Command Light C-Lite User manual

3842 Redman Drive 1-800-797-7974
Fort Collins, CO 80524 www.CommandLight.com
Effective November 2016
This guide supersedes all previous versions
Wireless

C-Lite
2
THANK YOU
Please allow us to express a simple thank you for investing in a COMMAND LIGHT product.
As a company we are dedicated to producing the very best and most versatile flood lighting
package available. We take great pride in the quality of our work and hope that you will find
many years of satisfaction from the use of this equipment.
Should you have any problems with your product please do not hesitate to contact us.
COMMAND LIGHT
3842 Redman Drive
Fort Collins, CO 80524
PHONE: [phone]
FAX: [phone]
WEB: www.CommandLight.com

USER GUIDE
3

C-Lite
4
Please take the time to read this manual before installing or operating the C-Lite.
Save this guide for future reference.
Contents
LIMITED WARRANTY............................................................................................................................5
Breakage or Damage During Shipment....................................................................................................6
General Description and Specifications....................................................................................................7
Electrical Wiring.........................................................................................................................................7
Installation...................................................................................................................................................7
Included Parts.........................................................................................................................................7
Tools Required.......................................................................................................................................7
Maintenance................................................................................................................................................8
Cleaning...................................................................................................................................................8
Troubleshooting..........................................................................................................................................8
Wireless Option...........................................................................................................................................8
Replacing Battery...................................................................................................................................8
Options.........................................................................................................................................................8
Manual Rotation Base...........................................................................................................................9
Electric Rotation Base...........................................................................................................................9
Technical Specifications ...........................................................................................................................10
Manual Rotation ...................................................................................................................................10
Electric Rotation ...................................................................................................................................11
Parts List –Exploded View......................................................................................................................11
Wiring Diagram........................................................................................................................................13

USER GUIDE
5
Command Light PHONE: [phone]
3842 Redman Drive FAX: [phone]
Fort Collins, CO 80524 WEB: www.CommandLight.com
LIMITED WARRANTY
Five Years
COMMAND LIGHT warrants that the equipment is free from defects in materials and workmanship
when used and operated for a period of five years. The responsibility of COMMAND LIGHT under this
limited warranty is limited to the repair and replacement of any parts found defective. Parts must be
returned to COMMAND LIGHT at 3842 Redman Drive, Ft Collins, Colorado 80524 with transportation
charges prepaid (C.O.D. shipments will not be accepted).
Prior to returning defective parts to COMMAND LIGHT, the original purchaser shall make a claim in
writing to COMMAND LIGHT at the above address indicating the model number, serial number and
type of defect. No parts or equipment will be received by COMMAND LIGHT for repair or replacement
under this warranty without specific written authority from it in advance.
Any parts damaged by improper installation, overloading, abuse or accident of any type or cause are not
covered by this warranty.
All equipment manufactured by us is tested before leaving our plant, and is shipped in good working
order and condition. We therefore extend to the original purchasers the following Limited Warranty for
the period of five years from the original date of purchase:
1. This warranty does not apply to defects caused by accident, misuse, neglect, or wear and
tear, nor can we be held responsible for incidental and consequential expense and loss, nor
does this warranty apply to equipment where alterations have been executed without our
knowledge or consent. These conditions are readily discernable when the equipment is
returned to us for inspection.
2. On all component parts not manufactured by COMMAND LIGHT, their warranty is to the
extent that the manufacturer of such component warrants them to COMMAND LIGHT, if
at all. Look in your local business telephone directory for the nearest repair station for the
brand of parts you have or write to us for the address.
3. If equipment received has been damaged in transit, a claim should be made against the
carrier within three days, as we assume no responsibility for such damage.
4. Any service other than our Authorized Service voids this warranty.
5. This warranty is in lieu of and is intended to exclude all other warranties, express or
implied, oral or written, including any warranties of MERCHANTIBILITY or FITNESS
for a particular purpose.
6. Travel time paid at a maximum of 50% and only if pre-approved.

C-Lite
6
Breakage or Damage During Shipment
The transportation company is fully responsible for all shipping damage and will resolve
problems promptly if you handle it correctly. Please read these instructions carefully.
Examine the contents of all shipping cases. If you find any damage, call your transportation
agent at once and have them make a description on the freight or express bill describing the
damage and the number of pieces. Then contact us and we will send you the original bill of
lading. Also promptly contact the transportation company and follow their procedure for
filing a claim. Each company will have a unique procedure to follow.
Please note, we cannot and will not enter claims for damages. If we filed claim here, it
would be sent to your local freight agent for verification and investigation. This time can be
saved by you filing the claim directly. Every consignee is on the ground floor, in contact
with the local agent who inspects the damaged goods, and thus, each claim can be given
individual attention.
Since our goods are packed to comply with the regulations of all railroad, truck, and express
companies, we cannot allow deduction from any invoice because of any damage, however,
be sure to file your claim promptly. Our goods are sold F.O.B. factory. We take receipt from
the transportation company certifying that the goods were delivered to them in good order
and our responsibility ceases.
It is seldom that any breakage or damage occurs in any of our shipments and in no case will
the customer be out any expense if they follow the above instructions.
Be sure to keep all damaged goods subject to examination of the truck or express company
inspector, who may call on you some time later. These damaged goods, of course, will
belong to them, and they will inform you what to do with them. If you dispose of these
damaged goods, your claim may not be paid.

USER GUIDE
7
General Description and Specifications
Optimal Operating Voltage
12VDC
Acceptable Operating Voltage
11-13VDC
Max Amp Draw
17.5 Amp
Electrical Wiring
The C-Lite is provided with 25 feet of 12AWG-2 Conductor Cable color coded with red and
black wires. Provide a 12VDC+ signal on the red wire and a 12VDC Ground signal on the
black wire to power the C-Lite. Reversing these wires may cause damage to the internal
circuitry or components of the C-Lite.
A 20 amp fuse is recommended to protect the C-Lite from electrical damage.
Installation
The C-Lite must be installed by a designated installation facility by qualified personnel
only. All safety precautions must be thoroughly understood before installation. Please
consult the factory for additional installation information assistance.
Included Parts
Four (4) –¼-20 x 1” Hex Head Bolt
Eight (8) –¼” Flat Washer
Four (4) –¼-20 Nyloc Nut
One (1) –½” Straight Sealcon with Nut
One (1) –Command Light Screwdriver
One (1) –User Guide
Tools Required
7/16” Wrench and Socket
Drill with assorted bits

C-Lite
8
Maintenance
Cleaning
The C-Lite is constructed with corrosion resistant aluminum and stainless steel fasteners. To
further enhance corrosion resistance all exposed surfaces receive a powder coated paint
finish. To assure years of trouble free service periodically clean all external surfaces with a
mild detergent solution and a gentle spray of water. DO NOT USE A HIGH-PRESSURE
WASHER, which will force water into sensitive electric circuitry.
Troubleshooting
If the C-Lite stops operating, disconnect and reconnect power. If operation does not resume,
test for a valid 12VDC power source and ground. If this does not remedy the issue, contact
Command Light at 1-800-797-7974 for Technical Support.
Wireless Option
Replacing Battery
The wireless controller for the C-Lite is powered with a CR2032 button style battery.
Follow these steps to replace the controller battery:
1. Remove red cover grip from the controller by stretching the bottom portion around
the back and sliding it towards the antenna.
2. Open the wireless controller by loosening the 4 screws
located on the back of the controller.
3. Slide the old battery out of the retainer clip on the
transmitter circuit board being careful to not press the
“Code Set” button located above the battery.
4. Slide the new battery into the retainer clip with the + Side
Up.
Code Set Button
Battery Retainer Clip

USER GUIDE
9
Options
Manual Rotation Base
If the C-Lite was ordered with the Manual Rotation Base option, it comes pre-installed. Mounting
hole pattern of the Manual Rotation Base is the same as the C-Lite. This option adds 2 inches to the
overall height of the C-Lite.
Electric Rotation Base
If the C-Lite was ordered with the Electric Rotation Base option, it comes pre-installed. Mounting
hole pattern of the Electric Rotation Base is the same as the C-Lite. This option adds 3 inches to the
overall height of the C-Lite.

C-Lite
10
Technical Specifications
Manual Rotation

USER GUIDE
11
Electric Rotation

C-Lite
12
Parts List –Exploded View

USER GUIDE
13

C-Lite
14

USER GUIDE
15
Wiring Diagram

C-Lite
16
