Vision X ADV Adventure Series Manual

VISIONXLIGHTING.COM
Installation Instructions & User’s Manual
8.7” ADV LIGHT CANNON KIT

VISION X
FEATURES
1. Iris Reector & Optic Technology Combo
2. Heavy Duty Trunnion Bracket
3. Snap-On Covers Available
8.7” ADV LED LIGHT CANNON SPECIFICATION
1. Warranty : Extended
2. Amp Draw (EA) : 11.67A @ 12V DC
3. Input Voltage : 9-32V DC
4. Beam Patterns : Mixed
5. LED Lifespan : 50,000 Hours
PREPARATION
1. We recommend completely reading instructions before installing.
2. Consult your local state regulatory agency regarding the use of LED
lighting.
3. The placement of LED lighting should not restrict airow to the radiator,
or block head lamps, turn signals, or parking lights.
About The 8.7” ADV Light Cannon Kit:
1
Qty: 2
ADV
Light Cannon
LIGHT
6Hex Head Bolt
[M10]
Qty: 2
PART (B1)
4
Qty: 2
Washer
[M10]
PART (W1)
5
Qty: 2
Nylock Nut
[M10]
PART (N1)
3Allen Key
[5mm]
Qty: 1
PART (A1)
2
Qty: 1
Two Light
Harness
WIRING

8.7” ADV LIGHT CANNON
WARNING: Bolts, Nuts, and Washers are Stainless Steel. DO NOT
USE Pneumatic or Electric Tools to Tighten and Loosen. The Hard-
ware Will Permanently Lock Together.
LIGHT ANGLE ADJUSTMENTS
1. Use the 5mm Allen Key (A1) to loosen the side bolts Part (B2) on each
side of the light.
2. Adjust the light to your desired angle and tighten Bolts (B2).
(B1)
(Mounting Bracket)
(W1)
(N1)
MOUNTING KEY
Part (B1) Bolt
Part (Mounting Bracket)
Part (W1) Washer
Part (N1) Nut
MOUNTING DIAGRAM
ADJUSTMENT KEY
Part (B2) Bolt
a. 5mm Allen Head Bolt (B2)
3.69”/93.7mm
MOUNTING INSTALLATION INSTRUCTION
1. Determine where the light/lights will be placed.
2. Place mounting bracket with light to desired location. Using a marker
or pick tool, mark the center point of the bolt hole on the mounting
surface.
3. Set the light aside. Drill out a large enough hole to t the [M10] bolt
Part (B1).
4. Line up the mounting bracket with the hole you just drilled, slide the
[M10] Bolt (B1) through both.
5. On the other side of mounting surface slide the [M10] Washer Part
(W1) and [M10] Nylock Nut Part (N1) onto the [M10] Bolt (B1). Tighten
Nut & Bolt to desired tightness.
LIGHT ANGLE ADJUSTMENT DIAGRAM:

VISIONXLIGHTING.COM
COMPONENTS KEY
Part (R1 & R2) Relay
Part (W1 & W3) Power Wire for Relay Coil
a. 9-32V DC Volt Positive (+) Input Wire
Part (W2 & W4) Ground Wire for Relay Coil
a. 9-32V DC Negative (-) Input Wire
Part (C1 & C2) Deutsch Connectors for Lights
a. Attached to 9-32V DC Positive (+) Power Wires
Part (S1) Switch
Part (P1) Switch Plug
WIRING INSTALLATION INSTRUCTION
1. Find a suitable place to mount Relays Part (R1 & R2) leaving enough room for
Power & Ground wires Part (W1,W2,W3,W4) to reach the battery & the Deutsch
connectors Part (C1 & C2) to reach the lights. Mount Relays.
2. Run Power wires (W1, W3) & Ground wires (W2 , W4) to the battery. Connect the
Power wires (W1 , W3) to the Positive (+) battery terminal and connect the Ground
wire (W2 , W4) to the Negative (-) Battery Terminal.
3. To connect the Halo wire Part (H1) tap the yellow wire to an existing power source or
on its own auxiliary switch.
4. Run the Deutsch Connector wiring, (C1 & C2) to each light and plug in. It doesn’t
matter which Deutsch Connector plugs into which light.
5. Disconnect the Switch Part (S1) at the white Plug Part (P1) and run the wire through
the vehicles re wall to desired mounting location inside the Cab, [using a factory
rubber or plastic grommet is suggested].
6. Drill the hole to the required size for the Switch (S1) and mount to desired position.
7. Reconnect the Switch (S1) to the Harness and Test Light.
WIRING DIAGRAM
(H1) Halo wire
HALO WIRE:
