CombiSteel 7455.0300 User manual

Blender
7455.0300
User Manual
Gebruikershandleiding
Gebrauchsanweisung
Le mode d’emploi

2
www.combisteel.com
CONTENT
ENGLISH
Important Safety Knowledge .................................................................................................................................. 4
Product Specification.............................................................................................................................................. 5
Sound insulation cover removing and installing ................................................................................................. 5
Operation control panel...................................................................................................................................... 5
Assembly of cover............................................................................................................................................... 6
Sound insulation cover ....................................................................................................................................... 6
Preparation before operation ............................................................................................................................. 7
Operation of special one-touch function............................................................................................................ 7
The intelligent modes instructions ..................................................................................................................... 8
Product maintenance ............................................................................................................................................. 9
Faults and their troubleshooting ........................................................................................................................ 9
Cleaning .............................................................................................................................................................. 9
Performance parameters .................................................................................................................................... 9
NEDERLANDS
Belangrijke veiligheidsinformatie ......................................................................................................................... 10
Productspecificatie .............................................................................................................................................. 11
Geluidsisolatie deksel verwijderen en installeren ............................................................................................ 11
Bedieningspaneel ............................................................................................................................................. 11
Afdekking monteren .........................................................................................................................................12
Geluidsisolatiedeksel ........................................................................................................................................12
Voorbereiding voor gebruik .............................................................................................................................. 13
Bediening van speciale one-touch-functie........................................................................................................ 13
Instructies voor de intelligente modus ............................................................................................................. 14
Product onderhoud .............................................................................................................................................. 15
Fouten en probleemoplossing .......................................................................................................................... 15
Schoonmaken ................................................................................................................................................... 15
Prestatieparameters .........................................................................................................................................15
DEUTSCH
Wichtige Sicherheitshinweise............................................................................................................................... 16
Produktspezifikation ............................................................................................................................................. 17
Schallschutzabdeckung entfernen und montieren ........................................................................................... 17
Bedienteil.......................................................................................................................................................... 17
Montage der Abdeckung ..................................................................................................................................18
Schallschutzabdeckung.....................................................................................................................................18
Vorbereitungsarbeiten vor der Inbetriebnahme/dem Betrieb.........................................................................19
Betrieb mit der besonderen One-Touch-Funktion............................................................................................ 19
The intelligent modes instructions ................................................................................................................... 20
Wartung des Geräts/Produkts .............................................................................................................................. 21
Störungen und deren Behebungsmöglichkeiten .............................................................................................. 21
Reinigung .......................................................................................................................................................... 21
Leistungsparameter .......................................................................................................................................... 21

3
www.combisteel.com
FRANÇAIS
Connaissances de sécurité importantes ............................................................................................................... 22
Spécification du produit........................................................................................................................................23
Enlever et installer la couverture d'isolation acoustique.................................................................................. 23
Panneau de commande d'opération ................................................................................................................ 23
Assemblage de la couverture............................................................................................................................ 24
Couverture d'isolation sonore .......................................................................................................................... 24
Préparation avant l'utilisation........................................................................................................................... 25
Marche de la fonction spéciale à une touche...................................................................................................25
Les instructions des modes intelligents ............................................................................................................ 26
Maintenance du produit....................................................................................................................................... 27
Défauts et leur dépannage ............................................................................................................................... 27
Nettoyage ......................................................................................................................................................... 27
Paramètres de performance............................................................................................................................. 27

4
www.combisteel.com
Important Safety Knowledge
Before using the machine, be sure to obey the following safety rules:
1. Please do not immerse the pedestal or motor of the machine in water or other liquid.
2. Children can only use this machine under the supervision of adults to ensure safety.
3. Please first unplug the machine after using it, when removing its parts or before washing it.
4. Do not contact the rotating parts of the product especially the blade.
5. Do not operate the machine in any of the following cases:
a. The power line or plug is damaged.
b. The product falls off and is damaged in the course of transportation. In this case, please send
the machine to the nearest after-sales service point for repair. Do not disassemble it without
permission.
6. Do not use accessories that are not original ones of the machine for repair.
7. Do not hang the power line on desk or counter with cover to avoid the power line from being damaged. 8.
8. Do not put the machine near gas appliance, electric gas appliance or other heating source.
9. Do not put hand or other appliance in the cup to start it in case personal injury might be caused or the
machine might be damaged.
10. Please do not go away when using the machine. Shut it down while away from it.
11. Warning I: Since the blade is very sharp, please be careful during operation.
a. Never try moving the blade when the cup is still on the pedestal.
b. Do not use the machine when the blade is found loose, missing or damaged. Instead, replace
the blade at once.
c. To avoid injury, do not use the machine when the blade assembly is not fully mounted to the
cup. Warning II: Do not open the cup cover and use mixing rod to mix food.
Correct using method: When using mixing rod, open the transparent lid in the middle of the cup cover and
the mixing rod can be inserted into the cup safely for normal use.
12. Do not overload the machine. Its maximum capacity should not exceed the top scale indicated on the cup.
The capacity should be relatively reduced for thick mixture.
13. The lid must be covered during operation of the lid. The machine needs no special maintenance but washing.
If any repair of it is needed, send it to the designated place. Never repair it without permission.
14. This machine has quick/slow start functions. Its effects can only be produced if the time is set first and gear
is selected.
15. The rotation speed of this machine is high and very high heat can be generated during dry grinding. When
the temperature of the food drily grinded reaches certain ignition point, it will spontaneously combust.
Therefore, dry grinding is not recommended.
ATTENTION!
During first use of this machine, you might smell unpleasant smell. This is normal. As the motor runs, the smell
will disappear slowly.

5
www.combisteel.com
Product Specification
Before using this machine, please read this instruction carefully.
Besides, keep it properly for future reference. Examine the rated
working voltage to see if it is consistent with the voltage in your home.
The blender is composed of the following:
1. Stirring up cover set
2. Stirring cup
3. Non-slip rubber mat
4. Operation panel
5. Sound cover
Sound insulation cover removing and installing
1. Make sure blender is power off, and sound cover was closed.
2. Sound insulation cover nuts loosely twisted to the left.
3. Outward direction to promote sound insulation cover.
4. Clean sound insulation cover, by the above steps to reverse
operation, can be installed.
Operation control panel
1. LCD display
2. Start/Stop
3. Time
(increase or decrease the time as circulation)
4. Speed
(increase or decrease the time as circulation)
5. Power switch
6. Pulse
7. Program 1
8. Program 2
9. Program 3
10. Program 4/DIY
11. Mixing

6
www.combisteel.com
Before using this machine, please Examine the rated working voltage to see if it is consistent with the voltage in
your home. The blender is composed of the following:
1. Sound cover
2. Container
3. Handle
4. Control panel
5. Housing/Base
6. Sound cover sides
7. Non-slip rubber mat
8. Enclosures fixed parts
9. Wires
10. Lids and Covers
11. Shockproof mat
Assembly of cover
The cover consists of two parts which makes it very easy for cleaning, installation
and sealing. Make sure jar (3) was placed correctly.
To open the closely fit stirring cup cover (2), you only need to pull it
upward. It will be covered if the pressed downward.
To lock the transparent cover, you only need to insert aligned to the center
slot of stirring cup cover (1) and rotate it clockwise. It will be unlocked if it
is turned counterclockwise.
Sound insulation cover
1. Pull the handle to open the front cover in place, and then both
hands Slightly outward open enclosures.
2. Re-install the sound cover, both hands steady put the cover clip in
rear cover protruding, and then pull the handle rotate downward
to check whether the flexible.

7
www.combisteel.com
Preparation before operation
1. Before operation, ensure the nutrition fruit blender is power off.
2. This device is equipped with magnetic induction safety switch. Please put the cup smoothly on the machine.
Connect it to a power source.
3. Put the processing material in the cup, Ensure its top is not higher than the “MAX” line and cover the lid.
Operation of special one-touch function
This machine is provided with one touch type. Just using the knob for adjusting the time and speed as your need.
The operator only needs to press the only button, and the making of a whole cup of fruit juice can be finished.
If the vegetable or fruit in the blender cannot be blended during mixing, please check the following:
If the quantity of water is enough
If the volume of vegetable or fruit is too high
Make sure you put the seeds or soft food materials at the bottom of the cup
If the blade gets loose

8
www.combisteel.com
The intelligent modes instructions
Modes
Instructions
Press the mode" ",LCD screen will display as " 1 ", and timer will set up as
"20"seconds,after press" ",Timer will in countdown mode and when operation
was finished, the machine emits "DeDeDe" sounds, suggesting that mixing
procedures have been completed.
Press the mode" ",LCD screen will display as " 2 ",and timer will set up as
"30"seconds,speed grade were 6grades.The machine running for
7 seconds, stop 3 seconds, followed by cycle operation. When operation was
finished, the machine emits "DeDeDe" sounds.
Press the mode" ",LCD screen will display as " 3 ",and timer will set up as
"40"seconds,speed grade were 6grades.The machine running for
7 seconds, stop 3 seconds, followed by cycle operation. When operation was
finished, the machine emits "DeDeDe" sounds.
Press the mode" ",LCD screen will display as " 4 ",The initial velocity is the
minimum speed, and initial time will set up as "10"seconds,Adjust the "speed"
and "time" according to personal usage. "Speed" and "time" data could be
regulated at any time. When operation was finished, the machine emits
"DeDeDe" sounds.
Tip:
"SPEED" with total of 10grades, Each click to increase SPEED, press and hold it,
the shift display rapidly increase or decrease.
"TIME" with 180 seconds, starting from 10 seconds, each click to increase 10
seconds, press and hold it, will rapidly increase or decrease.
1. Only the "DIY" mode can use the "speed" and "time" button.
2. With automatic memory last operation function, the initial data will be
restored automatically after the power.
Press the mode" ",LCD screen will display as " ",and timer will set up as
"30"seconds,the first"5" seconds from slow to fast buffer start, from the "25"
second start running high-speed rotation when operation was finished, the
machine emits "DeDeDe" sounds.
The above procedure in the process of operation, press the power button " " to terminate all
operating procedures. Then press the "POWER" to get power off.
When food is too much or crushed ice, first by a few intermittent operation key "P" button.
Please put the soft or juicy food in the cup bottom, hard food on the upper part, for blending or mixing
of, stirring better.

9
www.combisteel.com
Product maintenance
Faults and their troubleshooting
Fault description
Troubleshooting
1
The machine does not work.
Check the power switch to see if it is turned on.
2
Loud work noise is produced.
1- Remove the stirring cup and reposition it.
2- Examine the pedestal to see if it is put on solid panel.
3
The blade does not rotate.
1- Examine the power supply to see if it is normal.
2- Examine the connector to if it fall off.
4
The swing of the stirring cup is large.
1- Remove the stirring cup and reposition it.
2- Shut down the machine and remove the stirring cup
and see if there is any bulk matter in the cup.
5
The stirring cup has the problem of
water leakage.
1- Examine the screws at the bottom of the stirring cup to
see if they get loose.
2- Examine the seal ring to see if they fall off.
Cleaning
1. Before cleaning, be sure to unplug the blender.
2. Wipe the body and cover of the blender with sponge or duster cloth and then reverse it for airing.
3. Warm water is recommended for its washing. Add some detergent to the water. Start the motor and after it
rotates for 5s to 10s, pour the water and then flush the stirring cup, cup cover, etc. thoroughly with clean
water. Reverse the blender and allow it to dry.
4. Never wash the blender by putting the hand into it.
5. Neutral detergent can be used to wipe the motor seat. Never use water to wash it. Then wipe it clean with
dry cloth.
6. Wash the seat and stirring cup separately.
7. Do not immerse the seat in water or put it in dishwashing machine to wash it.
8. Never clean the cutting tool in the blender with hand. Cleaning tools must be used to ensure safety.
Performance parameters
Model: 7455.0300
Product name: Pro Commercial blender
Power: 1500W
Capacity: 64 Ounce/2.0L
Voltage/frequency: 110V-220V / 50-60Hz
Material: Copolyester environmental protection materials
Bearing: High-precision spherical bearing
Wire: 1.3m in length
Total height: 530mm

10
www.combisteel.com
Belangrijke veiligheidsinformatie
Voordat u de machine gebruikt, moet u zich aan de volgende veiligheidsregels houden:
1. Dompel het voetstuk of de motor van de machine niet onder in water of een andere vloeistof.
2. Kinderen mogen deze machine alleen onder toezicht van volwassenen gebruiken om de veiligheid te
waarborgen.
3. Ontkoppel eerst de machine na gebruik, bij het verwijderen van onderdelen of vóór het wassen.
4. Kom niet in contact met de draaiende delen van het product, vooral het mes.
5. Gebruik de machine niet in een van de volgende gevallen:
a. De voedingskabel of stekker is beschadigd
b. Het product valt af en is beschadigd tijdens het transport. Stuur de machine in dit geval naar het
dichtstbijzijnde servicecentrum voor reparatie. Demonteer het niet zonder toestemming.
6. Gebruik geen accessoires die niet origineel zijn voor reparatie.
7. Hang de elektriciteitskabel niet op een bureau of aanrecht met bedekking om te voorkomen dat de
voedingskabel beschadigd wordt.
8. Plaats de machine niet in de buurt van een elektrisch gastoestel of een andere warmtebron.
9. Steek geen hand of een ander apparaat in de beker om het te starten, want dat kan leiden tot persoonlijk
letsel of de machine zou beschadigd kunnen worden.
10. Ga alstublieft niet weg wanneer u de machine gebruikt. Schakel het uit wanneer u er niet bij bent.
11. Waarschuwing I: Aangezien het mes erg scherp is, wees voorzichtig tijdens het gebruik.
a. Probeer het mes nooit te verplaatsen als de beker nog op het voetstuk staat.
b. Gebruik de machine niet als het mes los zit, ontbreekt of beschadigd is. Vervang in plaats daarvan
het mes onmiddellijk.
c. Gebruik de machine niet als de mes constructie niet volledig op de beker is gemonteerd om letsel
te voorkomen.
Waarschuwing II: Open het deksel van de beker niet en gebruik mengstaaf om voedsel te mengen.
Correcte gebruiksmethode: Wanneer u de mengstaaf gebruikt, open het transparante deksel in het midden
van het deksel van de beker, zo kan de mengstaaf veilig ingebracht worden voor normaal gebruik.
12. Overlaad de machine niet. De maximale capaciteit mag de bovenste schaal aangegeven op de beker niet
overschrijden. De capaciteit moet relatief verlaagd worden voor een dik mengsel.
13. Het deksel moet afgedekt zijn tijdens het bedienen van het deksel. De machine heeft geen speciaal
onderhoud nodig, maar moet wel gewassen worden. Als een herstelling nodig is, stuur het dan naar de
aangewezen plaats. Herstel het nooit zonder toestemming.
14. Deze machine heeft snelle / langzame startfuncties. De effecten kunnen alleen worden geproduceerd als de
tijd eerst is ingesteld en de versnelling is geselecteerd.
15. De rotatiesnelheid van deze machine is hoog en er kan zeer hoge hitte gegenereerd worden tijdens droog
malen. Wanneer de temperatuur van het droog gemalen voedsel een bepaald ontstekingspunt bereikt, zal
het spontaan ontbranden. Daarom wordt droog malen niet aanbevolen.
OPGELET!
Tijdens het eerste gebruik van deze machine kunt u een onaangename geur ruiken. Dit is normaal. Terwijl de
motor loopt, zal de geur langzaam verdwijnen.
