, one for controlling the radio and one for
controlling a USB/memory card.
1. Radio: [ST/MO] – Select FM stereo/mono.
MP3: [P-MODE] – Select type of repetition when playing from USB memory or
memory card.
2. [SLEEP] – Sleep timer setup.
3. Radio: [TUN] – Station search. Search up or down frequency band for radio stations.
MP3: [◄◄] / [►►] – Select previous or next track.
4. MP3: [►ll] - PLAY/PAUSE.
5. [Fn] – Select playback function radio, USB or memory card.
6. [MODE] – Select setup mode/display time.
7. Radio: [MEM] – Save a radio station as a preset.
MP3: [■] – Stop playback of music files.
8. Radio: [CH/DIR] – Search up or down amongst preset radio stations.
MP3: Change playback list/folder.
9. [ ] – ON/OFF-button
10. [VOL] – Volume
Interior
11. Battery cover lock
12. USB memory slot
13. Battery compartment
14. Clock battery
15. Memory card slot
16. Reset button

5
English
Operation
Unscrew the lower half of the unit by turning it
clockwise.
Batteries
1. Open the battery compartment by opening the lock (11).
2. Remove the protective foil on the clock battery (14).
3. Insert 6 x AA/LR6 batteries into the compartment (13). Make sure to insert
the batteries according to the marking in the battery compartment.
Setting the clock
1. Press [MODE] (6) three times, EU (Europe) will start to flash on the display.
Press [VOL] (10) to select EU (Europe), JAP (Japan), AUS (Australia) or USA.
The clock can also be set when it is turned off. Press [MODE] once and complete
settings as above. If the unit is moved to another country/region it will need to be
reset to the appropriate setting since the radio broadcasting system varies from
region to region.
2. Press [MODE] three times, ”24Hr” will begin to flash on the display.
Press [VOL] (10) to select 24 hr or 12 hr display.
3. Press [MODE] three times, the digits of the clock will begin to flash on the display.
Press [TUN] (3) to set the hours.
4. Press [VOL] (10) to set the minutes.
Listening to the radio
Manual tuning
1. Turn the unit on using [ ] (9).
2. If necessary, press [Fn] (5) to select the radio mode.
3. Press [ST/MO] (1) to select stereo or mono.
4. Press [TUN] (3) and search up or down the frequencies for a desirable station.
5. Set the desired volume using [VOL] (8).

6
English
Automatic tuning
1. Turn the unit on using [ ] (9).
2. If necessary, press [Fn] (5) to select the radio mode.
3. Press [ST/MO] (1) to select stereo or mono.
4. Press and hold in [TUN] (3) for 3 seconds to start automatic station search.
The unit stops at the first station it finds. Press and hold in [TUN] (3) for another
3 seconds to continue searching.
5. Set the desired volume using [VOL] (8).
6. Press [MODE] (6) to switch the display from clock to radio frequency and
vice versa.
Saving preset stations
1. Turn the unit on using [ ] (9).
2. If necessary, press [Fn] (5) to select the radio mode.
3. Search for the station to be saved (refer to Manual tuning or Automatic tuning).
4. Press [MEM] (7) and ”CH01” (channel 1) starts flashing on the display.
5. Press [CH/DIR] (8) to choose a channel slot for the station.
6. Confirm your choice by pressing [MEM] again.
7. Up to 20 stations can be preset using the steps 3–6 above.
Listening to music from USB flash drives/
memory cards
1. Dry the unit thoroughly if it has been in contact with water.
2. Unscrew the lower half of the unit by turning it anticlockwise.
3. Open the battery compartment by opening the lock (11).
4. Insert a USB flash drive and/or memory card containing MP3 files to
the respective slots (12 and 15).
5. Close the battery cover.
6. Screw the lower half of the unit back on.
7. Turn the unit on using [ ] (9).
8. Press [Fn] (5) and select USB or SD. Your selection will appear on the display.
9. The unit automatically plays MP3 files from the selected memory.
10. Change tracks up or down in the playlist using [◄◄] / [►►] (3).
11. Change playlist/folder using [CH/DIR] (8).
12. To pause, press [►ll] (4). To resume playback, press [►ll] again.
13. To stop playback, press [MEM] (7).
14. Press [MODE] (6) to switch the display from clock to track information and
vice versa.

7
English
Repeat playback options
Press [P-MODE] (1) to select one of the three repeat playback options.
The following symbols will appear on the display:
Repeat all
Repeat one
Repeat folder
Sleep timer
1. To activate the sleep timer, press [SLEEP] (2) repeatedly to choose whether
the unit is to turn off automatically after 15, 30, 45, 60, 90 or 120 minutes.
2. The sleep indicator zZ will be displayed when a sleep time delay has been chosen.
3. To turn off the sleep timer, press [SLEEP] repeatedly until the zZ symbol disappears.
4. To turn the unit off before the set time, press [ ] (9) once.
Care and maintenance
• Remove the batteries if the unit is not to be used for a long time.
• Do not subject the unit to excessive force, shock, dust or extreme temperature.
• Do not tamper with or modify the unit in any way.
• Use a damp cloth to clean the outer casing. Never use solvents or
corrosive cleaning products.
• Avoid leaving the unit in direct sunlight for long periods.
• Keep the unit away from sources of electrical noise.
Resetting the unit
If the unit’s batteries are discharged or if the unit has been subjected to a power surge,
it is possible that the internal electronics “lock up”. The unit will then not respond to
any of the buttons 1–10. To reset:
1. Unscrew the lower half of the unit by turning it clockwise.
2. Open the battery compartment by opening the lock (11).
3. Use a straightened paper clip, toothpick or a similar object to press
the reset button (16).
Note! Do not use a sharp object to press the reset button and
do not press it too hard.

8
English
Troubleshooting guide
The unit does not start. • The batteries are flat. Insert new batteries.
• The batteries are inserted incorrectly, check
the polarity. Follow the markings on the bottom of
the battery compartment.
No sound or distorted
sound from the USB
flash drive/memory
card. The message “Er”
(error) appears on the
display.
• Wrong sound file format, only MP3 works.
• Damaged sound files.
• Damaged USB flash drive/memory card.
The clock is not
working.
• The clock battery is flat. Replace the battery
• The clock battery is inserted incorrectly, check
the polarity. Follow the markings on the bottom of
the battery compartment.
Disposal
Follow local ordinances when disposing of this product.
If you are unsure how to proceed, contact your local authority.
Batteries
Radio/MP3 DC 1.5 V, AA/LR6 batteries
Clock DC 3 V, CR2032 lithium battery

9
Svenska
Poolhögtalare med radio
och mp3-spelare
Art.nr 38-4256 Modell Seahorse
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida
bruk. Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data.
Vid tekniska problem eller andra frågor, kontakta vår kundtjänst.
Se adressuppgifter på baksidan.
Säkerhet
• Placera inte apparaten på ett sådant sätt att dess ventilation försämras.
Ställ den inte på sängen, i en soffa eller på en mjuk matta.
• Täck inte över apparaten.
• Placera inte apparaten i en trång hylla eller låda där luften inte kan cirkulera ordentligt.
• Placera inte apparaten nära element eller spis. Inte heller nära eller på
värmealstrande elektronik eller någon annan värmekälla.
• Låt inga öppna lågor komma i kontakt med apparaten.
• Använd inga andra tillbehör än de som rekommenderas av tillverkaren.
• Produkten får endast repareras av kvalificerad servicepersonal.
Produktbeskrivning
• Poolhögtalare med radio, 20 förprogrammerbara stationer.
• Uppspelning av mp3-filer från USB-minne och SD/MMC-minneskort.
• Klocka.
• LCD-display.

10
Svenska
1
34
5
6
7
8910
11
12
13
14
15
16
2
Knappar och funktioner
Utsida
Vissa knappar har dubbelfunktion, en för radio och en för USB/minneskort.
1. Radio: [ST/MO] – Val av FM stereo/mono.
Mp3: [P-MODE] – Välj repetitionsalternativ vid uppspelning från USB-minne eller
minneskort.
2. [SLEEP] – Inställning av insomningstimer.
3. Radio: [TUN] – Kanalsökning. Sök upp eller ner i frekvensområdet efter radiostation.
Mp3: [◄◄] / [►►] – Välj nästa eller föregående spår i spellistan.
4. Mp3: [►ll] – PLAY/PAUSE.
5. [Fn] – Välj uppspelningsfunktion radio, USB eller minneskort.
6. [MODE] – Välj inställningsläge/visa klockan i displayen.
7. Radio: [MEM] – Spara radiostation i minnet.
Mp3: [■] – Stoppa uppspelning av musikfiler.
8. Radio: [CH/DIR] – Sök upp eller ner bland förinställda radiostationer.
Mp3: Byt spellista/katalog.
9. [ ] – PÅ/AV-knapp
10. [VOL] – Volym
Insida
11. Lås för batterilucka
12. Anslutning för USB-minne
13. Batterifack
14. Batteri för klockan
15. Anslutning för minneskort
16. Återställningsknapp
