Commax DRC-4CPN2 User manual

Door Camera DRC-4CPN2
User Manual
•Thank you for purchasing COMMAX products.
•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
•The company is not responsible for any safety accidents caused by abnormal operation of the product.

6. Specification
13
specification Model
DRC-4CPN2
Image Sensor CMOS 1/4"
Power source 12V (supplied from the Monitor)
Wiring(household) Polar 4 wires
Call mode Duplex
Camera angle horizontal angle 47°, vertical angle 34°
Format NTSC or PAL STANDARD
Horizontal /vertical Frequency 15.734㎑/ 60㎐, 15.625㎑/ 50㎐
Lamp Built-in white LED (automatically turns on in night)
Low illumination 0.1 LUX (Up to 300mm in front of the camera)
Workable temperature -10℃+50℃
Dimension(mm) 50(W) x 118 (H) x 25.5(D)
Weight(g) 250g (B/K included)

1
1. Introdution..................................................... 2
2. Important Safeguard..................................... 3
3. The names & Functions of Each Part............ 4
4. Wiring & Installation....................................... 6
5. Package....................................................... 11
6. Specifications............................................... 13
Contents

2
Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the
unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided
below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.
Model No. Serial No.
To prevent fire or shock hazard, do not expose the unit to rain or moisture.
This symbol is intended to alert the use to the presence of uninsulated
“dangerous Voltage”
within the product’s enclose that
may be of sufficient magnitude to constitute a risk of electric shock to persons.
This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the
literature accompanying the appliance
CAUTION: To reduce the risk of electrix shick, do not remove cover(or back) no user-serviceable
part sinside refer servicing to quaured service personnel
caution
Rosk of electric shock
do not open
1. Introduction

3
▲
DamageRequiringService:This equipment from the power source and source and refer servicing to qualified service personnel under the following
conditions:
ⓐwhenthepowerisdamaged.
ⓑifliquidhas beenspiledorobjects havehallenintotheunit
ⓒifthe equipmenthasbeenexposed torainorwater.
ⓓifthe equipmenthasbeemdropped orotherwisedamaged.
ⓔwhentheequipment exhibitsadistinctchange inperformance-thisindicatesa needforservice.
▲ Waterand Moisture: Do not usethis product near water,forexample, near a bathtub, wash bowl, kitchen sink,or laundru tub, ina wet basement, or near
aswimming pool,andthelike.
▲ Accessories:The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any mounting of the manufacture’s
insturctions,andshould useamountingaccessory recommendedbythemanufacturer.
▲ Objectand Liquid Entry:Neverpush objectsofanykind intothisproductthroughopenings astheymaytouch dangerousvoltagepointsorshort-out parts
thatcouldresult inafireor electricshock.Neverspillliquid ofanykindon theproduct.
▲ Lightning:For added protection for this product before a lihgtning storm, or when it is left un attached and un used for long periods of time, unplug it from
the wall outlt and disconnect the other system. This will prevent damage to the product due to lightming and power-line surges. If you live in an
ared heavily prone to lightning stoms, it is recommended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge
protectorstoprotect yourappliancesystemfrom possipledamage
2. Important Safeguards

4
3. The names & Functions of Each Part
▶ Front sid ▶ Back side

5
①Speaker : Transmit sounds from the household.
②Camera Lens : keep cleaning up from dust or foreign substances.
③LED Lamp : The LED lamp is turned on for clear view during night.
④Page Button : Used to page the household
⑤Microphone : For use when communicating with the household
⑥Mounting Holes
⑦Monitor cable : Connect with household monitor after matching up the polarity
⑧Door release cable : Connect with door release switch
⑨Volume control : Used to adjust speaker volume

6
1. Align holes on the wall where the unit is to be installed with mounting brackets hole and
secure.
FIG-1 : Install the camera at a 30˚angle to the left
(install the bracket in reverse to angle 30˚to the right)
FIG-2 : Install the camera at a perpendicular angle to the front
2. Wire the household monitor cables as shown below with matched polarity as picture
below[FIG-3]
(#1:RED/VOICE, #2:BLUE/GND, #3:YELLOW/DC12V, #4:BLACK/VIDEO)
3. Wire the door release cable as shown in the diagram.[FIG-3]
4. Tighten using bolts and a wrench, then cover using the AL. screw covers.
4. Wiring & Installation

7
▶ [FIG-1] ▶ [FIG-2]

#1: RED(VOICE)
#2: BLUE(GND)
#3: YELLOW(+12V)
#4: BLACK(VIDEO)
▶ [FIG-3]
8

9
▶ [FIG-4]
You can adjust speaker volume using driver as shown below. [FIG-4]

10
60cm
34
●Please refer to the below images regarding the installation position of the product.

5. Package
11

12

Printed In Korea / 2013.02.105
